Laboratory Products
TAG:
BL-5704-08WH4
Architect/Engineering Specifications:
Single hole deck mount mixing faucet with polished chrome plated brass body, polished chrome plated rigid nozzle with vacuum breaker and
serrated tip outlet, compression cartridges, 4” wrist action handles and 18” flexible stainless steel supply hoses with 1/2” NPSM / 5/8”
compression connections. ASME A112.18.1 / CSA B125.1 and ASSE 1001. Meets ADA ANSI/ICC A117.1 requirements.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
12 1/4"
311mm
153mm
5 11/16"
144mm
6"
2 3/8"
60mm
10 3/4"
274mm
Laboratory Double Ledge Faucet
[57mm]
Flange
Features & Benefits:
Single hole deck mount mixing faucet w/ polished chrome•
plated brass body
Polished chrome plated rigid nozzle w/ vacuum breaker &•
serrated tip outlet
Eterna compression cartridges•
4” wrist action handles w/ color coded indexes
•
•
18” flexible stainless steel supply hoses with 1/2” NPSM /
5/8” compression connections
Material: Polished chrome plated brass body & tubular
•
spout, polished chrome metal handles
Optional Handles
4" Wrist Action (Standard)
Lever
4-Arm
Optional Cartridges
Quarter Turn Cerama
Eterna (Standard)
Quarter Turn Eterna
2 1/4"
1 3/8"
34mm
Maximum
Thickness
Product Compliance:
ASM E A112.18.1 / CSA B125.1•
NSF 61 Exempt (Non-Potable)•
ASSE 1001 (VB)
•
ANSI A117.1 (ADA)
Warranty:
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
Flow Rate: 4.47 GPM @ 60 psi
•
One Year (Limited)
F - 140 F•
T&S BRASS AND BRONZE WO RKS, INC.
• 2 Saddleback Cove
Ph 800-476-4103
Simi Valley, CA
•
•
Travelers Rest, SC 29690
Fax 864-834-3518
Ph 800-423-0150 • www.tsbrass.com
•
•
•
Date:
04/25/15
