Big-Flo Faucets
TAG:
B-0291
Architect/Engineering Specifications:
8” wall mount large flow mixing faucet with polished chrome plated brass body, 18” swing nozzle with plain end outlet, compression
spindles, 4-arm handles, 3/4” NPT female inlets and 3/4” NPT female short inlet elbows. Certified to ASME A112.18.1/CSA B125.1, NSF
61-Section 9 and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
Job Name__________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
Date______________________________________
10 5/8"
270mm
4 1/16"
104mm
10 3/16"
258mm
6 1/2"
166mm
18"
457mm
Big-Flo Mixing Faucet
2 1/2"
64mm
2"
[51mm]
1 15/16"
49mm
2"
[51mm]
Features & Benefits:
8” wall mount Big-Flo mixing faucet w/ polished chrome •
plated brass body
18” Big-Flo plain end swing nozzle•
Big-Flo compression spindles•
4-arm handles w/ color coded indexes•
3/4” NPT female eccentric inlets w/ Ø 2” flanges•
Adjustable centers from 7 3/4" to 8 1/4“•
3/4” NPT female short inlet elbows •
•
Material: Polished chrome plated brass body &
tubular spout and chrome plated metal handles
Product Compliance:
•
ASME A112.18.1 / CSA B125.1
• NSF 61 - Section 9
•
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Warranty:
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
Flow Rate: 44.27 GPM @ 60 psi
•
One Year (Limited)
F - 140 F•
T&S BRASS AND BRONZE WO RKS, INC.
• 2 Saddleback Cove
Ph 800-476-4103
Simi Valley, CA
•
Travelers Rest, SC 29690
•
•
Ph 800-423-0150 • www.tsbrass.com
•
Fax 864-834-3518
•
Date:
02/02/15
