Service Sink / Mop Sink Faucets
TAG:
B-0674-RGH
Architect/Engineering Specifications:
8” wall mount mixing faucet with rough chrome plated brass body, rough chrome plated brass spout with vacuum breaker, pail hook and garden
hose male outlet, compression cartridges with spring checks, lever handles and 1/2” NPT female inlets. Certified to ASME A112.18.1/CSA
B125.1 and ASSE 1001. Meets ADA ANSI/ICC A117.1 requirements.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
27mm
3 7/8"
98mm
1 1/16"
3 11/16"
94mm
12 7/16"
315mm
Service Sink Faucet
Ø 2" [51mm]
Flanges
Features & Benefits:
8” wall mount mixing faucet with rough chrome plated •
brass body
Vacuum breaker spout with pail hook & 3/4” garden •
hose male outlet
Lever handles with color coded indexes•
Eterna cartridges with spring checks to prevent cross •
flow of water
1/2” NPT female eccentric inlets with Ø2” flanges•
Adjustable centers from 7 3/4” to 8 1/4”•
Material: Rough chrome plated brass body, spout & •
inlets and chrome plated metal handles
Optional Handles
4" Wrist Action
Lever (Standard)
4-Arm
Optional Cartridges With Checks
Quarter Turn Cerama w/ Check Valve
Quarter Turn Eterna w/ Spring Check (Standard)
2 3/8"
61mm
2 3/8"
Product Compliance:
• ASME A112.18.1 / CSA B125.1
• NSF 61 Exempt (Non-Potable)
•
ANSI A117.1 (ADA)
•
ASSE 1001 (VB)
Warranty:
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
• Flow Rate: 14.98 GPM @ 60 psi
One Year (Limited)
61mm
F - 140 F•
T&S BRASS AND BRONZE WO RKS, INC.
• 2 Saddleback Cove
Simi Valley, CA
•
Travelers Rest, SC 29690
•
• Ph 800-476-4103
Ph 800-423-0150
•
Fax 864-834-3518
www.tsbrass.com
•
Date:
04/10/15
