Surface Mount SOIC
Resistor Networks

• Tested for COTS applications

• Both narrow and wide body versions available

• Standard JEDEC 8, 14, 16, and 20 pin packages

• Ultra-stable TaNSil® resistors on silicon substrates

• RoHS compliant and Sn/Pb terminations available

SOIC Series

IRC’s TaNSil

®

SOIC resistor networks are the perfect solution for high volume applications that demand a small
wiring board footprint. The .050" lead spacing provides higher lead density, increased component count,
lower resistor cost, and high reliability.

The tantalum nitride film system on silicon provides precision tolerance, exceptional TCR tracking, low cost
and miniature package. Excellent performance in harsh, humid environments is a trademark of IRC’s self-pas

-

sivating TaNSil

®

resistor film.

The SOIC series is ideally suited for the latest surface mount assembly techniques and each lead can be
100% visually inspected. The compliant gull wing leads relieve thermal expansion and contraction stresses
created by soldering and temperature excursions.

For applications requiring high performance resistor networks in a low cost, surface mount package, specify
IRC SOIC resistor networks.

Electrical Data Environmental Data

Resistance Range 10 − 250KΩ

Absolute Tolerance To ±0.1%

Ratio Tolerance to R1 To ±0.05%

Absolute TCR To ±25ppm/°C

Tracking TCR To ±5ppm/°C

Element Power Rating @ 70°C
Isolated Schematic
Bussed Schematic

100mW
50mW

Power Rating @ 70°C
SOIC-N Package

8-Pin 400mW
14-Pin 700mW
16-Pin 800mW

Power Rating @ 70°C
SOIC-W Package

16-Pin 1.2W
20-Pin 1.5W

Rated Operating Voltage

(not to exceed Power X Resistance)

100 Volts

Operating Temperature

-55°C to +125°C

Noise <-30dB

Test Per

MIL-PRF-83401

Typical
Delta R

Max

Delta R

Thermal Shock ±0.02% ±0.1%

Power
Conditioning

±0.03% ±0.1%

High Temperature
Exposure

±0.03% ±0.05%

Short-time
Overload

±0.02% ±0.05%

Low Temperature
Storage

±0.03% ±0.05%

Life

±0.05% ±2.0%

SOIC Series Issue January 2009 Sheet 1 of 4

√

________________

• 4222 South Staples Street • Corpus Christi Texas 78411 USA

© IRC Advanced Film Division

Telephone: [phone] • Facsimile: 361 992 3377 • Website: www.irctt.com

Surface Mount SOIC
Resistor Networks

Manufacturing Capability Data

Absolute

TCR

(ppm/°C)

ISOLATED SCHEMATIC A BUSSED SCHEMATIC B

Ohmic

Range

(Ω)

Available

Tolerances

Available

Ratio

Tolerances

Best

Tracking

(±ppm/°C)

Ohmic
Range

(Ω)

Available

Tolerances

Available

Ratio

Tolerances

Best

Tracking

(±ppm/°C)

250

10-25 F G J F G 50 10-25 F G J F G 200

26-50 D F G J C D F G 10 26-50 F G J D F G 100

51-200 C D F G J C D F G 5 51-100 D F G J C D F G 50

201-250K B C D F G J A B C D F G 5 101-200 D F G J B C D F G 25

201-500 B C D F G J B C D F G 20

501-100K B C D F G J A B C D F G 5

100

26-50 D F G J C D F G 10 26-50 F G J D F G 100

51-200 C D F G J C D F G 5 51-100 D F G J C D F G 50

201-250K B C D F G J A B F G 5 101-200 D F G J B C D F G 25

201-500 B C D F G J B C D F G 20

501-100K B C D F G J A B C D F G 5

50

26-50 D F G J C D F G 10 51-100 D F G J C D F G 50

51-200 C D F G J C D F G 5 101-200 D F G J B C D F G 25

201-250K B C D F G J A B F G 5 201-500 B C D F G J B C D F G 20

501-100K B C D F G J A B C D F G 5

25

51-200 C D F G J C D F G 5 201-500 B C D F G J B C D F G 20

201-250K B C D F G J A B F G 5 501-100K B C D F G J A B C D F G 5

SOIC Series Issue January 2009 Sheet 2 of 4
