T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
B-WH4
4" Wrist Action Handles
w/ Color Coded Indexes
2-1/4"
[57mm]
Escutcheons
Simi Valley, CA: 800-423-0150
1-11/16"
[43mm]
Swivel
Deck
Flange
8"
[203mm]
Fax: 864-834-3518
Black & Chrome
Sides
pray
w/ Automatic
Diverter &
4' Under Counter
Flexible
Reinforced Hose
[101mm]
Mounting
Surface
www.tsbrass.com
8" Swing Nozzle
w/ 2.2 GPM Aerator
4"
[203mm]
Fits Sinks
Up To
1-1/4" Thick
[36mm]
1/2" NPSM
Coupling Nuts
REG. #A2601
ISO #9001
8"
Model No.
B-2347-02-WH4CR
Item No.
7 1/8"
[181mm]
Note: Rough-In Required:
1"[25mm] for Center Shank
1-1/2" [38mm] for Hot/Cold Side [1-1/4" [32mm] Minimum]
Product Specifications:
EasyInsta ll Faucet w/ 4' Sidespray, 4" Wrist
Action Handles, Cerama Cartridges, 8" Inlet Centers
& Swing Nozzle w/ 2.2 GPM Aerator
Drawn Checked
JRM
Scale:
KJG
NTS
Approved
JHB
Date:
09/21/09
Sheet:
of
1
2
T&S BRASS AND BRONZE WORKS, INC.
Travelers Rest, SC: 800-476-4103
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Simi Valley, CA: 800-423-0150
Fax: 864-834-3518
REG. #A2601
ISO #9001
www.tsbrass.com
Model No.
B-2347-02-WH4CR
Item No.
1
19
18
17
16
ITEM
NO.
SALES NO. DESCRIPTION
1 B-0199-01 2.2 GPM Aerator
2 001194-45 Red HW Index
3 017208-40 Center Body Diverter Asy
4 002338-45 Diverter
5 001686-45 Blue CW Index
6 000925-45 Lab Handle Screw
2
3
4
5
7 B-WH4 4" Wrist Action Handle
8 016742-45 Center Flange Nut
9 016745-45 Compression Nut & Fitting
10 016767-25
CWS Bonnet & LTC
Cerama Cartridge
11 016749-45 C-Washer
6
7
12 016777-45 CWS Hanger
13 001495-45 Side Spray
14 001496-45 Hose Guide
8
9
10
11
15 000958-20 Coupling Nut
16 016768-25
CWS Bonnet & RTC Cerama
Cartridge
17 016743-25 CWS Bonnet Assembly
18 009002-25 Packing Assembly
19 001257-40 Bell Escutcheon
12
15
13
Product Specifications:
EasyInstall Faucet w/ 4' Sidespray, 4" Wrist
Action Handles, Cerama Cartridge s, 8" Inlet Centers
& Swing Nozzle w/ 2.2 GPM Aerator
14
017245-40
Installation Repair Kit
Includes #8, (2)#11, & #12
Drawn
JRM
Scale:
Checked
KJG
Approved
Date:
NTS
JHB
09/21/09
Sheet:
2
of
2
