Inductive Barrel Sensor Selection Guide

Embeddable/Nonembeddable Barrels

Housing 3 mm 4 mm 4 mm 4 mm 5 mm

Sensing Range 1 mm 1 mm 1 mm 1 mm 1 mm

Pages B9 B9 B9 B11 B11

Features

2-wire

3/4-wire

2-wire AC/DC

• • • • •

Embeddable/Nonembeddable Barrels

Housing 5 mm 6.5 mm 6.5 mm 8 mm

Sensing Range 1 mm 1.5 - 6 mm 1.5 - 6 mm 1.5 - 2 mm

Pages B11 B13 - 16 B13 - 16 B17

Features Uprox Uprox

2-wire

3/4-wire

2-wire AC/DC

• • • •

Embeddable/Nonembeddable Barrels

We reserve the right to make technical alterations without prior notice.

Housing 8 mm Side Sensing Side Sensing 8 mm

Sensing Range 1.5 - 2 mm 1 - 1.5 mm 1.5 mm 1.5 - 6 mm

Pages B17 B19 B19 B23 - 34

Features Uprox Uprox

2-wire

3/4-wire

2-wire AC/DC

• • • •

Turck Inc.

•

Inductive Barrel Sensor Selection Guide

Embeddable/Nonembeddable Barrels

Housing 8 mm 12 mm 12 mm 12 mm

Sensing Range 1.5 - 6 mm 2 - 10 mm 2 - 8 mm 2 - 10 mm

Pages B35 - 42 B43 - 64 B59 B65 - 72

Features Uprox Uprox

2-wire

3/4-wire

2-wire AC/DC

• • •

• • • •

• •

Embeddable/Nonembeddable Barrels

Housing 12 mm 12 mm 18 mm 18 mm

Sensing Range 2 - 8 mm 2 - 8 mm 5 - 15 mm 2 - 10 mm

Pages B73 B75 B77 - 104 B95 B103

Features Uprox Uprox Uprox Uprox

2-wire

3/4-wire

We reserve the right to make technical alterations without prior notice.

2-wire AC/DC

Housing 18 mm 18 mm 18 mm 18 mm

Sensing Range 5 - 15 mm 5 - 12 mm 5 - 10 mm 5 - 12 mm

Pages B105 - 110 B99 - 112 B113 B115

Features Uprox Uprox Uprox Uprox

2-wire

3/4-wire

2-wire AC/DC

• • • •

• •

• • • •

• •

Embeddable/Nonembeddable Barrels

Inductive Barrel Sensors

Turck Inc.

Inductive Barrel Sensor Selection Guide

Embeddable/Nonembeddable Barrels

Housing 30 mm 30 mm 30 mm 30 mm

Sensing Range 10 - 30 mm 10 - 20 mm 10 - 30 mm 10 - 20 mm

Pages B117 - 132 B127 B143 B133 - 140 B141

Features Uprox Uprox Uprox Uprox

2-wire

3/4-wire

2-wire AC/DC

• • • •

Embeddable/Nonembeddable Barrels

Housing 30 mm 30 mm 40 mm 47 mm

Sensing Range 10 - 20 mm 10 - 20 mm 30 mm 20 - 25 mm

Pages B145 B145 B147 B147

Features Uprox

2-wire

3/4-wire

2-wire AC/DC

• • • •

Embeddable/Nonembeddable Barrels

We reserve the right to make technical alterations without prior notice.

Housing 47 mm 40 mm 47 mm Variable

Sensing Range 20 - 25 mm 15 - 30 mm 25 - 40 mm 1 - 15 mm

Pages B147 B149 B149 B151 - 162

Features

2-wire

3/4-wire

2-wire AC/DC

• • •

Turck Inc.

•

Inductive Barrel Sensor Part Number Key

B I 10 U - G T 30 - A DZ 30 X2 Wiring Option* Special Option Code**

Mounting

B = embeddable N = nonembeddable

Principle of Operation

I = inductive

Rated Operating Distance (mm)

Sensing Characteristics

U = Uprox® sensor

Housing Material Modier

E = stainless steel

Housing Style Barrel - Metal

G = full threading, generally chrome plated brass GS = threaded side sensor H = smooth, chrome plated brass or stainless steel HS = smooth side sensor M = partial threading, chrome plated brass

Barrel - Plastic

K = smooth P = full threading S = partial threading SK = side sensing/slot sensor, plastic housing

Primary Barrel Modier

T = PTFE coated

Housing Diameter or Height (mm)

Secondary Barrel Modier

CA = conduit adaptor E = extended barrel length EE = extra long barrel length F = stainless steel face FE = stainless steel face, extended barrel length

We reserve the right to make technical alterations without prior notice.

H = Stoneface® K = shor t barrel length M = medium barrel length S = side sensing SE = extended length SK = right-angle terminal chamber SR = straight terminal chamber T = barb tting at cable entry TC = terminal chamber WD = washdown IP68/IP69K

Number of LEDs

(blank) = no LEDs X = 1 LED X2 = 2 LEDs

Voltage Range AC/DC: (No SCP**)

3 = 20-250 VAC, 10-300 VDC 14 = 20-132 VAC, 10-140 VDC 31 = 20-250 VAC, 10-300 VDC, plastic barrel 33 = 35-250 VAC, grounded metal barrel

AC/DC: (Latched SCP)

30 = 20-250 VAC, 10-300 VDC 32 = 20-250 VAC, 10-300 VDC 40 = 20-140 VAC/DC, high o-state current

DC:

4 = 10-65 VDC, polarity protected, pulsed SCP** 6 = 10-30 VDC, polarity protected, pulsed SCP 7 = 10-30 VDC, TTL compatible 8 = 20-30 VDC, polarity protected, pulsed SCP 41 = 10-55 VDC, polarity protected, pulsed SCP 44 = 10-55 VDC 45 = 8.4-64 Volts **SCP = short-circuit and overload protection

Output

D = 2-wire DC (transistor output) DZ = 2-wire AC/DC, (power MOSFET output) G = 2-wire DC, low voltage drop N = NPN transistor (current sinking) P = PNP transistor (current sourcing) Z = 2-wire AC or 2-wire AC/DC

Output Function

A = normally open (N.O.) DA = dynamic output (ring sensor), normally open F = connection programmable (N.O or N.C.) R = normally closed (N.C.) V = complementary outputs: one N.O., one N.C. Y0 = NAMUR output, requires switching amplier Y1 = NAMUR output, requires switching amplier, ATEX Approved

NOTE: Part number keys are to assist in identication only. Verify new part numbers with factory; some congurations are not possible.

Inductive Barrel Sensors

Turck Inc.

Inductive Barrel Sensor Part Number Key

Wiring Options*

A. Connectorized Sensor

Bi2-M12-AN6X - H1 1 4 1

Connector Family

B1 = Minifast®, 7/8”-16UN, metal, male B2 = Minifast®, 7/8”-16UN, plastic, male B3 = Microfast®, 1/2”-20UNF, metal, male H1 = Eurofast®, M12x1, metal or plastic, male V1 = Picofast®, snap and M8x1, metal, male (Q08 snap only) V2 = Picofast®, snap and M8x1, male (Q08 only)

Connector/Sensor Transition

1 = straight 3 = straight with adapter 4 = right-angle with adapter

Factory Code Example:

0 = non-standard wiring 1 = standard wiring 3 = N.C. DC output on pin 4 4 = N.O. 2-wire DC output on pin 4

Number of Pins

B. Potted Cable

Cable Length

(blank) = 2 meter cable 7M = 7 meter cable *M = custom cable lengths available

C. Potted Cable with Molded Connector

Bi2-G12-Y0X - 0.2M - RS 4.21T

Cable Length examples:

0.2M = 0.2 meters (minimum) 2M = 2 meter cable 7M = 7 meter cable

Option Codes for Special or Custom-Built Sensors**

Bi 2-S12-AN7X /S100 or Bi10-M30-AN6X-H1141 /F2

Bi2-G12-AN6X 7M

We reserve the right to make technical alterations without prior notice.

Standard Cordset Connector AC: RSM 30 = Minifast, 7/8”-16UN, metal, male, 3-conductor SB 3T = Microfast, 1/2”-20UNF, metal , male, 30 conductor DC: RS 4T = Eurofast, M12x1, metal or plastic, male, 3-conductor

RS 4.2T = Eurofast, M12x1, metal or plastic, male, 2-conductor RS 4.21T = Eurofast, M12x1, metal or plastic, male, NAMUR, 2-conductor RS 4.4T = Eurofast, M12x1, metal or plastic, male, 4-conductor RSM 40 = Minifast, 7/8”-16UN, metal, male, 4-conductor PSG 3 = Picofast, snap, plastic, male, 3-conductor PSG 3M = Picofast, M8x1, male, 3-conductor

examples:

/S34 = weld eld immune /S90 = TPU cable /S97 = -40 °C (-40 °F) operating temperature /S100 = +100 °C (+212 °F) operating temperature /S1589 = barrel sensors with Weldguard® laminate /S1610 = barrel sensors with tool steel sleeve and Weldguard® laminate

Turck Inc.

example:

/F2 = alternate oscillator frequency

Inductive Barrel Sensors

Mounting

Turck inductive proximity sensors are manufactured with a shielded coil, designated by “Bi” in the part number, and a nonshielded coil, designated by “Ni” in the part number. Embeddable (shielded) units may be safely ush-mounted in metal. Nonembeddable (nonshielded) units require a metal free area around the sensing face. Because of possible interference of the electromagnetic elds generated by the oscillators, minimum spacing is required between adjacent or opposing sensors.

It is good engineering practice to mount sensors horizontally or with the sensing face looking down. Avoid sensors that look up wherever considered, especially if metal lings and chips are present.

Maximum Locknut Torque Specications

The locknut torque should be considered for all threaded sensors to prevent the housing from being over stressed. The values below pertain to the locknut provided with each sensor. Liquid thread sealants of an anaerobic base, such as Loctite, are recommended if strong vibrations are likely.

Caution: Sensor barrels are typically brass. Consider break torque when selecting grade of thread sealant.

Barrel Size Metal Barrel Plastic Barrel

5 mm 5 Nm (3.7 ft-lb) - - - -

8 mm 5 Nm (3.7 ft-lb) - - - -

8 mm (M08 Ferrite) 7 Nm (5.2 ft-lb) - - - -

12 mm 10 Nm (7.4 ft-lb) 1 Nm (0.7 ft-lb)

18 mm 25 Nm (18 ft-lb) 2 Nm (1.4 ft-lb)

30 mm 75 Nm (55 ft-lb) 5 Nm (3.7 ft-lb)

47 mm 90 Nm (66 ft-lb) - - - -

Inductive Barrel Sensors

Drill Hole Sizes for Metric Threads

We reserve the right to make technical alterations without prior notice.

Thread Size Pitch Thru Hole (mm) Tap Hole Dia. (mm) Thru Hole (in) Tap Hole Dia. (in)

M5 x 0.5 0.5 5.0 4.5 13/64 5/32

M8 x 1 1.0 8.0 7 21/64 1/4

M12 x 1 1.0 12.0 11 31/64 13/32

M18 x 1 1.0 18.0 17 23/32 41/64

M30 x 1.5 1.5 30.0 28 1-3/16 1-5/64

PG 9 1.41 15.2 14 5/8 1/2

PG 13.5 1.41 20.4 19 13/16 23/32

PG 36 1.59 47.0 45.5 1-7/8 1-47/64

Turck Inc.

Inductive Barrel Sensors

Embeddable Mounting Considerations

Flush Mountable

Sensor Type Barrel Diameter A B C D E

Bi1 3.00 3.00 6.00 4.50 9.00 9.00

Bi1U 4.00 3.00 8.00 6.00 12.00 6.00

Bi1 4.00 3.00 8.00 6.00 12.00 6.00

Bi1 5.00 3.00 10.00 8.00 15.00 6.00

Bi1U 5.00 3.00 10.00 7.50 15.00 6.00

Bi1.5U 6.50 5.00 13.00 10.00 20.00 9.00

Bi1.5 6.50 5.00 13.00 10.00 20.00 9.00

Bi2 6.50 6.00 13.00 10.00 20.00 12.00

Bi1.5U 8.00 5.00 16.00 12.00 24.00 9.00

Bi1.5 8.00 5.00 16.00 12.00 24.00 9.00

Bi2 8.00 6.00 16.00 12.00 24.00 12.00

Bi2U 8.00 6.00 16.00 12.00 24.00 12.00

Bi3U 8.00 9.00 16.00 12.00 24.00 18.00

Bi2 11.00 6.00 22.00 17.00 33.00 12.00

Bi2 12.00 6.00 24.00 18.00 36.00 12.00

Bi3U 12.00 9.00 24.00 18.00 36.00 18.00

Bi3 12.00 9.00 24.00 18.00 36.00 18.00

Bi4 12.00 12.00 24.00 18.00 36.00 24.00

Bi4U 12.00 12.00 24.00 18.00 36.00 24.00

Bi6U 12.00 18.00 24.00 18.00 36.00 36.00

Bi5U 18.00 15.00 36.00 27.00 54.00 30.00

Bi5 18.00 15.00 36.00 27.00 54.00 30.00

Bi7 18.00 21.00 36.00 27.00 54.00 42.00

Bi8U 18.00 24.00 36.00 27.00 54.00 48.00

Bi8 18.00 24.00 36.00 27.00 54.00 48.00

Bi10U 18.00 30.00 36.00 27.00 54.00 60.00

Bi10U 30.00 27.00 60.00 45.00 90.00 54.00

Bi10 30.00 30.00 60.00 45.00 90.00 60.00

Bi12 30.00 36.00 60.00 45.00 90.00 72.00

Bi15 30.00 45.00 60.00 45.00 90.00 90.00

Bi15U 30.00 45.00 60.00 45.00 90.00 90.00

Bi 20U 30.00 60.00 60.00 45.00 90.00 120.00

Bi 20 47.00 60.00 94.00 71.00 141.00 120.00

Bi 25 47.00 75.00 94.00 71.00 141.00 150.00

Dimensions are in mm.

We reserve the right to make technical alterations without prior notice.

Turck Inc.

Inductive Barrel Sensors

Nonembeddable Mounting Characteristics

Non-Flush Mountable

Sensor Type Barrel Diameter A B C D E F 1 Side 2 Side 3 Side

Ni3 6.50 9.00 20.00 10.00 20.00 18.00 6.00

Ni3 8.00 9.00 24.00 12.00 24.00 18.00 6.00

Ni4U 8.00 12.00 32.00 12.00 32.00 24.00 8.00

Ni4 8.00 12.00 24.00 12.00 24.00 24.00 8.00

Ni6U 8.00 18.00 32.00 12.00 36.00 36.00 12.00

Ni5 11.00 15.00 33.00 17.00 33.00 30.00 10.00

Ni4 12.00 12.00 36.00 18.00 36.00 24.00 8.00

Ni5 12.00 15.00 36.00 18.00 36.00 30.00 10.00

Ni8U 12.00 24.00 48.00 18.00 45.00 48.00 16.00 Sr=6 mm*

Ni8 12.00 24.00 36.00 18.00 36.00 48.00 16.00

Ni10U 12.00 30.00 48.00 18.00 36.00 60.00 20.00

Ni8 18.00 24.00 54.00 27.00 54.00 48.00 16.00

Ni10 18.00 30.00 54.00 27.00 54.00 60.00 20.00

Ni12U 18.00 36.00 70.00 27.00 54.00 72.00 24.00

Ni14 18.00 42.00 54.00 27.00 54.00 84.00 20.00

Ni15U 18.00 45.00 70.00 27.00 54.00 90.00 30.00

Ni10 20.00 30.00 60.00 30.00 60.00 60.00 20.00

We reserve the right to make technical alterations without prior notice.

Ni15 30.00 45.00 90.00 45.00 90.00 90.00 20.00

Ni20U 30.00 60.00 90.00 45.00 90.00 120.00 40.00 Sr=15 mm* Sr=12 mm* Sr=11 mm*

Ni20 30.00 60.00 90.00 45.00 90.00 120.00 20.00

Ni30U 30.00 135.00 90.00 45.00 90.00 180.00 60.00

Ni20 40.00 60.00 120.00 60.00 120.00 120.00 40.00

Ni30 40.00 90.00 120.00 60.00 120.00 180.00 40.00

Ni25 47.00 75.00 141.00 71.00 141.00 150.00 40.00

Ni40 47.00 120.00 141.00 71.00 141.00 240.00 40.00

Dimensions are in mm.

* The above Uprox Ni sensors with DC outputs and Stainless barrels can be ush mounted because the sensor automatically compensates for metal alongside its sensing face by decreasing the sensing range, preventing the output from locking on.

1 Side 2 Side 3 Side

Inductive Barrel Sensors

Turck Inc.

LED

Inductive Barrel Sensors | 3 mm, 4 mm

Embeddable Smooth Metal Barrels with DC Outputs

Housing Style Dimension Drawings

.118 [3.0]

.866 [22.0]

LED

.157 [4.0]

.598 [15.2]

4 mm - Embeddable, Miniature Smooth Barrel,

Potted-In Cable

3 mm - Embeddable, Miniature Smooth Barrel,

4 mm - Embeddable, Miniature Smooth,

Potted-In Cable

M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Vibration:

Repeatability:

4 mm - Embeddable, Miniature Smooth Barrel,

Potted-In Cable

Mating Cordset: PKG 3M-*

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10%

Shock:

30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

Turck Inc.

