B-1125, B-1125-LN, B-1126,
B-1127, B-1128
Model B-1125-LN does not include nozzle
assembly (059X). Model B-1126 includes
8” nozzle (060X). Model B-1127 includes
10” nozzle (061X). Model B-1128
includes 12” nozzle (062X).
Faucet Assembly
1 Screw, Lever Handle 000922-45 9 Locknut 002954-45
2 Index, Button, Blue/Cold 001660-45 10 Asm, Swing Nozzle, 6" (B-1125) 059X
Index, Button, Red/Hot 001661-45 Asm, Swing Nozzle, 8" (B-1126) 060X
3 Handle, Lever 001638-45 Asm, Swing Nozzle, 10" (B-1127) 061X
4Asm, Spindle NSF - RH/Cold 009753-25 Asm, Swing Nozzle, 12" (B-1128) 062X
Asm, Spindle NSF - LH/Hot 009754-25 11 Washer 009538-45
5 Seat 000763-20 12 Sleeve 011429-45
6 Locknut, Cover Plate 000712-25 13 O-Ring 001074-45
7 Escutcheon, Body 001259-40 14 Knob 000082-40
8 Washer 000999-45
T&S Brass and Bronze Works, Inc. • Travelers Rest, South Carolina • 1-800-476-4103
