truMedic IS-BOT-1000 Instructions Manual

Modèle IS-BOT-1000

Head and Neck Massager

Instructions

Your Personal Masseuse

Products to Live Life Better

®

Included In Box

A. truMedic® InstaShiatsu+® Head and Neck Massager

B. Charging Base

C. Satin Bag

D. USB Charging Cable

E. USB Charging Adapter

A

C

D

E

B

1

WARNING

PLEASE READ AND OBSERVE ALL SAFETY WARNINGS

BEFORE USE AND KEEP THIS INSTRUCTION GUIDE HANDY

•

Do not use the truMedic® InstaShiatsu+® Head and
Neck Massager while it is charging; please wait for the
truMedic® InstaShiatsu+® Head and Neck Massager to
completely charge before using.

•

Never over-charge your battery; always remove the
truMedic® InstaShiatsu+® Head and Neck Massager from
the charging base when charging has been completed.

•

Only use the provided charging cable and adapter with
the charging base.

•

Never submerge the truMedic® InstaShiatsu+® Head and
Neck Massager in water.

•

Do not attempt to repair your truMedic® InstaShiatsu+®
Head and Neck Massager or use any spare parts that were
not supplied by truMedic®.

•

Do not insert any foreign objects into the mechanisms of
the truMedic® InstaShiatsu+® Head and Neck Massager.

•

If your truMedic® InstaShiatsu+® Head and Neck
Massager is damaged or malfunctioning, discontinue use
and contact truMedic® for service.

2

CAUTION

Consult your physician before using this product..

•

Children should not use the truMedic® InstaShiatsu+®

Head and Neck Massager without supervision.

•

Anyone with limited mobility or cognitive disabilities

should be supervised when using this unit.

•

The truMedic® InstaShiatsu+® Head and Neck

Massager is not a medical product and is not intended

to be used for medical purposes.

•

Consult your physician before using the truMedic®

InstaShiatsu+® Head and Neck Massager if you are

pregnant, have a blood disorder, are susceptible to

skin allergies or infections, or are using a pacemaker or

other implanted device.

•

Do not use the truMedic® InstaShiatsu+® Head and

Neck Massager for too long on one region of the body.

•

Do not use the truMedic® InstaShiatsu+® Head and

Neck Massager for more than 15 minutes per session.

Please wait at least 30 minutes between sessions.

•

Do not use the truMedic® InstaShiatsu+® Head and

Neck Massager while driving or operating heavy

machinery.

3

4

Features

The truMedic® InstaShiatsu+® Head and Neck Massager

allows you to enjoy a stimulating massage that relieves

tension. Easily used at home, in the oce, or while

traveling, this lightweight and wireless massager is there

when you need it.

The truMedic® InstaShiatsu+® Head and Neck Massager

is water-resistant, and designed to be used in the shower

or tub. Do not completely submerge the unit at any time.

If the unit appears to display damage, or is not functioning

properly, discontinue use and contact truMedic® for

service.

Power
Charging Light
Memory Button
Charging Interface

Massage Head

Charging Interface

Charging Pins

Charging Interface
Base

5

6

Operation

1. Place the truMedic® InstaShiatsu+® Head and

Neck Massager in the charging base and ensure the

charging terminals on the base connects with the

massager’s terminals. (See diagrams above).

7

2. Insert the charger’s plug into a proper household

outlet, and the other end into the charging base.

A red LED light will be shown on the truMedic®

InstaShiatsu+® Head and Neck Massager until

charging has been completed.

Make sure the charging terminals touch!

POWER

ON OFF

8

3. To turn on your truMedic® InstaShiatsu+® Head and

Neck Massager, give the power button a short press. The

truMedic® InstaShiatsu+® Head and Neck Massager is

intended to be used for 15 minutes per session.

No Worries! It’s Safe
for the Shower!

Its non-slip exterior is great for use while

taking a shower or relaxing in the tub.

CYCLE MODES

(Press while turned on to cycle)

Massage

Vibration

Massage with Vibration

9

4. To cycle between the dierent massage modes give the

power button a short press. The modes are as follows:

5. Press and hold the power button to shut o the

massager and end the massage session

A. Massage

B. Massage with vibration

C. Vibration

It Remembers So
You Don’t Have To!

The memory button is great for saving time

and quickly resuming your massage session.

10

Using the memory button

1. To have the memory button save the last massage

mode you were using, press the power and memory

button at the same time

2. To remove the saved massage mode, press and hold

the memory button for 3 seconds.

Memory Button

11

Caring For Your truMedic®
InstaShiatsu+® Head and
Neck Massager

•

The truMedic® InstaShiatsu+® Head and Neck

Massager is a water-resistant device but should never

be submerged in water. Use a damp cloth and gentle

detergent to clean the massager; gently wipe it dry

afterwards.

•

Please keep your truMedic® InstaShiatsu+® Head and

Neck Massager safely in its box when not in use. Store

it in a cool, dry place out of direct sunlight.

•

Do not use any corrosive liquids on your massager or

store the device near corrosive liquids.

12

Specications

Product Name

truMedic® InstaShiatsu+® Head and Neck Massager

Product Model

IS-BOT-1000

Adapter Input Rate

100V-240V-50Hz/60Hz

Adapter Output Rate

5.0Vm = 1.5A

Rated Power

5W

13

Troubleshooting

Problem: The truMedic® InstaShiatsu+® Head and Neck

Massager will not start.

Solution: Recharge the battery and verify that the unit is

connected properly to the charging base.

