TRUE INDUCTION DOUBLE BURNER
MINI DUO COOKTOP MANUAL
DOUBLE BURNER MINI DUO INDUCTION COOKTOP MANUAL
1
TABLE OF CONTENTS
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
Control Panel Overview
Cooktop Installation
Important safety Information
Product Specications
How to Use
> Power Invariance Technology
> Using the Temperature Setting
> Using the Timer Function
> Built-In Safety Shut O
> Turning O Unit
Compatible Cookware
Cleaning & Maintenance
Troubleshooting Error Codes
1
2-5
6-7
7
8
8-9
9
9
10
10
10
11
11-12
Thank you for purchasing the True Induction Double Burner Mini Duo
cooktop. Please read the entire instruction manual prior to using your
unit. If you have any questions regarding the True Induction cooktop
please visit http://www.Truelnduction.com or call: 1-877-862-7049.
DOUBLE BURNER MINI DUO INDUCTION COOKTOP MANUAL
2
I. Control Panel Overview
1. Left Cooking Zone
2. Right Cooking Zone
3. Ceramic– Glass
4. Left Touch Control Panel
5. Right Touch Control Panel
6. Power Option Display
7. Lower Power Key
8. Raise Power Key
9. Cooking Zone ON/OFF Key
10. Time Control Key
11. Child Safety Lock
12. Power Button
3
DOUBLE BURNER MINI DUO INDUCTION COOKTOP MANUAL P.1
II. Cooktop Installation
Portable Installation
For Portable Unit Install
To use the Mini Duo as a portable unit, locate the 4 feet in the packaging and screw them
into the bottom as illustrated below.
*Take out screw before installing
Parts
4
DOUBLE BURNER MINI DUO INDUCTION COOKTOP MANUAL P.2
II. Cooktop Installation Continued...
Dimensions and Placement for Cut-out in Countertop
This appliance is not user serviceable. Installation must be completed by a qualied
technician.
WARNING!
FOR YOUR SAFETY: Do not store or use gasoline or other ammable vapors and liquids in
the vicinity of the unit. To eliminate the risk of burns or re due to overheating, cabinets located
above the induction cooktop should be avoided or allowed a minimum of 30’’ clearance. If cabi-
net space is available, the risk can be reduced by installing a range hood at a minimum of 5
inches below the bottom of the cabinets.
IMPORTANT INSTALLATION INFORMATION:
All electric cooktops run o of a single phase, three-wire cable, 120V/60Hx AC only electrical
supply with ground. The installation should be made using wires, conduits, and ttings size in
accordance with the National Electrical Code– ANSI/NFPA 70.
Cut a rectangle hole in the countertop where the cook top is to be placed. The dimensions
for the cut-out are 13 3/4' x 20''
The cut-out must be placed at least 2 1/2" from any side of the countertop.
To achieve ush mounting installation, use a router tool to round the corners of the hole cut
into the countertop.
20’’
13 3/4’’
5
DOUBLE BURNER MINI DUO INDUCTION COOKTOP MANUAL P.3
