T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
Model No.
B-0133-CR-V-BCE
Item No.
This Space for Architect/Engineer Approval
Job Name
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
__________________________Date_________
44" Flex Hose w/
Overhead Spring &
Spray Valve Assembly
Spray Valve,
44" Flex Hose
& Spring not
Shown for Clarity
004R
Finger Hook
3/8" NPT x 18"
Riser
B-0107-C
Spray Valve
0.65 GPM
EPAct2005 COMPLIANT
B-0109-01
6" Wall
Support
37"
940mm
B-0970-FEZ
Vacuum Breaker
EasyInstall
Lock Nut &
Bushing
Cerama Cartridges
w/ Check Valves
& Lever Handles
w/ Color Coded
Indexes
6 3/8"
162mm
2"
8"
203mm
Adjustable from
7 3/4" to 8 1/4"
[51mm]
Flanges w/
1/2" NPT
Female Inlets
[197mm to 210mm]
Product Specifications:
EasyInstall Pre-Rinse Unit:
8" c/c Wall Mount Mixing Faucet, Cerama w/ Check Valves,
18" Riser, 44" Flex Hose, 6" Wall Bracket, Vacu um Breaker,
Installation Kit, & B-0107-C Spray Valve
2 3/8"
61mm
14 1/8"
358mm
Mounting
Surface
(2) B-0230-K
Short Elbow Installation Kit
w/ 1/2" NPT Male Inlets
Drawn
KJG
Scale:
Checked
GEF
Approved
Date:
1:8
JHB
11/28/11
Sheet:
of
1
2
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
ITEM
NO.
7
2
10 B-0109-01 6" Wall Bracket Assembly
8
6
9
10
11 000369-40 3/8" NPT x 18" Long Riser
12 B-0970-FEZ Easy-Install Vacuum Breaker
13 014200-45 Star Washer, Anti-Rotation
14 000922-45 Lever Handle Screw
15 001660-45 Blue Index-CW
SALES NO. DESCRIPTION
1 B-0107-C 0.65 GPM Spray Valve
2 010476-45 #27 Washer
3 000907-45 Spray Valve Hold Down Ring
4 002987-40 Grip Handle Assembly
5 001014-45 Washer, B-0100 Hose Barrel
6 B-0044-H2A 44" SS Flex Hose w/o Handle
7 000888-45 EasyInstall Overhead Spring
8 000821-40 Spring Body
9 004R Finger Hook Assembly
Model No.
B-0133-CR-V-BCE
Item No.
16 001638-45 Lever Handle
5
11
4
3
12
2
1
24
13
14
15
16
1723
17 012395-25
18 B-0230-K Short Elbow Installation Kit
19 002954-45 Shank Lock Nut
20 000999-45 Brass Lock Washer
21 00AA Coupling Flange Assembly
22 001019-45 Coupling Nut Washer
23 012394-25
24 001661-45 Red Index-HW
181920
Cerama Cartridge, LTC w/ Check
Valve
Cerama Cartridge, RTC w/ Check
Valve
21
22
Product Specifications:
EasyInstall Pre-Rinse Unit:
8" c/c Wall Mount Mixing Faucet, Cerama w/ Check Valves,
18" Riser, 44" Flex Hose, 6" Wall Bracket, Vacu um Breaker,
Installation Kit, & B-0107-C Spray Valve
Drawn
KJG
Scale:
Checked
NTS
GEF
Approved
JHB
Date:
11/28/11
2Sheet:
of 2
