ENERGY AND COMFORT
Ventilation Testing
VELOCICALC
Air Velocity Meter
Model 9555 Series
Operation and Service Manual
®
Copyright©
TSI Incorporated / June 2007 / All rights reserved.
Address
TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA
Fax No.
(651) 490-3824
LIMITATION OF WARRANTY AND LIABILITY (effective July 2000)
Seller warrants the goods sold hereunder, under normal use and service as described in the
operator's manual, shall be free from defects in workmanship and material for twenty-four (24)
months, or the length of time specified in the operator's manual, from the date of shipment to the
customer. This warranty period is inclusive of any statutory warranty. This limited warranty is
subject to the following exclusions:
a. Hot-wire or hot-film sensors used with research anemometers, and certain other
components when indicated in specifications, are warranted for 90 days from the date of
shipment.
b. Parts repaired or replaced as a result of repair services are warranted to be free from
defects in workmanship and material, under normal use, for 90 days from the date of
shipment.
c. Seller does not provide any warranty on finished goods manufactured by others or on any
fuses, batteries or other consumable materials. Only the original manufacturer's warranty
applies.
d. Unless specifically authorized in a separate writing by Seller, Seller makes no warranty
with respect to, and shall have no liability in connection with, goods which are
incorporated into other products or equipment, or which are modified by any person other
than Seller.
The foregoing is IN LIEU OF all other warranties and is subject to the LIMITATIONS stated
herein. NO OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE OR MERCHANTABILITY IS MADE.
TO THE EXTENT PERMITTED BY LAW, THE EXCLUSIVE REMEDY OF THE USER OR
BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES,
INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED
ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL
BE THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE
PRICE, OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE
GOODS. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY SPECIAL,
CONSEQUENTIAL OR INCIDENTAL DAMAGES. SELLER SHALL NOT BE
RESPONSIBLE FOR INSTALLATION, DISMANTLING OR REINSTALLATION COSTS
OR CHARGES. No Action, regardless of form, may be brought against Seller more than 12
months after a cause of action has accrued. The goods returned under warranty to Seller's
factory shall be at Buyer's risk of loss, and will be returned, if at all, at Seller's risk of loss.
Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND
LIABILITY, which contains the complete and exclusive limited warranty of Seller. This
LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms
waived, except by writing signed by an Officer of Seller.
Service Policy
Knowing that inoperative or defective instruments are as detrimental to TSI as they are to our
customers, our service policy is designed to give prompt attention to any problems. If any
malfunction is discovered, please contact your nearest sales office or representative, or call
Customer Service department at (800) 874-2811 (USA) or (1) 651-490-2811 (International).
CONTENTS
CHAPTER 1 UNPACKING AND PARTS IDENTIFICATION ............1
CHAPTER 2 SETTING-UP................................................................. 3
Supplying Power to the Model 9555 Series ...................................3
Installing the Batteries ...............................................................3
Using the Optional AC Adapter ................................................. 3
Using The Telescoping Probe ........................................................3
Extending The Probe................................................................. 3
Retracting The Probe ................................................................3
Connecting the Optional Bluetooth Portable Printer....................... 4
Connecting to a Computer.............................................................. 4
CHAPTER 3 OPERATION .................................................................5
Keypad Functions ........................................................................... 5
Common Terms .............................................................................. 5
Menus .............................................................................................6
DISPLAY SETUP................................................................................. 6
PRESSURE ZERO............................................................................... 6
SETTINGS .........................................................................................6
FLOW SET UP....................................................................................6
ACTUAL/STANDARD SETUP ................................................................7
DATA LOGGING .................................................................................7
Measurements...........................................................................7
Log Mode/Log Settings .............................................................7
Delete Data................................................................................ 8
% Memory .................................................................................8
APPLICATIONS ..................................................................................8
Printing Data Using the Portable Printer ........................................8
TRAKPRO™ Data Analysis Software ............................................... 8
CHAPTER 4 MAINTENANCE............................................................9
Recalibration...................................................................................9
Cases..............................................................................................9
Storage ...........................................................................................9
CHAPTER 5 TROUBLESHOOTING................................................ 11
APPENDIX A SPECIFICATIONS..................................................... 13
APPENDIX B DIP SWITCH SETTINGS...........................................17
iii
Chapter 1
Unpacking and Parts Identification
Carefully unpack the instrument and accessories from the shipping
container. Check the individual parts against the list of components below. If
anything is missing or damaged, notify TSI immediately.
