TSL AMU2-8HD+, AMU2-8HD-3G Handbook

USO RESTRITO

AMU2-8HD+ & 3G

Audio Monitoring

Units

Handbook

TSL

Vanwall Road, Maidenhead, Berkshire, SL6 4UB

Telephone [phone], FAX [phone]

USO RESTRITO

AMU2-8HD+/3G 1 Issue 1

USO RESTRITO

SAFETY

Installation.

Unless otherwise stated TSL equipment may be installed at any angle or position within
an operating temperature range of 5° - 30° C .

All TSL equipment conf o rm s to th e EC Low Voltage Directive:
EC Low Voltage Directive (73/23/EEC)(OJ L76 26.3.73)(LVD).

Amendment: (93/68/EEC) (OJ L220 30.8.93).
The earth pin on the IEC mains inlet connector is connected to the metal frame of the

equipment, to 0 volts on the internal DC PSU and to signal ground, unless otherwise
stated. All metal panels are bonded togethe r.

In all cases , the frame of the equipment must be ear thed on installation.
Due consideration for cooling requirements must be given when mounting the equipment.

Ideally 1RU of rack spac e should be left above and below the unit.
Check that the fuse rating is correct for the local power (mains) supply. Replacement

fuses must be of the same rating and type for continued protection against fire risk.

Do not switch on until all connections are made.

WARRANTY, MAINTENANCE AND REPAIR

All TSL equipment is guaranteed for one year from the date of delivery to the customer’s
premises. If the equipment is to be stored for a significant period, please contact TSL
concerning a possible extended warranty period.

Failure during warranty

If any TSL product should fail or become faulty within the warranty period, first please
check the PSU fuses.

All maintenance work must be carried out by trained and competent personnel.

Technical support information

E-Mail ad dress: support@televisionsy stems.ltd.uk
Telephone Support Number for the UK and Europe: [phone]
Telephone Support Number for the USA only: 1 877 591 2108

AMU2-8HD+/3G 2 Issue 1

USO RESTRITO

TSL Returns Proc e dure

Please telephone [phone] (Fax: [phone]) and ask for Production
Sales who will provide a Returns Number. This will enable us t o track the unit eff ectively
and will provide some information prior to the unit arriving.

For each item, this unique Returns Number must be included with the Fault Report sent
with the unit.

A contact name and telephone number are also required with the Fault Report sent with
the unit.

Fault report detail s req uir e d.

• Company:

• Name:

• Address:

• Contact Name:

• Telephone No:

• Returns Number:

• Symptoms of the fault (to include switch setting positions, inp ut signals etc):

Packing

Please ensure that the unit is well packed as all mechanical damage is chargeable. TSL
recommends that you insure your equipment for transit damage.

The original packaging, when available, should always be used when returning
equipment..

If returned equipment is received in a damaged condition, the damage should be
reported both to TSL and the ca r ri er imm e dia tely.

AMU2-8HD+/3G 3 Issue 1

USO RESTRITO

Contents

1.0 Introduction

2.0 Front Panel Controls

2.1 Input and Meter Selection Buttons

2.2 Output Switching and monitoring

3.0 Pin-out Details

3.1 Line output

3.2 Analogue Output Connector – D25 Socket Pinout

3.3 AES Input/Output connector – D25 Socket Pinout

3.4 Control Connector - D9 Socket

3.5 External Connector - D15 Plug

3.6 S/HD BNC connectors

3.7 Re clocked BNC connector

3.8 Down converted BNC connector

3.9 Remote Control Connector/ RS 422 - D9 Socket

3.10 Aux (Dolby Metadata) - D9 Socket

4.0 LS Output

5.0 Configuration Switch Functions

6.0 General Notes

7.0 Specification

8.0 Block schematic diagram

9.0 Front and Rear panel layout drawings.

AMU2-8HD+/3G 4 Issue 1

USO RESTRITO

AMU2-8HD+/3G AUDIO MONITORING UNIT

1.0 Introduction

This handbook covers the AMU2-8HD+ and AMU2-8HD-3G Audio Monitoring Units.
The AMU2-8HD+/3G are full rack 2RU x 310mm deep Audio Monitoring Units with eight

TSL 53 segment bargraphs.
The following features are standard:

• Four AES/EBU inputs.

• Two HD/SDV auto sensing inputs.

