True T-49 Parts List

®

®

T-49

T-49G

Parts Manual

115V

T-49

T-49G

TO PLACE AN ORDER OR OBTAIN INFORMATION:

WEBSITE:

www.truemfg.com (Visit our Parts eStore at: http://estore.truemfg.com)
Parts Department e-mail address: [e-mail]

SEND INQUIRIES TO:

TRUE MANUFACTURING COMPANY, INC. ATTN: PARTS DEPARTMENT

 2001EASTTERRALANE•O’Fallon,Missouri63366-4434•U.S.A

CALL TOLL-FREE:

 800-424-TRUE(DirecttoPartsDepartment)
 or800-325-6152(U.S.A&Canadaonly)
 ORCALL:636-240-2400

 FAX:636-272-9471

* At times changes and/or corrections may have been made to this parts manual after publication.

Please consult our Parts Department at 1-800-424-8783 for verification.

9/24/2011MS

Castors,Legs&Levelers

Castors

87928121/2”setof4
8720633”setof4
8720104”setof4

Legs

8720016”setof4

Castors

83028021/2”setof4
8302774”setof4

8720256”setof4

* Recommended Spare Parts

Legs, Siesmec

8803486”setof4

Legs

1.

Compressors

*Cord, Power
(Compressor)

801797(Embraco)

*Accumulator

866743

Cord,

*

Power

801701

84125091/2HPEmbraco(NEK6212Z)

Condensing Unit

884939-

(after11/8/05)

Outlet, Compressor

801229

*Motor, Condenser Fan

800439after11/8/05

Blade,

Bracket,
Fan Motor

865417

Fan Motor
Condenser

801006

Block, Terminal

*LineSet910802

*Capillary

Tube

851134

*Capacitor, start

911444

or947400

Block

801452

Compressor Pull out

874525

*Compressor

842509

Bolt, Compressor

831503

*Overload

842474

Coil, Condenser

*Relay

842463(Embraco)
802113

Shroud,
Condenser
Coil

801501

800601

* Recommended Spare Parts

*Drier,

Compressor

800801 or

925928

2.

Base, Compressor

861074

Door Parts

DoorHinges

T-Series Full Door

Shaft

832108

*Stop Pin

832103

Washer

830630

Bushing

832110

Block
Not Replaceable

*Kit, Door Hinge Top

870865-T-49
870865-TS-49GRH/LH
933800-TS-49GLeft
933799-TS-49GRight

*Spring

875587

or

928369LH

or

928370RH

Block
Not Replaceable

Bushing

832110

Bearing

832109

Washer

830630

*Kit, Door Hinge Bottom

870866-T-49
933106-TS-49GBottom,

Left, or Right

* Recommended Spare Parts

3.

*Gasket810719

DoorParts-T-49

Base, Door
Gasket (Plastic)

810719

Kit,Door

Gasket Base
(Stainless)

874707

Door with

RecessedHandle

LF, Wide Gasket

884835

RH,WideGasket

884836

Door Locks

Solid Door

831305

Keys

831306

* Recommended Spare Parts

Locks (for T Models)

Cooler&Freezer

4.

DoorParts-T-49G

T-Series&TS-SeriesCoolerGlassSwingDoorswithIntegratedDoorLight(IDL)

Base, Lampholder

841477

Lampholder Top

801230

Tape, Light Filler

Channel Aluminum

820204

Door

Base, Lampholder

841477

Lamp Shield

810873

Lampholder Bottom

801254

Lamp

801155

*Gasket

811125

Bushing,

Strain Relief

811235

*Cord,Power,Door“Y”

801732

* Recommended Spare Parts

Receptacle

878038

Back Plate Door

Gasket kit

873008

5.

*Cord, Power

801723

DoorParts-T-49G

T-Series&TS-SeriesCoolerGlassSwingDoorswithIntegratedDoorLight(IDL)

Door

933711-LeftHinged,SilverFramed,IDLSilver

after7/28/09or

870668-LeftHinged,SilverFramed,Non-IDL.

Gasket

810719

870667-RightHinged,SilverFramedNon-IDL

933712-Door,Righthinged,silverframe,IDL,

cartridgeSpringafter8/12/09

* Recommended Spare Parts

6.

Pan,Evaporator

Drain

871202

Grommet,

Evaporator

Drain Elbow

810203

EvaporatorParts

Coil,EvaporatorAssy

916434

Elbow,

Evaporator

Drain

811502

Bracket,EvaporatorFan

Motor

863476

*Motor,EvaporatorFan

800401-before11/9/05

922036-after3/19/08

800437-EmbracoSystem

after11/8/05.

Blade,

Evaporator

Fan Motor

861106

or801030

Insulation

820746

Hose,Evaporator

Drain

882671

Cover,Evaporator

884940

Thermometer

(Digital)

831930

Condensate Parts

Guard,Evaporator

Fan Motor

Thermometer

(Dial)

925507

860078

*Switch
(rocker)

921088

*Control,

Temperature

926530Dixell

or831932

Pan, Condensate

Drain

810231

* Recommended Spare Parts

Pad,Evaporator

Wicking

874655

Wicking Bar

WickingKit

820799

7.

Grill Parts

Roiunded Front,

928665-AllLH,StainlessSteel
928666-RH/LH,StainlessSteel
928664-AllRH,StainlessSteel
928694-AllLH
928693-AllRH
928695-RH/LH

GrillMountingKit

928725

Lighting Parts

*Switch Rocker 2 Prong

* Recommended Spare Parts

(Refrigerator)

921088

801266after9/2

Lamp Bulb

801155 after 11/28/00

8.

