1
PW2200
CAUTION : Do not use this device before reading the instructions.
High-Pressure Washer
2
The appliance has been
designed solely for private
use outdoors and not for
commercial use. Keep this
appliance away from heat,
direct sunlight, moisture and
rain, ice and sharp edges.
Do not allow anybody that
has not been trained to use a
pressure washer to operate
the machine without first
reading the instruction
manual.
WARNING: High-pressure
washers must not be used by
children or untrained persons.
Before starting your machine,
carefully check for defects. If
you find any, do not start
your machine and contact
your local distributor.
In particular, ensure that the
electric cable insulation is in
perfect condition and free of
cracks. If the electric cable is
damaged, an approved local
service centre must replace it.
WARNING: Hi pressure
jets can be dangerous if they
are used incorrectly. The jet
must not be directed towards
persons, electrical equipment
connected to the mains or
the appliance itself.
WARNING: Do not use the
appliance close to other
people unless they are
wearing protective clothing.
CAUTION: Do not direct
the jet towards yourself or
other persons to clean
clothing or shoes.
Hold the lance firmly in your
hands.
The operator and persons
within close proximity to the
cleaning area must take
necessary measures to
protect themselves from
dislodged debris when in use.
Wear protective gloves and
clothing during use.
WARNING: The appliance
has been designed for use
with a cleaning agent
1. Safety Instructions
3
supplied or recommended by
the manufacturer. Using
other cleaning products or
chemical products may
affect the safety of the
appliance.
WARNING: Disconnect the
appliance from the power
supply before carrying out
any maintenance.
CAUTION: To ensure the
safety of the appliance, only
use spare parts supplied or
approved by the
manufacturer.
Do not use the appliance if
the power cable or important
parts of the appliance are
damaged, for example, the
safety device, high pressure
hose and handgun.
Do not use the appliance
with wet hands. If the
appliance is damp or wet,
unplug it immediately. Do
not place it in water.
The tyres and valves on the
tyres can be damaged by the
high pressure jet and could
burst.
Never use the machine in an
environment where there is a
danger of explosion.
It is forbidden to clean
surfaces containing asbestos
at high pressure.
This high-pressure washer
must not be used in
temperatures below 0 ° C.
CAUTION - The hoses,
accessories and high
pressure couplings are
important for the safety of
the machine. Only use hoses,
accessories and couplings
recommended by the
manufacturer.
WARNING: Inadequate
extension cables may be
dangerous. Cables and
spools must always be
completely unwound to
avoid letting the cable
overheat.
If an extension cable is used,
the plug and socket must be
waterproof and conform to
the requirements below
regarding the length and
dimensions of the cable.
1,0 mm ² max. 12,5 m
1,5mm²max.20 m
4
If the power cable is
damaged, it must be
replaced by the
manufacturer, their service
agent or a qualified
professional in order to
avoid any danger.
WARNING: This machine
is not designed to be used
by persons (including
children) with reduced
physical, sensory or mental
capacities or whose lack
experience or knowledge.
WARNING: It is advisable
that you supervise children
to ensure that they do not
play with the appliance.
CAUTION – Risk of
explosion – do not spray
flammable liquids, do not
direct the jet towards
flammable liquids.
WARNING: Water that has
circulated in the antibackflow system is not
considered drinkable.
WARNING: Do not use
the appliance if the power
cable or important parts of
the appliance are damaged,
for example, the safety
devices, high pressure hoses
and handgun.
WARNING: If you have an
extension cable, it must be
waterproof.
WARNING: When you
switch on the machine, a
recoil movement is
produced due to the force of
the water jet. Use two hands
to control the lance. Wear
safety gloves when using
the appliance. Wear suitable
protective clothing.
In case of accidental contact
with detergent, wash with
water. If the liquid comes
into contact with the eyes,
also seek medical assistance
(the detergent can cause
irritations or burns).
In the event that the
appliance breaks down, do
not attempt to repair it
yourself but contact a
professional technician to
avoid any danger.
Main power connection
The following must be
observed when connecting the
5
high pressure washer to the
power supply:
Connecting the electrical
connection should be done
by a qualified electrician
conforming to 60364-1 CEI
It is recommended that the
electrical supply to this
machine should comprise a
residual current device
which interrupts the current
if the leakage current
exceeds 30 mA for 30ms.
CONNECTING TO THE
WATER NETWORK
WARNING
According to current
guidelines, the unit must never
be operated without a system
separator on the potable water
system. Use a EN 12729 type
BA system separator. Water
that passes through a system
separator is classified as nonpotable.
WARNING:
Always connect the system
separator to the water supply
and never directly to the
device!
6
Thank you for choosing the
PW2200 High-Pressure Washer
Chapter
Page
1. Safety Instructions
2
2. Getting Started
7
3. Operating your pressure washer
7
4. End of operation instructions
9
5. Environmental protection
9
6. Maintenance, cleaning and
repairing.
