Foot Pedal Valves
TAG:
B-0508
Architect/Engineering Specifications:
Wall mounted single pedal valve with chrome plated solid bras s body, adjustable height aluminum pedal, self-clo sing valve, 1/2” NPT female
inlet and outlet and mounting screws. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF 372.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
3 5/8"
222mm
Minimum
92mm
20 7/16"
477mm
Maximum
8 3/4"
Single Pedal Valve
Floor
Features & Benefits:
Wall mounted single pedal valve •
Adjustable heig ht blank pedal•
Pedal flips up for floor cleaning•
Self-closing v alve•
1/2” NPT female loose key angle stop inlet•
Includes mounting screws
•
Material: Polished chrome brass body, satin finish
•
aluminum pedal
Optional Cartridges
Metering Cartridge
14 5/8"
372mm
Product Compliance:
• ASME A112.18.1 / CSA B125.1
• NSF 61 - Section 9
• NSF 372 (Low Lead Content)
Warranty:
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
Flow Rate: 4.92 GPM @ 60 psi •
One Year (Limited)
F - 140 F•
T&S BRASS AND BRONZE WO RKS, INC.
Travelers Rest, SC 29690 • 2 Saddleback Cove
•
Ph 800-476-4103
Simi Valley, CA www.tsbrass.com
•
Ph 800-423-0150
•
• Fax 864-834-3518
•
Date:
03/17/15
