TRANSMITTER APIR-2150
Item 71091 Version 1.0
Visit www.trustsmarthome.com
for the latest instructions
WIRELESS MOTION SENSOR
USER MANUAL
MULTI LANGUAGE
Page 2
2
4
1
3
♫
Page 3
6
8
5
7
Page 4
9
11
10
Page 5
APIR-2150 WIRELESS MOTION SENSOR
1
1. Open sensor housing
Remove the screws to open the battery compartment.
2. Install transmitter batteries
Place 2x 1,5V AAA alkaline batteries in the battery compartments. The polarity should match the
symbols on the holder.
3. Assign code to a Trust SmartHome receiver
Program the code of this transmitter into the memory of one or several Trust SmartHome receivers.
Slide the LEARN switch from [DEL] to [SET] to send an ON-signal. Read the receiver’s manual for the
code learning procedure.
4. Code confirmation
Slide the LEARN switch back to DEL and after a short pause slide the LEARN switch to SET again. The
connected light or chime will react. If not, repeat the previous step.
5. Set switch-o delay
When no more motion is detected, the transmitter automatically sends an OFF-signal after 5 seconds
or 1/5/10 minutes.
6. Set light sensitivity
Slide the [R] switch to select 1 of the 3 light sensitivity levels. [H]: Sensor is always active. [M]: Sensor
is active when the environment brightness is less than 20 lux (late afternoon). [L]: Sensor is active
when the environment brightness is less than 10 lux (late evening). If you want to control a chime,
always choose [H].
7. Close sensor housing
Tighten all screws to ensure waterproofness.
EN
Page 6
APIR-2150 WIRELESS MOTION SENSOR
2
8. Set horizontal detection range
The horizontal detection range of the sensor is maximum 110° and minimum 20°. Remove, reposition
or adjust the size of the plastic screens to adjust the angle.
9. Mount the motion sensor
Ax the holder at any desired location and place the motion sensor into the holder.
10. Set detection direction
Loosen the clamp screw and point the motion sensor to your desired position. When satisfied tighten
the clamp screw. The sensor needs 30 seconds to analyze its environment, before
it becomes operational.
11. Delete code from Trust SmartHome receiver memory
Read the receiver’s manual for the single code delete procedure. Slide the LEARN switch from [SET] to
[DEL] to send an OFF-signal.
EN
Page 7
Page 8
1
APIR-2150 WIRELESS MOTION SENSOR
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example,
the thin metal coating in Low-emissivity (Low-E) glass has a negative impact on the range of
radio signals.
• There may be restrictions on the use of this device outside the EU. If applicable, check whether this
device complies with local directives.
REMARKS
• Avoid combining this wireless motion sensor with Trust SmartHome dimmer receivers.
• Keep in mind that external factors (cloudy or rainy weather, car headlights, street lights, etc.) can
influence the observed light level.
• Make sure the receivers that need to be controlled are within wireless range of the transmitter.
COMPATIBILITY
This transmitter works with all
Trust SmartHome receivers.
FUNCTIONALITY
Outdoor motion sensor for switching 1 or more
Trust SmartHome receivers on/o. Also compatible
with the Trust SmartHome doorbell chime.
Read these simple guidelines. Not following them may be dangerous and faulty installation will
invalidate any warranty that may apply to this product.
TECHNICAL SPECIFICATIONS
• Batteries
• RF frequency
• RF range
• Detection range
• Horizontal detection angle
• Vertical detection angle
• Switch-o delays
• Light level settings
2x 1,5 Volt AAA alkaline
433.92 MHz
Up to 30 m indoor/70 m outdoor (optimal conditions)
Up to 7 m
20° up to 110°
65°
4 (5 seconds, 1/5/10 minutes)
3 (High, Medium, Low)
EN
Page 9
2
APIR-2150 WIRELESS MOTION SENSOR
EN
LEGAL INFORMATION
CE: Trust declares this device complies with the Directives as listed in Section 2 of this document.
WEEE: Dispose of the device at a recycling centre. More information: www.trustsmarthome.com
Warranty information: www.trustsmarthome.com/warranty
BATTERY
Remove the batteries if the product will not
be used for an extended period. Extreme
temperatures reduce the capacity and lifetime of
the battery.
Replace the battery when the LED indicator in the
sensor eye starts flashing continously or when
the reach of the transmitter starts to decrease.
Do not crush, burn or shred batteries. Dispose
of batteries according to local regulations.
Please recycle when possible. Do not dispose as
household waste.
LIFE-SUPPORT
Never use Trust SmartHome products for lifesupport systems or other applications in which
equipment malfunctions can have
life-threatening consequences.
INTERFERENCE
All wireless devices may be subject to
interference, which could aect performance. The
minimum distance between 2 receivers should be
at least 50 cm.
REPAIRING
Do not attempt to repair this product. There are
no user-serviceable parts inside.
WATER-RESISTANCE
This product is IP64 water-resistant.
CLEANING
Use a dry cloth to clean this product. Do not use
harsh chemicals, cleaning solvents,
or strong detergents.
HANDLING
Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards
and fine mechanics.
ENVIRONMENT
Do not expose the product to excessive heat
or cold, as it can damage or shorten the life of
electronic circuit boards and batteries.