Inductive Barrel Sensors | 3 mm, 4 mm

Embeddable Smooth Metal Barrels with DC Outputs

Part Number/ ID Number

Bi1U-EH04-AN6X

4602114

Bi1U-EH04-AP6X

4602112

Bi1-EH04-AN6X

4609640

Bi1-EH04-AP6X

4609540

Bi1-EH04K-AN6X

4609768

Bi1-EH04K-AP6X

4609767

Bi1-EH03-AN6X

1619326

Bi1-EH03-AP6X

1619325

Bi1U-EH04-AN6X-V1331

4602115

Bi1U-EH04-AP6X-V1331

4602113

Bi1-EH04-AN6X-V1331

4608540

Bi1-EH04-AP6X-V1331

4608440

Features

Sensing Range (mm)

Uprox3 1 3-wire DC NPN 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

Uprox3 1 3-wire DC PNP 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

1 3-wire DC NPN 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

Short Barrel 1 3-wire DC NPN 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

Short Barrel 1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

1 3-wire DC NPN  10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

Uprox3 1 3-wire DC NPN 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- D 3 A4

Uprox3 1 3-wire DC PNP 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- D 4 A4

1 3-wire DC NPN 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- D 3 A4

1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- D 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B10

M8x1

M5x0.5

M8x1

.587 [14.9]

M5x0.5

LED

Inductive Barrel Sensors | 4 mm, 5 mm

EmbeddableThreaded Metal Barrels with DC Outputs

Housing Style Dimension Drawings

LED

ø.157 [4.0]

5 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

4 mm - Embeddable, Miniature Threaded Barrel,

4-WAY

5 mm - Embeddable, Miniature Threaded,

Potted-In Cable

LED

M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

1 2 3

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Ripple:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

.866 [22.0]

1.091 [27.7]

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Reverse Polarity Protection:

5 mm - Embeddable, Miniature Threaded Barrel,

5 mm - Embeddable, Miniature Threaded,

Power-On Effect:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Potted-In Cable

4-WAY

LED

M8 Picofast Quick Disconnect

.984 [25.0]

1.673 [42.5]

Mating Cordset: PKG 3M-*

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B11

Turck Inc.

Inductive Barrel Sensors | 4 mm, 5 mm

EmbeddableThreaded Metal Barrels with DC Outputs

Part Number/ ID Number

Bi1U-EG05-AN6X

4602118

Bi1U-EG05-AP6X

4602116

Bi1-EG05-AN6X

4609840

Bi1-EG05-AP6X

4609740

Bi1-EG05K-AN6X

4609764

Bi1-EG05K-AP6X

4609765

Bi1-EG04-AN6X

1619328

Bi1-EG04-AP6X

1619327

Bi1U-EG05-AN6X-V1331

4602119

Bi1U-EG05-AP6X-V1331

4602117

Bi1-EG05-AN6X-V1331

4608740

Bi1-EG05-AP6X-V1331

4608640

Bi1-EG05K-AP6X-V1331

4609766

Features

Uprox3 1 3-wire DC NPN 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

Uprox3 1 3-wire DC PNP 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

Short Barrel 1 3-wire DC NPN 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

Short Barrel 1 3-wire DC PNP 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

Uprox3 1 3-wire DC NPN 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- E 3 A4

Uprox3 1 3-wire DC PNP 10-30 VDC 2000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- E 4 A4

Short Barrel 1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- D 4 A4

Sensing Range (mm)

1 3-wire DC NPN 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

1 3-wire DC NPN  10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

1 3-wire DC NPN 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- E 3 A4

1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE -- E 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B12

Inductive Barrel Sensors | 6.5 mm

Embeddable Smooth Metal Barrels with DC Outputs

Housing Style Dimension Drawings

6.5 mm - Embeddable, Miniature Smooth, M8 Picofast Quick Disconnect

6.5 mm - Embeddable, Miniature Smooth Barrel,

6.5 mm - Embeddable, Miniature Smooth,

Potted-In Cable

M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Vibration:

Repeatability:

6.5 mm - Embeddable, Miniature Smooth Barrel, Potted-In Cable

Mating Cordset: PKG 3M-*

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10%

Shock:

30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B13

Turck Inc.

Inductive Barrel Sensors | 6.5 mm

Embeddable Smooth Metal Barrels with DC Outputs

Part Number/ ID Number

Bi2U-EH6.5-AN6X

4281170

Bi2U-EH6.5-AP6X

4281150

Bi2-EH6.5-AN6X

4612300

Bi2-EH6.5-AP6X

4612200

Bi2-EH6.5K-AN6X

4610100

Bi2-EH6.5K-AP6X

4610000

Bi1.5-EH6.5-AN6X

4612100

Bi1.5-EH6.5-AP6X

4612000

Bi1.5-EH6.5-AP6X/S100

4612001

Bi1.5-EH6.5K-AN6X

4610640

Bi1.5-EH6.5K-AP6X

4610540

Bi2U-EH6.5-AN6X-V1131

4281180

Bi2U-EH6.5-AP6X-V1131

4281160

Bi2-EH6.5-AN6X-V1131

We reserve the right to make technical alterations without prior notice.

4612320

Bi2-EH6.5-AP6X-V1131

4612220

Bi2-EH6.5K-AN6X-V1131

4610120

Bi2-EH6.5K-AP6X-V1131

4610020

Bi1.5-EH6.5-AN6X-V1131

4612120

Bi1.5-EH6.5-AP6X-V1131

4612020

Bi1.5-EH6.5K-AN6X-V1131

4610840

Bi1.5-EH6.5K-AP6X-V1131

4610740

Features

Uprox 2 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE

Uprox 2 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE

Short Barrel 2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

Short Barrel 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

High Temp.

100 °C

Short Barrel 1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

Short Barrel 1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

Uprox 2 3-wire DC NPN 10-30 VDC 1000 ≤150 -25 to +70 IP68 SS PA 12 N/A YE -- D 3 A4

Uprox 2 3-wire DC PNP 10-30 VDC 1000 ≤150 -25 to +70 IP68 SS PA 12 N/A YE -- D 4 A4

Short Barrel 2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- C 3 A4

Short Barrel 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- C 4 A4

Short Barrel 1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- C 3 A4

Short Barrel 1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- C

Sensing Range (mm)

2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

2 3-wire DC PNP 10-30 VDC 1000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150

2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- D 3 A4

2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- D 4 A4

1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- D 3 A4

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- D 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

-25 to +100

Operating Temp. (°C)

Protection

Housing

IP67 SS PA 12 N/A YE

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

2M/

B 1 A4

TPU

2M/

B 2 A4

TPU

2M/

B 1 A4

TPU

2M/

B 2 A4

TPU

2M/

A 1 A4

TPU

2M/

A 2 A4

TPU

2M/

B 1 A4

TPU

2M/

B 2 A4

TPU

2M/

B 2 A4

TPU

2M/

A 1 A4

TPU

2M/

A 2 A4

TPU

4 A4

Spec List

Inductive Barrel Sensors

Turck Inc.

B14

Inductive Barrel Sensors | 6.5 mm

Nonembeddable Smooth Metal Barrels with DC Outputs

Housing Style Dimension Drawings

6.5 mm - Nonembeddable, Miniature Smooth, M8 Picofast Quick Disconnect

6.5 mm - Nonembeddable, Miniature Smooth Barrel,

6.5 mm - Nonembeddable, Miniature Smooth,

Potted-In Cable

M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

6.5 mm - Nonembeddable, Miniature Smooth Barrel,

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Vibration:

Repeatability:

Shock:

Potted-In Cable

We reserve the right to make technical alterations without prior notice.

Mating Cordset: PKG 3M-*

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B15

Turck Inc.

Inductive Barrel Sensors | 6.5 mm

Nonembeddable Smooth Metal Barrels with DC Outputs

Part Number/ ID Number

Ni4U-EH6.5-AP6X

4600680

Ni3-EH6.5-AN6X

4612500

Ni3-EH6.5-AP6X

4612400

Ni3-EH6.5K-AN6X

4610300

Ni3-EH6.5K-AP6X

4610200

Ni6U-EH6.5-AP6X-V1131

4631510

Ni4U-EH6.5-AN6X-V1131

4600683

Ni4U-EH6.5-AP6X-V1131

4600681

Ni3-EH6.5-AN6X-V1131

4612520

Ni3-EH6.5-AP6X-V1131

4612420

Ni3-EH6.5K-AN6X-V1131

4610320

Ni3-EH6.5K-AP6X-V1131

4610220

Features

Uprox 4 3-wire DC PNP 10-30 VDC 3000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU B 2 A4

Short Barrel 3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

Short Barrel 3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

Uprox+ 6 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +70 IP68 SS PA 12 N/A YE -- D 4 A4

Uprox 4 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE -- D 3 A4

Uprox 4 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE -- D 4 A4

Short Barrel 3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- C 3 A4

Short Barrel 3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- C 4 A4

Sensing Range (mm)

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- D 3 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- D 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B16

Inductive Barrel Sensors | 8 mm

Embeddable and NonembeddableSmooth Metal Barrels with DC Outputs

Housing Style Dimension Drawings

8 mm - Embeddable, Miniature Smooth Barrel,

Potted-In Cable

8 mm - Embeddable, Miniature Smooth Barrel,

8 mm - Nonembeddable, Miniature Smooth Barrel,

Potted-In Cable

8 mm - Embeddable, Miniature Smooth,

M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

1 2 3

8 mm - Embeddable, Miniature Smooth Barrel,

Potted-In Cable

8 mm - Nonembeddable, Miniature Smooth,

M8 Picofast Quick Disconnect

We reserve the right to make technical alterations without prior notice.

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

B17

Turck Inc.

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Vibration:

Repeatability:

Shock:

Mating Cordset: PKG 3M-*

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

Inductive Barrel Sensors | 8 mm

Embeddable and NonembeddableSmooth Metal Barrels with DC Outputs

Part Number/ ID Number

Bi1.5-H08K-AN6X

1604341

Bi1.5-H08K-AP6X

1604331

Bi1.5-H08M-AP6X

1604301

Bi1.5-H08-AN6X

16143

Bi1.5-H08-AP6X

16043

Ni2-H08K-AN6X

16147

Ni2-H08K-AP6X

16047

Bi1.5-H08K-AN6X-V1131

1604340

Bi1.5-H08K-AP6X-V1131

1604330

Ni2-H08K-AN6X-V1131

16148

Ni2-H08K-AP6X-V1131

16048

Features

Short Barrel 1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

Short Barrel 1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

Short Barrel 2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU D 1 A4

Short Barrel 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU D 2 A4

Short Barrel 1.5 3-wire DC NPN 10-30 VDC 5000 ≤150 -25 to +70 IP67 SS PBT N/A YE -- F 3 A4

Short Barrel 1.5 3-wire DC PNP 10-30 VDC 5000 ≤150 -25 to +70 IP67 SS PBT N/A YE -- F 4 A4

Short Barrel 2 3-wire DC NPN 10-30 VDC 5000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- E 3 A4

Short Barrel 2 3-wire DC PNP 10-30 VDC 5000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE -- E 4 A4

Sensing Range (mm)

1.5 3-wire DC PNP 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

1.5 3-wire DC NPN 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

1.5 3-wire DC PNP 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B18

Inductive Barrel Sensors | 5 mm, 8 mm

EmbeddableSide Sensing Metal Barrels with Cable and DC Outputs

Housing Style Dimension Drawings

5 mm - Embeddable, Side Sensing, Miniature Smooth Barrel, Potted-In Cable

We reserve the right to make technical alterations without prior notice.

8 mm - Embeddable, Side Sensing, Miniature Smooth Barrel, Potted-In Cable

Wiring Diagrams/Mating Cordsets

1 2

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

8 mm - Embeddable, Miniature Threaded Barrel, Side Sensing, Potted-In Cable

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B19

Turck Inc.

Inductive Barrel Sensors | 5 mm, 8 mm

EmbeddableSide Sensing Metal Barrels with Cable and DC Outputs

Part Number/ ID Number

Bi1.5-HS865-AN6X

4604301

Bi1.5-HS865-AP6X

4604201

Bi1.5-GS880-AN6X

4604501

Bi1.5-GS880-AP6X

4604401

Bi1-HS540-AN6X

4604101

Bi1-HS540-AP6X

4604001

Features

Side Sensing 1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

Side Sensing 1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

Side Sensing 1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

Side Sensing 1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

Side Sensing 1 3-wire DC NPN 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

Side Sensing 1 3-wire DC PNP 10-30 VDC 3000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

Sensing Range (mm)

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B20

M8x1

M8x

M8x1

M8x

M8x1

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

4-WAY

LED

.610 [15.5]

.972 [24.7]

4-WAY

LED

8 mm - Embeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

.886 [22.5]

1.248 [31.7]

Mating Cordset: PKG 3M-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

8 mm - Embeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

8 mm - Embeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

8 mm - Embeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

WAY

LED

8 mm - Embeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

1.201 [30.5]

1.563 [39.7]

We reserve the right to make technical alterations without prior notice.

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B21

Turck Inc.

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Bi3U-EM08-AN6X-V1131

4602423

Bi3U-EMT08-AN6X-V1131

4602157

Bi3U-EM08-AP6X-V1131

4602413

Bi3U-EMT08-AP6X-V1131

4602156

Bi3-M08-AN6X-V1131

4602914

Bi3-M08-AP6X-V1131

4602911

Bi3-M08KK-AN6X-V1131

4602942

Bi3-M08KK-AP6X-V1131

4602939

Bi2-EG08K-AN6X-V1131

4669550

Bi2-EG08K-AP6X-V1131

4669450

Bi2-G08K-AP6X-V1131

4672803

Bi2-M08K-AN6X-V1131

4602965

Bi2-M08K-AP6X-V1131

4602968

Bi1.5-EG08K-AN6X-V1131

We reserve the right to make technical alterations without prior notice.

4672540

Bi1.5-EG08K-AP6X-V1131

4672440

Note: Reference sensor data sheet for considerations if mounting a BI3-M08 sensor ush in steel.

Features

Uprox3 3 3-wire DC NPN 10-30 VDC 1000 ≤150 0 to +60 IP68 SS PA 12 N/A YE D 1 A4

Uprox3, PTFE 3 3-wire DC NPN 10-30 VDC 1000 ≤150 0 to +60 IP68 SS TC N/A YE D 1 A4

Uprox3 3 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +60 IP68 SS PA 12 N/A YE D 2 A4

Uprox3, PTFE 3 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +60 IP68 SS TC N/A YE D 2 A4

Short Barrel 3 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE A 1 A4

Short Barrel 3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE A 2 A4

Sensing Range (mm)

3 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE E 1 A4

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE E 2 A4

2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE D 1 A4

2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE D 2 A4

2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PBT N/A YE D 2 A4

2 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE C 1 A4

2 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE C 2 A4

1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 1 A4

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B22

M8x1

M8x

M8x1

M8x

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

4-WAY

LED

1.594 [40.5]

1.957 [49.7]

8 mm - Embeddable, Miniature Threaded, M8 Picofast Quick Disconnect

Mating Cordset: PKG 3M-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

8 mm - Embeddable, Miniature Threaded, M8 Picofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Reverse Polarity Protection:

Mating Cordset: PKG 3M-*; PKG 3M-*/S1587

≤8 ms

Power-On Effect:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B23

Turck Inc.

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Bi2U-EG08-AN6X-V1131

4602036

Bi2U-EG08-AP6X-V1131

4602033

Bi2-EG08-AN6X-V1131

4602150

Bi2-EG08-AP6X-V1131

4602050

Bi2-EG08-AP6X-V1131/S1589

46020501

Bi2-EGT08-AP6X-V1131/S100

4602263

Bi2-EGT08-AP6X-V1131/S100/S1589

4602072

Bi2-G08-AP6X-V1131

4602002

Bi2-M08E-AN6X-V1131

4602953

Bi2-M08E-AP6X-V1131

4602956

Bi1.5U-EG08-AN6X-V1131

4600530

Bi1.5U-EG08-AP6X-V1131

4600520

Bi1.5-EG08-AN6X-V1131

4602350

Bi1.5-EG08-AP6X-V1131

We reserve the right to make technical alterations without prior notice.

4602220

Features

Uprox 2

Weldguard 2

PTFE, High Temp.

100 °C

PTFE, High Temp.

100 °C, Weldguard

Uprox 1.5

Sensing Range (mm)

3-wire DC

1.5

3-wire DC

1.5

NPN

PNP

NPN

PNP

NPN

PNP

NPN

PNP

NPN

PNP

Output

Voltage

10-30 VDC 1000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE C 1 A4

10-30 VDC 1000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE C 2 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 1 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 2 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE C 2 A4

10-30 VDC 3000 ≤150 -25 to +100 IP67 SS TC N/A YE C 2 A4

10-30 VDC 3000 ≤150 -25 to +100 IP67 SS WG N/A YE C 2 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 2 A4

10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE A 1 A4

10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE A 2 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 1 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 2 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PP-

GF20

PP-

GF20

Face

Power LED

N/A YE B 1 A4

N/A YE B 2 A4

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B24

M8x1

]

M8x1

.177 [4.5]

M8x1

.177 [4.5]

M8x1

]

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

4-WAY

LED

.886 [22.5]

1.248 [31.7]

8 mm - Nonembeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

4-WAY

LED

8 mm - Nonembeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

1.594 [40.5]

1.957 [49.7]

.177 [4.5

4-WAY

LED

.610 [15.5]

8 mm - Nonembeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

4-WAY

LED

8 mm - Nonembeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

1.201 [30.5]

1.563 [39.7]

.972 [24.7]

.177 [4.5

8 mm - Nonembeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

8 mm - Nonembeddable, Miniature Threaded,

M8 Picofast Quick Disconnect

We reserve the right to make technical alterations without prior notice.

