T. S. MicroTech IEEE1394 User Manual
USER'S MANUAL
USER'S MANUAL
FireSCSI Xpress
FireWire (IEEE1394) to SCSI Adapter
I N T E R N A T I O N A L, I N C.
USER'S MANUAL
USER'S MANUAL
Home
Controls within Adobe®Acrobat®Reader?
Getting started
Introduction
What's included with the FireSCSI Xpress
System requirements
Connecting to a Macintosh
Installation overview
Installing the driver software
Connect a SCSI device to the FireSCSI Xpress
Connect the FireSCSI Xpress to your computer
SCSI Termination
SCSI Addressing
Using the FireSCSI Xpress
Connecting to a PC Compatible
Installation overview
Installing the driver software
Connect a SCSI device to the FireSCSI Xpress
Connect the FireSCSI Xpress to your computer
SCSI Termination
SCSI Addressing
Using the FireSCSI Xpress
Obtaining Technical Support
Solutions to common problems
Contacting Microtech Technical Support
Returning products for service
Microtech Limited Warrantys
Contacting Microtech International
USER'S
MANUAL
USER'S
MANUAL
2
CONTENTS
USER'S MANUAL
USER'S MANUAL
3
Controls within Adobe®Acrobat®Reader
This manual has been produced as a Portable Document Format (PDF). Using the Adobe Acrobat
Reader, this manual may be viewed either directly on-screen or printed using your own printer.
Go to next page or to previous page. (Note: The "Left" and "Right" arrows on the
keyboard can also be used to advance to the previous or next page. The "Up" and
"Down" arrows can be used to scroll up or down on a current page, as well as
advance pages).
Undo or redo of certain actions or of pages visited.
Go to beginning or end of this document.
Zoom in and zoom out.
USER'S
MANUAL
USER'S
MANUAL
4
1
GETTING
STARTED
Introduction:
Thank you for purchasing the FireSCSI Xpress from Microtech International, Inc.
The FireSCSI Xpress is a USB to SCSI converter for new Apple Macintosh and PC Compatible
owners who wish to use their existing SCSI peripherals such as hard drives, Zip drives, and CDROM drives on a enabled system.
What's included with the FireSCSI Xpress:
The FireSCSI Xpress includes the following:
■ FireSCSI Xpress Adapter
■ Microtech Installer CD
■ Quick-Start Guide
■ Warranty Registration Card
System Requirements:
PC Compatible:
■ Desktop or laptop PC Compatible with an IEEE-1394 port
■ Windows 98SE, 2000, ME
Macintosh:
■ Any IEEE-1394 equipped Apple Macintosh*
■ Mac OS 9.0 or higher featuring FireWire Manager 2.3.3 or above.
* Does not support 3rd party USB add-on cards.
5
USER'S MANUAL
USER'S MANUAL
USER'S
MANUAL
USER'S
MANUAL
6
2
CONNECTING
to a Macintosh
7
USER'S MANUAL
USER'S MANUAL
Installation Overview
The FireSCSI Xpress is relatively easy to install and operate. To avoid complications during the
installation process, please follow the steps in order as described in this chapter.
Installing the Driver Software
Macintosh Installation (Mac OS 8.5 or above):
Insert the Microtech Installer CD-ROM
Double-click on the "Microtech Installer" Icon
Follow any instructions displayed on the screen.
After installing the driver software, finish reading this chapter and connect the FireSCSI
Xpress to your computer. For instructions on connecting your SCSI device to the FireSCSI
Xpress, proceed to the next page.
Installation note: If you attempt to attach the FireWire connector to the FireWire port of your
Macintosh prior to installing the FireSCSI Xpress drivers you may receive the following (or a similar) message:
If this occurs, click "OK", install the driver software, and then attach the FireWire connector.
1.
2.
3.
4.
