Wok Wand Faucets
TAG:
B-0577-09
Architect/Engineering Specifications:
Back mounted range faucet with chrome plated brass body, swing nozzle with 2.2 GPM aerator, 1/2” NPSM male inlet, stainless steel
escutcheon and on-off control actuated when nozzle swings to right or left. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and
NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
1 5/16"
33mm
10 7/16"
265mm
8 7/8"
225mm
1 1/4"
32mm
Chinese Range Faucet
2 9/16"
65mm
•
•
•
•
•
•
GPM
0.35
0.5
1.0
1.5
2.2
2 1/16"
52mm
Features & Benefits:
Back mounted range faucet w/ swing nozzle
On-off control actuated when nozzle swings to right or left
2.2 GPM aerator, Series 1 (B-0199-01)
1/2” NPSM male inlet
Ø2 1/2” escutcheon
Material: Polished chrome plated brass and stainless
steel escutcheon
Optional Outlets (Series 1 / VR Series 6)
Aerated
N/A
N/A
B-0199-01-F10
B-0199-01-WS
Non-Aerated
(Laminar)
B-0199-01-N035
B-0199-01-N05
N/A
B-0199-29
B-0199-21
VR Aerated
N/A
N/A
B-0199-06-F10
B-0199-06-WS
B-0199-06 Standard
2 1/2"
64mm
Product Compliance:
• ASME A112.18.1 / CSA B125.1
• NSF 61 - Section 9
NSF 372 (Low Lead Content)
•
ANSI A117.1 (ADA)
•
Warranty:
Performance Data:
• Flow Rate: 2.2 GPM @ 60 psi
VR Non-Aerated
(VR Laminar)
B-0199-06-N035
B-0199-06-N05
N/A
B-0199-29VR
B-0199-21-VRF
One Year (Limited)
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
T&S BRASS AND BRONZE WO RKS, INC.
• 2 Saddleback Cove
Simi Valley, CA
•
Travelers Rest, SC 29690
•
• Ph 800-476-4103
Ph 800-423-0150
•
Fax 864-834-3518
www.tsbrass.com
•
Date:
12/21/15