Backguard

872930

Shelf Parts

Bracket, Shelf

Standard

862451

BunTrayRack

FullDoor871729

HalfDoor871728

*Clip, Shelf

831600

Bracket, Shelf

Standard

Bottom

830185

Shelf Standard Front

(Center)

White871803
Silver871801

Back (Center)

White871807
Silver879490

Shelf

White

871781

Bar

880251

* Recommended Spare Parts

Slide,BunTray
Standard871754
Universal871755

Shelf(WineRackStyle)

879202

9.

T-49 115v w/Suggested spare parts

9/26/11 ZS

Part # Description CS Info

866743 ACCUMULATOR

872930 BACKGUARD KIT, WHITE WIRE

929778 BACKSCREEN KIT, BLACK ALUMINUM PERFORATED METAL THAT COVERS COMPRESSOR AREA IN REAR OF CABINET TO PREVENT ACCESS.

861074 BASE, COMPRESSOR, METAL PLATFORM

861301 BASE, GASKET, PERIMETER STAINLESS, VERTICAL CENTER MULLION LOCATED ON CABINET BETWEEN THE DOORS

873016 BASE, MULLION, VERTICAL, BLACK PLASTIC (DRAWING #905256)

832056 BASKET, NOVELTY, WHITE, 19 1/4"W X 17 1/8"D MUST SET ON SHELF

832055 BASKET, NOVELTY, WHITE, 19-1/4"W X 22"D SETS ON A SHELF. 3 DIVIDERS INCLUDED.

832109 BEARING, THRUST, DOOR HINGE

801006 BLADE, FAN MOTOR, CONDENSER

861106 BLADE, FAN MOTOR, EVAPORATOR

801030 BLADE, FAN MOTOR, EVAPORATOR, 115V FOR EMBRACO SYSTEM

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

801452 BLOCK, COMPRESSOR MOUNTING

928725 BRACKET KIT, GRILL T-49, TS-53 FOR MAGNETIC GRILLS

864970 BRACKET, BACKSCREEN GUARD, END PIECE, BLACK REQUIRES 4 PER GUARD. ONE FOR EACH END OF GUARD, AND ONE EACH TOP CORNER.

864487 BRACKET, BACKSCREEN, MIDDLE FOR POWER CORD, BLACK REQUIRES 1 PER CABINET.

867519 BRACKET, CENTER CABINET BACK SUPPORT

862690 BRACKET, CENTER DOOR SUPPORT USED ONLY WHEN ALL DOORS HINGED RIGHT OR ALL LEFT

865417 BRACKET, FAN MOTOR, CONDENSER

863476 BRACKET, FAN MOTOR, EVAPORATOR, SHALLOW, 115V

115V**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

861832 BRACKET, GRILL, CENTER TOP

862451 BRACKET, SHELF STANDARD, TOP

USED AFTER OCTOBER 1999. HAS WIDE I BEAM CUTOUT. REPLACES BRACKET PREVIOUSLY USED W/
NARROW CUTOUT.

842231 BRUSH, CLEANING, CONDENSER COIL OPTION ONLY

914705 CAP, START CAPACITOR USED W/ NEK6212Z COMPRESSOR

911444 CAPACITOR, START, 115V 60 HZ R-134A 1/2HP FOR EMBRACO COMPRESSOR USED AFTER 11/8/05 OR APPROX, SERIAL NO. 1-4317432

851134 CAPILLARY TUBE, R-134A

830434 CASTOR COASTER

872063 CASTOR KIT, FRAMED, SET/4 (OPTION) 3" CASTORS W/ 27" FRAMES RAISES CABINET ~3 3/4"

872010 CASTOR KIT, FRAMED, SET/4 (OPTION) 4" CASTORS W/ 27" FRAMES RAISES CABINET ~4 7/8"

879281 CASTOR KIT, FRAMED, SET/4 (OPTION) 2 1/2" CASTORS W/ 27" FRAMES RAISES CABINET ~3 1/2"

830280 CASTOR, SET/4, 2-1/2" 1/2" STEM OPTION. SILVER HOUSING. USE FOR SER. NO.(1- 793556 - 1005582) (1-1088851 & AFTER)

830277 CASTOR, SET/4, 4", 1/2" STEM STANDARD CASTOR. FOR SER. NO. (1- 793556 - 1005582) (1-1088801 & AFTER).
861942 CLAMP, COMPRESSOR

920158 CLIP KIT, SHELF (SET/4)

918740 CLIP, OVERLOAD MOUNTING

*USED AFTER 6/5/06 PRODUCTION DATE OR APPROX SERIAL NO. 1-4379187 IN MEX...OR AFTER 6/21/06
PRODUCTION DATE OR APPROX SERIAL NO. 1-4531945 FOR BLDG. 8.

831600 CLIP, SHELF Requires 4 per shelf

830301 CLIP, SHROUD, CONDENSER COIL REQUIRES 2

922914 CLIP, THERMOMETER SLEEVE USED TO MOUNT DISPLAY PROBE. PCN 3866

800601 COIL, CONDENSER

916434 COIL, EVAPORATOR ASSEMBLY 115V EMBRACO SYSTEM

USED AFTER 11/8/2005 FOR PACIFIC PRODUCTION & USED AFTER 11/20/2005 FOR BOWLING GREEN
PRODUCTION.