• Re clocked output of input.

• Two Stereo analogue inputs.

• Phase reverse switch.

• Out-of-phase error indication.

• Down converted video or SDV output

• Additive output switch selection.

• Composite output.

• Headphone outputs with LS muting.

• Fixed and variable st ereo line outputs of selected pair.

• Four simultaneous line outputs.

• Dolby compatible D and E.

• Metadata display.

• EBU digital, UK PPM and EBU PPM scales available.

• Internal amplifier.

• 1080p50 / 1080p/60 capable (3G units only)

AMU2-8HD+/3G 5 Issue 1

USO RESTRITO

2.0 Front Panel Controls

2.1 Input and Meter Selection Buttons

AES1, 2, 3 & 4 AES input. This is selected by first pressing the AES select

button, then selecting A(1/2),B(3/4), C(5/6 ), D(7/8) respectively
on the LS monitoring panel.

Anal ogue 1 & 2 These inputs are selected by pressing the Phase

Reverse/function button and then the AES/ANLG button on the
input select panel. The signals are displayed on bargraph A
(1/2) and B (3/4).

S/HD (Auto sensing) This is selected by pressing the S/HD button 1 or 2 and then

selecting GP1 to GP4. The de-embedded SDV or HD is then
displayed on the bargraphs A(1/2),B(3/4), C(5/6), D(7/8)
respectively. Selecting e.g. group 1 and 2 together allows all
eight channels to be monitored.

Dolby Encoded Dolby can either be carried on an AES bit stream or

as embedded HD or SD. To select the Dolby function press the
DOLBY button after selecting either AES or S/HD buttons. If a
valid Dolby signal is present the Dolby button will illuminate
steady red. If a Dolby signal is not present or is lost the button
will flash. To select one pair from one group containing two
Dolby signals on each pair, select the group (1, 2, 3 or 4) from
the H/SDV input and then either A, B, C, or D from the input
selector to choose the pair.

Letterbox Shows the composite output as 16:9 aspect ratio on a 4:3

monitor.

Ø Rev (Function) Momentary phase reverse between A1 and A2 outputs.
Brightness To increase the brightness of the ba rgraph disp lay

Press phase reverse and monitoring select A. To
decrease the Brightness press phase reverse and
monitoring select B.

Reference Marker To turn the reference marker on and off press phase
Reverse and the CUT button.

AMU2-8HD+/3G 6 Issue 1

USO RESTRITO

Meta Data Display This window indicates:

Channel coding (Rate/non PCM/Dolby D/Dolby)
Channel format (e.g. 8x1/2+2+2+2 etc)
Digital peak read out of selected pair.
Dialogue normalisation value where set

N.B. To reset/refresh display press Phase Reverse then Dolby select
switches simultaneously.

2.2 Output Switching and monitoring
A, B, C & D These buttons sel ect the audio from pairs 1/2 (A) through to 7/8

(D)

The buttons toggle. Additive mixing is possible if two or more

buttons are selected together and are fed only to the variable
line outputs.

ALL Enables multi-channel listening on variable outputs. When

selected, multichannel variable outputs are enabled and full
surround can be monitored.

Selecting ALL, holding down and pressing output selection A

or B will toggle between using ABC for d iscrete 5.1 or BCD for
discrete 5.1.

L Enables the left hand channel to be monitored by both outputs.
R Enables the right hand channel to be monitored by both

outputs.

M A mono signal of the left and right hand channels is applied to

both outputs.

Lt Rt Allows a multi channel signal to be monitored and is a stereo

‘down mix ‘of a Dolby decoded signal. (Mutes multi channel
outputs)

5.1 Enables/Disables 5.1 m et ad a ta dyn a m ic range con tro l.

Dim Approximately 16dB of attenuation is switched into the audio

path.

Cut/Mute The front panel button Cut(s) the signal to all Variable O/Ps.
Volume The loudspeaker, headphone and variable O/P’s may be

varied.

