T&S Brass B-0308-QT-VWS PARTS LIST

T&S BRASS AND BRONZE WORKS, INC.

2 Saddleback Cove / P.O. Box 1088

Travelers Rest, SC 29690

Model No.

B-0308-QT-VWS

Item No.

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com

3 5/16"

84mm

Swivel Gooseneck w/

B-0199-06-WS

This Space for Architect/Engineer Approval

Job Name

Model Specified_____________________ Quantity______

Customer/Wholesaler______________________________

Contractor_______________________________________

Architect/Engineer_________________________________

__________________________Date_________

5 3/4"

145mm

1.5 GPM
Vandal Resistant Aerator
Rigid Conversion
Requires 014200-45
Lock Washer (Included)

Quarter-Turn Eterna Cartridge
w/ Spring Check &
Lever Handle & Color
Coded Index

13 15/16"

354mm

2 7/16"

62mm

2 5/8"

66mm

Ø 2" [51mm] Flange
w/ 1/2" NPSM Shank

Mounting Surface

150A

Optional Tailpiece &
Nut For 1/4" NPT
Connection

Rough-In Requirement:

(Included)

Ø 1" [25mm] Mounting Hole

Product Specifications:

Single Hole Single Temperature Deck Mount Faucet, Quarter-Turn Eterna
Cartridge w/ Spring Check, Lever Handle, 5 3/4" Swivel/Rigid Gooseneck w/

1.5 GPM Vandal Resistant Aerator & 1/2" NPSM Male Inlet

9 1/2"

241mm

Product Compliance:

ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)

1 5/8"

41mm

Maximum

Thickness

Drawn: Approved:

MRC

Checked:

JHB

Date:

03/01/18JRM

Scale:

1:5

of

2

1Sheet:

T&S BRASS AND BRONZE WORKS, INC.

2 Saddleback Cove / P.O. Box 1088

Travelers Rest, SC 29690

Model No.

B-0308-QT-VWS

Item No.

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com

ITEM

NO.

1 B-0199-06-WS

SALES NO. DESCRIPTION

VR 1.5 GPM Aerator, 55/64-27 UN

Female w/ Key
2 009538-45 Swivel Washer
3 011429-45 Swivel Sleeves (2)
4 001074-45 O-Ring

5 014200-45 Star Washer, Anti-Rotation

Quarter-Turn Eterna Cartridge RTC w/
6 019639-40

Spring Check, Handle, Blue Index &

Screw

7 012443-40NS

1

8 001638-45NS Lever Handle (New Style)

9VRS-2

Quarter-Turn Eterna Cartridge w/ Spring

Check, RTC

VR Wrist Action Handle Screw (2) w/

Spanner Bit

10 018506-19NS Blue Button Index, Press-in

2

11 000999-45 Brass Lock Washer
12 002954-45 Shank Lock Nut

13 150A 1/4" NPT Tailpiece & Nut

3

11

12

13

4

5

014075-45

#10 Spanner Bit

6

8 10

7

9

015425-45

VR Aerator Key

Product Specifications:

Single Hole Single Temperature Deck Mount Faucet, Quarter-Turn Eterna
Cartridge w/ Spring Check, Lever Handle, 5 3/4" Swivel/Rigid Gooseneck w/

1.5 GPM Vandal Resistant Aerator & 1/2" NPSM Male Inlet

MRC

Checked:

JRM

Approved:Drawn:

Date:

03/01/18 Scale:

Product Compliance:

ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)

NTS

of

2

2Sheet:JHB