842509 COMPRESSOR, 115V 60HZ, R-134A 1/2HP EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

884939 CONDENSING UNIT, 115V 60HZ, R134A 1/2HP

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

842088 CONNECTOR, INSULATE QUICK SLIDE FEMALE, ROCKER SWITCH

USED TO INSULATE THE UNUSED ROCKER SWITCH TERMINAL WHEN USING THE THREE PRONG SWITCH
ON COOLERS

801302 CONNECTOR, LAMPHOLDER USED AFTER 9/02 PRODUCTION DATE.

802179 CONNECTOR, TERMINAL, TEMPERATURE CONTROL, BLUE

926530 CONTROL, TEMPERATURE, 115V, DIXELL

831932 CONTROL, TEMPERATURE, 115V/208V/220V CE

T-49 115v w/Suggested spare parts

9/26/11 ZS

922814 COPPER REDUCER 1/2 TO 3/8" FOR SUCTION LINE TO PULLOUT

937374 CORD KIT, 115V EMBRACO COMPRESSOR POWER CORD/CORD KIT

8 PIN AMP CONNECTOR FOR COMPRESSOR POWER CORD AND CORD KIT W/ 8 PIN CONNECTOR THAT
CONNECTS START COMPONENTS TO COMPRESSOR POWER CORD

917607

CORD KIT, 115V EMBRACO FROM COMPRESSOR POWER CORD TO START
COMPONENTS

USED W/ EMBRACO COMPRESSORS

801797 CORD, POWER, COMPRESSOR, 115V FOR EMBRACO COMPRESSOR ONLY

*NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/21/05 PROUDCTION DATE OR SERIAL NO. 1-4310180 FOR BOWLING GREEN
PRODUCTION.

801701 CORD, POWER, MAIN, 115V, 108"

801766 CORD, POWER, MAIN, 115V, 132" (11 FOOT), SPECIAL APPLICATION CAN BE USED WHENEVER CUSTOMER NEEDS LONGER CORD.

892621 COVER, CAPILLARY SUCTION LINE, STAINLESS, RADIUS TANK

865450 COVER, CAPILLARY SUCTION LINE, WHITE, RADIUS TANK

842494 COVER, COMPRESSOR START COMPONENT

914717 COVER, COMPRESSOR START COMPONENT USED W/ NEK6212Z COMPRESSOR

860540 COVER, ELECTRICAL BOX, 115V

860078 COVER, EVAP FAN MOTOR BLADE WHITE ALUMINUM (GUARD)

860075 COVER, EVAP FAN MOTOR BLADE WHITE ALUMINUM (GUARD), 115V

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

884940 COVER, EVAPORATOR COIL, WHITE, 115V, ONE FAN OPENING, EMBRACO SYSTEM

*NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-4310179 FOR BOWLING GREEN
PRODUCTION.

864703 COVER, MULLION, BACK, STAINLESS, WESTLYNN

810391 COVER, TEMPERATURE CONTROL, MOLDED PLASTIC OPTION FOR ALL VOLTAGES. PLASTIC COVER TO KEEP PEOPLE FROM ADJUSTING TEMPERATURES

860602 COVER, TEMPERATURE CONTROL, WHITE (W/O ROCKER SWITCH HOLE)

911436 COVER, TEMPERATURE CONTROL, WHITE(USED FOR ELECTRONIC CONTROL)

USED TO COVER HOLE IN EVAPORATOR HOUSING. ELECTRONIC CONTROL IS MOUNTED IN RAINSHIELD.
USED BY VRESSO BEBANON

894755

COVER, TEMPERATURE CONTROL/LIGHT SWITCH CLEAR ALUMINUM FOR GE
CONTROL

USED W/ 831932 GE CONTROL (PCN #2943)

894753

COVER, TEMPERATURE CONTROL/LIGHT SWITCH WHITE ALUMINUM FOR GE
CONTROL

USED W/ 831932 GE CONTROL (PCN #2943)

880251 CROSS BAR, BUN TRAY RACK, 18-3/16" FOR BUN TRAY RACK 20 7/8"W X 24"D

938752 DIGITAL VACUUM GAUGE, DIGITAL

910448 DIVIDER ASSEMBLY, NOVELTY BASKET, LARGE, WHITE USED W/ 832055 BASKET

832057 DIVIDER, NOVELTY BASKET, SMALL, WHITE FOR SMALL BASKET PART NO. 832056

870684 DOOR, LEFT HINGED, STAINLESS, 15" HANDLE

884835

DOOR, LEFT HINGED, STAINLESS, RECESSED HANDLE, WIDE DOOR GASKET,
REFRIGERATOR

USED AFTER 11/29/05 APPROXIMATE PRODUCTION DATE OR #4319998 FOR BOWLING GREEN BUT CHECK
SPECIAL SERIAL NUMBER LIST FOR EXCEPTIONS. USED AFTER 12/05 APPROXIMATE PRODUCTION DATE IN
PACIFIC.

870683 DOOR, RIGHT HINGED, STAINLESS, 15" HANDLE

884836

DOOR, RIGHT HINGED, STAINLESS, RECESSED HANDLE, WIDE DOOR GASKET,
REFRIGERATOR

USED AFTER 10/'05 APPROXIMATE PROD. DATE IN BOWLING GREEN BUT CHECK SPECIAL SERIAL NUMBER
LIST FOR EXCEPTIONS. USED AFTER 12/'05 APPROXIMATE PRODUCTION DATE IN PACIFIC.

863105 ELECTRICAL BOX

921089 FACE PLATE, ROCKER SWITCH, BLACK

STARTED USING ~FEBRUARY 2008 (PCN #3917) REPLACES THE 810368 WHITE FACE-PLATE PREVIOUSLY
USED.

831998 FACEPLATE, THERMOMETER, CELCIUS, DIXEL X420C ()

810719 GASKET, DOOR, MAGNETIC (NWDG)

USED AFTER 11/29/05 APPROXIMATE PRODUCTION DATE OR #4319998 FOR BOWLING GREEN BUT CHECK
SPECIAL SERIAL NUMBER LIST FOR EXCEPTIONS. USED AFTER 12/05 APPROXIMATE PRODUCTION DATE IN
PACIFIC.

