TSI Incorporated Alnor TH710, AIRFLOW RH710 Operation And Service Manual

Indoor Air Quality

Thermohygrometer

Alnor® Model TH710

AIRFLOWTM Model RH710

Operation and Service Manual

Copyright©

TSI Incorporated / March 2007 / All rights reserved.

Address

TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA

Fax No.

[phone]

LIMITATION OF WARRANTY AND LIABILITY (effective July 2000)

Seller warrants the goods sold hereunder, under normal use and service as described in the
operator's manual, shall be free from defects in workmanship and material for twenty-four (24)
months, or the length of time specified in the operator's manual, from the date of shipment to the
customer. This warranty period is inclusive of any statutory warranty. This limited warranty is
subject to the following exclusions:
a. Hot-wire or hot-film sensors used with research anemometers, and certain other

components when indicated in specifications, are warranted for 90 days from the date of
shipment.

b. Parts repaired or replaced as a result of repair services are warranted to be free from

defects in workmanship and material, under normal use, for 90 days from the date of
shipment.

c. Seller does not provide any warranty on finished goods manufactured by others or on any

fuses, batteries or other consumable materials. Only the original manufacturer's warranty
applies.

d. Unless specifically authorized in a separate writing by Seller, Seller makes no warranty

with respect to, and shall have no liability in connection with, goods which are
incorporated into other products or equipment, or which are modified by any person other
than Seller.

The foregoing is IN LIEU OF all other warranties and is subject to the LIMITATIONS stated
herein. NO OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE OR MERCHANTABILITY IS MADE.

TO THE EXTENT PERMITTED BY LAW, THE EXCLUSIVE REMEDY OF THE USER OR
BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES,
INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED
ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL
BE THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE
PRICE, OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE
GOODS. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY SPECIAL,
CONSEQUENTIAL OR INCIDENTAL DAMAGES. SELLER SHALL NOT BE
RESPONSIBLE FOR INSTALLATION, DISMANTLING OR REINSTALLATION COSTS
OR CHARGES. No Action, regardless of form, may be brought against Seller more than 12
months after a cause of action has accrued. The goods returned under warranty to Seller's
factory shall be at Buyer's risk of loss, and will be returned, if at all, at Seller's risk of loss.

Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND
LIABILITY, which contains the complete and exclusive limited warranty of Seller. This
LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms
waived, except by writing signed by an Officer of Seller.

Service Policy

Knowing that inoperative or defective instruments are as detrimental to TSI as they are to our
customers, our service policy is designed to give prompt attention to any problems. If any
malfunction is discovered, please contact your nearest sales office or representative, or call
Customer Service department at [phone] (UK), [phone] (USA), or (1) 651­490-2811 (International).

CONTENTS

CHAPTER 1 UNPACKING AND PARTS IDENTIFICATION ............

CHAPTER 2 SETTING-UP................................................................. 3

Supplying Power to the Alnor TH710/AIRFLOW RH10 ....................3

Installing the Batteries ............................................................... 3

Using the Probe.........................................................................3

CHAPTER 3 OPERATION .................................................................5

Keypad Functions ........................................................................... 5

CHAPTER 4 MAINTENANCE............................................................7

Recalibration...................................................................................7

Cases..............................................................................................7

Storage ...........................................................................................7

CHAPTER 5 TROUBLESHOOTING.................................................. 9

APPENDIX A SPECIFICATIONS..................................................... 11

1

iii

Chapter 1

Unpacking and Parts Identification

Carefully unpack the instrument and accessories from the shipping
container. Check the individual parts against the list of components below. If
anything is missing or damaged, notify TSI immediately.

1. Carrying case

2. Instrument

1

Chapter 2

Setting-up

Supplying Power to the Alnor TH710/AIRFLOW RH10

The Alnor TH710/A

Installing the Batteries

Insert four AA batteries as indicated by the diagram located on the
inside of the battery compartment. The Alnor TH710/AIRFLOW RH10 is
designed to operate with either alkaline or NiMH rechargeable batteries,
although it will not recharge NiMH batteries. Battery life will be shorter
if NiMH batteries are used. Carbon-zinc batteries are not recommended
because of the danger of battery acid leakage.

Using the Probe

The sensing probe relies on the diffusion of air. For best results, try to
keep the sensing probe surrounded by moving air. Do not breathe on the
probe, since it may take time for the probe to re-stabilize.

IRFLOW RH10 is powered with four size AA batteries.

