T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
REG. #A2601
ISO #9001
Model No.
B-0667-WW-POL
Item No.
Travelers Rest, SC: 800-476-4103
This Space for Architect/Engineer Approval
Job Name
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
__________________________Date_________
Simi Valley, CA: 800-423-0150
Variations or Applicable Options:
-WH6 6" Wrist Action Handles
-WH4 4" Wrist Action Handles
-175F 4-Arm Kitchen Handles
Fax: 864-834-3518
Support Rod,
Furnished w/
Wall Bracket &
Mounting Screws
Hot & Cold Spring
Check Cartridges
w/Lever Handles
and Color Coded
Indexes
www.tsbrass.com
Support Rod
Not Shown
14 3/4"
Wall
[376mm]
2 3/8"
[61mm]
Male Garden
Hose
Connection
2 15/16"
[74mm]
Product Specifications:
6 1/2"
[165mm]
Service Sink, Polished Chrome w/ Spring Check
Cartridges, Lever Handles & "00WW" 90° Mounting
Flanges
3 3/8"
[86mm]
Drawn
DHL
Scale:
Atmosheric
1/2" Vacuum
Breaker
Polished Chrome
Finish on Faucet
Body & Spout
Ø2"
[51mm] Flanges
w/ 1/2" NPT Female
Inlet Threads
Checked
WJS
1:4
Approved
JHB
Date:
12/01/06
Sheet:
of
1
2
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
REG. #A2601
ISO #9001
Model No.
B-0667-WW-POL
Item No.
Travelers Rest, SC: 800-476-4103
3
Simi Valley, CA: 800-423-0150
ITEM
NO.
1 002712-40
2 002711-40
3 009546-40
4 B-0969 Vacuum Breaker, 1/2"
5 002534-25
6 00WW
7 001019-45
4
Fax: 864-834-3518
www.tsbrass.com
SALES NO. DESCRIPTION
Spindle Asm, Hot Eterna
Spindle Asm, Cold Eterna
Rod Asm, Upper Support
Nipple, Rough Chrome 1/2" Close
Flange, 1/2" NPT 90° Female
Washer, Coupling Nut
Product Specifications:
5
6
7
1
2
Drawn
Checked
Approved
Service Sink, Polished Chrome w/ Spring Check
Cartridges, Lever Handles & "00WW" 90° Mounting
Flanges
DHL
Scale:
1:4
WJS
JHB
Date:
12/01/06
Sheet:
of
2
2