928694 GRILL KIT, ALL LEFT HINGE, MAGNETIC WITH MOUNTING BRACKETS USED TO RETROFIT OLDER STYLE GRILLS USED BEFORE 1/6/2009 (PCN #4115)

928693 GRILL KIT, ALL RIGHT HINGE, MAGNETIC WITH MOUNTING BRACKETS USED TO RETROFIT OLDER STYLE GRILLS USED BEFORE 1/6/2009 (PCN #4115)

928695 GRILL KIT, RIGHT HINGE/LEFT HINGE, MAGNETIC WITH MOUNTING BRACKETS USED TO RETROFIT OLDER STYLE GRILLS USED BEFORE 1/6/2009 (PCN #4115)

928665 GRILL, ASSEMBLY, STAINLESS, ALL LEFT HINGE, ROUNDED, MAGNETIC GRILL IS ROUNDED AND MOUNTING IS MAGNETIC. USE KIT TO RETROFIT OLD STYLE GRILLS.. PCN 4115

928664 GRILL, ASSEMBLY, STAINLESS, ALL RIGHT HINGE, ROUNDED, MAGNETIC GRILL IS ROUNDED AND MOUNTING IS MAGNETIC. USE KIT TO RETROFIT OLD STYLE GRILLS.. PCN 4115

928666 GRILL, ASSEMBLY, STAINLESS, LEFT HINGE/RIGHT HINGE, ROUNDED, MAGNETIC GRILL IS ROUNDED AND MOUNTING IS MAGNETIC. USE KIT TO RETROFIT OLD STYLE GRILLS.. PCN 4115

810203 GROMMET, DRAIN ELBOW

SERVES AS A PROTECTION ONLY AROUND HOLE CUT IN EVAPORATOR HOUSING FOR DRAIN ELBOW. DOES
NOT SERVE AS A WASHER FOR SEALING DRAIN ELBOW.

875545 HANDLE, DOOR, STAINLESS, SOLID DOORS HOLES DRILLED ON HANDLE AND DOOR 8-1/8" APART. USED ON SOLID DOORS.

928642 HEATER KIT, CONDENSATE PAN USED FOR FIELD INSTALL. 927642 HEATED DRAIN PAN SITS INSIDE OF 912540 METAL PAN. (FT #2388)

801801 HEATER, DOOR MULLION, 115V

870866 HINGE KIT, DOOR, BOTTOM LEFT OR RIGHT

T-49 115v w/Suggested spare parts

9/26/11 ZS

870865 HINGE KIT, DOOR, TOP, RIGHT OR LEFT

862006 HOLDER, CONDENSATE DRAIN PAN WICKING PAD, CLEAR ALUMINUM

882671 HOSE, EVAPORATOR DRAIN

820746 INSULATION, DRAIN PAN, EVAPORATOR

831306 KEY, LOCK, DOOR USED BEFORE 1/6/2009 W/ 831305/831357 LOCK ASSEMBLY

932992 KEY, LOCK, DOOR USED AFTER 1/5/2009 W/ 831373 LOCK ASSEMBLY

873054 KIT, GASKET BASE, PERIMETER PLASTIC

LOCATED ON CABINET "NOT ON DOOR". SURROUNDS DOOR OPENING. THIS PIECE HOLDS PERIMETER
STAINLESS ( AND PERIMETER HEATER WIRE ON SOME MODELS). 4 PIECE ASSEMBLY.

874707 KIT, GASKET BASE, PERIMETER STAINLESS

LOCATED ON CABINET "NOT ON DOOR". SURROUNDS DOOR OPENING. INSERTS INTO PERIMETER
PLASTIC. 4 PIECE ASSEMBLY.

918741

KIT, OVERLOAD/BRACKET, 115V 60 HZ R-134A, 1/3HP, FOR EMBRACO
COMPRESSOR

*USED AFTER 6/5/06 PRODUCTION DATE OR APPROX SERIAL NO. 1-4379187 IN MEX...OR AFTER 6/21/06
PRODUCTION DATE OR APPROX SERIAL NO. 1-4531945 FOR BLDG. 8.

913366 KIT, START COMPONET FOR EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

880982 KNOB, TEMPERATURE CONTROL, DANFOSS

831935 KNOB, TEMPERATURE CONTROL, GE

875548 KNOB, TEMPERATURE CONTROL, RANCO/CUTLER HAMMER

801112 LAMP, 115V ONE LAMP STANDARD

801266 LAMPHOLDER, 115V/208V/220V USED AFTER 9/02 PRODUCTION DATE. WILL REPLACE THE 801228 USED BEFORE.

872001 LEG KIT, 6" , SET/4, FRAME STYLE OPTIONAL ANY SERIAL NUMBER

880348 LEG KIT, 6" SET/4, 1/2" DIA. STEM, SEISMIC OPTION

872025 LEG KIT, 6", SET/4, 1/2" DIA. STEM USED AFTER SER. NO. 1-793556 EXCEPT FOR (1-1005583 - 1-1088848)

910802

LINE SET, ACCUMULATOR/CAPILLARY TUBE/SUCTION LINE, T-49, R-134A
EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

831373 LOCK, DOOR, STAINLESS (ONE PER DOOR)

STARTED USING ON 1/6/2009. REPLACES/RETROFITS PREVIOUS (831305/831357) LOCK ASSEMBLY. (PCN
#4115) CABINET HAS TWO DOORS

926534 MAGNETIC CATCH, GRILL

800439 MOTOR, CONDENSER FAN, 115V 60HZ, FOR EMBRACO COMPRESSOR

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

922036 MOTOR, EVAPORATOR FAN USED AFTER 3/19/08 PRODUCTION DATE. REPLACES THE 800437 PREVIOUSLY USED. PCN #3968

800437 MOTOR, EVAPORATOR FAN, 115V FOR EMBRACO SYSTEM

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

881781 MOUNTING KIT, BACKSCREEN

872925 MULLION ASSEMBLY, 115V, VERTICAL

811502 NOZZLE, EVAPORATOR DRAIN, PLASTIC, WHITE (45 DEGREE ELBOW)

801229 OUTLET/RECEPTACLE, COMPRESSOR POWER CORD, 115V/208V/220V NON CE

842474 OVERLOAD, 115V 60 HZ R-134A, 1/3HP, FOR EMBRACO COMPRESSOR

*USED AFTER 6/5/06 PRODUCTION DATE OR APPROX SERIAL NO. 1-4379187 IN MEX...OR AFTER 6/21/06
PRODUCTION DATE OR APPROX SERIAL NO. 1-4531945 FOR BLDG. 8.