3

Chapter 3

Operation

Keypad Functions

ON/OFF Key

%RH Key

WB Key

°C Key

Changing Units

Press to turn the Alnor TH710/A
and off. During the power up sequence the display
will show the following: Model Number, Serial
Number, Software Revision and Last Date
Calibrated.

Pressing this key changes the display to read
relative humidity.

Pressing this key changes the display to read wet
bulb.

Pressing this key changes the display to read
temperature.

To change units for temperature and wet bulb,
press and hold the unlabelled soft key for 5
seconds to bring up a menu. Then use the
ENTER key to select the units as °C or °F.

IRFLOW RH10 on

ST and

5

Chapter 4

Maintenance

The Alnor TH710/AIRFLOW RH10 requires very little maintenance to keep it
performing well.

Recalibration

To maintain a high degree of accuracy in your measurements, we
recommend that you return your Alnor TH710/
annual recalibration. Please contact one of TSI’s offices or your local
distributor to make service arrangements and to receive a Return Material
Authorization (RMA) number. To fill out an online RMA form, visit TSI’s
website at

U.S. & International UK

TSI Incorporated
Alnor Products Lancaster Road
500 Cardigan Road Cressex Business Park
Shoreview MN 55126-3996 High Wycombe
Tel: [phone] Buckinghamshire
[phone] HP12 3QP England
Fax: [phone] Tel: [phone]
Fax: [phone]

Cases

If the instrument case or storage case needs cleaning, wipe it off with a soft
cloth and isopropyl alcohol or a mild detergent. Never immerse the Alnor
TH710/A
RH10, it must be replaced immediately to prevent access to hazardous
voltage.

http://service.tsi.com.

IRFLOW RH10. If the enclosure of the Alnor TH710/AIRFLOW

AIRFLOW RH10 to TSI for

TSI Instruments Ltd.

Storage

Remove the batteries when storing the unit for more than one month to
prevent damage due to battery leakage.

7

Chapter 5

Troubleshooting

Table 5-1 lists the symptoms, possible causes, and recommended solutions
for common problems encountered with the Alnor TH710/A
If your symptom is not listed, or if none of the solutions solves your
problem, please contact TSI.

Table 5-1: Troubleshooting the Alnor TH710/A

Symptom Possible Causes Corrective Action

No Display Unit not turned on Switch unit on.
Low or dead batteries Replace batteries or plug

Dirty battery contacts Clean the battery

Temp. initially
reads high or low

Humidity reading
near zero or not
believable
Instrument Error
message appears

Temperature sensor is
still adjusting to
temperature
Probe exposed to intense
light

Fault in instrument Factory service required

IRFLOW RH10

in AC adaptor.

contacts.
Allow sufficient time for
the temperature to
stabilize.
Shade the probe while
taking samples.

on instrument.

WARNING!

Remove the probe from excessive temperature immediately:
excessive heat can damage the sensor. Operating temperature limits
can be found in Appendix A, Specifications.

IRFLOW RH10.

9

Appendix A

Specifications

Specifications are subject to change without notice.

Temperature

Range 32 to 122°F (0 to 50°C)
Accuracy
Resolution 0.1°F (0.1°C)
Response time 30 seconds (90% of final value, air velocity at

Display units °F or °C (user selectable)
Type Thermistor

Humidity

Range 5 to 95% RH
Accuracy
Resolution 0.1% RH
Response time 20 seconds (for 63% of final value)
Sensor type Thin-film capacitive

Instrument Temperature Range:

Operating (Electronics): 40 to 113°F (5 to 45°C)
Operating (Probe): 14 to 140°F (-10 to 60°C)
Storage: -4 to 140°F (-20 to 60°C)

Instrument Operating Conditions:

Altitude up to 4000 meters
Relative humidity up to 80% RH, non-condensing
Pollution degree 1 in accordance with IEC 664
Transient over voltage category II

External Meter Dimensions:

4.2 in. × 7.2 in. × 1.5 in. (10.7 cm × 18.3 cm × 3.8 cm)

Meter Weight:

Weight With Batteries: 0.6 lbs (0.27 kg)

Meter Display Dimensions:

4-digit LCD, 0.6 inches (15 mm) digit height

1

1.0°F (±0.6°C)

2 m/s)

2

±3% RH (includes ±1% hysteresis.)

11

Power Requirements:

Four AA-size batteries (included)

1

Accuracy with instrument case at 77°F (25°C), add uncertainty of 0.05°F/°F (0.03°C/°C) for

change in instrument temperature.

2

Accuracy with probe at 77°F (25°C). Add uncertainty of 0.1% RH/°F (0.2% RH/°C) for

change in probe temperature. Includes 1% hysteresis.

12 Appendix A
