TRUE INDUCTION SINGLE BURNER
INDUCTION COOKTOP MANUAL
SINGLE BURNER INDUCTION COOKTOP MANUAL
1
TABLE OF CONTENTS
I.
II.
III.
IV.
V.
VI.
VII.
Cooktop Installation
Important safety Information
Product Specications
How to Use
> Power Invariance Technology
> Using the Temperature Setting
> Using the Timer Function
> Built-In Safety Shut O
> Turning O Unit
Compatible Cookware
Cleaning & Maintenance
Troubleshooting Error Codes
1-3
4-5
5
6
6
6-7
7
7
7
8
8
9
Thank you for purchasing the True Induction Single Burner IT-1B cooktop. Please read the entire instruction manual prior to using your unit.
If you have any questions regarding the True Induction cooktop please
visit http://www.Truelnduction.com or call: 1-877-862-7049.
SINGLE BURNER INDUCTION COOKTOP MANUAL
2
I. Cooktop Installation
Dimensions and Placement for Cut-out in Countertop
• Cut a rectangle hole in the countertop where the cook top is to be placed. The dimensions
for the cut-out are 11 3/8'' x 13 3/4''
• The cut-out must be placed at least 2 1/2" from any side of the countertop.
• To achieve ush mounting installation, use a router tool to round the corners of the hole cut
into the countertop.
2 1/2’’ min
11 3/8’’
2 1/2’’ min
13 3/4’’
3
SINGLE BURNER INDUCTION COOKTOP MANUAL P.1
I. Cooktop Installation Continued...
First feed the power wire through the hole and to the location of the power receptacle un-
derneath the cabinet.
The 'h'' overhang on the induction cooker comes with pre-installed foam gasket. Peel o the
adhesive protector on the bottom of the gasket and set the induction cooker into the cutout. Gently press down on the induction cook top to secure the adhesive gasket to the coun-
tertop. The cook top should be sitting on the supports previously installed.
For RV use, apply butyl tape instead of the supplied foam tape. Butyl tape will provide ade-
quate adhesion and still allow for removal if the unit needs to be serviced.