831920 PAD, WICKING REQUIRES 5 TOTAL PADS

874655 PAD, WICKING (SET OF 5)

891858 PAN, DRAIN, CONDENSATE, BOTTOM, METAL, OPTION

912540 PAN, DRAIN, CONDENSATE, BOTTOM, METAL, WITH HOLE OPTION USE WITH ONE PIECE-DRAIN PAN HEATER

810231 PAN, DRAIN, CONDENSATE, BOTTOM, PLASTIC

871202 PAN, DRAIN, EVAPORATOR

832103 PIN, STOP, DOOR HINGE

801295 PLUG, HEATER, DRAIN PAN, 115V WAS USED WITH 801815 OR 801817 115V DRAIN PAN HEATERS, WHICH ARE NO LONGER AVAILABLE

892206 POST, MULLION, STAINLESS STEEL, TRAY SLIDE SYSTEM WILL NOT RETROFIT IN THE FIELD. FOR REPLACEMENT ONLY.

935910 PROBE, THERMOMETER USED W/ 800400 THERMOMETER

926488 PRODUCT ID STRIP, WIRE SHELF, BLACK (48")

873774 PRODUCT ID STRIP, WIRE SHELF, WHITE (48")

810501 PROTECTOR, DOOR SPRING THIS IS ONLY THE RUBBER COVER FOR A DOOR SPRING.

874525 PULLOUT ASSEMBLY, COMPRESSOR

871729 RACK, BUN TRAY, FULL DOOR

FOR 18"(46CM) X 26"(66CM) SHEET PANS. COMES WITH 44 PAN SUPPORTS TO HOLD 22 PANS. MAXIMUM
CAPACITY IS 32 PANS. SPACING OF NOTCHES ON VERTICAL SIDES OF RACK ARE 1-1/2" APART.

871728 RACK, BUN TRAY, HALF DOOR

FOR 18" X 26" PAN COMES WITH 22 PAN SUPPORTS TO HOLD 11 PANS. MAXIMUM CAPACITY IS 13 BUN
PANS.

919828 RAIL ASSEMBLY, BLACK

T-49 115v w/Suggested spare parts

9/26/11 ZS

871539 RAINSHIELD, FOR BOTH DOORS HINGED LEFT

938631 RAINSHIELD, FOR BOTH DOORS HINGED LEFT W/ DIGITAL THERMOMETER USED W/ RECTANGULAR DIGITAL THERMOMETER

871538 RAINSHIELD, FOR BOTH DOORS HINGED RIGHT

938632 RAINSHIELD, FOR BOTH DOORS HINGED RIGHT W/ DIGITAL THERMOMETER USED W/ RECTANGULAR DIGITAL THERMOMETER

938630 RAINSHIELD, FOR STANDARD HINGED 1 LEFT/1 RIGHT W/ DIGITAL THERMOMETER USED W/ RECTANGULAR DIGITAL THERMOMETER
871502 RAINSHIELD, FOR STANDARD HINGED DOOR 1 LEFT/1 RIGHT

842463 RELAY, 115V 60HZ R-134A 1/2HP, EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

800182 RELAY, TEMPERATURE CONTROL FOR DANFOSS 077B7633 CONTROL

874654 RIVNUT TOOL, CASTOR OR LEG, 1/2" STEM

874642 RIVNUT TOOL, KIT, SHELF STANDARD

874640 RIVNUT TOOL, SHELF STANDARD

861087 SCREEN, CONDENSER FAN MOTOR

832108 SHAFT, DOOR HINGE

917307 SHELF KIT, CHROME WIRE

871719 SHELF KIT, STAINLESS STEEL <<POSSIBLE 3-4 WEEK LEAD TIME DUE TO ELECTRO POLISHING>>

871781 SHELF KIT, WHITE WIRE

861105 SHELF STANDARD, 47 3/8", CABINET SIDE & BACK, WHITE STANDARD PRODUCTION

832195 SHELF STANDARD, 52", CABINET SIDE, STAINLESS STEEL (OPTION) INCLUDE: 9)830501 MOUNTING SCREWS

879490 SHELF STANDARD, BACK CENTER, SILVER

871807 SHELF STANDARD, BACK CENTER, WHITE

872974 SHELF STANDARD, CABINET SIDE, WHITE, 52", OPTION

871801 SHELF STANDARD, FRONT CENTER, SILVER

871803 SHELF STANDARD, FRONT CENTER, WHITE

801501 SHROUD, CONDENSER COIL

801504 SHROUD, CONDENSER FAN MOTOR & BLADE GOES OVER TOP CONDENSER SCREEN TO PROTECT HANDS FROM GOING INTO FAN AREA

867770 SLEEVE, TEMPERATURE CONTROL

832320 SLEEVE, THERMOMETER

USED ONLY WITH LED TEMPERATURE DISPLAY. ONLY THE DISPLAY PROBE IS IN BRASS SLEEVE AND
WRAPPED IN CORK TAPE PER PCN 3866

871754 SLIDE, BUN TRAY RACK, STANDARD STANDARD RAILS THAT COME WITH THE BUN TRAY RACKS.

871755 SLIDE, BUN TRAY RACK, UNIVERSAL

WIDER RAIL THAT ALLOWS NARROWER PANS AS WELL AS THE WIDER PANS TO FIT INTO THE BUN TRAY
RACK. (PURCHASED PART #832058)