9
7. Breakdown service
11
8. WEEE - Waste of Electric and
Electronic Equipment
12
Rated Pressure
110bar/11MPa
Max. pressure
165bar/16.5Mpa
Flow
5.5l/min
power
2200W
Voltage
240V/50Hz
Vibration gun
Max 2.25 m/s
2
1. Pressure gun
2. Pressure hose
3. Inlet connector
4. Swicth
5. Machine body
6. Cable
7. Plug
8. Inlet water hose
9. Water tap
10. Ourlet connector
11. wheels
Contents
Technical data
Contents
The Circuitry
7
This section will explain in details how to
make high pressure washer ready for use.
SAFETY DEVICES
The unloader valve can reduce pressure
if it exceeds pre-set values.
Locking device on trigger gun (see
illustration at the beginning of this manual):
The trigger gun features a locking device.
When the knob is activated, the trigger gun
cannot be operated.
THERMAL SENSOR
A thermal sensor protects the motor against
overloading. The machine will restart after
a few minutes when the thermal sensor has
cooled.
Screw the water inlet coupling (3) tight on
to the water inlet Note: The inlet filter (A)
must always be fitted in the water inlet pipe
to filter out sand, lime stone and other
impurities as these will damage the pump
valves.
Caution: Failure to fit the filter will
invalidate the guarantee.
Connect the garden hose with a standard
quick coupling
Attach the high pressure hose to the trigger
gun and machine.
Detach the high pressure hose by pressing
the pawl (A) or button (B)
Push the lance into the trigger gun
When inserted turn it. Caution: Make sure
the lance is properly fixed to the gun
Attach the nozzles. Caution: When
attaching the nozzle the button (A) on the
nozzle should come out again. Check
before activating the trigger that the nozzle
is properly fixed.
GB
2. First time instructions
3.1 Connection of garden hose
3.2 Mounting of high pressure hose
3.3 Mounting of lance and nozzle
3. Operation instructions
A
B
1
A
8
Connecting the water supply pipe
Follow your water supplier’s instructions .
For connection information, see the data
plate/technical specifications
Use a reinforced hose (not supplied) with a
standard connection (ext. diameter:
16mm/int. 12mm, maximum length: 25m).
IMPORTANT! Only use water without
any impurities. If there is a risk of sand
particles in the inlet water (i.e. from your
own well), an additional filter should be
mounted.
Let the water run through the water hose
before connecting it to the machine to
prevent sand and dirt from penetrating the
machine. Note: Check that the filter is fitted
in the water inlet pipe and that it is not
clogged up.
Connect the water hose to the water supply
by means of the quick connector (inlet
water, max. pressure: 10 bar, max.
temperature: 60°C).
Turn on the water.
The trigger gun (1) and lance is affected by
a thrust during operation - therefore always
hold it firmly with both hands.
IMPORTANT: Point the nozzle at the
ground.
Check that the machine is in upright
position. NOTE: Do not place the machine
in high grass!
Release the trigger lock .
Activate the trigger of the trigger gun (1)
and let the water run until all air has
escaped from the water hose.
Press the Start/stop switch (7).
Activate the trigger of the trigger gun (1).
Always adjust the distance and thus the
pressure of the nozzle to the surface, which
is to be cleaned.
Do not cover the machine during operation
or use it in a room without adequate
ventilation!
NOTE: If the machine is left or not used
for 5 minutes, it must be switched off on the
start/stop switch (7) "O":
Press the start/stop switch (7) "O".
Disconnect the electrical plug (12) from the
socket.
Shut off the water supply and activate the
trigger of the trigger gun (1) to relieve the
machine of pressure.
Lock the trigger gun (1)
When releasing the trigger of the trigger
gun (1), the machine automatically stops.
The machine will start again when you reactivate the trigger gun (1)
The pressure can for the multi nozzle be
adjusted by tuning it. WARNING: Do not
do this under operation to avoid that the
hand hits the jet.
3.4 Water connection
3.5 Start/stop of the machine
3.6 Multi Nozzle
12A
3
9
1.)gun hook assembly ;
2.)Handle assembly
3.)Quick connector structure on the
machine body . All the Accessories can be
storaged on the machine .
The machine should be stored in a frost-free
room!
Pump, hose and accessories should always
be emptied of water prior to storing as
follows:
Stop the machine (press the start/stop
switch “O” and detach water hose, high
pressure hose and nozzle
Restart the machine and activate the trigger
of the trigger gun Let the machine run until
no more water runs through the trigger gun
Stop the machine, unplug and wind up hose
and cable.
Place trigger gun, lance, nozzles and other
accessories in the holders of the machine.
The hook can be used for storage of the
hose and cord
5, All accessories can be stored in the
washer after using.