Problem: The truMedic® InstaShiatsu+® Head and Neck

Massager stops running.

Solution: Ensure the battery is charged, or wait at least 15

minutes to restart the massage cycle.

Problem: The truMedic® InstaShiatsu+® Head and Neck

Massager is making noises

Solution: While operating, the massager will make steady

noise as the motor functions. If any sudden or unusual

noises occur please contact truMedic® for service.

Have Questions? Call our toll-free hotline at
[phone] or visit support.trumedic.com

14

Warranty

truMedic® warrants this product against defects in

materials and/or workmanship for a period of 6 Months

from the date of purchase by the original purchaser. In

the event of a valid claim within the Warranty Period,

truMedic® will repair the defect or replace the unit at no

charge, using new or refurbished replacement parts at its

discretion. Proof of purchase is required prior to receiving

service under this warranty.

Warranty service is available by calling truMedic® service

at 888.264.1766 or via email at [email protected].

Repairs/replacements must be authorized by truMedic®

before service will be provided. You are responsible for

delivery and the cost of delivery of the product to and

from a truMedic® service center for replacement or repair

as, per our instructions.

This warranty does not cover damage caused by failure to

follow instructions, or damage caused by accident, abuse,

misuse, re, oods, earthquake or other external causes or

damage caused by unauthorized repairs.

15

truMedic® SHALL NOT BE LIABLE FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES RESULTING FROM

THE USE OF THIS PRODUCT, OR ARISING OUT OF

ANY BREACH OF THIS WARRANTY. TO THE EXTENT

PERMITTED BY APPLICABLE LAW, truMedic® DISCLAIMS

ANY AND ALL STATUTORY OR IMPLIED WARRANTIES,

INCLUDING, WITHOUT LIMITATION, WARRANTIES

OF MERCHANTABILITY, FITNESS FOR A PARTICULAR

PURPOSE AND WARRANTIES AGAINST HIDDEN OR

LATENT DEFECTS. IF truMedic® CANNOT LAWFULLY

DISCLAIM STATUTORY OR IMPLIED WARRANTIES,

THEN TO THE EXTENT PERMITTED BY LAW, ALL SUCH

WARRANTIES SHALL BE LIMITED IN DURATION TO THE

DURATION OF THIS EXPRESS WARRANTY.

Some states disallow the exclusion or limitation of

incidental or consequential damages or how long an

implied warranty lasts, so the above exclusions or

limitations may not apply to you. This warranty gives you

specic legal rights and you may also have other rights,

which vary from state to state.

16

FREE WARRANTY UPGRADE

GO TO http://www.RegistertruMedic.com

YOU MUST REGISTER YOUR PRODUCT WITHIN 10 DAYS

TO QUALIFY FOR A FREE UPGRADE TO YOUR WARRANTY

FROM 6 MONTHS TO ONE FULL YEAR AT NO COST!

When you register, you become a VIP member and get

these exclusive benets:

FREE Extended Warranty from 6 months to one

full year at NO CHARGE!

Discount on new product releases

HAVE QUESTIONS? Give us a call on our

toll-free hotline [phone]

Thank you! We Look forward to welcoming you into the VIP

User’s Group today!

Team truMedic®

17

FCC Statement:

CAUTION: Modications not approved by the party

responsible for compliance
could void user’s authority to operate the equipment.

NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and
receiver.

• Connect the equipment into an outlet on a

circuit dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV
technician for help.

18

IMPORTANT SAFETY
INSTRUCTIONS

Read all instructions before using this
household appliance

When using an electrical appliance, basic precautions

should always be followed, including the following:

DANGER

To reduce the risk of electric shock:

• Always unplug this appliance from the electrical
outlet immediately after using and before cleaning.

• Do not reach for an appliance that has fallen into
water. Unplug immediately.

• Do not use while bathing or in a shower.

• Do not place or store appliance where it can fall or
be pulled into a tub or sink. Do not place in or drop
into water or other liquid.

19

WARNING

To reduce the risk of burns, re, electric

shock, or injury to persons:

• An appliance should never be left unattended when
plugged in. Unplug from outlet when not in use, and

before putting on or taking o parts.

• Do not operate under blanket or pillow. Excessive

heating can occur and cause re, electric shock, or

injury to persons.

• Close supervision is necessary when this appliance
is used by, on, or near children, invalids, or disabled
persons.

• Use this appliance only for its intended use as
described in this manual. Do not use attachments
not recommended by the manufacturer.

• Never operate this appliance if it has a damaged
cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into
water. Return the appliance to a service center for
examination and repair.

20

SAVE THESE INSTRUCTIONS

• Do not carry this appliance by supply cord or use
cord as a handle.

• Keep the cord away from heated surfaces.

• Never operate the appliance with the air openings
blocked. Keep the air openings free of lint, hair,
and the like. Never operate on a soft surface such
as a bed or couch where the air openings may be
blocked.

• Never drop or insert any object into any opening.

• Do not use outdoors.

• Do not operate where aerosol (spray) products are
being used or where oxygen is being administered.

• To disconnect, turn all controls to the o position,
then remove plug from outlet.

• Do not use massager in close proximity to loose
clothing or jewelry.

• Keep long hair away from massager while in use.

21

TruCore Distributors, Inc.

252 Indian Head Rd. Kings Park, NY 11754

TEL#: [phone]

E-MAIL: [email protected]

WEBSITE: www.truMedic.com

v1 JAN2017
