TRUlink 29597 User Manual

1

USER GUIDE

WIRELESS USB SUPERBOOSTER EXTENDER

Model: 29597

1

Introduction.................................................................................................................................................2

Features......................................................................................................................................................3

System Requirements.................................................................................................................................4

Package Contents.......................................................................................................................................5

Device Overview

Wireless USB Host Adapter...............................................................................................................6

Wireless USB Device Adapter...........................................................................................................7

Software/Device Installation........................................................................................................................8

Using the Wireless USB Kit.......................................................................................................................14

Frequently Asked Questions.....................................................................................................................18

Technical Specifications............................................................................................................................19

Cables To Go Warranty............................................................................................................................20

Important Safety Information.....................................................................................................................21

FCC Statement.........................................................................................................................................22

TABLE OF CONTENTS

2

Thank you for purchasing the TruLink™ Wireless USB* Superbooster Extender. This product utilizes
robust wireless technology, so you can connect an USB enabled device such as a printer, scanner,
digital camera, or interactive whiteboard up to 150 feet away from your PC. With a highly reliable
connection you can use this product in settings such as corporate offices, classrooms, or in your home
office/entertainment system. We recommend that you read this manual thoroughly and retain for
future reference.

*Note- This term: Wireless USB is part of the product description, and is not reference to the Certified Wireless USB
technology standard.

INTRODUCTION

3

 Wireless connectivity up to 150 feet
 Reliable connection in the same room, in another room, or on another floor
 Easy setup, with software included
 Wireless specification: 2.4GHz, DSSS, internal antenna

FEATURES

4

 PC with available USB Port
 CD-ROM drive for driver installation
 Windows® XP or Vista®
 At least 5MB free drive space

SYSTEM REQUIREMENTS

5

 Wireless USB Host Adapter for your computer
 Wireless USB Device Adapter for USB device
 AC Power Adapter
 Quick Start Guide
 Driver CD
 User Manual

PACKAGE CONTENTS

6

1

WIRELESS USB HOST ADAPTER

1. Link: Data Connection Indicator

• LED is on when transfer device is connected

DEVICE OVERVIEW

7

1

WIRELESS USB DEVICE ADAPTER

1. Reset Button

• This allows the device to be put in its default setting

2. Infra LED Indicator

• Not active on this device

3. Link LED Indicator

• This is a status indicator that the device adapter is active

4. Status LED Indicator

• Indicates information being transmitted between the USB
Device and Host Adapter

5. USB A port

• Plug in a USB enabled device

6. Power Input

• DC 5V power input

DEVICE OVERVIEW

2 43

65
