T&S Brass EC-EASYWIRE4CC User Manual

T&S BRASS AND BRONZE WORKS, INC.

2 Saddleback Cove / P.O. Box 1088

Travelers Rest, SC 29690

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com

This Space for Architect/Engineer Approval

Job Name__________________________Date_________

Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________

Model No.

EC-EASYWIRE4CC

Item No.

Female Plug Connects to ChekPoint
EasyWire AC Transformer or Other
ChekPoint EasyWire Connector Cables

Male Plugs Connect to ChekPoint
Control Modules and/or Other ChekPoint
EasyWire Connector Cables

NOTE:

ChekPoint EasyWire 4Ft. Connector Cables Can be Used to Connect up to 1.
(8) ChekPoint Electronic Faucets in a Daisy Chain Circuit
ChekPoint EasyWire 5Ft. Extension Cables (EC-EASYWIRE5EXT) are Also 2.
Available for Intermediate Connections Where More Length is Needed.
For Use with ChekPoint EasyWire Plug-in AC Transformer (EC-EASYWIRE)3.

Product Specifications:

ChekPoint EasyWire Connector Cable, 4 Feet Long

Drawn:

KJG

Checked:

Product Compliance:

JHBApproved:

Date:

06/04/15JRM of
