T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Model No.
B-1112-CR
Item No.
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
8 5/8"
219mm
6 1/2"
165mm
2"
51mm
This Space for Architect/Engineer Approval
Job Name
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
__________________________Date_________
Polished Chrome
Plated Escutcheon
061X-A22
10" Swing Nozzle
w/ 2.2 GPM Aerator
Swivel Joint
Converts to Rigid
w/ 014200-45
Lock Washer
Quarter-Turn Cerama
Cartridges w/ Check
Valves & Lever Handles
w/ Color Coded Indexes
(Included)
7 7/16"
189mm
3 1/4"
26mm
1"
4 5/16"
109mm
82mm
1/4"
6mm
Maximum
Thickness
4"
102mm
1"
25mm
1/2" NPT Male Inlets
Rough-In Requirement:
1" [25mm] Mounting Holes
(2)
Product Specifications:
4" Deck Mount Workboard Faucet, Quarter-Turn Cerama Cartridges w/ Check
Valves, Lever Handles, 10" Swing Nozzle, 2.2 GPM Aerator & 1/2" NPT Male
Inlets
10"
254mm
Mounting
Surface
(2)150A
Optional Tailpieces &
Nuts For 1/4" NPT
Connection (Included)
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Drawn: Approved:
KJG
Checked:
JHB
Date:
06/29/18MRC
Scale:
1:4 of
1Sheet:
2
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Model No.
B-1112-CR
Item No.
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
ITEM
NO.
SALES NO. DESCRIPTION
1 B-0199-01 2.2 GPM Aerator, 55/64"-27 UN Female
2 061X-A22 10" Swing Nozzle w/ 2.2 GPM Aerator
3 009538-45 Swivel Washer
2
4 011429-45 Swivel Sleeves (2)
5 001074-45 O-Ring
6 014200-45 Star Washer, Anti-Rotation
7 018506-19NS Blue Button Index, Press-in
3
4
1
5
6
19
7
18
17
8
9
10
8 000925-45 Lab Handle Screw
Quarter-Turn Cerama Cartridge w/
9 012447-25NS
Check Valve, Handle, Blue Index &
Screw, LTC
10 001638-45NS Lever Handle (New Style)
11 012395-25NS
Quarter-Turn Cerama Cartridge w/
Check Valve, LTC
12 019376-40 Escutcheon Lock Nut
13 019374-40 B-1110 Eterna Workboard Escutcheon
14 000999-45 Brass Lock Washer
15 002954-45 Shank Lock Nut
16 150A 1/4" NPT Tailpiece & Nut
17 012394-25NS
Quarter-Turn Cerama Cartridge w/
Check Valve, RTC
Quarter-Turn Cerama Cartridge w/
11
18 012446-25NS
Check Valve, Handle, Red Index &
Screw, RTC
19 001193-19NS Red Button Index, Press-in
12
13
14
15
16
Product Specifications:
4" Deck Mount Workboard Faucet, Quarter-Turn Cerama Cartridges w/ Check
Valves, Lever Handles, 10" Swing Nozzle, 2.2 GPM Aerator & 1/2" NPT Male
Inlets
KJG
Checked: Date:
MRC
Approved:Drawn:
06/29/18
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Scale:
NTS
of
2
2Sheet:JHB
