2 5/16"
59mm
5SP-05C
equip 5 13/16" Swivel Gooseneck
w/ Laminar Flow Device.
Rigid Conversion Requires
014200-45 Lock Washer
(Sold Separately)
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Model Number
5F-1WLB05C
Product Compliance:
Ceramic Cartridge w/
equip Lever Handle
1 15/16"
50mm
Product Specifications:
6 1/4"
159mm
5 13/16"
148mm
1 5/8"
10 5/16"
262mm
41mm
1/2" BSPP
Male Inlet
5/8"
16mm
Single Supply Wall Mount Faucet w/ Ceramic Cartridge,
Lever Handle, 5 13/16" Swivel Gooseneck & 1/2" BSPP Male Inlet
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Drawn:
equip
Foodservice
Accessories
Approved:MRC
JHB
by
09/17/19
2 Saddleback Cove, P.O. Box 1088
Travelers Rest, South Carolina 29690
Phone: 800.891.4808 Fax: 800.868.0084
Scale:JRM Date:Checked:
equip.tsbrass.com
1:4
Sheet: 1
of
2
ITEM
NO.
SALES NO. DESCRIPTION
1 5SP-05C 5 13/16" equip Swivel Gooseneck
2 014250-45 Laminar Full Flow Outlet Device
3 013839-25 equip Swivel Nut
4 013848-45 Swivel O-Ring (10)
5 019047-45 Supply Nipple, 1/2" NPT x 1/2" BSPP
6 013849-45 Screw, 4mm Metric (10)
7 5-HDL-L equip Lever Handle
8 013787-45 equip Ceramic Cartridge, RTC
2
1
3
4
5
8
7
6
Model Number
5F-1WLB05C
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Drawn:
MRC
Product Specifications:
Single Supply Wall Mount Faucet w/ Ceramic Cartridge,
Lever Handle, 5 13/16" Swivel Gooseneck & 1/2" BSPP Male Inlet
equip
Foodservice
Accessories
JRMChecked:
Approved:
JHB
Date:
by
09/17/19
2 Saddleback Cove, P.O. Box 1088
Travelers Rest, South Carolina 29690
Phone: 800.891.4808 Fax: 800.868.0084
Scale:
equip.tsbrass.com
NTS 2
of
2Sheet:
