TSI Alnor IAQ-CALC-7515 Operating Manual

ENERGY AND COMFORT

Indoor Air Quality

IAQ-CALCTM

Indoor Air Quality Meter

Model 7515

Operation and Service Manual

Copyright©

TSI Incorporated / May 2007 / All rights reserved.

Address

TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA

Fax No.

[phone]

LIMITATION OF WARRANTY AND LIABILITY (effective July 2000)

Seller warrants the goods sold hereunder, under normal use and service as described in the
operator's manual, shall be free from defects in workmanship and material for twenty-four (24)
months, or the length of time specified in the operator's manual, from the date of shipment to the
customer. This warranty period is inclusive of any statutory warranty. This limited warranty is
subject to the following exclusions:
a. Hot-wire or hot-film sensors used with research anemometers, and certain other

components when indicated in specifications, are warranted for 90 days from the date of
shipment.

b. Parts repaired or replaced as a result of repair services are warranted to be free from

defects in workmanship and material, under normal use, for 90 days from the date of
shipment.

c. Seller does not provide any warranty on finished goods manufactured by others or on any

fuses, batteries or other consumable materials. Only the original manufacturer's warranty
applies.

d. Unless specifically authorized in a separate writing by Seller, Seller makes no warranty

with respect to, and shall have no liability in connection with, goods which are
incorporated into other products or equipment, or which are modified by any person other
than Seller.

The foregoing is IN LIEU OF all other warranties and is subject to the LIMITATIONS stated
herein. NO OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE OR MERCHANTABILITY IS MADE.

TO THE EXTENT PERMITTED BY LAW, THE EXCLUSIVE REMEDY OF THE USER OR
BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES,
INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED
ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL
BE THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE
PRICE, OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE
GOODS. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY SPECIAL,
CONSEQUENTIAL OR INCIDENTAL DAMAGES. SELLER SHALL NOT BE
RESPONSIBLE FOR INSTALLATION, DISMANTLING OR REINSTALLATION COSTS
OR CHARGES. No Action, regardless of form, may be brought against Seller more than 12
months after a cause of action has accrued. The goods returned under warranty to Seller's
factory shall be at Buyer's risk of loss, and will be returned, if at all, at Seller's risk of loss.

Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND
LIABILITY, which contains the complete and exclusive limited warranty of Seller. This
LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms
waived, except by writing signed by an Officer of Seller.

Service Policy

Knowing that inoperative or defective instruments are as detrimental to TSI as they are to our
customers, our service policy is designed to give prompt attention to any problems. If any
malfunction is discovered, please contact your nearest sales office or representative, or call
Customer Service department at [phone] (USA) or (1) 651-490-2811 (International).

CONTENTS

CHAPTER 1 UNPACKING AND PARTS IDENTIFICATION ............

CHAPTER 2 SETTING-UP................................................................. 3

Supplying Power to the Model 7515...............................................3

Installing the Batteries ............................................................... 3

Using the Integral Probe............................................................ 3

CHAPTER 3 OPERATION .................................................................5

Keypad Functions ........................................................................... 5

CHAPTER 4 MAINTENANCE............................................................7

Recalibration...................................................................................7

Cases..............................................................................................7

Storage ...........................................................................................7

CHAPTER 5 TROUBLESHOOTING.................................................. 9

APPENDIX A SPECIFICATIONS..................................................... 11

1

iii

Chapter 1

Unpacking and Parts Identification

Carefully unpack the instrument and accessories from the shipping
container. Check the individual parts against the list of components below. If
anything is missing or damaged, notify TSI immediately.

1. Carrying case

2. Instrument

3. Calibration collar

1

Chapter 2

Setting-up

Supplying Power to the Model 7515 IAQ-CALC Indoor Air Quality Meter

The Model 7515 is powered with four size AA batteries.

Installing the Batteries

Insert four AA batteries as indicated by the diagram located on the
inside of the battery compartment. The Model 7515 is designed to
operate with either alkaline or NiMH rechargeable batteries, although it
will not recharge NiMH batteries. Battery life will be shorter if NiMH
batteries are used. Carbon-zinc batteries are not recommended because
of the danger of battery acid leakage.

Using the Integral Probe

The sensing probe relies on the diffusion of air. For best results, try to
keep the sensing probe surrounded by moving air. Do not breathe on the
probe. Humans exhale CO
take time for the probe to re-stabilize.

levels exceeding 10,000 ppm and it may

2

3

Chapter 3

Operation

Keypad Functions

ON/OFF Key

Sample Key

Stats Key

CAL Key

Press to turn the Model 7515 on and off. During
the power up sequence the display will show the
following: Model Number, Serial Number,
Software Revision, and Last Date Calibrated.