Mating Cordset: PKG 3M-*

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

B25

Turck Inc.

Ripple:

Wiring Diagrams/Mating Cordsets

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: PKG 3M-*

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Ni6U-EG08-AN6X-V1131

4635804

Ni6U-EG08-AP6X-V1131

4635801

Ni5-M08-AN6X-V1131

4602924

Ni5-M08-AP6X-V1131

4602921

Ni5-M08KK-AN6X-V1131

4602949

Ni5-M08KK-AP6X-V1131

4602946

Ni4U-EG08-AN6X-V1131

4600630

Ni4U-EG08-AP6X-V1131

4600620

Ni3-M08E-AN6X-V1131

4602833

Ni3-M08E-AP6X-V1131

4602836

Ni3-M08K-AN6X-V1131

4602849

Ni3-M08K-AP6X-V1131

4602853

Ni3-EG08-AN6X-V1131

4602850

Ni3-EG08-AP6X-V1131

We reserve the right to make technical alterations without prior notice.

4602750

Ni3-EG08K-AN6X-V1131

4669750

Ni3-EG08K-AP6X-V1131

4669650

Features

Uprox+ 6 3-wire DC NPN  10-30 VDC 1000 ≤150 0 to +70 IP68 SS LCP N/A YE E 1 A4

Uprox+ 6 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +70 IP68 SS LCP N/A YE E 2 A4

Short Barrel 5 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE A 1 A4

Short Barrel 5 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE A 2 A4

Uprox 4 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE E 1 A4

Uprox 4 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE E 2 A4

Sensing Range (mm)

5 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE D 1 A4

5 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE D 2 A4

3 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE F 1 A4

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE F 2 A4

3 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE C 1 A4

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP PP-GF20 N/A YE C 2 A4

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE E 1 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE E 2 A4

3 3-wire DC NPN  10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 1 A4

3 3-wire DC PNP  10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B26

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

4-WAY

LED

M12x1

M8x1

.610 [15.5]

1.283 [32.6]

4-WAY

M12x1

LED

M8x1

.866 [22.0]

1.535 [39.0]

4-WAY

LED

M12x1

8 mm - Embeddable, Miniature Threaded,

M12 Eurofast Quick Disconnect

M8x1

.886 [22.5]

1.559 [39.6]

Mating Cordset: RK 4.23T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

8 mm - Embeddable, Miniature Threaded,

M12 Eurofast Quick Disconnect

4-WAY

LED

M12x1

8 mm - Embeddable, Miniature Threaded,

M12 Eurofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

Mating Cordset: RK 4T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

M8x1

1.181 [30.0]

1.850 [47.0]

Off-State (Leakage) Current:

Transient Protection:

Time Delay Before Availability:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

8 mm - Embeddable, Miniature Threaded,

4-WAY

M12x1

8 mm - Embeddable, Miniature Threaded,

Power-On Effect:

Shock:

Vibration:

Repeatability:

Power-On Effect:

Temperature Drift:

Shock:

Vibration:

Repeatability:

M12 Eurofast Quick Disconnect

M8x1

LED

1.201 [30.5]

1.874 [47.6]

We reserve the right to make technical alterations without prior notice.

M12 Eurofast Quick Disconnect

Mating Cordset: RK 4T-*; RK 4T-*/S1587

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B27

Turck Inc.

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Bi3U-EM08-AN6X-H1341

4602422

Bi3U-EMT08-AN6X-H1341

4602158

Bi3U-EM08-AP6X-H1341

4602412

Bi3U-EMT08-AP6X-H1341

4602156

Bi3-M08-AN6X-H1341

4602915

Bi3-M08-AP6X-H1341

4602912

Bi3-M08KK-AN6X-H1341

4602943

Bi3-M08KK-AP6X-H1341

4602940

Bi2-EG08K-AG41X-H1341

4562011

Bi2-EG08K-AG41X-H1341/S1589

4562090

Bi2-EGT08K-AG41X-H1341/S1589

4602599

Bi2-EG08K-AN6X-H1341

4669560

Bi2-EG08K-AP6X-H1341

4669460

Bi2-EG08K-AP6X-H1341/S1589

We reserve the right to make technical alterations without prior notice.

4669486

Bi2-M08K-AN6X-H1341

4602964

Bi2-M08K-AP6X-H1341

4602967

Bi1.5-EG08K-AN6X-H1341

4669150

Bi1.5-EG08K-AP6X-H1341

4669050

Note: Reference sensor data sheet for considerations if mounting a BI3-M08 sensor ush in steel.

PTFE, Short barrel,

Features

Uprox3 3

Uprox3, PTFE 3

Uprox3 3

Uprox3, PTFE 3

Short Barrel 3

Weldguard 2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE B 1 A2

Weldguard

Weldguard 2

Sensing Range (mm)

2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE B 1 A2

2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE B 1 A2

1.5

Output

3-wire DC

NPN

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

Voltage

10-30 VDC 1000 ≤150 0 to +60 IP68 SS PA 12 N/A YE D 2 A4

10-30 VDC 1000 ≤150 0 to +60 IP68 SS TC N/A YE D 2 A4

10-30 VDC 1000 ≤150 0 to +60 IP68 SS PA 12 N/A YE D 3 A4

10-30 VDC 1000 ≤150 0 to +60 IP68 SS TC N/A YE D 3 A4

10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 2 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 3 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE B 3 A4

10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 2 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 3 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

Face

Power LED

Output LED

N/A YE E 2 A4

N/A YE E 3 A4

N/A YE A 2 A4

N/A YE A 3 A4

N/A YE C 2 A4

N/A YE C 3 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B28

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

M8x1

4-WAY

LED

M12x1

1.594 [40.5]

2.268 [57.6]

8 mm - Embeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4T-*; RK 4T-*/S1587

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

8 mm - Embeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Reverse Polarity Protection:

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4T-*; RK 4T-*/S1587

≤0.8 mA

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Power-On Effect:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B29

Turck Inc.

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Bi2U-EG08-AN6X-H1341

4602037

Bi2U-EG08-AP6X-H1341

4602034

Bi2-EG08-AG41X-H1341

4562001

Bi2-EG08-AG41X-H1341/S1589

4562095

Bi2-EG08-AN6X-H1341

4602160

Bi2-EG08-AN6X-H1341/S1589

4602182

Bi2-EG08-AP6X-H1341

4602060

Bi2-EG08-AP6X-H1341/S1589

4602086

Bi2-EGT08-AP6X-H1341/S100

4602257

Bi2-EG08-VN6X-H1341

4602521

Bi2-EG08-VP6X-H1341

S4602522

Bi2-G08-AN6X-H1341

46026

Bi2-G08-AP6X-H1341

46025

Bi2-M08E-AN6X-H1341

We reserve the right to make technical alterations without prior notice.

4602952

Bi2-M08E-AP6X-H1341

4602955

Bi1.5U-EG08-AN6X-H1341

4600550

Bi1.5U-EG08-AP6X-H1341

4600540

Bi1.5U-EG08-AP6X-H1341/S1589

46005401

Bi1.5U-EGT08-AP6X-H1341

4600555

Bi1.5-EG08-AD6X-H1341

4600203

Bi1.5-EG08-AN6X-H1341

4602360

Bi1.5-EG08-AP6X-H1341

4602260

Bi1.5-G08-

4603700

Bi1.5-G08-AN7X-H1341

4701126

Bi1.5-G08-AP6X-H1341

4603600

AN6X-H1341

Features

Uprox 2

Weldguard 2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE A 1 A2

Weldguard 2

PTFE, High Temp.

100 °C

Comp. Outputs 2

Uprox 1.5

Uprox, Weldguard 1.5

Uprox, PTFE 1.5

TTL Compatible 1.5

Sensing Range (mm)

Output

3-wire DC

NPN

3-wire DC

PNP

2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE A 1 A2

3-wire DC

NPN

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

4-wire DC

NPN

4-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

1.5 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE A 2 A2

3-wire DC

1.5 NPN

3-wire DC

1.5

PNP

3-wire DC

1.5

NPN

3-wire DC

NPN

3-wire DC

1.5

PNP

Voltage

10-30 VDC 1000 ≤150 -35 to +85 IP68 SS PA 12 N/A YE A 3 A4

10-30 VDC 1000 ≤150 -35 to +85 IP68 SS PA 12 N/A YE A 4 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 3 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE A 3 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 4 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE A 4 A4

10-30 VDC 3000 ≤150 -25 to +100 IP67 TC TC N/A YE A 4 A4

10-30 VDC 3000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 5 A4

10-30 VDC 3000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 6 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 3 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 4 A4

10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

10-30 VDC 2000 ≤150 -30 to +85 IP67 SS PA 12 N/A YE A 3 A4

10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE A 4 A4

10-30 VDC 2000 ≤150 -30 to +85 IP67 SS WG N/A YE A 4 A4

10-30 VDC 2000 ≤150 -30 to +85 IP67 TC TC N/A YE A 4 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 3 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 3 A4

10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 4 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PP-

GF20

PP-

GF20

Face

Power LED

Output LED

N/A YE B 3 A4

N/A YE B 4 A4

YE A 4 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B30

.177 [4.5]

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

4-WAY

M12x1

LED

M8x1

.610 [15.5]

1.283 [32.6]

8 mm - Nonembeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

4-WAY

M12x1

LED

M8x1

.886 [22.5]

1.559 [39.6]

8 mm - Nonembeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

M8x1

4-WAY

LED

1.201 [30.5]

M12x1

1.874 [47.6]

8 mm - Nonembeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

Mating Cordset: RK 4.23T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

8 mm - Nonembeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

Mating Cordset: RK 4T-*

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Reverse Polarity Protection:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Power-On Effect:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4T-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B31

Turck Inc.

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Ni5-M08-AN6X-H1341

4602925

Ni5-M08-AP6X-H1341

4602922

Ni5-M08KK-AN6X-H1341

4602950

Ni5-M08KK-AP6X-H1341

4602947

Ni4-EG08K-AG41X-H1341

4561011

Ni4-EG08K-AG41X-H1341/S1589

4561090

Ni3-EG08K-AN6X-H1341

4669760

Ni3-EG08K-AP6X-H1341

4669660

Ni3-M08K-AN6X-H1341

4602848

Ni3-M08K-AP6X-H1341

4602852

Features

Short Barrel 5 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE A 2 A4

Short Barrel 5 3-wire DC PNP  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE A 3 A4

Weldguard 4 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE B 1 A2

Sensing Range (mm)

5 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE D 2 A4

5 3-wire DC PNP  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE D 3 A4

4 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE B 1 A2

3 3-wire DC NPN  10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 2 A4

3 3-wire DC PNP  10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE B 3 A4

3 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE C 2 A4

3 3-wire DC PNP  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB PP-GF20 N/A YE C 3 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B32

.177 [4.5]

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

4-WAY

LED

M12x1

M8x1

1.594 [40.5]

2.268 [57.6]

8 mm - Nonembeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

Mating Cordset: RK 4.23T-*; RK 4.23T-*/S1587

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

8 mm - Nonembeddable, Miniature Threaded, M12 Eurofast Quick Disconnect

Wiring Diagrams/Mating Cordsets

Mating Cordset: RK 4T-*;

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Reverse Polarity Protection:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Power-On Effect:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4T-*; RK 4T-*/S1587

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B33

Turck Inc.

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Ni6U-EG08-AN6X-H1341

4635805

Ni6U-EG08-AP6X-H1341

4635802

Ni4U-EG08-AN6X-H1341

4600650

Ni4U-EG08-AP6X-H1341

4600640

Ni4U-EG08-AP6X-H1341/S1589

4600641

Ni4-EG08-AG41X-H1341

4561001

Ni4-EG08-AG41X-H1341/S1589

4561091

Ni3-EG08-AN6X-H1341

4602860

Ni3-EG08-AN7X-H1341

4669761

Ni3-EG08-AP6X-H1341

4602760

Ni3-EG08-AP6X-H1341/S1589

4602799

Ni3-M08E-AN6X-H1341

4602832

Ni3-M08E-AP6X-H1341

4602835

Ni3-G08-AN6X-H1341

We reserve the right to make technical alterations without prior notice.

4602704

Ni3-G08-AP6X-H1341

4602705

Ni2-G08-AN6X-H1341

46033

Ni2-G08-AP6X-H1341

46032

Features

Uprox+ 6 3-wire DC NPN 10-30 VDC 1000 ≤150 0 to +70 IP68 SS LCP N/A YE A 2 A4

Uprox+ 6 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +70 IP68 SS LCP N/A YE A 3 A4

Uprox 4 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE A 2 A4

Uprox 4 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE A 3 A4

Uprox, Weldguard 4 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP67 SS WG N/A YE A 3 A4

Weldguard 4 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE A 1 A2

TTL Compatible 3 3-wire DC NPN 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 2 A4

Weldguard 3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE A 3 A4

Sensing Range (mm)

4 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE A 1 A2

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 2 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE A 3 A4

3 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 2 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 3 A4

2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 2 A4

2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE C 3 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PP-

GF20

PP-

GF20

Face

Power LED

Output LED

N/A YE B 2 A4

N/A YE B 3 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B34

M8x1

.063 [1.6]

LED

M8x1

.063 [1.6]

LED

.063 [1.6]

M8x1

LED

.063 [1.6]

M8x1

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Cable and DC Outputs

Housing Style Dimension Drawings

.610 [15.5]

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable, PTFE Coated

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

1.201 [30.5]

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

Wiring Diagrams/Mating Cordsets

1 2

.886 [22.5]

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

1.181 [30.0]

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

We reserve the right to make technical alterations without prior notice.

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

B35

Turck Inc.

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Cable and DC Outputs

Part Number/ ID Number

Bi3U-EM08-AN6X

4602421

Bi3U-EM08-AP6X

4602411

Bi3-M08-AN6X

4602913

Bi3-M08-AP6X

4602910

Bi3-M08KK-AN6X

4602941

Bi3-M08KK-AP6X

4602938

Bi2-EG08K-AN6X

4669500

Bi2-EG08K-AN6X/S1589

4669587

Bi2-EG08K-AP6X

4669400

Bi2-EG08K-AP6X/S97

4669413

Bi2-EGT08K-AP6X

4602541

Bi2-EGT08K-AP6X/S100

4602544

Bi2-EGT08K-AP6X/S1589

46025413

Bi2-M08K-AN6X

We reserve the right to make technical alterations without prior notice.

4602963

Bi2-M08K-AP6X

4602966

Bi1.5-EG08K-AN6X

4669140

Bi1.5-EG08K-AP6X

4669040

Bi1.5-EG08K-AP6/S100

4669016

Note: Reference sensor data sheet for considerations if mounting a BI3-M08 sensor ush in steel.

Features

Uprox3 3 3-wire DC NPN 10-30 VDC 1000 ≤150 0 to +60 IP68 SS PA 12 N/A YE 2M/TPU E 1 A4

Uprox3 3 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +60 IP68 SS PA 12 N/A YE 2M/TPU E 2 A4

Short Barrel 3 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

Short Barrel 3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

Weldguard 2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE 2M/TPU B 1 A4

Low Temp. -40 °C 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -40 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

PTFE 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 TC TC N/A YE 2M/TPU C 2 A4

PTFE, High Temp.

100 °C

PTFE, Weldguard 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 TC WG N/A YE 2M/TPU C 2 A4

High Temp.

100 °C

Sensing Range (mm)

3 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +100 IP67 TC TC N/A YE 2M/TPU C 2 A4

2 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

2 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +100 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

Face

Power LED

Output LED

Cable Length/Jacket

N/A YE 2M/TPU F 1 A4

N/A YE 2M/TPU F 2 A4

N/A YE 2M/TPU A 1 A4

N/A YE 2M/TPU A 2 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

PP-

N/A YE 2M/TPU D 1 A4

GF20

PP-

N/A YE 2M/TPU D 2 A4

GF20

Turck Inc.

B36

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Cable and 2-Wire Outputs

Housing Style Dimension Drawings

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

8 mm - Embeddable, Miniature Threaded Barrel,

Potted-In Cable

Potted-In Cable, PTFE Coated

Wiring Diagrams/Mating Cordsets

1 2

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

2-wire DC - (AD, RD, AG)

8 mm - Embeddable, Miniature Threaded Barrel,

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Potted-In Cable, PTFE Coated

We reserve the right to make technical alterations without prior notice.

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10 ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

B37

Turck Inc.

