Medical And Lavatory Faucets
TAG:
B-0330-04
Surgical Sink Faucet
Architect/Engineering Specifications:
8” wall mount mixing faucet with polished chrome plated brass body, 5 1/2” spread rigid gooseneck with stream regulator outlet,
compression cartridges, 4” wrist action handles and 1/2” NPT female inlets. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9
and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
16"
406mm
5 1/2"
140mm
10 7/8"
277mm
5 3/8"
136mm
5 7/8"
149mm
Features & Benefits:
8” wall mount mixing faucet with polished chrome plated•
brass body
•
5 1/2” spread rigid gooseneck
•
Stream regulator outlet, Series 2
Eterna compression cartridges
•
•
4” wrist action handle w/ color coded indexes
•
1/2” NPT female eccentric inlets w/ Ø2” flanges
Adjustable centers from 7 3/4” to 8 1/4”
•
•
Material: Polished chrome plated brass body &
tubular spout and chrome plated metal handles
Aerated
GPM
N/A
0.35
N/A
0.5
1.0
1.5
2.2
B-0199-02-F10
B-0199-02-WS
B-0199-02
Optional Outlets (Series 2 / VR Series 7)
Non-Aerated
(Laminar)
B-0199-02-N035
B-0199-02-N05
N/A
N/A
N/A
VR Aerated
N/A
N/A
B-0199-07-F10
B-0199-07-WS
B-0199-07
2 3/8"
61mm
Product Compliance:
•
ASME A112.18.1 / CSA B125.1
• NSF 61 - Section 9
•
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Warranty:
One Year (Limited)
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
•
Flow Rate: 23.09 GPM @ 60 psi
F - 140 F•
VR Non-Aerated
(VR Laminar)
B-0199-07-N035
B-0199-07-N05
N/A 4-Arm
N/A
N/A
Optional Cartridges
Quarter Turn Cerama
Eterna (Standard)
Quarter Turn Eterna
Push Button Metering
Pivot Action Metering
Optional Handles
4" Wrist Action (Standard)
Lever
Wrist Action Metering
LOW
LEAD
COMPLIANT
T&S BRASS AND BRONZE WO RKS, INC.
• 2 Saddleback Cove
Simi Valley, CA
•
Travelers Rest, SC 29690
•
Fax 864-834-3518
Ph 800-423-0150 • www.tsbrass.com
•
• Ph 800-476-4103
•
Date:
02/06/15