875544 SPACER KIT, DOOR HANDLE, SILVER, SOLID DOOR

875587 SPRING, HINGE, DOOR

830170 STAND OFF, SHELF

875510 STRIKER, ROCKER SWITCH , NO CHARGE PART

BLACK PLASTIC SHIM LOCATED ON TOP OF DOOR TO ACTIVATE ROCKER SWITCH AND PREVENT ROCKER
SWITCH FROM TEARING DOOR GASKET. . REQUIRES 2) PER COOLER. PCN 4042 8/19/08 RETROFITS

801924 SWITCH, POWER, 115V TO SHUT OFF POWER TO SERVICE.

921088 SWITCH, ROCKER, 3 PRONG, BLACK, LIGHT REPLACES THE 801907 WHEN THE CENTER PRONG IS CAPPED WITH 842088 CONNECTOR

925507

THERMOMETER, DIAL, CELCIUS/FAHRENHEIT, ROUND EXTERIOR, BLACK FACED,
STANDARD

REPLACES 831914 PREVIOUSLY USED (PCN #4115)

830426 THERMOMETER, DIAL, CELCIUS/FAHRENHEIT, ROUND INTERIOR HANGING OPTION

822205 THERMOMETER, DIGITAL, CELCIUS, LED, 115V ROUND EXTERIOR, WITH BUILT IN TRANSFORMER

831904 THERMOMETER, DIGITAL, CELSIUS, LED, ROUND

REQUIRES TRANSFORMER. IN PRODUCTION THIS WAS USED BEFORE 6/25/03. WHEN WE RUN OUT OF
THESE THE 831930-FI CAN BE SENT AS A REPLACEMENT

800400 THERMOMETER, DIGITAL, FAHRENHEIT, LED, 115V, ROUND EXTERIOR OPTION

831908 THERMOMETER, DIGITAL, FAHRENHEIT, ROUND EXTERIOR OPTION

800321 THERMOMETER, TUBE TYPE, FAHRENHEIT/CELSIUS

832270 TOOL, ADJUSTMENT, DANFOSS TEMPERATURE CONTROL USED TO CALIBRATED DANFOSS CONTROL

831970 TRANSFORMER, THERMOMETER, 115V REPLACES 831909 MODEL 015-0054-01

820799 WICKING KIT, CONDENSATE PAN OPTION.

866524 WIRE HARNESS, 115V/208V/220V

830271 WRENCH, 2-1/2" CASTOR, W/SILVER FRAME

USED BEFORE ~8/2000. BETWEEN 8/2000 & 3/2001 COULD USE EITHER THE 830272 WRENCH OR THE
8730271 WRENCH.

830263 WRENCH, 2-1/2", 4", 5" CASTOR FOR 8 SIDED NUT ON UNDERSIDE OF HOUSING. CURRENT PRODUCTION.

872904 WRENCH, DOOR HINGE, TORSION SPRING THIS IS A NO CHARGE ITEM

T-49G 115v w/Suggested spare parts

9/22/11 DS

Part # Description

CS Info

866743

ACCUMULATOR

929778

BACKSCREEN KIT, BLACK ALUMINUM

PERFORATED METAL THAT COVERS COMPRESSOR AREA IN REAR OF CABINET TO PREVENT ACCESS.

800506

BALLAST, LIGHT, 115V, NON-IDL

914241

BALLAST, LIGHT, 115V208V, DOOR, IDL,

USE AFTER 11/28/00 PRODUCTION DATE. REPLACES 800542 & 800559

861074

BASE, COMPRESSOR, METAL PLATFORM

861301

BASE, GASKET, PERIMETER STAINLESS, VERTICAL CENTER
MULLION

LOCATED ON CABINET BETWEEN THE DOORS

841477

BASE, LAMPHOLDER/ LAMPSHIELD, IDL DOOR

IF COOLER WAS PRODUCED BEFORE 12/99 PRODUCTION DATE NEW SCREW HOLES MAY HAVE TO BE DRILLED
AS THIS BASE HAS A DIFFERENT SCREW HOLE CONFIGURATION.

832056

BASKET, NOVELTY, WHITE, 19 1/4"W X 17 1/8"D

MUST SET ON SHELF

832055

BASKET, NOVELTY, WHITE, 19-1/4"W X 22"D

SETS ON A SHELF. 3 DIVIDERS INCLUDED.

832109

BEARING, THRUST, DOOR HINGE

801006

BLADE, FAN MOTOR, CONDENSER

861106

BLADE, FAN MOTOR, EVAPORATOR

801030

BLADE, FAN MOTOR, EVAPORATOR, 115V FOR EMBRACO SYSTEM

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

924848

BLOCK ASSEMBLY, BOTTOM DOOR HINGE

USED BEFORE 7/29/09 (PCN #4283) W/ TORSION SPRING

801452

BLOCK, COMPRESSOR MOUNTING

832319

BLOCK, DOOR HINGE, BOTTOM

USED AFTER 7/28/09 (PCN #4283) W/ CARTRIDGE HINGE SPRING

832126

BLOCK, DOOR HINGE, TOP

USED BEFORE 7/29/09 (PCN #4283) W/ TORSION SPRING

914647

BRACKET KIT, GRILL MOUNTING EURO ROUNDED FRONT

THIS KIT WILL REPLACE THE PLASTIC FASTENERS USED BEFORE WHEN PLASTIC FASTENERS ARE REMOVED
FROM BACKSIDE OF GRILL. USED BEFORE MAGNETIC GRILLS.