Inductive Barrel Sensors | 8 mm

Embeddable Threaded Metal Barrels with Cable and 2-Wire Outputs

Part Number/ ID Number

Bi2-EG08-AG41X

4562000

Bi2-EG08-AG41X/S1589

4562088

Bi2-EG08-AZ14X

4100001

Bi2-EGT08-AG41X

4602540

Bi2-EGT08-AG41X/S1589

46020003

Bi2-EG08K-AG41X

4562010

Bi2-EG08K-AG41X/S1589

4562091

Bi2-EGT08K-AG41X

4602545

Features

Weldguard 2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE 2M/TPU C 1 A2

PTFE 2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 TC PA 12 N/A YE 2M/TPU D 1 A2

PTFE,

Weldguard

Weldguard 2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 SS WG N/A YE 2M/TPU A 1 A2

PTFE 2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 TC PA 12 N/A YE 2M/TPU B 1 A2

Sensing Range (mm)

2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A2

2 2-wire AC/DC

2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE 2M/TPU D 1 A2

2 2-wire DC 10-55 VDC 1000 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A2

Output

Voltage

20-132 VAC/10-

140 VDC

Switching Freq. (Hz)

Operating Current (mA)

20 ≤100 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A6

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B38

LED

.063 [1.6]

M8x1

Inductive Barrel Sensors | 8 mm

Embeddable Threaded MetalBarrels with Cable and DC Outputs

Housing Style Dimension Drawings

1.594 [40.5]

8 mm - Embeddable, Miniature Threaded Barrel, Potted-In Cable

Wiring Diagrams/Mating Cordsets

8 mm - Embeddable, Miniature Threaded Barrel, Potted-In Cable

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Repeatability:

Shock:

Vibration:

We reserve the right to make technical alterations without prior notice.

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B39

Turck Inc.

Inductive Barrel Sensors | 8 mm

Embeddable Threaded MetalBarrels with Cable and DC Outputs

Part Number/ ID Number

Bi2U-EG08-AN6X

4602035

Bi2U-EG08-AP6X

4602032

Bi2-EG08-AN6X

4602140

Bi2-EG08-AP6X

4602040

Bi2-EG08-AP6X/S100

4602047

Bi2-EG08-AP6X/S1589

4602085

Bi2-EG08-VP6X

1604610

Bi2-G08-AN6X

46021

Bi2-G08-AP6X

46020

Bi2-M08E-AN6X

4602951

Bi2-M08E-AP6X

4602954

Bi1.5U-EG08-AN6X

4600510

Bi1.5U-EG08-AP6X

4600500

Bi1.5-EG08-AN6X

We reserve the right to make technical alterations without prior notice.

4602340

Bi1.5-EG08-AN7X

1766110

Bi1.5-EG08-AP6X

4602240

Bi1.5-G08-AN6X

46023

Bi1.5-G08-AP6X

46022

Features

Uprox 2 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU A 1 A4

Uprox 2 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU A 2 A4

Extended Range 2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

Extended Range 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

High Temp. 100 °C 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +100 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

Weldguard 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE 2M/TPU A 2 A4

Comp. Outputs 2 4-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 3 A4

Extended Range 2 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

Extended Range 2 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

Uprox 1.5 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU A 1 A4

Uprox 1.5 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU A 2 A4

TTL Compatible 1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

Sensing Range (mm)

2 3-wire DC NPN 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

2 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CBP

1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 1 A4

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU A 2 A4

1.5 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 1 A4

1.5 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU C 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PP-

GF20

PP-

GF20

Face

Power LED

Output LED

Cable Length/Jacket

N/A YE 2M/TPU B 1 A4

N/A YE 2M/TPU B 2 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B40

M8x1

.063 [1.6]

LED

M8x1

.063 [1.6]

LED

.063 [1.6]

M8x1

LED

.063 [1.6]

M8x1

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Cable and DC Outputs

Housing Style Dimension Drawings

.177 [4.5]

8 mm - Nonembeddable, Miniature Threaded Barrel,

Potted-In Cable

.886 [22.5]

1.594 [40.5]

.177 [4.5]

8 mm - Nonembeddable, Miniature Threaded Barrel,

Potted-In Cable

8 mm - Nonembeddable, Miniature Threaded Barrel,

.177 [4.5]

8 mm - Nonembeddable, Miniature Threaded Barrel,

Potted-In Cable

Wiring Diagrams/Mating Cordsets

1 2

.610 [15.5]

1.201 [30.5]

8 mm - Nonembeddable, Miniature Threaded Barrel,

Potted-In Cable

8 mm - Nonembeddable, Miniature Threaded Barrel,

Potted-In Cable

We reserve the right to make technical alterations without prior notice.

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

B41

Turck Inc.

Ripple:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

Inductive Barrel Sensors | 8 mm

Nonembeddable Threaded Metal Barrels with Cable and DC Outputs

Part Number/ ID Number

Ni6U-EG08-AN6X

4635803

Ni6U-EG08-AP6X

4635800

Ni5-M08-AN6X

4602923

Ni5-M08-AP6X

4602920

Ni5-M08KK-AN6X

4602948

Ni5-M08KK-AP6X

4602944

Ni4U-EG08-AN6X

4600610

Ni4U-EG08-AP6X

4600600

Ni3-EG08-AN6X

4602840

Ni3-EG08-AN6X/S1589

4602888

Ni3-EG08-AN7X

4669759

Ni3-EG08-AP6X

4602740

Ni3-EG08-AP6X/S1589

4602789

Ni3-EG08K-AN6X

We reserve the right to make technical alterations without prior notice.

4669700

Ni3-EG08K-AP6X

4669600

Ni3-G08-AN6X

46028

Ni3-G08-AP6X

46027

Ni3-M08E-AN6X

4602831

Ni3-M08E-AP6X

4602834

Ni3-M08K-AN6X

4602847

Ni3-M08K-AP6X

4602851

Ni2-G08-AN6X

4601300

Ni2-G08-AP6X

46012

Features

Uprox+ 6 3-wire DC NPN  10-30 VDC 1000 ≤150 0 to +70 IP68 SS LCP N/A YE 2M/TPU E 1 A4

Uprox+ 6 3-wire DC PNP 10-30 VDC 1000 ≤150 0 to +70 IP68 SS LCP N/A YE 2M/TPU E 2 A4

Short Barrel 5 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

Short Barrel 5 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

Uprox 4 3-wire DC NPN 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU E 1 A4

Uprox 4 3-wire DC PNP 10-30 VDC 2000 ≤150 -30 to +85 IP68 SS PA 12 N/A YE 2M/TPU E 2 A4

Weldguard 3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE 2M/TPU E 1 A4

TTL Compatible 3 3-wire DC NPN 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU E 1 A4

Weldguard 3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS WG N/A YE 2M/TPU E 2 A4

Sensing Range (mm)

5 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

5 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU E 1 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU E 2 A4

3 3-wire DC NPN 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 1 A4

3 3-wire DC PNP 10-30 VDC 3000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU B 2 A4

3 3-wire DC NPN 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU G 1 A4

3 3-wire DC PNP 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU G 2 A4

3 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

3 3-wire DC NPN  10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

3 3-wire DC PNP 10-30 VDC 2800 ≤150 -25 to +70 IP67 CPB

2 3-wire DC NPN 10-30 VDC 2000 ≤150

2 3-wire DC PNP 10-30 VDC 2000 ≤150 -25 to +70 IP67 SS PA 12 N/A YE 2M/TPU G 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

-25 to +70 IP67 SS PA 12 N/A YE 2M/TPU G

Protection

Housing

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

PP-

GF20

Face

Power LED

Output LED

Cable Length/Jacket

N/A YE 2M/TPU D 1 A4

N/A YE 2M/TPU D 2 A4

N/A YE 2M/TPU A 1 A4

N/A YE 2M/TPU A 2 A4

N/A YE 2M/TPU F 1 A4

N/A YE 2M/TPU F 2 A4

N/A YE 2M/TPU C 1 A4

N/A YE 2M/TPU C 2 A4

Dimension Drawings

1 A4

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B42

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Mating Cordset: RK 4T-*; RKV 4T-*

Mating Cordset: RK 4.4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

12 mm - Embeddable, M12 Eurofast Connection

Wiring Diagrams/Mating Cordsets

Mating Cordset: RK 4T-*; RKV 4T-*

Mating Cordset: RK 4.4T-*; RKV 4.4T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

12 mm - Embeddable, M8 Picofast Connection

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Mating Cordset: RK 4.2T-*

Mating Cordset: PKG 3M-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B43

Turck Inc.

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi6U-M12-AN6X-H1141

1644808

Bi6U-M12-AP6X-H1141

1644810

Bi6U-M12-VP6X-H1141

1644805

Bi4U-EM12-AN6X-H1141

1634827

Bi4U-M12-AN6X-H1141

1634824

Bi4U-EM12-AP6X-H1141

1634807

Bi4U-M12-AP6X-H1141

1634804

Bi4U-M12-AP6X-V1131

1634780

Bi4-M12-AN6X-H1141

4607100

Bi4-M12-AP6X-H1141

46070

Bi4-M12-VN6X-H1141

1643200

Bi4-M12-VP6X-H1141

1633200

Bi4-EM12-VP6X-H1141

1633201

Bi3U-EM12-AN6X-H1141

We reserve the right to make technical alterations without prior notice.

1634350

Bi3U-M12-AN6X-H1141

1634150

Bi3U-EM12-AP6X-H1141

1634340

Bi3U-M12-AP6X-H1141

1634140

Bi3-M12-AD4X-H1141

4405041

Bi2-M12-AD4X-H1141

44065

Bi2-EM12-AN6X-H1141

4606601

Bi2-M12-AN6X-H1141

46066

Bi2-EM12-AP6X-H1141

4606501

Bi2-M12-AP6X-H1141

46065

Bi2-M12-VN6X

16430

Bi2-M12-VP6X-H1141

16330

-H1141

Features

Uprox3 6 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP68 CPB LC P N/A YE A 1 A4

Uprox3 6 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP68 CPB LCP N/A YE A 2 A4

Uprox3, Comp. Outputs 6 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP68 CPB LC P N/A YE A 5 A4

Uprox+ 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS LCP N/A YE A 1 A4

Uprox+ 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 1 A4

Uprox+ 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS LCP N/A YE A 2 A4

Uprox+ 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 2 A4

Uprox+ 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 CPB LCP N/A YE B 6 A4

Extended Range 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A4

Extended Range 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A4

Ext. Range, Comp. Outputs 4 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

Ext. Range, Comp. Outputs 4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 5 A4

Ext. Range, Comp. Outputs 4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 5 A4

Uprox 3 3-wire DC NPN 10-30 VDC 3000 ≤200 -30 to +85 IP68 SS PA 12 N/A YE A 1 A4

Uprox 3 3-wire DC NPN 10-30 VDC 3000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 1 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP68 SS PA 12 N/A YE A 2 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 2 A4

Comp. Outputs 2 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

Comp. Outputs 2 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 5 A4

Sensing Range (mm)

3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A2

2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A2

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 1 A4

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 2 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

A 2 A4

Spec List

Inductive Barrel Sensors

Turck Inc.

B44

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

12 mm - Embeddable, M12 Eurofast Connection, Extended Barrel Length

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Mating Cordset: RK 4.4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4.2T-*

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4.4T-*

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B45

Turck Inc.

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi4-M12E-AN6X-H1141

4607193

Bi4-EM12E-AN6X-H1141/S1589

4607185

Bi4-M12E-AP6X-H1141

4608030

Bi4-EM12E-AP6X-H1141/S1589

4607184

Bi4-M12E-VN6X-H1141

1643201

Bi4-M12E-VP6X-H1141

4608092

Bi3U-EM12E-AN6X-H1141

1634351

Bi3U-EM12HE-AN6X2-H1141

1634311

Bi3U-EM12E-AN6X2-H1141/S1589

1634397

Bi3U-M12E-AP6X-H1141

1634148

Bi3U-EM12HE-AP6X2-H1141

1634310

Bi3U-EM12E-AP6X2-H1141/S1589

1634398

Bi3U-M12E-AN6X-H1141

1634151

Bi3U-EM12E-AP6X-H1141

We reserve the right to make technical alterations without prior notice.

1634343

Bi3U-M12E-VN4X-H1141

1580354

Bi3U-M12E-VP4X-H1141

1580252

Bi3-M12E-AD4X-H1141

4405080

Bi2U-M12E-AD4X-H1144

4405060

Bi2-M12E-AN6X-H1141

4606602

Features

Extended Range 4 3-wire DC NPN

Ext. Range, Weldguard 4 3-wire DC NPN

Extended Range 4 3-wire DC PNP

Ext. Range, Weldguard 4 3-wire DC PNP

Extended Range 4 4-wire DC NPN

Extended Range 4 4-wire DC PNP

Uprox 3 3-wire DC NPN

Uprox, Stoneface 3 3-wire DC NPN

Uprox, Weldguard 3 3-wire DC NPN

Uprox 3 3-wire DC PNP

Uprox, Stoneface 3 3-wire DC PNP

Uprox, Weldguard 3 3-wire DC PNP

Uprox 3 3-wire DC NPN

Uprox 3 3-wire DC PNP

Uprox 3 4-wire DC NPN

Uprox 3 4-wire DC PNP

Uprox 2 2-wire DC

Sensing Range (mm)

3 2-wire DC 

2 3-wire DC NPN

Output

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-30

VDC

10-65

VDC

10-65

VDC

10-30

VDC

Voltage

Switching Freq. (Hz)

Operating Current (mA)

2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

2000 ≤200 -25 to +70 IP67 SS WG N/A YE A 3 A4

2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

2000 ≤200 -25 to +70 IP67 SS WG N/A YE A 4 A4

2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 5 A4

2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 6 A4

3000 ≤200 -30 to +85 IP68 SS PA 12 N/A YE A 3 A4

3000 ≤200 -30 to +85 IP68 SS PA 12 GN YE A 3 A4

3000 ≤200 -30 to +85 IP68 SS WG GN YE A 3 A4

3000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 4 A4

3000 ≤200 -30 to +85 IP68 SS SF GN YE A 4 A4

3000 ≤200 -30 to +85 IP68 SS WG GN YE A 4 A4

3000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 3 A4

3000 ≤200 -30 to +85 IP68 SS PA 12 N/A YE A 4 A4

3000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 5 A4

3000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 6 A4

1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A2

1000 ≤100 -30 to +85 IP68 CPB LCP N/A YE A 1 A2

2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B46

Inductive Barrel Sensors | 12 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable, M12 Eurofast Connection, PTFE Coated Sensors

Wiring Diagrams s/Mating Cordset

Mating Cordset: RK 4.2T-*

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4.23T-*

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B47

Turck Inc.

Inductive Barrel Sensors | 12 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi6U-MT12-AN6X-H1141

1644858

Bi6U-MT12-AP6X-H1141

1644831

Bi6U-MT12-AP6X2-H1141

1644904

Bi4U-MT12-AN6X-H1141

1634829

Bi4U-MT12-AN6X-H1141/S1589

16348290

Bi4U-MT12-AP6X-H1141

1634809

Bi4-MT12H-AN6X-H1141

4607194

Bi4-MT12-AN6X-H1141/S1589

4607188

Bi4-MT12H-AP6X-H1141

4607093

Bi4-MT12-AP6X-H1141/S1589

4607099

Bi3U-MT12-AN6X-H1141

1634250

Bi3U-MT12-AP6X-H1141

1634240

Bi3U-MT12-AP6X2-H1141

1634245

Bi3U-MT12H-AP6X-H1141

We reserve the right to make technical alterations without prior notice.

1634212

Bi3U-MT12-AP6X2-H1141/S1589

1634293

Bi3-MT12-AD4X-H1141/S1589

4405082

Bi3-MT12-AD4X-H1144/S1589

4405084

Features

Uprox3, PTFE 6

Uprox+, PTFE 4

Uprox+, PTFE,

Weldguard

Uprox+, PTFE 4

Ext. Range, PTFE,

Stoneface

Ext. Range, PTFE,

Weldguard

Ext. Range, PTFE,

Stoneface

Ext. Range, PTFE,

Weldguard

Uprox, PTFE 3

Uprox, PTFE, Stoneface 3

Uprox, PTFE,

Weldguard

PTFE, Weldguard 3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE A 1 A2

PTFE, Weldguard 3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE A 2 A2

Sensing Range (mm)

3-wire DC

NPN

PNP

NPN

PNP

NPN

PNP

NPN

PNP

Output

Voltage

10-30 VDC 2000 ≤200 -25 to +70 IP68 TC TC N/A YE A 3 A4

10-30 VDC 2000 ≤200 -25 to +70 IP68 TC TC N/A YE A 4 A4

10-30 VDC 2000 ≤200 -25 to +70 IP68 TC TC GN YE A 4 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 TC TC N/A YE A 3 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 TC WG N/A YE A 3 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 TC TC N/A YE A 4 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC SF N/A YE A 3 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC WG N/A YE A 3 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC SF N/A YE A 4 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC WG N/A YE A 4 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC TC N/A YE A 3 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC TC N/A YE A 4 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC TC GN YE A 4 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC TC N/A YE A 4 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC WG GN YE A 4 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B48

Inductive Barrel Sensors | 12 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Wiring Diagrams/Mating Cordset

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

12 mm - Embeddable, M12 Eurofast Connection, Extended Barrel Length,

PTFE Coated Sensors

Mating Cordset: RK 4.2T-*

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B49

Turck Inc.

