Depth dimension does not include 26mm required for rear ventilation. Dimensions rounded up to the next whole number.
Specifi cations subject to change without notice.
UNDERCOUNTER REFRIGERATORS
Model Doors
Capacity
(liters)
Shelves
Cabinet Dimensions
(L x D† x Hmm)
HP Voltage Amps
Cord
Length
Crated
Weight
TGU-2 2 297 6 1420 x 712 x 864 1/3 230-240/50/1 2.3 2.74 m 157 kg
TGU-3 3 456 9 1880 x 712 x 864 1/3 230-240/50/1 3.0 2.74 m 200 kg
UNDERCOUNTER FREEZERS
Model Doors
Capacity
(liters)
Shelves
Cabinet Dimensions
(mm)
HP Voltage Amps
Cord
Length
Crated
Weight
TGU-2F 2 297 6 1420 x 712 x 864 1/2 230-240/50/1 3.5 2.74 m 182 kg
TGU-3F 3 456 9 1880 x 712 x 864 1/2 230-240/50/1 4.1 2.74 m 207 kg
300 series stainless steel interior & exterior
standard on all True Gastronorm Units.
TGU-2
TGU-3F
True’s Gastronorm Units are
designed with enduring quality
that protects your long term
investment.
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility costs,
superior food safety and the best
value in today’s food service
marketplace.
All Gastronorm
Units include True’s
industry leading 5-year
compressor warranty.
Page 3
www.truemfg.com
True’s 16-gauge stainless steel radius
counter-top design provides a durable,
long-lasting, beautiful fi nish.
†
Depth dimension does not include 26mm required for rear ventilation. Dimensions rounded up to the next whole number.
Specifi cations subject to change without notice.
WORKTOP REFRIGERATORS
Model Doors
Capacity
(liters)
Shelves
Cabinet Dimensions
(L x D† x Hmm)
HP Voltage Amps
Cord
Length
Crated
Weight
TGW-2 2 297 6 1420 x 712 x 966 1/3 230-240/50/1 2.3 2.74 m 166 kg
TGW-3 3 456 9 1880 x 712 x 966 1/3 230-240/50/1 3.0 2.74 m 216 kg
WORKTOP FREEZERS
Model Doors
Capacity
(liters)
Shelves
Cabinet Dimensions
(mm)
HP Voltage Amps
Cord
Length
Crated
Weight
TGW-2F 2 297 6 1420 x 712 x 966 1/2 230-240/50/1 3.5 2.74 m 166 kg
TGW-3F 3 456 9 1880 x 712 x 966 1/2 230-240/50/1 4.1 2.74 m 216 kg
TGW-2
TGW-3F
Refrigerators - Oversized,
environmentally friendly (134A)
forced-air refrigeration system
holds .5°C to 3.3°C (33°F to
38°F).
Freezers - Oversized,
environmentally friendly (404A)
forced-air refrigeration system
holds -23.3°C (-10°F).
300 series stainless steel exterior.
16-gauge radius counter-top.
300 series stainless steel interior.
LED temperature display.
Front ventilation.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
3 sets of 1/1 gastronorm rails
with stainless steel shelves per
section.
