Tuff Stuff EID-42 User Manual

OWNER’S MANUAL

& Assembly Instructions

EID-42

Multi-Purpose Bench

L61 X W22 1/4 X H48

EID-42_Rev0

Revision Date 5-4-12

Table of Contents

DANGER, WARNING, & CAUTION LABELS INFORMATION ...............Page 3-4

IMPORTANT SAFETY INSTRUCTIONS ..........................................................Page 5

PREPARATION & ASSEMBLY TIPS ..................................................................Page 6

ASSEMBLY INSTRUCTIONS – STEP 1 ...........................................................Page 7

ASSEMBLY INSTRUCTIONS – STEP 2 ...........................................................Page 8

ASSEMBLY INSTRUCTIONS – STEP 3 ...........................................................Page 9

PARTS LIST ......................................................................................................... Page 10

EXPLODED VIEW ............................................................................................. Page 11

BASIC EXERCISE GUIDE ...........................................................................Page 12-15

WARRANTY ....................................................................................................... Page 16

Tu Stu Fitness Equipment Inc. continually engages in research related to product improvements. Please take the time to carefully read through this

manual thoroughly. Instructions contained in this manual are not intended to cover all details or variations possible with Gladiator equipment, or to cover
every contingency that may be met in conjunction with assembly, installation, operation, maintenance or troubleshooting of the equipment. Eventhough
we have prepared this manual with extreme care, neither the manufacturer nor the author can accept responsibility for any errors in, or omission from, the
information given. Should additional information be required, or should situations arise that are not covered by this manual, the matter should be directed
to Customer Service at Tu Stu Fitness Equipment Inc. in Chino, California.

2

EID-42 Multi-Purpose Bench

Carefully read ALL Danger, Warning & Caution labels posted on the machine

BNH2903BNH2907

BNH2917 BNH2918

EID-42 Multi-Purpose Bench

3

Carefully read ALL Danger, Warning & Caution labels posted on the machine

BNH2916

BNH2911BNH2915

BNH2919

4

EID-42 Multi-Purpose Bench

Important Safety Instructions

Before beginning any form of exercise program, it is important to get your physician approval. If you have
not participated in a regular exercise program, smoke or have signs of high blood pressure, you must consult
with your personal physician before performing any form of physical activities.

Before using the equipment, read and
understand the Owner’s Manual and all DANGER, WARNING & CAUTION
labels posted on the machine. SERIOUS INJURY OR DEATH CAN OCCUR IF
THESE RULES ARE NOT FOLLOWED:

1. Inspect the equipment before each use for wear and tear, loose
 ttings, and welded joints for cracks. If it appears to be inoperable
or damaged, DO NOT USE equipment until repaired. Use only
genuine Tu Stu parts. Failure to do so will void warranty and
could result in serious injury or death.

2. Children must not be allowed near this machine. Teenager must
be supervised.

3. Stop exercising if you feel faint or dizzy. Consult a physician if you
are experiencing pain.

4. Use this equipment only for exercises shown pages 12-15.

5. Use spotters/helpers to assist when using weights.

6. Keep body, clothing and hair clear from all moving parts. Do not
attempt to free any jammed parts by yourself.

7. Always warm-up before and cool-down after weight training.
Warm-up for 10-15 minutes with stretching and cardiovascular
exercises. Cool-down should include light stretching exercises for
5-15 minutes.

8. Never hold your breath – will limit the  ow of oxygen to your brain
and may cause dizziness. The most often used breathing pattern is
inhaling during least resistance and exhaling during maximum
resistance.

9. Do not remove any decals a xed to the machine. Replace if
damaged.

10. Periodic maintenance is required to keep your equipment in safe
and proper operating condition. Follow the maintenance schedule
as shown in “Inpection” and “Schedule” labels.

11. Do not use accessories or accessory attachments that are not
recommended by Tu Stu .

12. Make sure all pull-pins are fully engaged and secured in the holes
before performing the exercises.

13. Do not use the equipment outdoors.

DO NOT ATTEMPT to use over

maximum weight capacity

MAXIMUM

400 lbs

NOTE: Maximum load capacity includes user’s weight.

EID-42 Multi-Purpose Bench

LOAD

Personal Safety During Assembly

Before beginning assembly, it is important to take the time to read and
review all of the assembly instructions provided in this manual.

Read each step in the assembly instructions and follow the steps in
sequence. Do not skip ahead as you may learn later the you have to
disassemble the components and that you may have damaged the
components or parts.

Assemble, lubricate all moving parts, and operate the EID-42 on a solid,
level and clean surface.
Locate the unit a few feet from the walls or furniture to provide easy
access.

After assembly, you should check all nuts & bolts that are wrench­tightened, and all functions to ensure correct operation. If you experience
problems,  rst recheck the assembly instructions to locate any possible
errors made during assembly. If you are unable to correct the problem(s),
call the dealer from whom you made the purchase  rst before contacting
Tu Stu Customer Service.

Obtaining Service

Please use this Owner’s Manual as your guide to all parts included in
your shipment. When ordering parts, you must specify the part number
and description from this manual. Use only genuine Tu Stu replacement
parts when servicing the equipment. Failure to do so will void your
warranty and could result in serious injury or death.

For information about product operation or service:
Phone: [phone]
Fax: [phone]
Toll Free: 888-884-8275
E-mail: service@tu stu .net
Hours: M–F 8:00 – 4:30 PST

Or write to: Tu Stu Fitness Equipment Inc.
Customer Service
13971 Norton Avenue, Chino, CA 91710

Retain this Owner’s Manual for future reference when ordering
service or parts. To assist you better, please be prepared to
provide the following information:

1. Model Number

2. Place of Purchase

3. Serial Number

4. Part # and Description

5
