Tunap Injecto Clean, 13310 V2 System Operating Manual
Gen. Operating Manual Device description
Version 1.3. – 29-01-2018
The specifications provided in this Service Information sheet are the results of careful analysis. Any application-related specifications shall be viewed as
recommendations based on past experiences. Due to the wide variety of applications and work methods, we are unable to provide binding specifications. There fore,
there exists no contractual legal relationship, nor will secondary obligations arise from any purchase contracts. Only the most recent version of the Service Information
sheet retains its validity.
TUNAP GmbH & Co. KG | D-82515 Wolfratshausen | Tel. 08171 / 16 00 – 0 | info@tunap.com | www.tunap.com
13310 V2 Injecto Clean System for Injector
Cleaning
Diesel & Gasoline Fuel Injection Systems
Introduction
Congratulations on purchasing the TUNAP Injecto-Clean System and thank you for the trust you have placed
in us.
With the TUNAP Injecto-Clean System you have chosen to combine state-of-the-art technology with high
customer satisfaction and sustainable cost reduction. In order to take full advantage of this system, we ask you
to follow closely the instructions and information provided in this device manual.
Device description
1
Filling level indication
6
Inline-filter
2
ON/OFF switch
7
Power cable with fuse
3
Pressure gauge
8
Supply connection with closing cap
4
Pressure control valve
9
Closing cap tank ventilation
5
Connecting hoses return (IN ) & supply (OUT)
Gen. Operating Manual Device description
Version 1.3. – 29-01-2018
The specifications provided in this Service Information sheet are the results of careful analysis. Any application-related specifications shall be viewed as
recommendations based on past experiences. Due to the wide variety of applications and work methods, we are unable to provide binding specifications. There fore,
there exists no contractual legal relationship, nor will secondary obligations arise from any purchase contracts. Only the most recent version of the Service Information
sheet retains its validity.
TUNAP GmbH & Co. KG | D-82515 Wolfratshausen | Tel. 08171 / 16 00 – 0 | info@tunap.com | www.tunap.com
Technical Data
Weight
5.8 kg
Flow rate
Max. 195 l/h
Nominal voltage
12V DC
System pressure
3.0 bar
Max. current drain
10A
Pressure regulation
8.0 bar
