SUBMERSIBLE SITE DRAINAGE
HS
SINGLE PHASE
The HS series are 50mm (2”) and 80mm (3”) submersible pumps with motor sizes in 400watt
and 750watt. The models HS2.75S and HS3.75S offer increased head and ow capability over
the HS2.4S. All models have a solid cast aluminium body, cast iron pump casing and an impact
resistant PVC strainer base for durability during robust handling. The urethane vortex impeller
offers excellent wear resistance in site applications where water contains sand and silt in
suspension, thus maintaining performance and reliability. The 750watt pumps feature an oil lifter
to maintain seal lubrication during operation in any position. All models have a 403 stainless steel
shaft, that is tted with an ultra hardwearing, double mechanical seal (inboard: silicon carbide -
silicon carbide) – which runs in an oil chamber - and have a stirring device to reduce blockages.
Used predominantly as contractor pumps on site drainage duties, they can also be used in other
industrial applications. Supplied with 10 metres of heavy duty, rubber power cable. Available in
single-phase only with an optional oat switch.
The puddle pump adaptor kit is an optional extra that will convert the HS2.4S to a puddle sucker.
It will enable the pumping of water levels down to 10mm, maximize utilisation and is very simple to
t. The kit comprises a rubber coated steel bottom plate, stainless steel bolts, nuts and washers.
All Tsurumi 110 volts contractor pumps are factory tted with 16A plugs and supplied with a hose
clip. However the HS2.4S is available without either to keep the price competitive - see model code
HS2.4S(B). This model is supplied only when specically requested.
●
Hire fleets
●
Construction
●
Utilities
●
Dewatering
●
Fixed installations
●
Water features
WANT A PUDDLE PUMP?
Convert the HS2.4S by
tting a residue plate.
Pumps down
HS3.75S manual
model
HS2.4S(B) M 50 0.4 110 205 12 7 185x241x328 11.30 13.35 260.00 2
HS2.4S M 50 0.4 110 205 12 7 185x241x328 11.30 13.50 285.00 2
HS2.4S M 50 0.4 230 205 12 7 185x241x328 11.30 13.50 294.00 2
HS2.4S A 50 0.4 110 205 12 7 185x241x328 11.70 13.60 316.00 2
HS2.4S A 50 0.4 230 205 12 7 185x241x328 11.70 13.60 325.00 2
HS2.75S M 50 0.75 110•230 230 18 7 185x290x385 16.90 20.00 432.00 2
HS2.75S A 50 0.75 110•230 230 18 7 185x290x385 17.30 20.30 463.00 2
HS3.75S M 80 0.75 110•230 310 18 7 185x290x385 16.90 20.00 432.00 2
HS3.75S A 80 0.75 110•230 310 18 7 185x290x385 17.30 20.30 463.00 2
Puddle pump adaptor kit for HS2.4S 0.55 0.55 45.00 2
Manual or
Auto
outlet
(mm)
kW volt
HS2.4S manual
flow
(l/min)
head
(mtrs)
free passage
(mm)
to 10mm
w x l x h
(mm)
dry weight
(kgs)
Rubber coated
steel plate
packing weight
(kgs)
Price
(£)
code
29
