Tuff Stuff CXT-125 User Manual

DO NOT DISCARD THIS MANUAL

HOME LIFETIME WARRANTY

TuffStuff products are warranted to the retail purchaser to be free from defects in materials and workmanship.
TuffStuff exclusive Home Lifetime Warranty coverage extends for the life of the product while owned by the
original retail purchaser, and used only in a home or residential setting unless otherwise noted in the owner’s
manual.

This warranty does not cover:

1. TuffStuff products sold for and used in a commercial or institutional setting.

2. Any damage, failure or loss caused by accident, misuse, neglect, abuse, improper assembly, improper
maintenance, or failure to follow instructions or warnings in the owner’s manual and warning labels
posted on the machine.

3. Use of products in a manner for which they were not designed.

4. Original product that is altered, or the use of replacement parts and components of another manufac­turer other than TuffStuff.

OWNER’ S MANUAL

Limitations:
The foregoing shall constitute the sole remedy of the purchaser and the sole liability of TuffStuff with regard to
warranty, whether express or implied by operation of law or otherwise, including but not limited to any implied
warranties of merchantability or fitness. TuffStuff shall in no event be liable for incidental or consequential
losses, damages or expenses in connection with exercise products. TuffStuff’s liability hereunder is expressly
limited to the repairs or replacements of warranted defective parts.

Procedures:
Warranty service will be performed at TuffStuff’s facility in Pomona, California. TuffStuff will have the option of
either repair or replacement at no charge for any defective product. Purchaser is responsible for installation of
repaired or replaced parts and all transportation and insurance costs on returned or replaced equipment to and
from TuffStuff’s facility in Pomona.

This warranty gives you specific legal rights and you may also have other rights, which may vary from state to
state. Effective July 1, 2004.

This warranty is the final, complete and exclusive agreement of the parties with respect to the quality or performance of the equipment
and no action for breach of this written warranty or any implied warranty shall be commenced more than one (1) year after the accrual
of the cause of action. No modification of this warranty or waiver of its terms shall be binding on either party unless approved in
writing by an authorized representative of the party. Contact TuffStuff at 1325 E. Franklin Avenue, Pomona, California 91766, before
returning any defective equipment.

Note: Retain your sales receipt and be sure to mail in the warranty registration card to insure that a

permanent record of your purchase is on file with the factory and to avoid unnecessary delays in
warranty service.

TuffStuff Fitness Equipment, Inc.

1325 E. Franklin Avenue

Pomona, CA 91766, USA

Ph: 909-629-1600 Fax: [phone]

E-mail: [e-mail] Net: www.tuffstuff.net

CXT-125

Smith Machine Attachment
(CXT-100 Option)

95 1/2"

135"

CXT-100 + CXT-125

L 95 1/2" W 135" H 84 3/4"

AMERICA’S PREMIER EXERCISE EQUIPMENT

CXT-125 Rev0

Revision Date 10-18-06

Introduction

About the Smith Machine Attachment CXT-125

Congratulations on your new purchase of the Smith Machine
Attachment (CXT-100 Option). We hope you are completely

satisfi ed with this product and wish you many years of enjoyment.

Tuff Stuff Equipment

This Tuffstuff product has been built to precise quality standards
and has been carefully packaged to ensure that damage will not
occur during shipment. The Home Lifetime Warranty and signature
indicating fi nal inspection has been conducted by our line foreman,
is an expression of our confi dence in the completeness, the
materials, and workmanship of this product.

Warranty

SEE A COPY OF WARRANTY ON BACK PAGE.

Registration Card

To avoid unnecessary delays in warranty service and to insure that
a permanent record of your purchase is on fi le with our factory,
be sure to complete the warranty registration card and send it to
TuffStuff Fitness Equipment today.

Specifi cations

1. Maximum Wt. Capacity - 250 lbs.

2. Total Machine Weight - 175 lbs.

3. Footprint (LWH) - See Front Cover.

Note: Due to continuing product improvements, specifi cations and designs are subject to change
without notice.

