T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Model No.
B-0685
Item No.
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
3 3/4"
3 3/4"
95mm
95mm
± 1/8"
± 1/8"
B-0929
Vacuum
Breaker
Tee Handle & Mounting
Screw (Included)
B-0104
Wall Hook Outlet
Hold Down Ring &
Washer (Included)
B-0068-R
68" Reinforced PVC Hose
& Spray Valve w/ Extended
Nozzle
20 1/2"
20 1/2"
521mm
521mm
When Raised
When Raised
For Cleaning
For Cleaning
When Raised
When Raised
For Cleaning
For Cleaning
15 5/16"
15 5/16"
389mm
389mm
1 1/4"
32mm
2 1/8"
54mm
4 1/8"
105mm
8 3/4"
222mm
(See Note)
Floor
3/8" NPT
Female
Outlet
3/8" NPT
Female
Inlet
3/8" NPT
Female
Inlet
3/8" NPT
Female
Outlet
(2) Wood
Mounting
Screws
(Included)
1/2" NPT
Female
Inlet
Adjustable From 4 7/16" to 7"
Adjustable From 4 7/16" to 7"
[113mm to 178mm] When Valve Is
[113mm to 178mm] When Valve Is
Closed, 1 3/8" to 3 1/8 " [35mm to
Closed, 1 3/8" to 3 1/8 " [35mm to
79mm] When Valve is Open
79mm] When Valve is Open
Note: All Pedal Position Dimensions are Based
on Minimum Recommended Mounting Height of
8 3/4" [222mm] Above Finished Floors.
Product Specifications:
Bedpan Washer, Foot Valve Control, Integral Loose Key Stops, Vacuum
Breaker & Spray Valve w/ Extended Nozzle w/ 2.2 GPM Rosespray
Drawn: Approved:
MRC
Checked:
JHB
Date:
Product Compliance:
ASME A112.18.1 / CSA B125.1
ASSE 1001 (VB)
2019 DOE PRSV Non-Compliant
08/01/19JRM
Scale:
1:8
of
2
1Sheet:
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Model No.
B-0685
Item No.
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
ITEM
NO.
SALES NO. DESCRIPTION
1 002865-40 Extended Spray Wand
2 010476-45 #27 Washer
3 000907-45
Spray Valve Hold Down
Ring
4 B-0068-R 68" Reinforced PVC Hose
7
8
6 5
2
9
10
4
11
12
17
5
10
13
14
5 001019-45 Coupling Nut Washer
6 B-0929
7 B-0968
8 B-0104
Atmospheric Vacuum
Breaker
3/8" NPT Vacuum
Breaker
Wall Hook, 3/4-14 UN
Male Outlet
9 001605-45 Cap
10 166A
Service Stop Spindle w/
Tee Handle & Screw
11 000763-20 Seat
Loose Key 3/8" NPT
12 B-1355
Angle Stop w/ Tee Handle
& Screw
13 000356-45 Nipple, 3/8" NPT x 1 3/4"
14 002535-25 3/8" Close Nipple
15 001359-40
16 B-0508-01
Hex Bushing, 1/2" NPT
Male x 3/8" NPT Female
Wall Mount Single Pedal
Valve w/ Angle Stops
Loose Key 1/2" NPT
17 B-1351
5
Angle Stop w/ Tee Handle
& Screw
15
3
16
2
1
Product Specifications:
Bedpan Washer, Foot Valve Control, Integral Loose Key Stops, Vacuum
Breaker & Spray Valve w/ Extended Nozzle w/ 2.2 GPM Rosespray
MRC
Checked:
JRM Date:
Approved:Drawn:
Product Compliance:
ASME A112.18.1 / CSA B125.1
ASSE 1001 (VB)
2019 DOE PRSV Non-Compliant
08/01/19 Scale:
002432-45
T-Handle Screw
(2) 001802-45
T-Handle
NTS
of
2
2Sheet:JHB
