USER MANUAL

DIGITECH PRO

650/850 VA

UNINTERRUPTIBLE POWER SUPPLY

UPS

ENGLISH

Front View

AC Input
USB Communication Port
RJ 11/45 Protection Port
Output Receptacles

1

2

3

Back View

Product Overview

4

Power Switch
LCD Display

1

2

650 VA / 850 VA

Product Features

Modern, stylish concept

Today the IT users not only want functional products, but also nice looking
products which they will enjoy to see every day. Digitech Pro is a unique design
and has a display which looks up, if you think 90% of the UPS work under your
table on the floor; this makes the user to see the display without bending down.

Multi funtion LCD display with voltage meter

Digitech Pro has his own way of communicating to it’s user; you can see many
information from the LCD display like the input/output voltage, load level, battery
level, overload etc.

CPU control for reliability

Digitech Pro is a digital UPS which has a high speed CPU ensuring that it does all
of it’s functions right and on time. This very critical especially for protection of the
UPS; as all the overload, overvoltage, undervoltage protections and controlled
digitally by the CPU, it provided exceptional reliability to the UPS.

Simulated sine wave

Digitech Pro provides simulated sinewave form which is suitable PC and IT
equipment.

LCD Display

Input

Voltage

Load

Level

Over

Load

Fault

Line Mode

Battery Mode

Output
Voltage

Battery
Level

Low
Battery
