TT-820
Precision OD Grinder
Quick Set-Up
•
Precision
•
Profiles with
Standard 1A1 Wheel
Easy Pick-N-Place
•
Programming
Optional Telescoping Splash Doors
EASY TO PROGRAM PRECISION O.D. GRINDING
TRU TECH continues the precision
round grinding industrial revolution with
the TT-820 Precision OD Grinder.
Equipped with the TRU TECH Pick-NPlace
are programmed in minutes, optimizing
your productivity and dramatically
increasing your grinding capabilities.
Intuitive Pick-N-PlaceTM software makes programming each
part a quick, simple task. Simply drag move icons into place,
edit their values and start grinding.
TM
software, shapes and profiles
Built-in training and maintenance
modules dramatically reduce cost of
ownership.
Available options include precision
probing, ID spindle attachment,
telescoping safety splash doors, oil
filtration to 1-micron, and precision oil
chiller.
Page 2
TT-820 SPECIFICATIONS
Maximum Grind Length (Distance Between Centers)
20”
Maximum Grind Diameter
8”
Maximum Travel
X Axis
Y Axis
20”
8”
Standard Wheel Size
14” Max.
Wheel Speed
500-3000 RPM
Maximum Velocity
Y Axis
Z Axis
50”/Min.
60”/Min.
Input Increment
.000010”
Accuracy
±.00010”
Repeatability
±.000050”
Wheel Spindle Motor
5 HP Variable
Workhead Motor HP
5C Taper
1/4
50-600 RPM
Workhead Angle Adjustment
±45 Degrees
Table Angle Adjustment
±8 Degrees
ID Spindle Motor
1/2 HP
Power Requirements
30 Amps
208-230V 60 Hz
Shipping Dimensions
Pallet #1
Pallet #2
40”x48”x60”
91”x90”x65”
Shipping Weight
4500 LBS.
TT-820
4'
9'
FRONT
7' Min.
18" Min.
11' Min.
Console
Optional Overhead
Probing accurately
adjusts for variations
in length and part
orientation.
Optional 5 Micron
filtration ensures
maximum precision.
All photographs may include non-standard or optional features. For specific needs, please contact your local Tru Tech Systems distributor, or Tru Tech Systems, direct.
Toll Free: (877) TRU-TECH ● Phone: 586 469-2700 ● Fax: 586 469-1344
P.O. Box 46965 ● Mt. Clemens, MI 48046 ● www.trutechsystems.com
Floor Layout
TRU TECH SYSTEMS, INC.
Page 3
TT-820 Options & Accessories
5 Micron Ebbco Filtration (24” Wide Tank & Dual Pump)
•
Ebbco 5 Micron Replacement Filters (Sold by the case)
•
Ebbco Chiller (8,000 BTU or 12,000 BTU)
•
High Precision Dual Axis Scales
•
Dressing Block w/ (2) Diamonds
•
Steady Rest (2 or 3 Point)
•
Renishaw Probe
•
ID Grinding Attachment (40,000 RPM)
•
Rotary Dress w/ (1) Roll
•
Air Operated 5C Collet w/ Hand Operated Valve
•
Manual Pulse Generator
•
5” Wheel Flange w/ (1) Spacer
•
Balancing Stands
•
Telescoping Safety Door
•
Telescoping Safety Door w/ Interlock
•
480 Volt Upgrade
•
On-Site Training at Your Facility
•