1. Carrying case
2. Instrument
3. Static pressure tip
4. Rubber tubing
5. USB cable
6. CD-ROM with downloading software
7. AC adapter
1
Chapter 2
Setting-up
Supplying Power to the Model 9555 Series
The Model 9555 V
two ways: four size AA batteries or the AC adapter.
Installing the Batteries
Insert four AA batteries as indicated by the diagram located on the
inside of the battery compartment. The Model 9555 is designed to
operate with either alkaline or NiMH rechargeable batteries. Battery life
will be shorter if NiMH batteries are used. If NiMH batteries are used
the DIP switch will need to be changed. Refer to Appendix B,
Switch Settings. Carbon-zinc batteries are not recommended because of
the danger of battery acid leakage.
Using the AC Adapter
When using the AC adapter, the batteries (if installed) will be bypassed.
Be sure to provide the correct voltage and frequency, which is marked
on the back of the AC adapter.
Using The Telescoping Probe
The telescoping probe contains the velocity, temperature, and humidity
sensors. When using the probe, make sure the sensor window is fully
exposed and the orientation dimple is facing upstream.
ELOCICALC Air Velocity Meter can be powered in one of
DIP
NOTE: For temperature and humidity measurements, make sure that at
least 3 inches (7.5 cm) of the probe is in the flow to allow the temperature
and humidity sensors to be in the air stream.
Extending The Probe
To extend the probe, hold the handle in one hand while pulling on the
probe tip with the other hand. Do not hold the cable while extending the
probe as this prevents the probe from extending.
Retracting The Probe
To retract the probe, hold the handle in one hand while gently pushing
on the probe tip with the other hand. If you feel the probe antenna
binding, pull gently on the probe cable until the smallest antenna section
is retracted. Collapse the rest of the antenna by pressing the probe tip.
3
Connecting the Optional Bluetooth Portable Printer
To connect the Bluetooth printer to the Model 9555, power on the unit and
the printer. Then select the MENU soft key. From the Menu use the
S and T
keys to highlight Discover Printer and press the key. If other TSI Bluetoothprinters are in the area, turn them off before searching. The Model 9555 will
then search for and list all available Bluetooth devices. Select the device
”Handy700”.
If the Model 9555 has previously been connected to a TSI printer, then it
should automatically reconnect to that printer.
If the printer prints question marks (??????), asterisks (******), or random
characters, reset it by turning it off and then on again. If necessary, refer to
the Portable Printer Manual.
Connecting to a Computer
Use the Computer Interface USB Cable provided with the Model 9555 to
connect the instrument to a computer for downloading stored data or for
remote polling. Connect the end labeled “COMPUTER” to the computer
USB port and the other end to the data port of the Model 9555.
For more information on how to download stored data see Chapter 3 section
TrakPro™ Data Analysis Software.
titled
Caution: This symbol is used to indicate that the data port
of the Model 9555 is not intended for connection to a
public telecommunications network. Connect the USB
data port only to another USB port.
4 Chapter 2
Chapter 3
Operation
Keypad Functions
ON/OFF Key
Arrow (ST) Keys
(Enter) Key
Arrow (gor h) and
Menu Soft Keys
Common Terms
In this manual there are several terms that are used in different places. The
following is a brief explanation of the meanings of those terms.
Sample
Press to turn the Model 9555 on and off. During
the power up sequence the display will show the
following: Model Number, Serial Number,
Software Revision and Last Date Calibrated.
Press to scroll through choices while setting a
parameter. Pressing the
will lock the keypad to prevent unauthorized
adjustments to the instruments. To unlock the
keypad, press the
Press to accept a value or condition.
Press arrow keys to change choices while setting a
parameter. Press the Menu soft key to select the
Menu selections, which are Display Setup,
Pressure Zero, Settings, Flow Setup, Actual/Std
Set up, Data Logging, Applications, Calibration
and Printer.
Consists of all of the measurement parameters
stored at the same time.
ST keys simultaneously
ST keys simultaneously.
Test ID
A group of samples. The statistics (average,
minimum, maximum, and count) are calculated for
each test ID. The maximum number of test IDs is
100.
5
Time Constant
The time constant is an averaging period. It is used
to dampen the display. If you are experiencing
fluctuating flows, a longer time constant will slow
down those fluctuations. The display will update
every second, but the displayed reading will be the
average over the last time constant period. For
example, if the time constant is 10 seconds, the
display will update every second, but the displayed
reading will be the average from the last 10
seconds. This is also referred to as a “moving
average”.
Logging Interval
Menus
DISPLAY SETUP
Display setup menu is where you will setup the desired parameters to be
displayed on the running screen. With a parameter highlighted you can then
use the ON soft key to have it show up on the running screen or select the
OFF soft key to turn off the parameter. Use PRIMARY soft key to have a
parameter show up on the running screen in a larger display. Only one
parameter can be selected as a primary, and up to 4 secondary parameters
can be selected at one time.
PRESSURE ZERO
To zero the pressure reading, select the Pressure Zero menu. The instrument
will indicate if the pressure zero was successful.
SETTINGS
Settings menu is where you can set the general settings. These include
Language, Beeper, Select Units, Time Constant, Contrast, Set Time, Set
Date, Time Format, Date Format, Number Format, Backlight and Auto Off.
Use the g
key to accept settings.
or h soft keys to adjust the settings for each option and use the
The logging interval is a frequency period that the
instrument will log readings. For example, if the
logging interval is set to 30 minutes, each sample
will be the average of the last 30 minutes.
FLOW SET UP
In Flow Setup mode, there are 5 types: Round Duct, Rectangle Duct, Duct
Area, Horn and K-Factor. Use the g
types and then press the key to accept the desired type. To change the
value, highlight the Enter Settings option and press the key.
6 Chapter 3
or h soft keys to scroll through the
NOTE: The horn numbers are the models of the horns. For example, 100
refers to a horn model number AM 100. Only horns with Model
numbers as follows can be used with this function: AM 100,
AM 300, AM 600 and AM 1200. If a horn model number is chosen,
the instrument will return to measuring mode and use a
preprogrammed curve to calculate flow rate from velocity.
ACTUAL/STANDARD SETUP
Choose Actual/Standard measurements and parameters in the Act/Std Setup
menu. Within this menu, the user can also select Standard Temperature,
Standard Pressure and a source for the actual temperature. The Model 9555
measures the actual barometric pressure.
DATA LOGGING
Measurements
Measurements to be logged are independent of measurements on the
display, and must therefore be selected under DATA LOGGING Æ
Measurements.
Log Mode/Log Settings
You can set Log Mode to Manual, Auto-save, Cont-key, Cont-time,
Program 1 or Program 2.
• Manual mode does not automatically save data, but instead prompts
the user to save a sample.
• In Auto-save mode, the user manually takes samples that are
automatically logged.
• In Cont-key mode, the user starts taking readings and logging by
pressing the key. The instrument will continue taking
measurements until the key is pressed again.
• In Cont-time mode, the user starts taking readings by pressing the
key. The instrument will continue taking samples until a set period
of time has passed.
• Auto-save, Cont-Key and Cont-time modes have the following
additional Log Settings:
Log Settings
Mode
Auto-save Log Interval
Cont-key Log Interval
Cont-time Log Interval
Test Length
Operation 7
• Pressing the
ST keys simultaneously will lock the keypad to
prevent unauthorized adjustments to the instruments. To unlock the
keypad, press the
ST keys simultaneously.
Delete Data
Use this to delete all data, delete test or delete sample.
% Memory
This option displays the memory available. Delete All, under Delete
Data, will clear memory and reset the memory available.
APPLICATIONS
You can choose Draft Rate, Heat flow, Turbulence and % Outside Air in the
Applications menu. After choosing one of these applications, take
measurements or enter data for each line.
Printing Data Using the Portable Printer
To print logged data, first enter the DATALOGGING menu. Then, use the
CHOOSE TEST item to select the data to be printed. After the test is
selected, use the VIEW STATS and VIEW SAMPLES items to select
statistics or individual data points to view and print. After selecting VIEW
STATS or VIEW SAMPLES, press the PRINT key to print the data.
RAKPRO™ Data Analysis Software
T
The V
ELOCICALC Model 9555 comes with special software called
RAKPRO™ Data Analysis Software, which is designed to provide you with
T
maximum flexibility and power. To install this software on your computer,
follow the instructions on the label of the T
RAKPRO software.
Follow the instructions on the label of the T
software on your computer. T
RAKPRO software contains a very
RAKPRO software to install the
comprehensive Help Function. This utility provides all the necessary
information to guide you in all aspects of software operation. The software is
shipped on a CD-ROM. Updates are available from the TSI website at
http://software.tsi.com.
To download data from the Model 9555, connect the supplied computer
interface USB cable to the Model 9555 and to a computer USB port. Any
USB port from can be used.
8 Chapter 3
Chapter 4
Maintenance
The Model 9555 requires very little maintenance to keep it performing well.
Recalibration
To maintain a high degree of accuracy in your measurements, we
recommend that you return your Model 9555 to TSI for annual recalibration.
Please contact one of TSI’s offices or your local distributor to make service
arrangements and to receive a Return Material Authorization (RMA)
number. To fill out an online RMA form, visit TSI’s website at
http://service.tsi.com.
U.S. & International
TSI Incorporated
500 Cardigan Road
Shoreview MN 55126-3996
Tel: (800) 874-2811
(651) 490-2811
Fax: (651) 490-3824
The Model 9555 can also be recalibrated in the field using the
CALIBRATION menu. These field adjustments are intended to make minor
changes in calibration to match a user's calibration standards. The field
adjustment is NOT intended as a complete calibration capability. For
complete, multiple-point calibration and certification, the instrument must be
returned to the factory.
Cases
If the instrument case or storage case needs cleaning, wipe it off with a soft
cloth and isopropyl alcohol or a mild detergent. Never immerse the
Model 9555. If the enclosure of the Model 9555 or the AC adapter becomes
broken, it must be replaced immediately to prevent access to hazardous
voltage.
Storage
Remove the batteries when storing the unit for more than one month to
prevent damage due to battery leakage.
9
Chapter 5
Troubleshooting
Table 5-1 lists the symptoms, possible causes, and recommended solutions
for common problems encountered with the Model 9555. If your symptom is
not listed, or if none of the solutions solves your problem, please contact
TSI.
Table 5-1: Troubleshooting the Model 9555
Symptom Possible Causes Corrective Action
No Display Unit not turned on Switch unit on.
Low or dead batteries Replace batteries or plug
in AC adapter.
Dirty battery contacts Clean the battery
contacts.
Velocity reading
fluctuates unstable
No response to
keypad
Instrument Error
message appears
Fault in instrument Factory service required
Probe Error
message appears
Remove the probe from excessive temperature immediately:
excessive heat can damage the sensor. Operating temperature limits
can be found in Appendix A, Specifications. The pressure sensor is
protected from damage up to 7 psi (48 kPa or 360 mmHg). At higher
pressure it can burst!
Fluctuating flow Reposition probe in
less-turbulent flow or use
longer time constant.
Keypad locked out Unlock keypad by
pressing
simultaneously.
Memory is full Download data if desired,
then DELETE ALL
memory.
on instrument.
Fault in probe Factory service required
on probe.
ST keys
WARNING!
11
Appendix A
Specifications
Specifications are subject to change without notice.
Velocity (TA Probe):
Range: 0 to 9999 ft/min (0 to 50 m/s)
Accuracy
Resolution: 1 ft/min (0.01 m/s)
Velocity (Pitot Tube):
Range
Accuracy
Resolution: 1 ft/min (0.01 m/s)
Duct Size:
Range: 1 to 250 inches in increments of 0.1 in.
Volumetric Flow Rate:
Range: Actual range is a function of actual velocity, pressure, duct
Temperature (TA Probe):
Range: 14 to 140°F (-10 to 60°C)
Accuracy
Resolution: 0.1°F (0.1°C)
1&2
: ±3% of reading or ±3 ft/min (±0.015 m/s), whichever is
greater
3
: 250 to 15500 ft/min (1.27 to 78.7 m/s)
4
: ±1.5% at 2000 ft/min (10.16 m/s)
(1 to 635 cm in increments of 0.1 cm)
size, and K factor
5
: ±0.5°F (±0.3°C)
Relative Humidity(TA Probe):
Range: 0 to 95% RH
Accuracy
6
: ±3% RH
Resolution: 0.1% RH
Wet Bulb Temperature (TA Probe):
Range: 40 to 140°F (5 to 60°C)
Resolution: 0.1°F (0.1°C)
Dew Point (TA Probe):
Range: 5 to 120°F (-15 to 49°C)
Resolution: 0.1°F (0.1°C)
Heat Flow (TA Probe):
Range: Function of velocity, temperature, humidity, and
barometric pressure
Measurements available: Sensible heat flow, latent heat flow, total heat
flow and sensible heat factor
Units measured: BTU/hr, kW
13
Static / Differential Pressure:
7
: -15 to +15 in. H2O (-28.0 to +28.0 mm Hg, -3735 to +3735 Pa)
Range
Accuracy: ±1% of reading ±0.005 in. H
O (±1 Pa, ±0.01 mm Hg)
2
±0.02%/°F (±0.03%/°C)
Resolution: 0.001 in. H
O (1 Pa, 0.01 mm Hg)
2
Barometric Pressure:
Range: 20.36 to 36.648 in. Hg (517.15 to 930.87 mm Hg)
Accuracy: 2% of reading
Instrument Temperature Range:
Operating (Electronics): 40 to 113°F (5 to 45°C)
Operating (Probe): 14 to 140°F (-10 to 60°C)
Storage: -4 to 140°F (-20 to 60°C)
Instrument Operating Conditions:
Altitude up to 4000 meters
Relative humidity up to 80% RH, non-condensing
Pollution degree 1 in accordance with IEC 664
Transient over voltage category II
Data Storage Capabilities:
Range: 26,500+ samples and 100 test IDs (one sample can contain
fourteen measurement types)
Logging Interval:
Intervals: 1 second to 1 hour
Time Constant:
Intervals: User selectable
Response Time:
Velocity: 200 msec
Temperature: 2 minutes (to 66% of final value)
Pressure: 0.1 msec
Humidity: <1 minute (to 66% of final value)
External Meter Dimensions:
3.8 in. × 8.3 in. × 2.1 in. (9.7 cm × 21.1 cm × 5.3 cm)
Meter Probe Dimensions:
Probe length: 40 in. (101.6 cm)
Probe diameter of tip: 0.28 in. (7.0 mm)
Probe diameter of base: 0.51 in. (13.0 mm)
Articulating Probe Dimensions:
Articulating section length:
6.0 in. (15.24 cm)
Diameter of articulating knuckle: 0.38 in. (9.5 mm)
Meter Weight:
Weight with batteries: 0.8 lbs (0.36 kg)
14 Appendix A
Power Requirements:
Four AA-size batteries (included) or AC adapter (optional) 7.2 VDC,
300 mA, 4-18 watts (input voltage and frequency vary depending on which
adapter is used)
1
Temperature compensated over an air temperature range of 40 to 150°F (5 to 65°C).
2
The accuracy statement of ±3.0% of reading or ±3 ft/min (±0.015 m/s), whichever is greater,
begins at 30 ft/min through 9999 ft/min (0.15 m/s through 50 m/s).
3
Pressure velocity measurements are not recommended below 1000 ft/min (5 m/s) and are
best suited to velocities over 2000 ft/min. Range can vary depending on barometric
pressure.
4
Accuracy is a function of converting pressure to velocity. Conversion accuracy improves
when actual pressure values increase.
5
Accuracy with instrument case at 77°F (25°C), add uncertainty of 0.05°F/°F (0.03°C/°C) for
change in instrument temperature.
6
Accuracy with probe at 77°F (25°C). Add uncertainty of 0.1% RH/°F (0.2% RH/°C) for
change in probe temperature. Includes 1% hysteresis.
7
Overpressure range = 190 in. H2O (7 psi , 360 mmHg, 48 kPa).
Specifications 15
Appendix B
DIP Switch Settings
To access the DIP switch, remove the batteries from the battery
compartment. On the inside of the battery compartment, there is a window
with a single DIP switch (see Figure B-1). The table below shows the
functions for the switch.
Caution: Make certain that power is turned off before changing the
DIP switch settings.
Switch Function Settings
1 NiMH OFF: Alkaline Batteries
ON: NiMH Rechargeable Batteries
Figure B-1: DIP Switch Location
17
TSI Incorporated – 500 Cardigan Road, Shoreview, MN 55126 U.S.A
USA Tel: +1 800 874 2811 E-mail: info@tsi.com Website:
UK Tel: +44 149 4 459200 E-mail: tsiuk@tsi.com Website:
France Tel: +33 491 95 21 90 E-mail: tsifrance@tsi.com Website:
Germany Tel: +49 241 523030 E-mail: tsigmbh@tsi.com Website
Sweden Tel: +46 8 595 13230 E-mail: tsiab@tsi.com Website:
www.tsi.com
www.tsiinc.co.uk
www.tsiinc.fr
: www.tsiinc.de
www.tsi.se
India Tel: +91 80 41132470 E-mail: tsi-india@tsi.com
China Tel: +86 10 8260 1595 E-mail: tsibeijing@tsi.com
Contact your local TSI Distributor or visit our website www.tsi.com for more detailed specifications.
P/N 1980565 Rev D Copyright © 2007 by TSI Incorporated Printed in U.S.A.
Loading...