AMU2-8HD+/3G 7 Issue 1

USO RESTRITO

3.0 Pin-out Details

3.1 Line output

XLRS PIN FUNCTION

ANALOG 1 1 GND
ANALOG 1 2 1 IN+
ANALOG 1 3 1 IN­ANALOG 2 1 GND
ANALOG 2 2 2 IN+
ANALOG 2 3 2 IN-

3.2 D25 Socket, Analogue output connector

D 25 SOCKET

ON AMU

PIN NO FUNCTION

1 A8+ (7.1)

14 A8- (7.1)

2 Ground

15 A7+ (7.1)

3 A7- (7.1)

16 Ground

4 A6+ (RS)

17 A6- (RS)

5 Ground

18 A5+ (LS)

6 A5- (LS)

19 Ground

7 A4+ (LFE)

20 A4- (LFE)

8 Ground

21 A3+ (Centre)

9 A3- (Centre)
22 Ground
10 A2+ (FR)
23 A2- (FR)
11 Ground
24 A1+ (FL)
12 A1- (FL)
25 Ground
13 N/C

AUDIO OUTPUTS

AMU2-8HD+/3G 8 Issue 1

USO RESTRITO

3.3 D25 Socket, AES Input/Output connector

D 25 SOCKET

ON AMU

PIN NO FUNCTION

1 Ch1&2 Input 1+
14 Ch1&2 Input 1-

2 Ch3&4 Input 2+
15 Ch3&4 Input 2-

3 Ch5&6 Input 3+
16 Ch5&6 Input 3-

4 Ch7&8 Input 4+
17 Ch7&8 Input 4-

5 Ch1&2 Output 1+
18 Ch1&2 Output 1-

6 Ch3&4 Output 2+
19 Ch3&4 Output 2-

7 Ch5&6 Output 3+
20 Ch5&6 Output 3-

8 Ch7&8 Output 4+
21 Ch7&8 Output 4-

9 N/C
22 Ground
10 Ground
23 Ground
11 N/C
24 Ground
12 Ground
25 Ground
13 Ground

AES INPUTS/OUTPUTS

3.4 Control Connector - D9 Socket

This is wired for RS 4 2 2.

D9 CONTROL

1 0V
6 0V
2 TX­7 TX+
3 RX+
8 RX­4 0V
9 0V
5 N/C

AMU2-8HD+/3G 9 Issue 1

USO RESTRITO

3.5 External Connector – D15 Plug

D15 EXTERNAL

PIN FUNCTION

1 Dim
2 Cut
3 GPI
4 Cut
5 Lt Rt enable
6 GPI
7 N/C
8 N/C

9 N/C
10 N/C
11 N/C
12 N/C
13 N/C
14 +5V
15 0V

3.6 S/HD connectors

This input auto detects HD or SD V signals.

3.7 Re clocked connect o r
This connector gives a re clocked output of the selected H/SDI input signal.

3.8 Video output connector
This g ives a down converted output of HD (Vision only) or a composite PAL/NTSC

video. N.B. This is dependant on the switch selection detailed in section 5.

AMU2-8HD+/3G 10 Issue 1

USO RESTRITO

3.9 Remote Control Connector/ RS 422 - D9 Socket

This is wired f or RS422.

D9 CONTROL

1 0V
6 0V
2 TX­7 TX+
3 RX+
8 RX­4 0V
9 0V
5 N/C

3.10 Aux (Dolby Metadata) - D9 Socket

This is wired f or RS422.

D9 CONTROL

1 0V
6 0V
2 TX­7 TX+
3 RX+
8 RX­4 0V
9 0V
5 N/C

4.0 LS Output

This is a single ended amplifier therefore one side may be connected to ground.

AMU2-8HD+/3G 11 Issue 1

USO RESTRITO

5.0 Con figuration Switch Functions (z12a.hex/z13.mcs FPGA)
ACI code 7.03 (Note:Subject to change)

SWITCH

SECTION

1 N/U
2 N/U
3 Loudspeaker O/P mute - UP
4 D25 Anlg variable – Up/Fixed - Dwn
5 AES variable –Up/Fixed -Dwn
6** XLR line O/P’s fixed – Up/variable-Dwn
7 Lo Ro-Up/Lt Rt-Dwn
8 Comp out-Up/ SDI - Dwn

** This output on the first pair of the D25 – Analogue output connector.

Note: The calibration, Frame delay (In Dolby mode) and scale type are factory set.

FUNCTION

AMU2-8HD+/3G 12 Issue 1

USO RESTRITO

6.0 Notes

0 dBm = 0.775V into 600Ω i.e. 1mW power dissipation.
0 dBu = 0.775V rms = PPM 4.
Nominally, -18 dB ref 0FS = 0 dBu output.
European line up: -18 dBu
American lineup: -20 dBu
Please note that some American equipment has the function of the XLR pins 2 & 3

reversed.

