Pre-Rinse Units
B-2180
TAG:
Pre-Rinse Unit
Architect/Engineering Specifications:
8” wall mount mixing faucet with polished chrome plated bra ss body, add-on faucet with compression cartridge and lever handle, 18” swing nozzle
with stream regulator outlet, 18” riser, 44” flexible stainless steel hose with heat resistant handle, 1.42 GPM spray valve, compression cartridges
with spring checks, lever handles, 1/2" NPT female inlets, 12” adjustable wall bracket, spray valve holder, and overhead spring. Certified to ASME
A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF 372. EPAct 2005 compliant.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
18"
457mm
12 7/16"
316mm
Features & Benefits:
7 7/8"
201mm
14 1/16"
357mm
2 5/16"
59mm
2 3/8"
61mm
Product Compliance:
11 3/16"
284mm
37 7/16"
951mm
8” wall mount mixing faucet w/ polished chrome plated bra ss body•
Add-on faucet w/ polished chr ome plated brass body•
18” swing nozzle with stream regulator outlet, Series 1•
44” flexible stainless steel hose w/ heat resistant gray handle and hold•
down ring
1.42 GPM spray valve •
Eterna compression cartridges with internal spring checks to prevent cross•
flow of water
•
Lever handles w / color coded indexes
1/2" NPT female eccentric inlets with Ø 2" flanges
•
Adjustable centers from 7 3/4" to 8 1/4"
•
•
12” adjustable wall bracket
Material: Polished chrome plated brass body, riser and spray valve body,•
stainless steel hose & chrome plated metal handles
Optional Add-On Faucet Outlets (Series 1 / VR Series 6)
GPM
1.0
1.5
2.2
Aerated
B-0199-01-F10
B-0199-01-WS
B-0199-01
VR Aerated
B-0199-06-F10
B-0199-06-WS
B-0199-06
• ASME A112.18.1 / CSA B125.1
• NSF 61 - Section 9
• NSF 372 (Low Lead Content)
EPAct 2005 (PRSV)
•
Warranty:
Performance Data:
Optional Cartridges With Checks
Quarter Turn Cerama w/ Check Valve
Quarter Turn Eterna w/ Spring Check (Standard)
Optional Pre-Rinse Spray Valves
B-0107 (1.42 GPM) (Standard)
B-0107-C (0.65 GPM)
B-0107-J (1.07 GPM)
B-0108 (1.48 GPM)
B-0108-C (0.65 GPM)
One Year (Limited)
Pressure: 20 - 125 psi •
Temperature: 40
Flow Rate: •
Spray Valve: 1.42 GPM @ 60 psi
Add-On Faucet: 8.91 GPM @ 60 psi
F - 140 F•
Optional Handles
4" Wrist Action
Lever (Standard)
4-Arm
LOW
LEAD
COMPLIANT
T&S BRASS AND BRONZE WO RKS, INC.
2 Saddleback Cove
•
Simi Valley, CA
•
Travelers Rest, SC 29690
•
Ph 800-423-0150
•
Fax 864-834-3518• Ph 800-476-4103
www.tsbrass.com
•
Date:
08/10/15
