D-Size 1 3/8” powerfast Connectivity
D-Size 1 3/8” Powerfast Tee Selection Matrix
13 14 15
Integral D-Size Connector Drop Integral A-Size Connector Drop Integral M16 Connector Drop
Pins
3
4
Drop
AWG
Trunk
Current
Rating
10 30 Amps 30 Amps GSDM/2GKDM 30
14 30 Amps 15 Amps GSDM/GKDM/RKM 34 GSDM/GKDM/BKM 34
10 25 Amps 25 Amps GSDM/2GKDM 40
14 25 Amps 15 Amps GSDM/GKDM/RKM 44 GSDM/GKDM/BKM 44
Drop
Current
Rating
16 17 18 19
Cable Drop
Drop
Pins
AWG
3
4
We reserve the right to make technical alterations without prior notice.
Pins
3
4
Drop
AWG
Trunk
Current
Rating
10 30 Amps 30 Amps GSDM/GKDM/T30-* GSDM/2GKDM 30-*
12 30 Amps 25 Amps GSDM/GKDM/T32-* GSDM/2GKDM 32-*
14 30 Amps 18 Amps GSDM/GKDM/T34-* GSDM/2GKDM 34-*
10 25 Amps 25 Amps GSDM/GKDM/T40-* GSDM/2GKDM 40-*
12 25 Amps 20 Amps GSDM/GKDM/T42-* GSDM/2GKDM 42-*
14 25 Amps 15 Amps GSDM/GKDM/T44-* GSDM/2GKDM 44-* GSDM/GKDM/RKM 44-*
Trunk
Current
Rating
10 30 Amps 30 Amps GSDM/GKDM/T30-*/S4000 GSDM/2GKDM 30-*/S4000
12 30 Amps 25 Amps GSDM/GKDM/T32-*/S4000 GSDM/2GKDM 32-*/S4000
14 30 Amps 18 Amps GSDM/GKDM/T34-*/S4000 GSDM/2GKDM 34-*/S4000
10 25 Amps 25 Amps GSDM/GKDM/T40-*/S4000 GSDM/2GKDM 40-*/S4000
12 25 Amps 20 Amps GSDM/GKDM/T42-*/S4000 GSDM/2GKDM 42-*/S4000
Drop
Current
Rating
Drop
Current
Rating
TC-ER STOOW TC-ER STOOW TC-ER STOOW TC-ER STOOW
TC-ER TC-ER TC-ER TC-ER
Cable Drop With
D-Size Power Connector
Cable Drop With
A-Size Power Connector
GSDM/GKDM/RKM 34-*
GSDM/GKDM/RKM 34-*/S4000
†
Cable Drop With
M16 Power Connector
†
GSDM/GKDM/BKM 34-*/S4000
D-Size 1 3/8” powerfast
†
14 25 Amps 15 Amps GSDM/GKDM/T44-*/S4000 GSDM/2GKDM 44-*/S4000 GSDM/GKDM/RKM 44-*/S4000 GSDM/GKDM/BKM 44-*/S4000
See page 19-20 for dimensional drawings.
*
Length in meters.
†
Drop current rating of 15 amps.
Note: Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 11) for anodized aluminum and 316 stainless steel options.
B2007 J17
D-Size 1 3/8” powerfast Connectivity
D-Size 1 3/8” Powerfast h-Style Tee Selection Matrix
20 21 22
Integral D-Size Connector Drop Integral A-Size Connector Drop Integral M16 Connector Drop
Pins
3
4
Pins
Drop
AWG
Drop
AWG
Trunk
Current
Rating
10 30 Amps 30 Amps SH-GSDM/2GKDM 30
14 30 Amps 15 Amps SH-GSDM/GKDM/RKM 34-* SH-GSDM/GKDM/BKM 34
10 25 Amps 25 Amps SH-GSDM/2GKDM 40
14 25 Amps 15 Amps SH-GSDM/GKDM/RKM 44-* SH-GSDM/GKDM/BKM 44
Trunk
Current
Rating
10 30 Amps 30 Amps SH-GSDM/GKDM/T30-* SH-GSDM/2GKDM 30-*
Drop
Current
Rating
Drop
Current
Rating
23 24 25 26
Cable Drop
TC-ER STOOW TC-ER STOOW TC-ER STOOW TC-ER STOOW
Cable Drop With
D-Size Power Connector
Cable Drop With
A-Size Power Connector
We reserve the right to make technical alterations without prior notice.
Cable Drop With
M16 Power Connector
3
12 30 Amps 25 Amps SH-GSDM/GKDM/T32-* SH-GSDM/2GKDM 32-*
14 30 Amps 18 Amps SH-GSDM/GKDM/T34-* SH-GSDM/2GKDM 34-*
10 25 Amps 25 Amps SH-GSDM/GKDM/T40-* SH-GSDM/2GKDM 40-*
4
12 25 Amps 20 Amps SH-GSDM/GKDM/T42-* SH-GSDM/2GKDM 42-*
14 25 Amps 15 Amps SH-GSDM/GKDM/T44-* SH-GSDM/2GKDM 44-* SH-GSDM/GKDM/RKM 44-*
Drop
Pins
AWG
3
4
See page 21-22 for dimensional drawings.
*
Length in meters.
†
Drop current rating of 15 amps.
Note: Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 11) for anodized aluminum and 316 stainless steel options.
Trunk
Current
Rating
10 30 Amps 30 Amps SH-GSDM/GKDM/T30-*/S4000 SH-GSDM/2GKDM 30-*/S4000
12 30 Amps 25 Amps SH-GSDM/GKDM/T32-*/S4000 SH-GSDM/2GKDM 32-*/S4000
14 30 Amps 18 Amps SH-GSDM/GKDM/T34-*/S4000 SH-GSDM/2GKDM 34-*/S4000
10 25 Amps 25 Amps SH-GSDM/GKDM/T40-*/S4000 SH-GSDM/2GKDM 40-*/S4000
12 25 Amps 20 Amps SH-GSDM/GKDM/T42-*/S4000 SH-GSDM/2GKDM 42-*/S4000
14 25 Amps 15 Amps SH-GSDM/GKDM/T44-*/S4000 SH-GSDM/2GKDM 44-*/S4000
Drop
Current
Rating
TC-ER TC-ER TC-ER TC-ER
SH-GSDM/GKDM/RKM 34-*
SH-GSDM/GKDM/RKM 34-*/
SH-GSDM/GKDM/RKM 44-*/
S4000
S4000
†
†
SH-GSDM/GKDM/BKM 34-*/
SH-GSDM/GKDM/BKM 44-*/
S4000
S4000
†
J18 B2007 www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • Turck • Minneapolis, MN 55441 B2007 J19