TSL product is wired to the European standard

The Dolby (CAT552) card can be rese t by pressing the ph ase reverse an d th e
Dolby select buttons simultaneously.

The screw locks on the D25 connectors use UNC 4-40 standard threads.

6.1 One frame Delay in Dolby mode option.
This operates on the down converted output only.

AMU2-8HD+/3G 13 Issue 1

USO RESTRITO

7.0

Power Supp ly

Supply Voltage 100 -240V AC @ 50Hz/60Hz +/- 10%
Power Consumption 60 Watts.
Or

Supply Voltage 12V DC

Physical Dimensions

Height 88mm (2RU)
Width 483mm (19”)
Depth 280mm
Weight 3500gm

Input 1 and 2

Connector Type XLR 3 pin. Pin 1 Gnd, Pin 2 hot, Pin 3 cold.
Signal Balanced line level audio.
Frequency Response 30Hz to 25kHz
Impedance >20kΩ

Inputs AES 1, AES 2

Connector Type XLR (F) 3 pin. Pin 1 Gnd,Pin 2 hot,Pin 3co
Standard AES3 (1994) 32, 44.1, 48, 96 KHz
Impedance Balanced110 Ohm.

Inputs AES 1, 2, 3 and 4

Connector type D25
Standard AES3 (1994) 32, 44.1, 48, 96 KHz
Impedance Balanced110 Ohm.

Inputs, HD/SDV (auto sensing)
Connector Type BNC.
Standard SMPTE 259M 4:2:2 component 525/60

Impedance 75ohm
Return Loss <-20dB to 1.5GHz (3GHz TBA)

AMU2-8HD+/3G Technical Specifications

or 625/50 with embedded 48kHz audio.
HDSDI (SMPTE 292M) – 720P & 1080i @ 50, 59.94 & 60Hz
(1080p @ 50/59.94/60Hz where
applicable)

AUX (Metadata Output)
Connector D9 (RS422)

Remote Control
Connector D9 (RS 422)

AMU2-8HD+/3G 14 Issue 1

USO RESTRITO

Setup Flash card port. (Factory use only)

Dolby

Dolby Digital or Dolby E decoding from selected
AES input or selected embedded audio.
Note: The Dolby (CAT522) card can be reset by
pressing the phase reverse and the Dolby select
buttons simultaneously.

Display indicates: Channel coding

(rate/non pcm/dolby D/dolby)
Channel format (e.g. 8x1/2+2+2+2 etc)
Digital peak readout of selected pair.
Dial norm value where set

Down converted Output
Return Loss Better than -16.5dB to 1.5GHz

Connector BNC

Note: This is a video monitoring point only.

This connector also gives re clocked

SDV out when SDV is applied to the input.

Re clocked Output
Return Loss < -15dB up to 1.5GHz (3GHz TBA)
Connector BNC

Line Output.

Connector XLR 3 pin Male (variable line out A1 &A2)
Impedance 50Ω
Output Levels Through level control with 12dB gain.

Connector D25

Impedance >20kΩ

Output Levels Fixed (+ and – 1dB) and Variable (12dB gain).

Noise Better than -70 dB (22Hz to 22 KHz)
Headphone Output.

Connector Stereo Jack socket type A
Impedance 50Ω
Output Levels Through level control with 0dB gain.

Loudspeaker Outputs.

Connectors 4mm Binding Posts

Output rating Max 15W /Ch into 4Ω,

AMU2-8HD+/3G 15 Issue 1

USO RESTRITO

HD Standards Supported
1080p/50/59.94/60Hz (3G units only)
1080i/50

1080i/59.94
1080i/60
720p/50
720p/59.94
720p/60

8.0 Block schematic Diagra m

AMU2-8HD+/3G 16 Issue 1

USO RESTRITO

AMU2-8HD+/3G 17 Issue 1

USO RESTRITO

AMU2-8HD+/3G 18 Issue 1

USO RESTRITO

9.0 Front and rear Panel layouts

SLT

SLT

ON

87654321

AMU2-8HD+/3G 19 Issue 1

USO RESTRITO

AMU2-8HD+/3G 20 Issue 1
