BA – 1 0 5
USER’S GUIDE
Multifunctional Steam Cleaner
Product Description
1111
Specifications
4444
Safety Instructions
2222
Product View
3333
Operation
5555
Maintenance
6666
Page 2
Trueshopping.co.uk
1
www.trueshopping.co.uk
Please read and retain this leaflet for future reference and safety instructions.
Product Description
•
This multifunctional steamer is an efficient and safe way to keep your home
hygienically clean, without the use of chemical detergents. Tap water is quickly
vaporized into high temperature steam through components in the unit and expelled
at high pressure through the nozzle, for a deep clean.
•
The high temperature steam kills bacteria and germs more efficiently than antibacterial soaps, loosens dirt and removes grease, for a thorough and
environmentally friendly clean.
•
Can be used to clean, disinfect, degrease and kill germs in the home and workplace,
creating a clean and healthy working and living environment without the use of harsh
chemicals. This unit can also conveniently be used to steam-iron clothes.
•
Ready to use in under 30 seconds.
•
Steam temperature of over 150°c, which is over 20°c degrees hotter than the nearest
competitor.
•
Up to 30 minutes continuous steam time.
•
550ml water capacity. Transparent and detachable fill tank, easy to fill and refill.
IMPORTANT! Safety Instructions
This is appliance uses high temperature steam. Please take care and follow these safety
instructions when operating the appliance:
•
This appliance should not be used by children. Store out of reach and take special
care when operating the appliance in the presence of children.
•
The steam released by this appliance can reach temperatures of 150°c. It should
never be sprayed at humans, animals or other objects which are not heat-resistant.
•
Do not direct the liquid or steam towards equipment containing electrical
components. Switch the power off when cleaning the interior of refrigerators,
microwaves and other electrical appliances.
•
Never remove the cover or disassemble this unit yourself. There are hightemperature components inside which can cause serious injury or fire.
•
Do not place the appliance in water or other liquids. Do not get the main unit wet,
especially around the switch. In the event of the unit becoming wet, stop operation
and unplug the appliance. Wipe the main unit with a clean, dry cloth and leave it to
dry in a ventilated area.
•
Do not leave the appliance unattended whilst it is plugged in. In the event of
overheating, smoking or a peculiar smell, stop operating the appliance immediately
Page 3
Trueshopping.co.uk
2
www.trueshopping.co.uk
and unplug. Contact your local dealer for professional advice. Do not disassemble
the appliance by yourself.
•
Always unplug the appliance after use and before carrying out user maintenance.
•
This steam cleaner requires time to warm-up. After plugging the appliance in and
before using, wait at least 20 seconds before pressing the ‘on’ switch. Failure to do
so may result in water spraying from the appliance.
•
Use ordinary, clean tap water to operate this appliance. Do not use warm or hot
water, or chemical solutions such as detergents or alcohol. In the event of poor water
quality, please use purified water.
•
Never operate this appliance without water in the tank. Doing so may damage the
appliance.
•
If the power cable or connection plug are found to be damaged, do not operate the
appliance. Contact the supplier to arrange replacement or disposal of the appliance.
•
It is normal for small water droplets to be expelled by the appliance on first use.
•
This appliance is designed for 360° use and can be used at many angles. It is usual
for the steam to be sprayed at different pressure or in a different quantity, depending
on the angle. Do not keep the appliance upright for extended periods of time.
•
Take care when switching off the appliance, as residual steam may be expelled from
the nozzle.
Page 4
Trueshopping.co.uk
3
www.trueshopping.co.uk
Product View
Handle
Quick release cord wrap
Connection handle
Assembly tube
Holder Water tank
Body
Switch
Bottom
Page 5
Trueshopping.co.uk
4
www.trueshopping.co.uk
Specifications
Accessories:
Name Water tank Cloth mop Glider Round brush Manual
Quantity 1 2 1 2 1
Name Straight
brush
Nozzle Steam iron Glass
scraper
Tube
Quantity 1 1 1 1 1
Specifications:
Item BA-105 Tank capacity 500ml
Power 1200W Rated Voltage 230 V
Pressure 1-3Bar Steam temperature
100-150
Page 6
Trueshopping.co.uk
5
www.trueshopping.co.uk
Operations
• Unpack the carton.
• Please refer to Page 4, to check the appliance has been supplied with all necessary
parts.
• If a part is missing or damaged, do not use the appliance and contact the supplier.
Using the Steam Mop
• Connect the handle to the assembly tube
• Insert the water tank into the body and fill with water
• Fit the body on to the bottom
• Plug appliance in. Wait 30 seconds before turning on at the switch.
Page 7
Trueshopping.co.uk
6
www.trueshopping.co.uk
Using the steam cleaner function
• Install the straight brush: fit the straight brush on to the body, making sure they are
firmly connected.
• Install the round brush and nozzle: fit the straight brush on to the body and make
them stable, then fit the round brush or nozzle on the head of the straight brush.
• Install the steam iron: fit the straight brush on the body, then fix the steam iron on
the straight brush. When installing the glass scraper, fix the small hook of the glass
brush into the ironing’s board suspension loop. Pull the large hook on the glass brush
and push up to fix on the ironing board.
Page 8
Trueshopping.co.uk
7
www.trueshopping.co.uk
Using the steam garment function
• Unload the nozzle. Fit the steam iron.
• Wait for 30 seconds until steam is produced.
• Raise the steam iron to clothes or upholstery, letting the steam spray onto the item.
Maintenance
Surface cleaning:
• Make sure the switch is turned to ‘off’.
• Wipe with a clean, damp cloth. Wipe dry.
• Do not use gas or other solvents. Keep in a dry place.
Body cleaning:
• Make sure the appliance is unplugged before cleaning.
• Open the water tank and fill with water.
• Using your thumb as a stop, shake the water tank.
• Repeat 2-3 times.
Accessories cleaning:
• Wipe accessories after use, with a clean, damp cloth.
• Store in a dry and ventilated place.
Examples of use
Object to clean Job purpose Usage method composite Switch
Fridge,
microwave oven
Clean, eliminate
smells
II
Vase，artwork
Remove dust
II
Glass, mirror
Remove dust
II
Table, chair, sofa Remove dust
I
Curtain, window
Clean, disinfect
I
Page 9
Trueshopping.co.uk
8
www.trueshopping.co.uk
Clothes, sheets
Clean, disinfect
I
Kitchen items
Degrease, clean
II
Pet products
Clean, disinfect
II
Tile
Clean
II
Tableware
Disinfect
II
Car interiors
Eliminate smells
I
Car engine
Remove dust
II
Hotel room
Humidify
I
Key:
Grasp the spray head to spray the steam towards the object to be cleaned.
Fit the steam iron and straight brush on to the nozzle. Spray while brushing.
Fit the round brush on to the nozzle. Spray while brushing
Fit the steam iron on to the nozzle. If necessary, a cotton cloth can be put on the steam
iron.
Fit the steam iron and glass scraper on to the nozzle. Spray while brushing
Add a neutral detergent to clean, if the item is heavily soiled.
