T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
This Space for Architect/Engineer Approval
Model No.
B-0044-RV9
Item No.
Job Name
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
__________________________Date_________
3/4-14 UN
Female Outlet
(2) 010476-45
Washers
(Included)
9 1/4"
235mm
3/4-14 UN
Female Inlet
(2) 053A
Adapters
Product Specifications:
44" Reinforced PVC Hose w/ Vacuum Breaker
B-0970-FE
Continuous Pressure
Atmospheric Vacuum
Breaker
44"
[1117mm]
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
CSA B64.8 (VB)
Drawn:
KJG
Checked:
Approved:
JHB
Date:
07/09/19JRM
Scale:
1:4
Sheet:
of
2
1
Page 2
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
ITEM
NO.
1 010476-45 #27 Washer
1
2 053A Adapter, 3/8" NPT x 3/4-14 UN Male
3 B-0970-FE 3/8" NPT Vacuum Breaker
1
SALES NO. DESCRIPTION
Model No.
B-0044-RV9
Item No.
1
2
3
2
1
Product Specifications:
44" Reinforced PVC Hose w/ Vacuum Breaker
Drawn: Approved:
KJG
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
CSA B64.8 (VB)
Date:Checked:
Scale:
NTS
Sheet:
of
2
2