WARNING: Never start up a frozen
machine. Frost damages are not covered by
the guarantee!
Old appliances contain valuable materials
that can be recycled. Please arrange for the
proper recycling of old appliances. Please
dispose your old appliances using
appropriate collection systems.
WARNING! Always disconnect the
electrical plug from the socket prior to
maintenance or cleaning.
5. Environmental protection
4. After use instructions
6. Maintenance, cleaner and repair
3.6 Install indicator diagram
10
To ensure a long and problem free working
life, please take the following advice:
Wash out water hose, high pressure hose,
spray lance and accessories before
mounting.
Clean the connectors of dust and sand.
Rinse the detergent spraying attachment
after use.
Clean the nozzles.
Any repair should always be made in an
authorized workshop with original spare
parts.
Clean the water inlet filter regularly once a
month or more frequently according to use.
Carefully loosen the filter with a
screwdriver and clean it . Check that it is
intact before re-mounting it.
The inlet filter must always be fitted inside
the water inlet pipe to filter out sand,
limestone and other impurities, as they will
damage the pump valves.
CAUTION: Failure to fit the filter will
invalidate the warranty
The machine should be kept clean so as to
let cooling air pass freely through the
machine vents.
To ensure an easy connection and that orings do not dry up; the couplings should be
greased regularly.
6.1 Cleaning of inlet filter
6.3 Greasing of couplings
6.2 Cleaning of air vents
11
Symptom
Cause
Recommended action
The machine will not
start
The machine is not plugged-in
Plug the machine in
Faulty receptacle
Try another receptacle
The fuse has blown
Replace the fuse Unplug other appliances
Faulty extension cable
Try without the extension cable
Fluctuating pressure
The pump is drawing in air
Check that hoses and connections are airtight.
Valves dirty, worn or sticking
Contact your service centre
The water supply is not
sufficient
Increase water pressure, check for blockages
and / or change the large pipe.
Pump seals worn
Contact your nearest service centre
The machine stops
The fuse has blown
Replace the fuse
Incorrect mains voltage
Unplug other appliances
Check that the mains voltage corresponds to the
specifications on the nameplate
Thermal sensor activated
Leave the machine to cool for 5 mins
Partially blocked jet
Clean the jet with a needle and by spraying
water rearwardly through the jet
Fuse blown
Fuse too small
Replace it with a fuse with higher amp
consumption than the washer.
Increase in the amperage
Try without the extension cable
Pulsing machine
Air in inlet hose / pump
Allow machine to run with open trigger until
regular working pressure resumes.
Inadequate supply of water
generated
Increase water pressure, check for blockages
and / or change the large pipe.
Partially blocked jet
Clean the jet with a needle and by spraying
water rearwardly through the jet
Water filter blocked
Clean the filter
Folded pipe
Unfold the pipe
The machine turns on
and off by itself
Pump fuse and/or trigger out of
order
Contact your nearest service centre
No water supply
Connect the inflow water.
The machine is on
but no water comes
out
Water filter blocked
Clean the filter
Blocked jet
Clean the jet with a needle and by spraying
water rearwardly through the jet
7. Breakdown service
12
The symbol on the product or on its packing indicates that this product may not be treated as
household waste. Instead it shall be handed over. To the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.
WEEE - Waste of Electric and Electronic Equipment
EC Declaration of Conformity
In accordance with EN ISO 17050-1:2004
We ( Big Home Shop )
Of ( Unit 10B, Dean Court, Shuttleworth Mead, Padiham, BB12 7NG)
In accordance with the following Directive(s):
EC Council Directive 2006/42/EC Machinery
GS Product Safety Law
EC Council Directive 2004/108/EC Electromagnetic Compatibility
Hereby declare that:
Equipment Pressure Washer 2200W
Model(s) BCNH (PW2200)
Is in conformity with the applicable requirements of the following documents:
Ref No: EC Type Examination Certificate No:
EN 55014-1:2006+A1+A2 AE 50333996 0001
EN 55014-2:1997+A1+A2
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 60335-1:2012+A11 AM 50379439 0001
EN 60335-2-2:2010+A11+A11 S 50379438 0001
EN 62233:2008
AFPS GS 2014:01
In accordance with the notified body:
TUV Rheinland LGA Products GmbH – Tillystrabe 2- 90431 Nurnberg.
I hereby declare that the equipment named above has been designed to comply with the relevant sections of
the above referenced specifications and is in accordance with the requirements of the Directive(s).
Signed by: Document Ref.
No. ( BHS0000150 )
Name: John Ramsdale
Position: Product Manager
Done at Padiham, BB12 7NG
On 10/08/2017
The technical documentation for the machinery is available from:
Name: ( Big Home Shop Ltd )
Address: ( Unit 10B, Dean Court, Shuttleworth Mead, Padiham, BB12 7NG )
Loading...