Press and release to start the sample, then press the
END key to stop the sample.

Press to view the minimum, maximum and
average of the last sample taken.

Press to begin the field-calibration process. To re­calibrate in the field, first connect zero gas to the
instrument and open the regulator. Then use the

ST and ENTER keys to select ZERO. The

instrument will automatically make zero itself after
one minute.

After zeroing the sensor, connect span gas to the
instrument and open the regulator. Then use the

ST and ENTER keys to select SPAN. The

instrument will take one minute to make a reading.
Then use the
concentration displayed on the instrument to
match the concentration on the gas cylinder.

ST and ENTER keys to adjust the

5

Chapter 4

Maintenance

The Model 7515 requires very little maintenance to keep it performing well.

Recalibration

To maintain a high degree of accuracy in your measurements, we
recommend that you return your Model 7515 to TSI for annual recalibration.
Please contact one of TSI’s offices or your local distributor to make service
arrangements and to receive a Return Material Authorization (RMA)
number. To fill out an online RMA form, visit TSI’s website at

http://service.tsi.com.

U.S. & International

TSI Incorporated
500 Cardigan Road
Shoreview MN 55126-3996
Tel: [phone]
[phone]
Fax: [phone]

The Model 7515 can also be recalibrated in the field using the
CALIBRATION menu. These field adjustments are intended to make minor
changes in calibration to match a user's calibration standards. The field
adjustment is NOT intended as a complete calibration capability. For
complete, multiple-point calibration and certification, the instrument must be
returned to the factory.

Cases

If the instrument case or storage case needs cleaning, wipe it off with a soft
cloth and isopropyl alcohol or a mild detergent. Never immerse the
Model 7515. If the enclosure of the Model 7515, it must be replaced
immediately to prevent access to hazardous voltage.

Storage

Remove the batteries when storing the unit for more than one month to
prevent damage due to battery leakage.

7

Chapter 5

Troubleshooting

Table 5-1 lists the symptoms, possible causes, and recommended solutions
for common problems encountered with the Model 7515. If your symptom is
not listed, or if none of the solutions solves your problem, please contact
TSI.

Table 5-1: Troubleshooting the Model 7515

Symptom Possible Causes Corrective Action

No Display Unit not turned on Switch unit on.
Low or dead batteries Replace batteries.
Dirty battery contacts Clean the battery

contacts.

High CO2 levels Breathing on probe Shield probe from breath

and allow instrument to

re-stabilize.
Instrument Error
message appears

Remove the probe from excessive temperature immediately:
excessive heat can damage the sensor. Operating temperature limits
can be found in Appendix A, Specifications.

Fault in instrument Factory service required

on instrument.

WARNING!

9

Appendix A

Specifications

Specifications are subject to change without notice.

CO

:

2

Range: 0 to 5000 ppm
Accuracy
Resolution: 1 ppm
Sensor type: Non-Dispersive Infrared (NDIR)

Instrument Temperature Range:

Operating (Electronics): 40 to 113°F (5 to 45°C)
Storage: -4 to 140°F (-20 to 60°C)

Instrument Operating Conditions:

Altitude up to 4000 meters
Relative humidity up to 80% RH, non-condensing
Pollution degree 1 in accordance with IEC 664
Transient over voltage category II

External Meter Dimensions:

3.3 in. × 9.6 in. × 1.8 in. (8.4 cm × 24.4 cm × 4.4 cm)

Meter Weight:

Weight with batteries: 0.6 lbs (0.27 kg)

1

: ±3% of reading or ±50 ppm, whichever is greater

Meter Display Dimensions:

Primary display: 4-digit LCD, 0.6 in. (15 mm) digit height
Secondary display: 3.5-digit LCD, 0.3 in. (8 mm) digit height

Power Requirements:

Four AA-size batteries (included)

1

At 77°F (25°C). Add uncertainty of ±0.2%/°F (±0.2%/°C) away from calibrated temperature

11

TSI Incorporated – 500 Cardigan Road, Shoreview, MN 55126 U.S.A

USA Tel: [phone] E-mail: [e-mail] Website:
UK Tel: [phone] E-mail: [e-mail] Website:
France Tel: [phone] E-mail: [e-mail] Website:
Germany Tel: [phone] E-mail: [e-mail] Website
Sweden Tel: [phone] E-mail: [e-mail] Website:

www.tsi.com
www.tsiinc.co.uk
www.tsiinc.fr

: www.tsiinc.de

www.tsi.se

India Tel: [phone] E-mail: [e-mail]
China Tel: [phone] E-mail: [e-mail]

Contact your local TSI Distributor or visit our website www.tsi.com for more detailed specifications.
P/N 1980571 Rev B Copyright © 2007 by TSI Incorporated Printed in U.S.A.