Inductive Barrel Sensors | 12 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi4U-MT12E-AP6X2-H1141

1644742

Bi4U-MT12E-AP6X2-H1141/S1589

1644797

Bi4-MT12E-AP6X-H1141

46080932

Bi4-MT12HE-AN6X-H1141

4607197

Bi4-MT12HE-AP6X-H1141

4608093

Bi4-MT12E-AN6X-H1141/S1589

4607187

Bi4-MT12E-AP6X-H1141/S1589

4608094

Bi3U-MT12HE-AN6X2-H1141

1634230

Bi3U-MT12E-AN6X2-H1141/S1589

1634290

Bi3U-MT12HE-AP6X2-H1141

1634220

Bi3U-MT12E-AP6X2-H1141/S1589

1634291

Bi3-MT12E-AD4X-H1141

44050882

Bi3-MT12HE-AD4X-H1141

4405088

Bi3-MT12E-AD4X-H1141/S1589

We reserve the right to make technical alterations without prior notice.

4405086

Bi3-MT12E-AD4X-H1144/S1589

4405087

Bi2U-MT12E-AD4X-H1144

4405061

Features

Uprox+ 4

Uprox+, PTFE,

Weldguard

Ext. Range, PTFE 4

Ext. Range, Stoneface 4

Ext. Range, Weldguard 4

Uprox, PTFE, Stoneface 3

Uprox, Weldguard 3

Uprox, PTFE, Stoneface 3

Uprox, Weldguard 3

PTFE 3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC TC N/A YE A 2 A2

Stoneface 3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC TC N/A YE A 2 A2

PTFE, Weldguard 3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE A 2 A2

Uprox+, PTFE 2 2-wire DC 10-65 VDC 1000 ≤100 -30 to +85 IP68 TC TC N/A YE A 1 A2

Sensing Range (mm)

3-wire DC

PNP

NPN

PNP

NPN

PNP

NPN

PNP

Output

Voltage

10-30 VDC 2000 ≤200 -30 to +85 IP68 TC TC GN YE A 4 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 TC WG N/A YE A 4 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC TC N/A YE A 4 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC TC N/A YE A 3 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC TC N/A YE A 4 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC WG N/A YE A 3 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 TC WG N/A YE A 4 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC TC GN YE A 3 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC WG GN YE A 3 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC TC GN YE A 4 A4

10-30 VDC 3000 ≤200 -30 to +85 IP67 TC WG GN YE A 4 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B50

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

12 mm - Nonembeddable, M12 Eurofast Connection

Mating Cordset: RK 4.2T-*

Mating Cordset: RK 4T-*; RKV 4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4.4T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Mating Cordset: RK 4T-*; RKV 4T-*

Mating Cordset: RK 4.4T-*RKV 4.4T-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B51

Turck Inc.

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Ni10U-M12-AN6X-H1141

1634826

Ni10U-M12-AP6X-H1141

1634806

Ni10U-EM12-AN6X-H1141

1634828

Ni10U-EM12-AP6X-H1141

1634808

Ni8U-M12-AN6X-H1141

1644150

Ni8U-M12-AN6X2-H1141

1644155

Ni8U-M12-AP6X-H1141

1644140

Ni8U-M12-AP6X2-H1141

1644145

Ni8U-EM12-AN6X-H1141

1644350

Ni8U-EM12-AP6X-H1141

1644340

Ni8-M12-AD4X-H1141

4411241

Ni8-M12-AD4X-H1144

4411289

Ni8-M12-AN6X-H1141

4611315

Ni8-M12-AP6X-H1141

We reserve the right to make technical alterations without prior notice.

4611310

Ni8-M12-VN6X-H1141

4611323

Ni8-M12-VP6X-H1141

4611324

Ni5-M12-AN6X-H1141

4671390

Ni5-M12-AP6X-H1141

4653400

Ni4-M12-AD4X-H1141

44067

Ni4-M12-AN6X-H1141

46068

Ni4-M12-AP6X-H1141

46067

Ni4-EM12-AN7X-H1141

4606893

Ni4-M12-VN6X-H1141

16431

Ni4-M12-

VP6X-H1141

16331

Ni4-EM12-VP6X-H1141

1633101

Features

Uprox+ 10 3-wire DC NPN 10-30 VDC 1000 ≤200 -30 to +85 IP68 CPB LC P N/A YE A 3 A4

Uprox+ 10 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 CPB LC P N/A YE A 4 A4

Uprox+ 10 3-wire DC NPN 10-30 VDC 1000 ≤200 -30 to +85 IP68 SS LC P N/A YE A 3 A4

Uprox+ 10 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS LC P N/A YE A 4 A4

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LC P N/A YE A 3 A4

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LC P GN YE A 3 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LC P N/A YE A 4 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LC P GN YE A 4 A4

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS LCP N/A YE A 3 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT N/A YE A 4 A4

Extended Range 8 2-wire DC 10-65 VDC 2000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A2

Extended Range 8 2-wire DC 10-65 VDC 2000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A2

Extended Range 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

Extended Range 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

Ext. Range, Comp. Outputs 8 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 5 A4

Ext. Range, Comp. Outputs 8 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 6 A4

TTL Compatible 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

Comp. Outputs 4 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A

Comp. Outputs 4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 6 A4

Comp. Outputs 4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 6 A4

Sensing Range (mm)

5 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

5 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

4 2-wire DC 10-65 VDC 2000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A2

4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

YE A 5 A4

Spec List

Inductive Barrel Sensors

Turck Inc.

B52

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

12 mm - Nonembeddable, Extended Barrel Length, M12 Eurofast Connection

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4.4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Mating Cordset: RK 4.4T-*; RKV 4.4T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B53

Turck Inc.

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Ni8U-M12E-AN6X-H1141

1644151

Ni8U-EM12E-AN6X2-H1141

1644315

Ni8U-EM12E-AN6X2-H1141/S1589

1644391

Ni8U-M12E-AP6X-H1141

1644144

Ni8U-EM12E-AP6X-H1141

1644342

Ni8U-EM12E-AP6X2-H1141

1644314

Ni8U-EM12E-AP6X2-H1141/S1589

1644392

Ni8U-M12E-VN4X-H1141

1580552

Ni8U-M12E-VP4X-H1141

1580454

Ni8U-EM12E-VP4X-H1141

1580463

Ni8-M12E-AN6X-H1141

4611325

Ni8-EM12E-AN6X-H1141/S1589

4611395

Ni8-M12E-AP6X-H1141

46113981

Ni8-EM12E-AP6X-H1141/S1589

We reserve the right to make technical alterations without prior notice.

4611396

Ni8-M12E-VP6X-H1141

4611389

Ni4-M12E-AD4X-H1144

4406792

Ni4-EM12E-VP6X-H1141

1633191

Features

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB PBT N/A YE A 2 A4

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PA 12 GN YE A 2 A4

Uprox,

Weldguard

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB PA 12 N/A YE A 3 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT N/A YE A 3 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT GN YE A 3 A4

Uprox,

Weldguard

Uprox, Comp.

Outputs

Uprox 8 4-wire DC PNP 10-65 VDC 2000 ≤200 -30 to +85 IP67 SS PA 12 N/A YE A 5 A4

Extended

Range

Ext. Range, Weldguard

Extended

Range

Weldguard 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 WG WG N/A YE A 3 A4

Ext. Range,

Comp. Outputs

Comp. Outputs 4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE A 5 A4

Sensing Range (mm)

8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 WG WG GN YE A 2 A4

8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 WG WG GN YE A 3 A4

8 4-wire DC NPN 10-65 VDC 2000 ≤200 -30 to +85 IP67 SS PA 12 N/A YE A 4 A4

8 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A4

8 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 WG WG N/A YE A 2 A4

8 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

8 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 5 A4

4 2-wire DC  10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A2

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B54

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Mating Cordset: RKC 4.2T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

12 mm - Nonembeddable, M12 Eurofast Connection,

PTFE Coated

Wiring Diagrams/Mating Cordsets

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

12 mm - Nonembeddable, Extended Barrel Length,

M12 Eurofast Connection, PTFE Coated

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B55

Turck Inc.

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Ni10U-MT12-AN6X-H1141

1634830

Ni10U-MT12-AP6X-H1141

1634810

Ni10U-MT12-AP6X-H1141/S1589

16348101

Ni10U-MT12E-AP6X2-H1141

1634844

Ni10U-MT12E-AP6X2-H1141/S1589

1634994

Ni8U-MT12-AP6X-H1141

1644240

Ni8U-MT12-AP6X2-H1141

1644245

Ni8U-MT12-AP6X2-H1141/S1589

1644292

Ni8U-MT12E-AN6X2-H1141

1644248

Ni8U-MT12E-AP6X2-H1141

1644247

Ni8-MT12-AD4X-H1141/S1589

4411291

Ni8-MT12E-AN6X-H1141/S1589

4611397

Ni8-MT12E-AP6X-H1141/S1589

4611398

Features

Uprox+, PTFE 10

Uprox+, PTFE,

Weldguard

Uprox+, PTFE 10

Uprox+, PTFE,

Weldguard

Uprox, PTFE 8

Uprox, PTFE,

Weldguard

Uprox 8

PTFE, Weldguard 8 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE A 1 A2

Ext. Range, Weldguard

Sensing Range (mm)

Output

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

Voltage

10-30 VDC 1000 ≤200 -30 to +85 IP68 TC LCP N/A YE A 2 A4

10-30 VDC 1000 ≤200 -30 to +85 IP68 TC LCP N/A YE A 3 A4

10-30 VDC 1000 ≤200 -30 to +85 IP68 TC WG N/A YE A 3 A4

10-30 VDC 1000 ≤200 -30 to +85 IP68 TC LCP GN YE B 3 A4

10-30 VDC 1000 ≤200 -30 to +85 IP68 TC WG N/A YE B 3 A4

10-30 VDC 2000 ≤200 -30 to +85 IP67 TC TC N/A YE A 3 A4

10-30 VDC 2000 ≤200 -30 to +85 IP67 TC TC GN YE A 3 A4

10-30 VDC 2000 ≤200 -30 to +85 IP67 TC WG GN YE A 3 A4

10-30 VDC 2000 ≤200 -30 to +85 IP67 TC TC N/A YE B 2 A4

10-30 VDC 2000 ≤200 -30 to +85 IP67 TC TC N/A YE B 3 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 WG WG N/A YE B 2 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 WG WG N/A YE B 3 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B56

Inductive Barrel Sensors | 12 mm

Fully Threaded Metal Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable, M8 Picofast Connection

12 mm - Nonembeddable, M12 Eurofast Connection

Mating Cordset: PKG 3M-*

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Ripple:

Wiring Diagrams/Mating Cordsets

Mating Cordset: PKG 3M-*

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4T-*

12 mm - Embeddable, M12 Eurofast Connection

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4T-*; RKV 4T-*

B57

Turck Inc.

Inductive Barrel Sensors | 12 mm

Fully Threaded Metal Barrels with Connector and DC Outputs

Part Number/ ID Number

Bi4-G12-AN6X-V1131

1690707

Bi4-G12-AP6X-V1131

1690703

Bi4-EG12-AP6X-H1141

4607091

Bi2-G12-AN6X-V1131

4635583

Bi2-G12-AN6X-H1141

4606693

Bi2-G12-AP6X-H1141

4606595

Bi2-G12-AP6X-V1131

4606597

Ni8-G12-AN6X-H1141

4611383

Ni5-G12-AN6X-V1131

4635721

Ni5-G12-AN6X-H1141

4635793

Ni5-G12-AN7X-H1141

1714593

Ni5-G12-AP6X-V1131

4635690

Ni5-G12-AP6X-H1141

4635692

Features

Extended Range 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A4

Extended Range 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A4

Extended Range 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A RD C 4 A4

Extended Range 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A RD D 3 A4

TTL Compatible 5 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A RD D 3 A4

Sensing Range (mm)

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A4

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A RD C 3 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A RD C 4 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 2 A4

5 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 1 A4

5 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A RD D 3 A4

5 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 2 A4

5 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A RD D 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B58

Inductive Barrel Sensors | 12 mm

Threaded PlasticBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable/Nonembeddable, Plastic, M12 Eurofast Connection

Mating Cordset: RKK 4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Wiring Diagrams/Mating Cordsets

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Reverse Polarity Protection:

Wire-Break Protection:

Mating Cordset: RKK 4T-*

Power-On Effect:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B59

Turck Inc.

Inductive Barrel Sensors | 12 mm

Threaded PlasticBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi3U-S12-AN6X-H1141

1634620

Bi3U-S12-AP6X-H1141

16346

Bi2-S12-AN6X-H1141

46521

Bi2-S12-AP6X-H1141

46520

Ni8U-S12-AN6X-H1141

1644620

Ni8U-S12-AP6X-H1141

1644600

Ni4-S12-AN6X-H1141

46523

Ni4-S12-AP6X-H1141

46522

Features

Sensing Range (mm)

Uprox 3 3-wire DC NPN 10-30 VDC 3000 ≤200 -30 to +85 IP68 PBT PBT N/A YE B 1 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP68 PBT PBT N/A YE B 2 A4

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A RD A 1 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A RD A 2 A4

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 PBT PBT N/A YE B 1 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 PBT PBT N/A YE B 2 A4

4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A RD A 1 A4

4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A RD A 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B60

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Connector and AC/DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable, 1/2” Microfast Connection

12 mm - Embeddable, 1/2“ Microfast Connection, PTFE Coated

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Continuous Load Current:

Off-State (Leakage) Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

Wiring Diagrams/Mating Cordsets

Mating Cordset: KB 3T-*

2-wire AC/DC w/ Short-Circuit Protection - (ADZ, RDZ, FDZ, VDZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≥440 mA; DC: ≥330 mA AC: ≥120 mA; DC: ≥120 mA AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA (AC) ≤1.5 mA (DC)

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

Minimum Load Current:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

≥3.0 mA ≤3 A (≤20 ms, max 5 Hz) Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

B61

Turck Inc.

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Connector and AC/DC Outputs

Part Number/ ID Number

Bi4-G12-ADZ32X-B3131

4205031

Bi4-GT12H-ADZ32X-B3131

4205097

Bi4-GT12-ADZ32X-B3131/S1589

4205087

Bi2U-G12-ADZ32X-B3131

4281005

Bi2U-GT12-ADZ32X-B3131

4281015

Bi2-G12-AZ33X-B3131

1304032

Bi2-G12-ADZ32X-B3131

4205001

Bi2-GT12H-ADZ32X-B3131/S34

4205093

Bi2-GT12-ADZ32X-B3131/S34

4205005

Bi2-GT12-AZ33X-B3131/S34

1304082

Features

Sensing Range (mm)

Extended

Range

Stoneface 4

PTFE,

Weldguard

Uprox 2

PTFE, WFI, Stoneface

PTFE, WFI 2

PTFE, WFI 2 2-wire AC/DC 

Short-Circuit Protected

2 2-wire AC/DC 

Short-Circuit Protected

Output

2-wire AC/DC

Voltage

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

Switching Freq. (Hz)

Operating Current (mA)

20 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A5

20 ≤100 -25 to +70 IP67 TC TC N/A YE B 1 A5

20 ≤100 -25 to +70 IP67 TC WG N/A YE B 1 A5

10 ≤100 -30 to +85 IP67 CPB PBT N/A YE A 1 A5

10 ≤100 -30 to +85 IP67 TC TC N/A YE B 1 A5

20 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A6

20 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A5

20 ≤100 -25 to +70 IP67 TC TC N/A YE B 1 A5

20 ≤100 -25 to +70 IP67 TC TC N/A YE B 1 A6

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B62

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded Metal Barrels with Connector and AC/DC Outputs

Housing Style Dimension Drawings

12 mm - Nonembeddable, 1/2” Microfast Connection

12 mm - Nonembeddable, 1/2“ Microfast Connection, PTFE Coated

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Continuous Load Current:

Off-State (Leakage) Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

Wiring Diagrams/Mating Cordsets

Mating Cordset: KB 3T-*

2-wire AC/DC w/ Short-Circuit Protection - (ADZ, RDZ, FDZ, VDZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≥440 mA; DC: ≥330 mA AC: ≥120 mA; DC: ≥120 mA AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA (AC) ≤1.5 mA (DC)

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

Minimum Load Current:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

≥3.0 mA ≤3 A (≤20 ms, max 5 Hz) Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

B63

Turck Inc.

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded Metal Barrels with Connector and AC/DC Outputs

Part Number/ ID Number

Ni8U-G12-ADZ32X-B3131

4281105

Ni8U-GT12-ADZ32X-B3131

4281115

Ni4-G12-ADZ32X-B3131

4205201

Ni4-G12-AZ33X-B3131

1304232

Ni4-GT12-ADZ32X-B3131/S34

4205205

Ni4-GT12-AZ33X-B3131/S34

1304292

Ni4-GT12-ADZ32X-B3131/S34/S1589

4205293

Features

Sensing Range (mm)

Uprox 8

PTFE, WFI 4

PTFE, WFI 4 2-wire AC/DC

PTFE,

Weldguard

Short-Circuit Protected

4 2-wire AC/DC 

Short-Circuit Protected

Output

2-wire AC/DC

Voltage

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

Switching Freq. (Hz)

10 ≤100

20 ≤100

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

-30 to

-25 to

IP67 CPB PBT N/A YE A 1 A5

+85

IP67 TC PA 12 N/A YE B 1 A5

+85

IP67 CPB PA 12 N/A YE A 1 A5

+70

IP67 CPB PA 12 N/A YE A 1 A6

+70

IP67 TC PA 12 N/A YE B 1 A5

+70

IP67 TC PA 12 N/A YE B 1 A6

+70

IP67 TC WG N/A YE B 1 A5

+70

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B64

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Cable and DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable, Potted-in Cable

12 mm - Embeddable, Extended Length Barrel, Potted-in Cable

Wiring Diagrams/Mating Cordsets

1 2 3

We reserve the right to make technical alterations without prior notice.