Prior to the Assembly of the Smith Machine Attachment

1. We advise you to consult your local Tuf f Stuff retailer if you should
have a question or problem regarding the proper assembly of
this unit.

Tool Requirements

1. One 9/16” combination wrench

2. One ratchet

3. One 9/16” socket

4. One rubber mallet

5. Windex or household glass cleaner

6. Measuring tape

7. Utility knife

Hardware Measurement Diagram

H

T

G

N

E

L

W

E

R

C

S

R

E

H

S

A

W

H

T

D

I

W

W

E

R

C

S

R

E

T

E

M

A

I

D

R

E

T

E

M

A

I

D

T

U

N

Maintenance

Part Three: Lubrication

Bearing and linear bearings systems have advanced over the years but they must be maintained on a regu­lar basis if you expect them to last and perform effi ciently. TuffStuff uses only the highest quality bearings
and linear motion components that are virtually trouble-free but requires the regular preventive maintenance
to insure long-lasting performance.

1. Bronze and nylon bushings, we recommend on a monthly basis to spray a tefl on-base lubricant
(silicone-free) directly onto the shaft as it passes through these bushings. Spray a small amount
onto the shaft and rotate it through its complete movement and wipe off any excess.

2. Weight stack guide rods and bushings, again use tefl on spray lubricant and this time spray onto
a rag and wipe the guide rods down with this rag on a weekly basis. Do not use WD-40 or other
lubricants as they attract dirt and will crate a mess between the weight plates and bushings.

3. Sealed bearings pivot points, as the name implies are protected from the outside environment
and require no lubrication. During the machine wipe down, wipe the external bearing surfaces
with the damp rag and dried to prevent the build up of dust and sweat.

4. Linear bearing systems are precision, high load components that require regular maintenance.
Dirt and corrosion are the major culprits in linear bearing failure. The hardened shafts must be
wiped down weekly and lubricated with a light layer of tefl on grease. We recommend a tefl on-
base (silicone-free) gel/grease for this purpose. Lack of care and maintenance will result in cor­rosion of the linear shaft causing the bearings to clogged and jammed.

Safety Precautions

Safety First

Regardless of how enthusiastic you may be about getting on
your equipment and exercising, take the time to ensure that your
safety is not jeopardized. A moment’s lack of attention can result
in an accident, as can failure to observe certain simple safety
precautions.

1. Read, study and understand the Owner’s Manual and all the
warning labels on this product. Furthermore, it is recommended
to familiarize yourself and others with the proper operation and
workout recommendations for this Tuff Stuff product prior to
use.

2. It is imperative that you retain this Owner’s Manual and be sure
all warning labels are legible and intact. Replacement Owner’s
Manual and labels are available from your local Tuff Stuff
retailer.

3. Consult with your physician before beginning any exercise
program.

4. Use proper discretion when children are present.

5. Keep hands, limbs, loose clothing and long hair well out of the
way of moving parts.

6. Do not attempt to lift more weight than you can control safely.

7. Inspect the Unit for any sign of wear on parts, hardware becoming
loose or cracks on welds. If a problem is found do not use or
allow the machine to be used until the defective part is repaired
or replaced.

If you religiously perform the maintenance procedures, you will increase the life of the machine and ulti­mately lower your maintenance costs with fewer replaced components and downtime.

Any doubts, equipment with mechanical problems should be placed “Out-of-Service” until all problems are
corrected. If replacement parts are required or maintenance questions, please contact:

TuffStuff Fitness Equipment, Inc.
Service Department
1325 E. Franklin Avenue
Pomona, CA 91766
1-800-961-9377
e-mail: [e-mail]

9CXT-125 Smith Machine Attachment (CXT-100 Option)2 CXT-125 Smith Machine Attachment (CXT-100 Option)
