Turck BI5-EM18D-VP6X/S12010M Data Sheet
Inductive sensor
For harsh environments and temperatures up to 120°C
BI5-EM18D-VP6X/S120 10M
Type designation BI5-EM18D-VP6X/S120 10M
Ident-No. 4614901
Rated switching distance Sn 5 mm
Mounting conditions Flush
Secured operating distance
Correction factors St37 = 1; Al = 0.3; stainless steel = 0.7; Ms = 0.4
Repeat accuracy
Temperature drift
Hysteresis 3…15 %
Ambient temperature -25…+120 °C
Operating voltage 10…30 VDC
Residual ripple
DC rated operational current
Rated operational current See derating curve
No-load current I
Residual current
Isolation test voltage
Short-circuit protection yes/ Cyclic
Voltage drop at I
Wire breakage/Reverse polarity protection yes/ Complete
Output function 4-wire, Complementary contact, PNP
Switching frequency 0.1 kHz
0
e
ð (0,81 x Sn) mm
ð 2 % of full scale
ð ± 10 %
ð ± 20 %, ï +70 °C
ð 10 % U
ss
ð 200 mA
ð 15 mA
ð 0.1 mA
ð 0.5 kV
ð 1.8 V
■ Threaded barrel, M18 x 1
■ Stainless steel, 1.4571
■ Viton sealing ring
■ Protection classes IP68 - IP69K
■ Temperatures up to +120 °C
■ PTFE front cap
■ Climate-proof
■ Resistance to cooling lubricants, cut-
ting and grinding oils
■ For the food industry
■ DC 4-wire, 10…30 VDC
■ Changeover contact, PNP output
■ Cable connection
Wiring Diagram
Functional principle
TURCK offers leak-proof sensors for the food
industry and machine engineering that are resistant to cleaning agents, cooling lubricants,
cutting and grinding oils. They are made for
rough environmental conditions and not only
meet but even exceed the requirements of the
protection classes IP68 and IP69.
Special versions are available for ambient
temperatures between -60°C and +250°C.
Derating Curve
Design Threaded barrel,M18 × 1
Dimensions 95 mm
Housing material Stainless steel, V4A (1.4571)
Active area material Plastic, PTFE
End cap Plastic, PTFE
Admissible pressure on front cap
Max. tightening torque housing nut 25 Nm
Electrical connection Cable
Cable quality 3.7mm, PTFE, FEP, 10
Cable cross section
Vibration resistance 55 Hz (1 mm)
Shock resistance 30 g (11 ms)
Protection class IP68/IP69K
Switching state LED,Yellow
Edition • 2018-04-10T22:10:23+02:00
1 / 3 TURCK Inc.
ð 10 bar
4 x 0.25 mm
2
Inductive sensor
For harsh environments and temperatures up to 120°C
BI5-EM18D-VP6X/S120 10M
Distance D 2 x B
Distance W 3 x Sn
Distance T 3 x B
Distance S 1.5 x B
Distance G 6 x Sn
Diameter active area B Ø 18 mm
Edition • 2018-04-10T22:10:23+02:00
2 / 3 TURCK Inc.