913700

BRACKET KIT, GRILL MOUNTING EURO ROUNDED FRONT

USED BEFORE MAGNETIC GRILLS.

928725

BRACKET KIT, GRILL T-49, TS-53 FOR MAGNETIC GRILLS

864487

BRACKET, BACKSCREEN, MIDDLE FOR POWER CORD, BLACK

REQUIRES 1 PER CABINET.

862690

BRACKET, CENTER DOOR SUPPORT

USED ONLY WHEN ALL DOORS HINGED RIGHT OR ALL LEFT

863642

BRACKET, DOOR SUPPORT (CRATING)

865417

BRACKET, FAN MOTOR, CONDENSER

863476

BRACKET, FAN MOTOR, EVAPORATOR, SHALLOW, 115V

115V**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

830185

BRACKET, SHELF STANDARD, BOTTOM MOLDED PLASTIC

REPLACES THE METAL L BRACKET USED BEFORE 4/97 AND MOLDED BRACKET USED FOR 4/97 - 6/02 .

862451

BRACKET, SHELF STANDARD, TOP

USED AFTER OCTOBER 1999. HAS WIDE I BEAM CUTOUT. REPLACES BRACKET PREVIOUSLY USED W/ NARROW
CUTOUT.

914706

BRACKET, START CAPACITOR, 1/2HP, NEK6212Z, 115V

914705

CAP, START CAPACITOR

USED W/ NEK6212Z COMPRESSOR

947400

CAPACITOR, START, 115V 60HZ, R134A, 1/2HP

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

911444

CAPACITOR, START, 115V 60 HZ R-134A 1/2HP FOR EMBRACO
COMPRESSOR

USED AFTER 11/8/05 OR APPROX, SERIAL NO. 1-4317432

851134

CAPILLARY TUBE, R-134A

872010

CASTOR KIT, FRAMED, SET/4

(OPTION) 4" CASTORS W/ 27" FRAMES RAISES CABINET ~4 7/8"

872063

CASTOR KIT, FRAMED, SET/4

(OPTION) 3" CASTORS W/ 27" FRAMES RAISES CABINET ~3 3/4"

879281

CASTOR KIT, FRAMED, SET/4

(OPTION) 2 1/2" CASTORS W/ 27" FRAMES RAISES CABINET ~3 1/2"

830280

CASTOR, SET/4, 2-1/2" 1/2" STEM

OPTION. SILVER HOUSING. USE FOR SER. NO.(1- 793556 - 1005582) (1-1088851 & AFTER)

Suggested Spare Parts

T-49G 115v w/Suggested spare parts

9/22/11 DS

830277

CASTOR, SET/4, 4", 1/2" STEM

STANDARD CASTOR. FOR SER. NO. (1- 793556 - 1005582) (1-1088801 & AFTER).

861942

CLAMP, COMPRESSOR

920158

CLIP KIT, SHELF (SET/4)

909188

CLIP, EUROPEAN GRILL

918740

CLIP, OVERLOAD MOUNTING

*USED AFTER 6/5/06 PRODUCTION DATE OR APPROX SERIAL NO. 1-4379187 IN MEX...OR AFTER 6/21/06
PRODUCTION DATE OR APPROX SERIAL NO. 1-4531945 FOR BLDG. 8.

831600

CLIP, SHELF

Requires 4 per shelf

830301

CLIP, SHROUD, CONDENSER COIL

REQUIRES 2

922914

CLIP, THERMOMETER SLEEVE

USED TO MOUNT DISPLAY PROBE. PCN 3866

800601

COIL, CONDENSER

916437

COIL, EVAPORATOR ASSEMBLY (REPLACES THE 800201 PREVIOUSLY
USED)

*115V NOTE FACTORY DATES: USED BEFORE 11/9/05 PRODUCTION OR SERIAL NO. 1-4310406 FOR PACIFIC
PRODUCTION. USED BEFORE 11/21/05 PROUDCTION DATE OR SERIAL NO. 1-4310180 FOR BOWLING GREEN
PRODUCTION. STILL USED ON OTHER VOLTAGES.

916434

COIL, EVAPORATOR ASSEMBLY 115V EMBRACO SYSTEM

USED AFTER 11/8/2005 FOR PACIFIC PRODUCTION & USED AFTER 11/20/2005 FOR BOWLING GREEN PRODUCTION.

842509

COMPRESSOR, 115V 60HZ, R-134A 1/2HP EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

884939

CONDENSING UNIT, 115V 60HZ, R134A 1/2HP

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

802179

CONNECTOR, TERMINAL, TEMPERATURE CONTROL, BLUE

831932

CONTROL, TEMPERATURE, 115V/208V/220V CE

922814

COPPER REDUCER 1/2 TO 3/8" FOR SUCTION LINE TO PULLOUT

937374

CORD KIT, 115V EMBRACO COMPRESSOR POWER CORD/CORD KIT

8 PIN AMP CONNECTOR FOR COMPRESSOR POWER CORD AND CORD KIT W/ 8 PIN CONNECTOR THAT
CONNECTS START COMPONENTS TO COMPRESSOR POWER CORD

917607

CORD KIT, 115V EMBRACO FROM COMPRESSOR POWER CORD TO
START COMPONENTS

USED W/ EMBRACO COMPRESSORS

915105

CORD, CONNECTS START COMPONENTS TO COMPRESSOR POWER
CORD

REPLACE W/ 917607 CORD KIT

801797

CORD, POWER, COMPRESSOR, 115V FOR EMBRACO COMPRESSOR
ONLY

*NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC PRODUCTION.
USED AFTER 11/21/05 PROUDCTION DATE OR SERIAL NO. 1-4310180 FOR BOWLING GREEN PRODUCTION.