4 5

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Reverse Polarity Protection:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Power-On Effect:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B65

Turck Inc.

Inductive Barrel Sensors | 12 mm

Embeddable Threaded MetalBarrels with Cable and DC Outputs

Part Number/ ID Number

Bi6U-M12-AN6X

1644806

Bi6U-M12-AP6X

1644801

Bi6U-M12-VP6X

1644803

Bi4U-M12-AN6X

1634823

Bi4U-M12-AP6X

1634803

Bi4-M12-AN6X

4607130

Bi4-M12-AP6X

4607006

Bi4-M12-VN6X

1643300

Bi4-M12-VP6X

1633300

Bi4-M12E-VN6X

1643290

Bi4-M12E-VP6X

1633391

Bi3U-M12-AN6X

1634120

Bi3U-M12-AP6X

1634100

Bi3U-M12E-AP6X

We reserve the right to make technical alterations without prior notice.

1634108

Bi3U-EM12-AN6X

1634320

Bi3U-EM12-AP6X

1634300

Bi3-M12-AD4X

4405035

Bi2U-M12E-AD4X

4405062

Bi2-M12-AD4X

44050

Bi2-M12-AP6X

46050

Bi2-M12-VN6X

16402

Bi2-M12-VP6X

16302

Features

Uprox3 6 3-wire DC NPN  10-30 VDC 2000 ≤200 -25 to +70 IP68 CPB LCP N/A YE 2M/PVC A 2 A4

Uprox3 6 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP68 CPB LCP N/A YE 2M/PVC A 3 A4

Uprox3, Comp. Outputs 6 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP68 CPB LCP N/A YE 2M/PVC A 5 A4

Uprox+ 4 3-wire DC NPN  10-30 VDC 2000 ≤200 -30 to +85 IP68 CPB LCP N/A YE 2M/PVC A 2 A4

Uprox+ 4 3-wire DC PNP  10-30 VDC 2000 ≤200 -30 to +85 IP68 CPB LCP N/A YE 2M/PVC A 3 A4

Extended Range 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 2 A4

Extended Range 4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 3 A4

Ext. Range, Comp.

Outputs

Ext. Range, Comp.

Outputs

Ext. Range, Comp.

Outputs

Ext. Range, Comp.

Outputs

Uprox 3 3-wire DC NPN 10-30 VDC 3000 ≤200 -30 to +85 IP67 CPB PBT N/A YE 2M/PVC A 2 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP67 CPB PBT N/A YE 2M/PVC A 3 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP67 CPB PBT N/A YE 2M/PVC B 3 A4

Uprox 3 3-wire DC NPN 10-30 VDC 3000 ≤200 -30 to +85 IP68 SS PBT N/A YE 2M/PVC A 2 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP68 SS PBT N/A YE 2M/PVC A 3 A4

Extended Range 3 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 1 A2

Uprox 2 2-wire DC 10-65 VDC 1000 ≤100 -30 to +85 IP68 CPB LCP N/A YE 2M/PVC B 1 A2

Comp. Outputs 2 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 4 A4

. Outputs 2 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 5 A4

Comp

Sensing Range (mm)

4 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 4 A4

4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 5 A4

4 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 4 A4

4 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 5 A4

2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 1 A2

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 3 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B66

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded MetalBarrels with Cable and DC Outputs

Housing Style Dimension Drawings

12 mm - Nonembeddable, Potted-in Cable

12 mm - Nonembeddable, Potted-In Cable, Extended Barrel Length

Wiring Diagrams/Mating Cordsets

1 2 3

4 5

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Repeatability:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Repeatability:

Shock:

Vibration:

Shock:

Vibration:

We reserve the right to make technical alterations without prior notice.

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B67

Turck Inc.

Inductive Barrel Sensors | 12 mm

Nonembeddable Threaded MetalBarrels with Cable and DC Outputs

Part Number/ ID Number

Ni10U-M12-AN6X

1634825

Ni10U-M12-AP6X

1634805

Ni8U-M12-AN6X

1644120

Ni8U-M12-AP6X

1644100

Ni8U-M12E-AP6X

1644102

Ni8U-EM12-AP6X

1644300

Ni8-M12-AD4X

4411235

Ni8-M12-AN6X

4611318

Ni8-M12E-AN6X

4611326

Ni8-M12-AP6X

4611319

Ni8-M12-VN6X

4611321

Ni8-M12-VP6X

4611322

Ni4-M12-AD4X

44052

Ni4-M12E-AD4X

We reserve the right to make technical alterations without prior notice.

4405298

Ni4-M12-AP6X

46052

Features

Uprox 10 3-wire DC NPN 10-30 VDC 1000 ≤200 -30 to +85 IP68 CPB LC P N/A YE 2M/PVC A 2 A4

Uprox 10 3-wire DC PNP 10-30 VDC 1000 ≤200 -30 to +85 IP68 CPB LCP N/A YE 2M/PVC A 3 A4

Uprox 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LCP N/A YE 2M/PVC A 2 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LCP N/A YE 2M/PVC A 3 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP67 CPB LCP N/A YE 2M/PVC B 3 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS LC P N/A YE 2M/PVC A 3 A4

Extended Range 8 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 1 A2

Extended Range 8 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 2 A4

Extended Range 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 3 A4

Ext. Range, Comp.

Outputs

Ext. Range, Comp.

Outputs

Sensing Range (mm)

8 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 2 A4

8 4-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 4 A4

8 4-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 5 A4

4 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 1 A2

4 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 1 A2

4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 3 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B68

Inductive Barrel Sensors | 12 mm

Fully Threaded Metal Barrels with Cable and DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable, Potted-In Cable

12 mm - Nonembeddable, Potted-In Cable

Wiring Diagrams/Mating Cordsets

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Repeatability:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Repeatability:

12 mm - Embeddable, Potted-In Cable

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2

Shock:

Vibration:

Shock:

Vibration:

30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B69

Turck Inc.

Inductive Barrel Sensors | 12 mm

Fully Threaded Metal Barrels with Cable and DC Outputs

Part Number/ ID Number

Bi4-G12-AN6X

1690706

Bi4-G12K-AN6X

4670251

Bi4-G12K-AP6X

4670250

Bi2-G12-AN6X

4635500

Bi2-G12-AN7X

4730500

Bi2-EG12-AP6X

4605001

Bi2-G12-AP6X

4635400

Bi2-G12K-AN6X

46712

Bi2-G12K-AP6X

46702

Ni8-G12-AN6X

4611327

Ni8-G12K-AD4X

4411230

Ni5-G12K-AN6X

46713

Ni5-G12K-AP6X

46703

Ni5-G12-AN6X

We reserve the right to make technical alterations without prior notice.

4635700

Ni5-G12-AN7X

1714500

Ni5-G12-AP6X

46356

Features

Extended Range 4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 1 A4

Ext. Range, Short

Barrel

Ext. Range, Short

Barrel

TTL Compatible 2 3-wire DC NPN 10-30 VDC 2000 ≤150 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 1 A4

Short Barrel 2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 1 A4

Short Barrel 2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 2 A4

Extended Range 8 3-wire DC NPN 10-30 VDC 1500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC D 1 A4

Short Barrel 8 2-wire DC  10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC C 3 A2

Short Barrel 5 3-wire DC NPN 10-30 VDC 1500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC C 2 A4

Short Barrel 5 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC C 2 A4

TTL Compatible 5 3-wire DC NPN 10-30 VDC 1500 ≤150 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC D 1 A4

Sensing Range (mm)

4 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 1 A4

4 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC A 2 A4

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 1 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 SS PA 12 N/A YE 2M/PVC B 2 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC B 2 A4

5 3-wire DC NPN 10-30 VDC 1500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC D 1 A4

5 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE 2M/PVC D 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B70

Inductive Barrel Sensors | 12 mm

Fully Threaded Metal Barrels with Cable and AC/DC Outputs

Housing Style Dimension Drawings

12 mm - Nonembeddable, Potted-In Cable

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Continuous Load Current:

Off-State (Leakage) Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

12 mm - Embeddable, Potted-In Cable

12 mm - Nonembeddable, Potted-In Cable, PTFE Coated

Wiring Diagrams/Mating Cordsets

2-wire AC/DC w/ Short-Circuit Protection - (ADZ, RDZ, FDZ, VDZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≥440 mA; DC: ≥330 mA AC: ≥120 mA; DC: ≥120 mA AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA (AC) ≤1.5 mA (DC)

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

12 mm - Embeddable, Potted-In Cable, PTFE Coated

Minimum Load Current:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

We reserve the right to make technical alterations without prior notice.

≥3.0 mA ≤3 A (≤20 ms, max 5 Hz) Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

B71

Turck Inc.

Inductive Barrel Sensors | 12 mm

Fully Threaded Metal Barrels with Cable and AC/DC Outputs

Part Number/ ID Number

Bi4-G12-ADZ32X

4205030

Bi2-G12-ADZ32X

4205000

Bi2-G12-AZ33X

1304002

Bi2-GT12-ADZ32X/S34

4205210

Bi2-GT12-AZ33X/S34

1304052

Ni8-G12-ADZ32X

4205400

Ni4-G12-AZ33X

1304202

Ni4-G12-ADZ32X

4205200

Ni4-GT12-ADZ32X/S34

4205210

Ni4-GT12-AZ33X/S34

1304294

Features

Extended

Range

PTFE, WFI 2

PTFE, WFI 2 2-wire AC/DC 35-250 VAC 20 ≤200

Extended

Range

PTFE, WFI 4

PTFE, WFI 4 2-wire AC/DC 35-250 VAC 20 ≤100

Sensing Range (mm)

Short-Circuit Protected

2 2-wire AC/DC  35-250 VAC 20 ≤200

Short-Circuit Protected

4 2-wire AC/DC 35-250 VAC 20 ≤100

Short-Circuit Protected

Output

2-wire AC/DC

Voltage

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

Switching Freq. (Hz)

20 ≤100

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

-25 to IP67 CPB PA 12 N/A YE 2M/PVC A 1 A5

+70

-25 to IP67 CPB PA 12 N/A YE 2M/PVC A 1 A5

+70

-25 to IP67 CPB PA 12 N/A YE 2M/PVC A 1 A6

+70

-25 to IP67 TC TC N/A YE 2M/PVC B 1 A5

+70

-25 to IP67 TC TC N/A YE 2M/PVC B 1 A6

+70

-25 to IP67 CPB PA 12 N/A YE 2M/PVC C 1 A5

+70

-25 to IP67 CPB PA 12 N/A YE 2M/PVC C 1 A6

+70

-25 to IP67 CPB PA 12 N/A YE 2M/PVC C 1 A5

+70

-25 to IP67 TC TC N/A YE 2M/PVC D 1 A5

+70

-25 to IP67 TC TC N/A YE 2M/PVC D 1 A6

+70

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B72

Inductive Barrel Sensors | 12 mm

Threaded Plastic Barrels with Cable and AC/DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable/Nonembeddable, Plastic,

Potted-In Cable

Wiring Diagrams/Mating Cordsets

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

Power-On Effect:

Transient Protection:

12 mm - Embeddable/Nonembeddable, Plastic,

Shock:

Vibration:

Repeatability:

Inrush Current:

Shock:

Vibration:

Repeatability:

Potted-In Cable

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B73

Turck Inc.

Inductive Barrel Sensors | 12 mm

Threaded Plastic Barrels with Cable and AC/DC Outputs

Part Number/ ID Number

Bi3U-S12-AN6X

1634520

Bi3U-S12-AP6X

1634500

Bi2-S12-AN6X

46531

Bi2-S12-AN7X

1713800

Bi2-S12-AP6X

46530

Bi2-S12-AP7X/S100

17555

Bi2-S12-AZ31X

13020

Bi2-S12-AZ31X/S100

1302001

Ni8U-S12-AN6X

1644520

Ni8U-S12-AP6X

1644500

Ni4-S12-AN6X

46533

Ni4-S12-AN7X

1713900

Ni4-S12-AP6X

46532

Ni4-S12-AZ31X

We reserve the right to make technical alterations without prior notice.

13022

Ni4-S12-AZ31X/S100

1302201

Features

Uprox 3

TTL Compatible 2

TTL Compatible,

High Temp. 100 °C

High Temp. 100 °C 2

Uprox 8

TTL Compatible 4

High Temp. 100 °C 4

Sensing Range (mm)

3-wire

DC NPN

3-wire

DC PNP

3-wire

DC NPN

3-wire

DC NPN

3-wire

DC PNP

3-wire

DC PNP

2-wire

AC/DC

2-wire AC/DC

3-wire

DC NPN

3-wire

DC PNP

3-wire

DC NPN

3-wire

DC NPN

3-wire

DC PNP

2-wire

AC/DC

2-wire AC/DC

Output

Voltage

10-30 VDC 3000 ≤200 -30 to +85 IP68 PBT PBT N/A YE 2M/PVC A 1 A4

10-30 VDC 3000 ≤200 -30 to +85 IP68 PBT PBT N/A YE 2M/PVC A 2 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE 2M/PVC B 1 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE 2M/PVC B 2 A4

10-30 VDC 2000 ≤200 -25 to +100 IP67 PA 12 PA 12 N/A YE 2M/PVC B 2 A4

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

10-30 VDC 2000 ≤200 -30 to +85 IP68 PBT PBT N/A YE 2M/PVC A 1 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 PBT PBT N/A YE 2M/PVC A 2 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE 2M/PVC B 1 A4

10-30 VDC 1500 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE 2M/PVC B 1 A4

10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE 2M/PVC B 2 A4

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

Switching Freq. (Hz)

Operating Current (mA)

20 ≤100 -25 to +70 IP67 PA 12 PA 12 N/A RD 2M/PVC B 3 A6

20 ≤100 -25 to +100 IP67 PA 12 PA 12 N/A RD 2M/PVC B 3 A6

20 ≤100 -25 to +70 IP67 PA 12 PA 12 N/A RD 2M/PVC B 3 A6

20 ≤100 -25 to +100 IP67 PA 12 PA 12 N/A RD 2M/PVC B 3 A6

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Cable Length/Jacket

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B74

Inductive Barrel Sensors | 12 mm

Threaded Barrels with Terminal Chamber and DC Outputs

Housing Style Dimension Drawings

12 mm - Embeddable, Terminal Chamber

We reserve the right to make technical alterations without prior notice.

12 mm - Nonembeddable, Terminal Chamber

Wiring Diagrams/Mating Cordsets

12 mm - Embeddable/Nonembeddable, Plastic, Terminal Chamber

1 2 3

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

2-wire DC - (AD, RD, AG)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Repeatability:

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Repeatability:

Shock:

Vibration:

Shock:

Vibration:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B75

Turck Inc.

Inductive Barrel Sensors | 12 mm

Threaded Barrels with Terminal Chamber and DC Outputs

Part Number/ ID Number

Bi3U-EG12SK-AP6X

1634400

Bi3U-P12SK-AP6X

1634700

Bi2-G12SK-AN6X2

4636500

Bi2-G12SK-AP6X2

4636400

Bi2-P12SK-AD4X

4453050

Bi2-P12SK-AN6X2

4654000

Bi2-P12SK-AP6X2

4653900

Ni8U-EG12SK-AP6X

1644400

Ni5-G12SK-AP6X2

46366

Ni5-P12SK-AP6X2

4654100

Features

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP68 SS PBT N/A YE A 2 A4

Uprox 3 3-wire DC PNP 10-30 VDC 3000 ≤200 -30 to +85 IP68 PA 12 PA 12 N/A YE C 2 A4

Uprox 8 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT N/A YE B 2 A4

Sensing Range (mm)

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 GN YE A 1 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 CPB PA 12 GN YE A 2 A4

2 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 PA 12 PA 12 N/A YE C 3 A2

2 3-wire DC NPN 10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 GN YE C 1 A4

2 3-wire DC PNP 10-30 VDC 2000 ≤200 -25 to +70 IP67 PA 12 PA 12 GN YE C 2 A4

5 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP67 CPB PA 12 GN YE B 2 A4

5 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP67 PA 12 PA 12 GN YE C 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B76

Inductive Barrel Sensors | 18 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

18 mm - Embeddable M12 Eurofast Connection

Mating Cordset: RK 4.2T-*

Mating Cordset: RK 4.4T-*; RKV 4.4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4T-*; RKV 4T-*

Mating Cordset: RK 4.4T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Mating Cordset: RK 4T-*; RKV 4T-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B77

Turck Inc.

Inductive Barrel Sensors | 18 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi10U-M18-AN6X-H1141

1644847

Bi10U-M18-AP6X-H1141

1644830

Bi10U-M18-VP6X-H1141

1644844

Bi8U-M18-AN6X-H1141

1644737

Bi8U-EM18-AN6X-H1141

1644738

Bi8U-M18-AP6X-H1141

1644731

Bi8U-EM18-AP6X-H1141

1644734

Bi8-M18-AN6X-H1141

4615100

Bi8-M18-AP6X-H1141

46150

Bi8-EM18H-AP6X-H1141

4615094

Bi8-EM18-AP6X-H1141/S1589

4615099

Bi8-M18-VN4X-H1141

4590702

Bi8-M18-VP4X-H1141

4590701

Bi7-M18-AD4X-H1141

We reserve the right to make technical alterations without prior notice.

