T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
REG. #A2601
ISO #9001
Model No.
B-0665-BSTP-CVB
Item No.
Travelers Rest, SC: 800-476-4103
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Wall
Simi Valley, CA: 800-423-0150
Support Rod,
Furnished w/
Wall Bracket &
Mounting Screws
Fax: 864-834-3518
Hot & Cold Spring Check
Cartridges w/Lever Handles
and Color Coded Indexes
www.tsbrass.com
18"
[456mm]
1/2" NPT
Female
Inlets
Product Specifications:
3/8" NPT x
1/2" NPT
Reducer Elbow
8 7/8"
[224mm]
Male Garden
Hose Outlet
2.67
[68mm]
4 9/16"
[116mm]
Service Sink, Inlet Stops, Eterna Cartridges w/ Spring
Checks, Dual Check 3/8" NPT Vacuum Breaker Lever
Handles, Polished Chrome
Dual Check
3/8" NPT
Vacuum
Breaker
[197mm to 210mm]
Support Rod
Not Shown
8" [203mm] c/c
Adjustable from
7 3/4" to 8 1/4"
Drawn Checked
DHL
Scale:
DMH
1:4
Polished Chrome
Finish on Faucet
Body & Spout
Ø2"
[51mm]
Flanges
Integral
Service Stop
Approved
JHB
Date:
07/24/09
Sheet:
of
1
2
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
REG. #A2601
ISO #9001
Model No.
B-0665-BSTP-CVB
Item No.
Travelers Rest, SC: 800-476-4103
1
2
3
7
8
Simi Valley, CA: 800-423-0150
ITEM NO. SALES NO. DESCRIPTION
1 009546-40
2 009545-40
3 001661-45 Red Index-HW
4 001638-45 Lever Handle
5 012443-40
6 002712-40
7 B-0975 Dual Check Valve VB
8 000922-45 Lever Handle Screw
9 163A BST Assembly, 163A
10 001660-45 Blue Index-CW
11 002711-40
12 012442-40
13 00AA
14 001019-45 Coupling Nut Washer
Fax: 864-834-3518
www.tsbrass.com
SUPRT ROD B-665 - POLISH
CHROME
Spout w/ Clevis - Polished
Chrome
Hot Eterna Spindle Assembly w/
Spring Check
Hot Eterna Spindle Assembly w/
Spring Check, Handle, Index &
Screw
Hot Eterna Spindle Assembly w/
Spring Check, Handle, Index &
Screw
Cold Eterna Spindle Assembly w/
Spring Check
Coupling Flange Assembly w/
Washer
4
5
6
Product Specifications:
Service Sink, Inlet Stops, Eterna Cartridges w/ Spring
Checks, Dual Check 3/8" NPT Vacuum Breaker Lever
Handles, Polished Chrome
10
11
12
13
9
14
Drawn
DHL
Scale:
Checked
DMH
1:4
Approved
JHB
Date:
07/24/09
Sheet:
of
2
2
