Big-Flo Faucets
TAG:
B-0293-01
Architect/Engineering Specifications:
8" deck mount large flow mixing faucet with polished chrome plated brass body, 12" swing nozzle with plain end outlet, compression spindles,
4-arm handles, 3/4" NPT female inlets and 3/4" NPT supply nipples. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF
372. Meets ADA ANSI/ICC A117.1 requirements.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
10 5/8"
270mm
12"
305mm
Big-Flo Mixing Faucet
2 1/2"
64mm
6 5/16"
160mm
Features & Benefits:
8" deck mount Big-Flo mixing faucet with polished •
chrome plated brass body
12” Big-Flo plain end swing nozzle•
Big-Flo compression spindles•
4-arm handles w/ color coded indexes•
3/4" NPT female inlets w/
3/4" NPT suppy nipples•
•
Material: Polished chrome plated brass body &
tubular spout and chrome plated metal handles
10 5/16"
262mm
6 11/16"
169mm
Product Compliance:
• ASME A112.18.1 / CSA B125.1
•
NSF 61 - Section 9
NSF 372 (Low Lead Content)
•
ANSI A117.1 (ADA)
•
2" flanges•
Warranty:
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40 F - 140 F•
Flow Rate: 44.27 GPM @ 60 psi •
One Year (Limited)
2 1/4"
57mm
LOW
LEAD
COMPLIANT
T&S BRASS AND BRONZE WO RKS, INC.
• 2 Saddleback Cove
Ph 800-476-4103
Simi Valley, CA
•
•
Travelers Rest, SC 29690
Ph 800-423-0150
•
Fax 864-834-3518•
www.tsbrass.com
•
Date:
12/21/15