4414541

Bi5U-M18-AN6X-H1141

1635150

Bi5U-EM18-AN6X-H1141

1635350

Bi5U-M18-AP6X-H1141

1635140

Bi5U-EM18-AP6X-H1141

1635340

Bi5-M18-AD4X-H1141

44145

Bi5-M18-AN6X-H1141

46146

Bi5-M18-AP6X-H1141

46145

Bi5-EM18-AP6X-H1141

4614501

Bi5-M18-VN4X

15718

Bi5-EM18-VN4X-H1141

4614699

Bi5-M18-VP4X-H1141

15618

-H1141

Features

Uprox3 10 3-wire DC NPN 10-30 VDC 1500 ≤200 -25 to +70 IP68 CPB LCP N/A YE A 2 A4

Uprox3 10 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP68 CPB LCP N/A YE A 3 A4

Uprox3, Comp.

Outputs

Uprox+ 8 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 2 A4

Uprox+ 8 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 SS LCP N/A YE A 2 A4

Uprox+ 8 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 3 A4

Uprox+ 8 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 SS LCP N/A YE A 3 A4

Extended Range 8 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 SS

Extended Range 8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 SS

Ext. Range,

Stoneface

Weldguard 8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 SS WG N/A YE A 3 A4

Ext. Range,

Comp. Outputs

Ext. Range,

Comp. Outputs

Extended Range 7 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB

Uprox 5 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB PBT N/A YE A 2 A4

Uprox 5 3-wire DC NPN 10-30 VDC 2500 ≤200 -30 to +85 IP68 SS PBT N/A YE A 2 A4

Uprox 5 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB PBT N/A YE A 3 A4

Uprox 5 3-wire DC PNP 10-30 VDC 2500 ≤200 -30 to +85 IP68 SS PBT N/A YE A 3 A4

Comp. Outputs 5 4-wire DC NPN 10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB

Comp. Outputs 5 4-wire DC NPN 10-65 VDC 1000 ≤200 -25 to +70 IP67 SS

Comp. Outputs 5 4-wire DC PNP 10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB

Sensing Range (mm)

10 4-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP68 CPB LCP N/A YE A 5 A4

8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 SS SF N/A YE A 3 A4

8 4-wire DC NPN 10-65 VDC 500 ≤200 -25 to +70 IP67 SS

8 4-wire DC PNP 10-65 VDC 500 ≤200 -25 to +70 IP67 SS

5 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB

5 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB

5 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB

5 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 SS

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PA 12

Face

Power LED

Output LED

Dimension Drawings

N/A YE A 2 A4

N/A YE A 3 A4

N/A YE A 4 A4

N/A YE A 5 A4

N/A YE A 1 A2

N/A YE A 2 A4

N/A YE A 3 A4

N/A YE A 3

N/A YE A 4 A4

N/A YE A 5 A4

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B78

Inductive Barrel Sensors | 18 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

18 mm - Embeddable, M12 Eurofast Connection

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4T-*; RKC 4T-*/S15872Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

2-wire DC - (AD, RD, AG)

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

Mating Cordset: RK 4.23T-*

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Vibration:

Repeatability:

Shock:

Mating Cordset: RK 4.4T-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B79

Turck Inc.

Inductive Barrel Sensors | 18 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi8U-EM18M-AP6X2-H1141/S1589

1644771

Bi8U-M18M-VP44X-H1141

1634877

Bi8-M18M-AP6X-H1141

4615083

Bi5U-M18M-AD4X-H1144

4405066

Bi5U-M18-AN6X-H1141/S395

1635154

Bi5U-M18-AP6X-H1141/S395

1635141

Bi5U-EM18-AP6X-H1141/S395

1635342

Bi5U-EM18H-AN6X2-H1141/S395

1635146

Bi5U-EM18H-AN6X2-H1141/S395/S1589

1635196

Bi5U-EM18H-AP6X2-H1141/S395

1635158

Bi5U-EM18-AP6X2-H1141/S395/S1589

1635197

Bi5U-EM18M-AP6X2-H1141

1635349

Features

Uprox+,

Weldguard

Uprox+, Comp.

Outputs

Extended Range 8

Uprox+ 5 2-wire DC 10-65 VDC 10 ≤100 -30 to +85 IP68 TC LCP N/A YE A 3 A2

Uprox 5

Uprox, Stoneface 5

Uprox, Weldguard 5

Uprox, Stoneface 5

Uprox, Weldguard 5

Uprox 5

Sensing Range (mm)

3-wire DC

4-wire DC

3-wire DC

PNP

PNP 

PNP

NPN

PNP

NPN

PNP

Output

Voltage

10-30 VDC 1000 ≤200 -30 to +85 IP68 SS WG GN YE A 2 A4

10-55 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 4 A4

10-30 VDC 500 ≤200 -25 to +75 IP67 CPB PBT N/A YE A 2 A4

10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB

10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB PBT N/A YE A 2 A4

10-30 VDC 2500 ≤200 -30 to +85 IP68 SS

10-30 VDC 2500 ≤200 -30 to +85 IP68 SS SF GN YE A 1 A4

10-30 VDC 2500 ≤200 -30 to +85 IP68 SS WG GN YE A 1 A4

10-30 VDC 2500 ≤200 -30 to +85 IP68 SS SF GN YE A 2 A4

10-30 VDC 2500 ≤200 -30 to +85 IP68 SS WG GN YE A 2 A4

10-30 VDC 2500 ≤200 -30 to +85 IP68 SS PBT GN YE A 2 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PA 12

Face

Power LED

N/A YE A 1 A4

N/A YE A 2 A4

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B80

Inductive Barrel Sensors | 18 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

18 mm - Embeddable, Ext. Barrel Length, M12 Eurofast Connection

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4.2T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4T-*; RKV 4T-*; RKC 4T-*/S1587

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B81

Turck Inc.

Inductive Barrel Sensors | 18 mm

Embeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi8U-EM18E-AP6X-H1141

1634865

Bi8-M18E-AN6X-H1141

4615190

Bi8-EM18HE-AN6X-H1141

4615194

Bi8-EM18E-AN6X-H1141/S1589

4615193

Bi8-EM18E-AP6X-H1141

46150952

Bi8-EM18HE-AP6X-H1141

4615095

Bi8-EM18E-AP6X-H1141/S1589

4615096

Bi7-M18E-AD4X-H1141

4414580

Bi5U-M18E-AN6X-H1141

1635122

Bi5U-M18E-AP6X-H1141

1635103

Bi5-M18E-AD4X-H1141

4414591

Bi5-M18E-AN6X-H1141

4614697

Features

Uprox+ 8 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 SS LCP N/A YE A 3 A4

Extended Range 8 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 SS

Ext. Range, Stoneface 8 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 SS SF N/A YE A 2 A4

Ext. Range, Weldguard 8 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 SS WG N/A YE A 2 A4

Extended Range 8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 SS

Ext. Range, Stoneface 8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 SS SF N/A YE A 3 A4

Ext. Range, Weldguard 8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 SS WG N/A YE A 3 A4

Extended Range 7 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB

Uprox 5 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB PBT N/A YE A 2 A4

Uprox 5 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB PBT N/A YE A 3 A4

Sensing Range (mm)

5 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 CPB

5 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PA 12

Face

Power LED

Output LED

N/A YE A 2 A4

N/A YE A 3 A4

N/A YE A 1 A2

N/A YE A 2 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B82

Inductive Barrel Sensors | 18 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

18 mm - Embeddable, M12 Eurofast Connection, PTFE Coated

Wiring Diagrams/Mating Cordsets

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4.2T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Mating Cordset: RK 4T-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B83

Turck Inc.

Inductive Barrel Sensors | 18 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

BI10U-MT18-AN6X-H1141

1644858

Bi10U-MT18-AP6X-H1141

1644831

Bi10U-MT18-AP6X2-H1141

1644905

Bi8U-MT18-AN6X-H1141

1644739

Bi8U-MT18-AP6X-H1141

1644730

Bi8U-MT18-AN6X-H1141/S1589

1644791

Bi7-MT18H-AD4X-H1141

44145801

Bi5U-MT18-AN6X-H1141

1635250

Bi5U-MT18-AP6X-H1141

1635240

Bi5U-MT18-AP6X2-H1141

1635245

Features

Uprox3, PTFE 10 3-wire DC NPN 10-30 VDC 1500 ≤200 -25 to +70 IP68 TC TC N/A YE A 2 A4

Uprox3, PTFE 10 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP68 TC TC N/A YE A 3 A4

Uprox3, PTFE 10 3-wire DC PNP 10-30 VDC 1500 ≤200 -25 to +70 IP68 TC TC GN YE A 3 A4

Uprox+, PTFE 8 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC TC N/A YE A 2 A4

Uprox+, PTFE 8 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC TC N/A YE A 3 A4

Uprox+, PTFE,

Weldguard

Ext. Range, PTFE 7 2-wire DC  10-65 VDC 1000 ≤100 -25 to +70 IP67 TC SF N/A YE A 1 A2

Uprox, PTFE 5 3-wire DC NPN 10-30 VDC 2500 ≤200 -30 to +85 IP67 TC TC N/A YE A 2 A4

Uprox, PTFE 5 3-wire DC PNP 10-30 VDC 2500 ≤200 -30 to +85 IP67 TC TC N/A YE A 3 A4

Uprox, PTFE 5 3-wire DC PNP 10-30 VDC 2500 ≤200 -30 to +85 IP67 TC TC GN YE A 3 A4

Sensing Range (mm)

8 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC WG N/A YE A 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B84

Inductive Barrel Sensors | 18 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

18 mm - Embeddable, M12 Eurofast Connection, PTFE Coated

18 mm - Embeddable, Ext. Barrel Length, M12 Eurofast Connection, PTFE Coated

Wiring Diagrams/Mating Cordsets

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4.2T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4.23T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4T-*; RKC 4T-*/S15874Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B85

Turck Inc.

Inductive Barrel Sensors | 18 mm

Embeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Bi8U-MT18M-AP6X2-H1141

1644740

Bi8U-MT18M-AP6X2-H1141/S1589

16447411

Bi7-MT18HE-AD4X-H1141

4414597

Bi7-MT18HE-AD4X-H1144

4414598

Bi7-MT18HE-AD4X-H1141/S1589

4414588

Bi7-MT18HE-AD4X-H1144/S1589

4414599

Bi5U-MT18E-AP6X2-H1141

1635247

Bi5U-MT18M-AP6X2-H1141

1635252

Bi5U-MT18H-AN6X2-H1141/S395

1635225

Bi5U-MT18-AN6X2-H1141/S395/S1589

1635290

Bi5U-MT18-AP6X-H1141/S395

1635231

Bi5U-MT18H-AP6X2-H1141/S395

1635220

Bi5U-MT18-AP6X2-H1141/S395/S1589

1635291

Features

Uprox+, PTFE 8 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC LCP GN YE A 4 A4

Uprox+, PTFE,

Weldguard

PTFE, Stoneface 7 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC SF N/A YE B 1 A2

PTFE, Stoneface 7 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC SF N/A YE B 2 A2

PTFE, Weldguard 7 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE B 1 A2

PTFE, Weldguard 7 2-wire DC 10-65 VDC 1000 ≤100 -25 to +70 IP67 TC WG N/A YE B 2 A2

Uprox, PTFE 5 3-wire DC PNP 10-30 VDC 2500 ≤200 -30 to +85 IP68 TC TC GN YE B 4 A4

Uprox, PTFE 5 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC GN YE A 4 A4

Uprox, PTFE,

Stoneface

Uprox, PTFE,

Weldguard

Uprox, PTFE 5 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC N/A YE A 4 A4

Uprox, PTFE,

Stoneface

Uprox, PTFE,

Weldguard

Sensing Range (mm)

8 3-wire DC PNP 10-30 VDC 1000 ≤200 -30 to +85 IP68 TC WG GN YE A 4 A4

5 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC SF GN YE A 3 A4

5 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC WG GN YE A 3 A4

5 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC SF GN YE A 4 A4

5 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC WG GN YE A 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B86

Inductive Barrel Sensors | 18 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

Wiring Diagrams/Mating Cordsets

18 mm - Nonembeddable, M12 Eurofast Connection

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4.2T-*

Mating Cordset: RK 4T-*; RKV 4T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Mating Cordset: RK 4.23T-*

Mating Cordset: RK 4.4T-*

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

Mating Cordset: RK 4T-*; RKV 4T-*

Mating Cordset: RK 4.4T-*

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B87

Turck Inc.

Inductive Barrel Sensors | 18 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Ni15U-M18-AN6X-H1141

1635335

Ni15U-EM18-AN6X-H1141

1635336

Ni15U-M18-AP6X-H1141

1635331

Ni15U-EM18-AP6X-H1141

1635332

Ni14-M18-AD4X-H1141

4417241

Ni14-M18-AD4X-H1144

4417290

Ni14-M18-AN6X-H1141

4611410

Ni14-M18-AP6X-H1141

4611400

Ni14-M18-VN4X-H1141

4590603

Ni14-M18-VP4X-H1141

4590602

Ni12U-M18-AN6X-H1141

1645150

Ni12U-EM18-AN6X-H1141

1645350

Ni12U-M18-AP6X-H1141

1645140

Ni12U-M18-AP6X2-H1141

We reserve the right to make technical alterations without prior notice.

1645145

Ni12U-EM18-AP6X-H1141

1645340

Ni12U-EM18-AP6X2-H1141

1645345

Ni10-M18-AN6X-H1141

4614892

Ni10-M18-AP6X-H1141

4641291

Ni8-M18-AD4X-H1141

44147

Ni8-M18-AD4X-H1144

4411288

Ni8-M18-AN6X-H1141

46148

Ni8-M18-AP6X-H1141

46147

Ni8-M18-VN4X-H1141

15719

Ni8-M18-

VP4X-H1141

15619

Features

Uprox+ 15 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 3 A4

Uprox+ 15 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 SS LCP N/A YE A 3 A4

Uprox+ 15 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 4 A4

Uprox+ 15 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 SS LCP N/A YE A 4 A4

Extended Range 14 2-wire DC 10-65 VDC 500 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A2

Extended Range 14 2-wire DC 10-65 VDC 500 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A2

Extended Range 14 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

Extended Range 14 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

Ext. Range, Comp.

Outputs

Ext. Range, Comp.

Outputs

Uprox 12 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB LCP N/A YE A 3 A4

Uprox 12 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT N/A YE A 3 A4

Uprox 12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB LCP N/A YE A 4 A4

Uprox 12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB LCP GN YE A 4 A4

Uprox 12 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT N/A YE A 4 A4

Uprox 12 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT GN YE A 4 A4

Comp. Outputs 8 4-wire DC NPN 10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12

Comp. Outputs 8 4-wire DC PNP 10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 6 A4

Sensing Range (mm)

14 4-wire DC NPN 10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 5 A4

14 4-wire DC PNP 10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 6 A4

10 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

10 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

8 2-wire DC 10-65 VDC 500 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A2

8 2-wire DC 10-65 VDC 500 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A2

8 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 3 A4

8 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 4 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

N/A YE A 5 A4

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B88

Inductive Barrel Sensors | 18 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

18 mm - Nonembeddable, Ext. Barrel Length M12 Eurofast Connection

Wiring Diagrams/Mating Cordsets

18 mm - Nonembeddable, M12 Eurofast Connection

We reserve the right to make technical alterations without prior notice.

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Mating Cordset: RK 4.2T-*

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Minimum Load Current:

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

2-wire DC - (AD, RD, AG)

≤10% 3-15% (5% typical) Non-polarized (AD) <5.0 V Polarized (AG) ≤4.2 V ≥120 mA ≥3.0 mA

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Mating Cordset: RK 4.4T-*

Off-State (Leakage) Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤0.8 mA Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B89

Turck Inc.

Inductive Barrel Sensors | 18 mm

Nonembeddable Threaded MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Ni14-M18E-AD4X-H1141

4417292

Ni14-M18E-AN6X-H1141

4611483

Ni14-EM18E-AN6X-H1141/S1589

4611494

Ni14-M18E-AP6X-H1141

4611489

Ni14-EM18E-AP6X-H1141/S1589

4611495

Ni12U-M18-AN6X-H1141/S395

1645151

Ni12U-EM18-AP6X2-H1141/S395

1645304

Ni12U-EM18-AN6X2-H1141/S395/S1589

1645490

Ni12U-EM18-AP6X2-H1141/S395/S1589

1645491

Ni12U-M18E-AP6X-H1141

1645143

Ni12U-M18-AP6X-H1141/S395

1645142

Ni12U-M18M-VP4X-H1141

1581458

Ni10-M18E-AN6X-H1141

4614894

Ni10-M18E-AP6X-H1141

We reserve the right to make technical alterations without prior notice.

4641294

Ni8-M18E-AD4X-H1141

4411210

Ni8-M18E-VP4X-H1141

1561990

Features

Extended

Range

Extended

Range

Ext. Range, Weldguard

Extended

Range

Ext. Range, Weldguard

Uprox 12

Uprox,

Weldguard

Uprox,

Weldguard

Uprox 12

Uprox, Comp.

