Swivel Gooseneck
w/ Serrated Tip
www.tsbrass.com
4-Arm Lab Handles w/
Color Coded Indexes
5 7/8"
[149mm]
4 1/2"
[115mm]
[51mm]
Inlets Adjustable from
1/2" NPT Female Inlet
2 1/4" to 8 1/4" cc
[57mm] to [210mm]
Below or Above Centerline
Product Specifications:
Wall Mount Polish Chrome Mixing Faucet w/ Adjustable
Inlet Arms & Swivel Gooseneck w/
Serrated Tip,& 4-Arm Lab Handles
2"
Drawn
ARH
Scale:
9"
[229mm]
Checked
DHL
1:4
10 15/16"
[278mm]
Approved
JHB
Date:
12/20/07
Sheet:
1
of
2
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
REG. #A2601
ISO #9001
Model No.
BL-5740-02
Item No.
Travelers Rest, SC: 800-476-4103
12
Simi Valley, CA: 800-423-0150
ITEM
NO.
1
2
3
4
5
6
7
8
9
10
11
12
SALES NO.
005960-40
000059-40
001191-45
001194-45
000925-45
001019-45
00GG
B-0198
009538-45
011429-45
001074-45
009641-45
Fax: 864-834-3518
Eterna Cartridge, Hot
4-Arm Lab Handle
Cap, Index, Green, Cold Water
Red HW Index
Lab Handle Screw
Washer, Coupling Nut
Flange Assembly, 1/2" NPT, Adjustable
Hose End, Serrated, Brass, PLTD
Swivel Washer
Swivel Sleeves (2)
O-Ring
Washer, 7/8" OD X 11/16 ID X 3/32 Thick
www.tsbrass.com
DESCRIPTION
8
9
11
10
4
1
1
6
7
2
5
3
Product Specifications:
Wall Mount Polish Chrome Mixing Faucet w/ Adjustable
Inlet Arms & Swivel Gooseneck w/
Serrated Tip,& 4-Arm Lab Handles
Drawn
ARH
Scale:
Checked
DHL
1:4
Approved
JHB
Date:
12/20/07
Sheet:
of
2
2