Outputs

Comp.

Outputs

Sensing Range (mm)

Output

14 2-wire DC 10-65 VDC 500 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE B 3 A2

3-wire DC

NPN

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

3-wire DC

PNP

3-wire DC

PNP

4-wire DC

PNP

3-wire DC

NPN

3-wire DC

PNP

8 2-wire DC 10-65 VDC 500 ≤100 -25 to +70 IP67 CPB PA 12 N/A YE B 3 A2

4-wire DC

PNP

Voltage

10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 1 A4

10-30 VDC 1000 ≤200 -25 to +70 IP67 SS WG N/A YE B 1 A4

10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 2 A4

10-30 VDC 1000 ≤200 -25 to +70 IP67 SS WG N/A YE B 2 A4

10-30 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 1 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 SS PBT GN YE A 2 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 SS WG GN YE A 1 A4

10-30 VDC 2000 ≤200 -30 to +85 IP68 SS WG GN YE A 2 A4

10-30 VDC 1500 ≤200 -30 to +85 IP67 CPB LCP N/A YE B 2 A4

10-30 VDC 1500 ≤200 -30 to +85 IP68 CPB LCP N/A YE A 2 A4

10-65 VDC 1500 ≤200 -30 to +85 IP68 CPB PBT N/A YE A 4 A4

10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 1 A4

10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 2 A4

10-65 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 4 A4

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B90

Inductive Barrel Sensors | 18 mm

Nonembeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Housing Style Dimension Drawings

18 mm - Nonembeddable, M12 Eurofast Connection, PTFE Coated

We reserve the right to make technical alterations without prior notice.

18 mm - Nonembeddable, M12 Eurofast Connection, PTFE Coated

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

Wiring Diagrams/Mating Cordsets

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

18 mm - Nonembeddable, Ext. Barrel Length M12 Eurofast Connection, PTFE Coated

Mating Cordset: RK 4T-*; RKC 4T-*/S1587

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

B91

Turck Inc.

Inductive Barrel Sensors | 18 mm

Nonembeddable Threaded PTFE Coated MetalBarrels with Connector and DC Outputs

Part Number/ ID Number

Ni15U-MT18-AN6X-H1141

1635337

Ni15U-MT18-AN6X-H1141/S1589

16353370

Ni15U-MT18-AP6X-H1141

1635333

Ni15U-MT18-AP6X-H1141/S1589

1635333-1

Ni15U-MT18M-AP6X2-H1141

1635338

Ni15U-MT18M-AP6X2-H1141/S1589

16352920

Ni14-MT18E-AP6X-H1141/S1589

4611497

Ni12U-MT18-AN6X-H1141

1645250

Ni12U-MT18-AP6X-H1141

1645240

Ni12U-MT18-AP6X-H1141/S1589

1645292

Ni12U-MT18-AP6X2-H1141

1645245

Ni12U-MT18-AP6X2-H1141/S1589

1645293

Ni12U-MT18-AP6X-H1141/S395

1645242

Ni12U-MT18-AP6X2-H1141/S395

We reserve the right to make technical alterations without prior notice.

1645246

Ni12U-MT18-AP6X2-H1141/S395/ S1589

1645291

Features

Uprox+, PTFE 15 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC TC N/A YE A 1 A4

Uprox+, PTFE,

Weldguard

Uprox+, PTFE 15 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC TC N/A YE A 2 A4

Uprox+, PTFE,

Weldguard

Uprox+, PTFE 15 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC TC GN YE B 2 A4

Uprox+, PTFE,

Weldguard

Ext. Range, PTFE,

Weldguard

Uprox, PTFE 12 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC N/A YE A 1 A4

Uprox, PTFE 12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC N/A YE A 2 A4

Uprox,

Weldguard

Uprox, PTFE 12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC GN YE A 2 A4

Uprox,

Weldguard

Uprox, PTFE 12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC N/A YE B 2 A4

Uprox, PTFE 12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC TC GN YE B 2 A4

Uprox, PTFE,

Weldguard

Sensing Range (mm)

15 3-wire DC NPN 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC WG N/A YE A 1 A4

15 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC WG N/A YE A 2 A4

15 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP68 TC WG GN YE B 2 A4

14 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 TC WG N/A YE C 2 A4

12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC WG N/A YE A 2 A4

12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC WG GN YE A 2 A4

12 3-wire DC PNP 10-30 VDC 1500 ≤200 -30 to +85 IP67 TC WG GN YE B 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B92

Inductive Barrel Sensors | 18 mm

Fully Threaded Metal Barrels with Connector and AC/DC Outputs

Housing Style Dimension Drawings

18 mm - Embeddable, 7/8” Minifast Connection

18 mm - Embeddable, Right Angle, 7/8” Minifast Connection

18 mm - Nonembeddable, 7/8” Minifast Connection

We reserve the right to make technical alterations without prior notice.

18 mm - Nonembeddable, 7/8” Minifast Right Angle Connection

Wiring Diagrams/Mating Cordsets

Mating Cordset: RKM 40-*M

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

B93

Turck Inc.

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

Inductive Barrel Sensors | 18 mm

Fully Threaded Metal Barrels with Connector and AC/DC Outputs

Part Number/ ID Number

Bi5-G18-AN6X-B1341

46952

Bi5-G18-AP6X-B1341

46963

Bi5-G18-AN6X-B1441

46956

Bi5-G18-AP6X-B1441

46967

Ni10-G18-AN6X-B1341

46953

Ni10-G18-AP6X-B1341

46964

Ni10-G18-AN6X-B1441

46957

Ni10-G18-AP6X-B1441

46968

Ni10-G18-VN6X-B1441

46991

Ni10-G18-VP6X-B1441

4699190

Features

Comp. Outputs 10 4-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE D 3 A4

Comp. Outputs 10 4-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE D 4 A4

Sensing Range (mm)

5 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 1 A4

5 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE A 2 A4

5 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 1 A4

5 3-wire DC PNP  10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE B 2 A4

10 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE C 1 A4

10 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE C 2 A4

10 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE D 1 A4

10 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 CPB PA 12 N/A YE D 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B94

Inductive Barrel Sensors | 18 mm

Threaded Plastic Barrels with Connector and DC Outputs

Housing Style Dimension Drawings

18 mm - Embeddable and Nonembeddable, Partial Threading, M12 Eurofast Connection

18 mm - Embeddable and Nonembeddable, Partial Threading, M12 Eurofast ConnectionC18 mm - Embeddable and Nonembeddable, Partial Threading, M12 Eurofast Connection

18 mm - Embeddable and Nonembeddable, Full Threading, 7/8” Minifast Connection

Wiring Diagrams/Mating Cordsets

Mating Cordset: RKK 4T-*

Mating Cordset: RK 40-*M

Mating Cordset: RKK 4T-*

Mating Cordset: RKK 4.4T-*

Mating Cordset: RK 40-*M

We reserve the right to make technical alterations without prior notice.

Ripple:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Off-State (Leakage) Current:

No-Load Current:

B95

Turck Inc.

3 and 4-wire DC - (AN, RN, AP, RP, VN, VP)

≤10% 3-15% (5% typical) ≤1.8 V ≥220 mA on 200 mA Load Current ≥170 mA on 150 mA Load Current ≥120 mA on 100 mA Load Current ≤0.1 mA ≤15 mA (Ferrite, Uprox) ≤20 mA (Uprox+, Uprox3)

Time Delay Before Availability:

Power-On Effect:

Reverse Polarity Protection:

Wire-Break Protection:

Transient Protection:

Temperature Drift:

Shock:

Vibration:

Repeatability:

≤8 ms Per IEC 947-5-2 Incorporated Incorporated Per EN 60947-5-2 ≤±10% 30 g, 11 ms 55 Hz, 1 mm Amplitude in all 3 Planes ≤2% of Rated Operating Distance

Inductive Barrel Sensors | 18 mm

Threaded Plastic Barrels with Connector and DC Outputs

Part Number/ ID Number

Bi5U-S18-AN6X-H1141

1635620

Bi5U-S18-AP6X-H1141

1635600

Bi5-S18-AN6X-H1141

46525

Bi5-S18-AP6X-H1141

46524

Bi5-S18-VP4X-H1141

1513401

Bi5-P18-AN6X-B2341

46972

Bi5-P18-AP6X-B2341

46973

Ni12U-S18-AN6X-H1141

1645620

Ni12U-S18-AP6X-H1141

1645600

Ni10-P18-AN6X-B2341

4697800

Ni10-P18-AP6X-B2341

4697900

Ni8-S18-AN6X-H1141

46527

Ni8-S18-AP6X-H1141

46526

Features

Uprox 5 3-wire DC NPN 10-30 VDC 2500 ≤200 -30 to +85 IP68 PA 12 PA 12 N/A YE C 1 A4

Uprox 5 3-wire DC PNP 10-30 VDC 2500 ≤200 -30 to +85 IP68 PA 12 PA 12 N/A YE C 2 A4

Comp. Outputs 5 4-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE B 3 A4

Uprox 12 3-wire DC NPN 10-30 VDC 2000 ≤200 -30 to +85 IP68 PA 12 PA 12 N/A YE C 1 A4

Uprox 12 3-wire DC PNP 10-30 VDC 2000 ≤200 -30 to +85 IP68 PA 12 PA 12 N/A YE C 2 A4

Sensing Range (mm)

5 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE A 1 A4

5 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE A 2 A4

5 3-wire DC NPN 10-30 VDC 1000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE D 4 A4

5 3-wire DC PNP 10-30 VDC 1000 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE D 5 A4

10 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE D 4 A4

10 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE D 5 A4

8 3-wire DC NPN 10-30 VDC 500 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE A 1 A4

8 3-wire DC PNP 10-30 VDC 500 ≤200 -25 to +70 IP67 PA 12 PA 12 N/A YE A 2 A4

Output

Voltage

Switching Freq. (Hz)

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

Face

Power LED

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B96

Inductive Barrel Sensors | 18 mm

Embeddable Fully Threaded Metal Barrels with Connector and AC/DC Outputs

Housing Style Dimension Drawings

18 mm - Embeddable, 1/2” Microfast Connection

18 mm - Embeddable, 1/2” Microfast Connection, PTFE Coated

18 mm - Embeddable, 1/2” Microfast Right Angle Connection, PTFE Coated

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Continuous Load Current:

Off-State (Leakage) Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

2-wire AC/DC w/ Short-Circuit Protection - (ADZ, RDZ, FDZ, VDZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≥440 mA; DC: ≥330 mA AC: ≥120 mA; DC: ≥120 mA AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA (AC) ≤1.5 mA (DC)

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

Wiring Diagrams/Mating Cordsets

Mating Cordset: KB 3T-*; KBE 3T-*/S600

18 mm - Embeddable, 1/2” Microfast Connection

Minimum Load Current:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

≥3.0 mA ≤3 A (≤20 ms, max 5 Hz) Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

We reserve the right to make technical alterations without prior notice.

B97

Turck Inc.

Inductive Barrel Sensors | 18 mm

Embeddable Fully Threaded Metal Barrels with Connector and AC/DC Outputs

Part Number/ ID Number

Bi8-G18-ADZ30X2-B3331

4209301

Bi5U-G18-ADZ30X2-B3331

4281213

Bi5U-GT18-ADZ30X2-B3331

4281223

Bi5-G18-ADZ30X2-B3331

4208092

Bi5-GT18-ADZ30X2-B3331

4255491

Bi5-GT18-ADZ30X2-B3331/S34

4255400

Bi5-GT18H-ADZ30X2-B3331/S34

4255289

Bi5-GT18H-ADZ30X2-B3331/S34/S1589

4255283

Bi5-GT18-ADZ30X2-B3431/S34

4255605

Bi5-G18-AZ3X-B3331

We reserve the right to make technical alterations without prior notice.

4372098

Bi5-G18-AZ3X-B3431

4372090

Features

Extended

Range

Uprox 5

Uprox, PTFE 5

PTFE 5

PTFE, WFI 5

PTFE, WFI, Stoneface

PTFE,

Weldguard

PTFE, WFI 5

Sensing Range (mm)

5 2-wire AC/DC

5 2-wire AC/DC 

Output

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

2-wire AC/DC

Short-Circuit

Protected

Voltage

20-250 VAC/10300 VDC

Switching Freq. (Hz)

20 ≤400/300 -25 to +70 IP67 SS

10 ≤400/300 -30 to +85 IP67 CPB PBT GN YE A 1 A5

10 ≤400/300 -30 to +85 IP67 TC TC GN YE B 1 A5

20 ≤400/300 -25 to +70 IP67 CPB

20 ≤400/300 -25 to +70 IP67 TC TC GN RD B 1 A5

20 ≤400/300 -25 to +70 IP67 TC SF GN RD B 1 A5

20 ≤400/300 -25 to +70 IP67 TC WG GN RD B 1 A5

20 ≤400/300 -25 to +70 IP67 TC TC GN RD D 1 A5

20 ≤400/300 -25 to +70 IP67 CPB

Operating Current (mA)

Operating Temp. (°C)

Protection

Housing

PA 12

Face

Power LED

Output LED

GN RD A 1 A5

N/A RD A 1 A6

N/A RD C 1 A6

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

Turck Inc.

B98

Inductive Barrel Sensors | 18 mm

Nonembeddable Fully Threaded Metal Barrels with Connector and AC/DC Outputs

Housing Style Dimension Drawings

18 mm - Nonembeddable, 1/2” Microfast connection

We reserve the right to make technical alterations without prior notice.

18 mm - Nonembeddable, 1/2” Microfast connection, PTFE Coated

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Trigger Current for Short Circuit Protection:

Continuous Load Current:

Off-State (Leakage) Current:

Line Frequency:

Differential Travel (Hysteresis):

Voltage Drop Across Conducting Sensor:

Continuous Load Current:

Off-State (Leakage) Current:

Minimum Load Current:

18 mm - Nonembeddable, PTFE Coated, 1/2” Microfast Right Angle Connection

Wiring Diagrams/Mating Cordsets

Mating Cordset: KB 3T-*

2-wire AC/DC w/ Short-Circuit Protection - (ADZ, RDZ, FDZ, VDZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≥440 mA; DC: ≥330 mA AC: ≥120 mA; DC: ≥120 mA AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA (AC) ≤1.5 mA (DC)

2-wire AC/DC w/o Short-Circuit Protection - (AZ, RZ, FZ)

≥50... ≤60 Hz 3-15% (5% typical) ≤6.0 V AC: ≤400 mA; DC: ≤300 mA AC: ≤100 mA; DC: ≤100 mA ≤1.7 mA ≥3.0 mA

Minimum Load Current:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

Inrush Current:

Power-On Effect:

Transient Protection:

Shock:

Vibration:

Repeatability:

≥3.0 mA ≤3 A (≤20 ms, max 5 Hz) Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

≤8 A (≤10ms max. 5 Hz) ≤1 A (≤10 ms max. 5 Hz) 12 mm ≤0.2 A (≤10 ms max. 0.2 Hz) 8 mm Per IEC 947-5-2 Per EN 60947-5-2 30 g, 11 ms 55 Hz, 1 mm Amplitude, in all 3 Planes ≤2% of Rated Operating Distance

B99

Turck Inc.

Inductive Barrel Sensors | 18 mm

Nonembeddable Fully Threaded Metal Barrels with Connector and AC/DC Outputs

Part Number/ ID Number

Ni14-G18-ADZ30X2-B3331

4205403

Ni12U-G18-ADZ30X2-B3331

4281413

Ni12U-GT18-ADZ30X2-B3331

4281423

Ni10-G18-AZ3X-B3331

4372192

Ni8-G18-ADZ30X2-B3331/S34

4209100

Ni8-GT18-ADZ30X2-B3331/S34

4209101

Ni8-GT18-ADZ30X2-B3431/S34

4209201

Ni8-G18-AZ3X-B3331

4350588

Features

Extended

Range

Uprox 12

Uprox,

PTFE

WFI 8

PTFE, WFI 8

Sensing Range (mm)

2-wire AC/DC Short-

10 2-wire AC/DC

2-wire AC/DC Short-

8 2-wire AC/DC

Output

Circuit Protected

Voltage

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

20-250 VAC/10-

300 VDC

Switching Freq. (Hz)

Operating Current (mA)

20 ≤400/300

10 ≤400/300

20 ≤400/300

Operating Temp. (°C)

Protection

Housing

Face

Power LED

-25 to IP67 CPB

+70

-30 to IP67 CPB PBT GN YE A 1 A5

+85

-30 to IP67 TC TC GN YE B 1 A5

+85

-25 to IP67 CPB

+70

-25 to IP67 CPB

+70

-25 to IP67 TC TC GN RD B 1 A5

+70

-25 to IP67 TC TC GN RD C 1 A5

+70

-25 to IP67 CPB

+70

GN RD A 1 A5

N/A RD A 1 A6

GN RD A 1 A5

N/A RD A 1 A6

Output LED

Dimension Drawings

Wiring Diagrams

Spec List

Inductive Barrel Sensors

We reserve the right to make technical alterations without prior notice.

Turck Inc.

B100

Turck Inductive Barrel Sensor Catalog Page

Specifications and Main Features

Frequently Asked Questions

User Manual