801732

CORD, POWER, DOOR, "Y", IDL

801704

CORD, POWER, MAIN, 115V , 15 AMP/WIRE
HARNESS/OUTLET/RECEPTACLE, 92"

FOR REPLACEMENT ONLY

801701

CORD, POWER, MAIN, 115V, 108"

801766

CORD, POWER, MAIN, 115V, 132" (11 FOOT), SPECIAL APPLICATION

CAN BE USED WHENEVER CUSTOMER NEEDS LONGER CORD.

860540

COVER, BALLAST BOX, 115V

892621

COVER, CAPILLARY SUCTION LINE, STAINLESS, RADIUS TANK

865450

COVER, CAPILLARY SUCTION LINE, WHITE, RADIUS TANK

842494

COVER, COMPRESSOR START COMPONENT

914717

COVER, COMPRESSOR START COMPONENT

USED W/ NEK6212Z COMPRESSOR

860078

COVER, EVAP FAN MOTOR BLADE WHITE ALUMINUM (GUARD)

860075

COVER, EVAP FAN MOTOR BLADE WHITE ALUMINUM (GUARD), 115V

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

911436

COVER, TEMPERATURE CONTROL, WHITE(USED FOR ELECTRONIC
CONTROL)

USED TO COVER HOLE IN EVAPORATOR HOUSING. ELECTRONIC CONTROL IS MOUNTED IN RAINSHIELD. USED
BY VRESSO BEBANON

894755

COVER, TEMPERATURE CONTROL/LIGHT SWITCH CLEAR ALUMINUM
FOR GE CONTROL

USED W/ 831932 GE CONTROL (PCN #2943)

894753

COVER, TEMPERATURE CONTROL/LIGHT SWITCH WHITE ALUMINUM
FOR GE CONTROL

USED W/ 831932 GE CONTROL (PCN #2943)

T-49G 115v w/Suggested spare parts

9/22/11 DS

890104

COVER, TEMPERATURE CONTROL/LIGHT SWITCH, WHITE

HAS V SHAPED NOTCH TO SET TEMPERATURE.

880251

CROSS BAR, BUN TRAY RACK, 18-3/16"

FOR BUN TRAY RACK 20 7/8"W X 24"D

938752

DIGITAL VACUUM GAUGE, DIGITAL

910448

DIVIDER ASSEMBLY, NOVELTY BASKET, LARGE, WHITE

USED W/ 832055 BASKET

832057

DIVIDER, NOVELTY BASKET, SMALL, WHITE

FOR SMALL BASKET PART NO. 832056

933711

DOOR, LEFT HINGED, SILVER FRAMED, 115V/208V, WDG, IDL,
CARTRIDGE SPRING

STARTED USING CARTRIDGE SPRINGS AFTER 8/12/2009 (PCN #4283) REPLACES/RETROFITS TORSION SPRING
DOORS USED PRIOR.

870668

DOOR, LEFT HINGED, SILVER FRAMED, NON-IDL

933712

DOOR, RIGHT HINGED, SILVER FRAMED, 115V/208V, WDG, IDL,
CARTRIDGE SPRING

STARTED USING CARTRIDGE SPRINGS AFTER 8/12/2009 (PCN #4283) REPLACES/RETROFITS TORSION SPRING
DOORS USED PRIOR.

870667

DOOR, RIGHT HINGED, SILVER FRAMED, NON-IDL

925928

DRIER, COMPRESSOR, 115V

115V ONLY REPLACES ALL THE 800801 PREVIOUSLY USED. STARTED TO USE IN PRODUCTION AFTER 5/23/11
PRODUCTION DATE OR SER. NO 1-7146849 PER PCN 5043

831998

FACEPLATE, THERMOMETER, CELCIUS, DIXEL X420C ()

810719

GASKET, DOOR, MAGNETIC (NWDG)

USED AFTER 9/01/2009 (PCN #4106)

912382

GLASS INSERT, DOOR, IDL

912290

GLASS INSERT, DOOR, NON-IDL

928694

GRILL KIT, ALL LEFT HINGE, MAGNETIC WITH MOUNTING BRACKETS

USED TO RETROFIT OLDER STYLE GRILLS USED BEFORE 1/6/2009 (PCN #4115)

928693

GRILL KIT, ALL RIGHT HINGE, MAGNETIC WITH MOUNTING
BRACKETS

USED TO RETROFIT OLDER STYLE GRILLS USED BEFORE 1/6/2009 (PCN #4115)

928695

GRILL KIT, RIGHT HINGE/LEFT HINGE, MAGNETIC WITH MOUNTING
BRACKETS

USED TO RETROFIT OLDER STYLE GRILLS USED BEFORE 1/6/2009 (PCN #4115)

928665

GRILL, ASSEMBLY, STAINLESS, ALL LEFT HINGE, ROUNDED,
MAGNETIC

GRILL IS ROUNDED AND MOUNTING IS MAGNETIC. USE KIT TO RETROFIT OLD STYLE GRILLS.. PCN 4115

928664

GRILL, ASSEMBLY, STAINLESS, ALL RIGHT HINGE, ROUNDED,
MAGNETIC

GRILL IS ROUNDED AND MOUNTING IS MAGNETIC. USE KIT TO RETROFIT OLD STYLE GRILLS.. PCN 4115

928666

GRILL, ASSEMBLY, STAINLESS, LEFT HINGE/RIGHT HINGE,
ROUNDED, MAGNETIC

GRILL IS ROUNDED AND MOUNTING IS MAGNETIC. USE KIT TO RETROFIT OLD STYLE GRILLS.. PCN 4115

810203

GROMMET, DRAIN ELBOW

SERVES AS A PROTECTION ONLY AROUND HOLE CUT IN EVAPORATOR HOUSING FOR DRAIN ELBOW. DOES NOT
SERVE AS A WASHER FOR SEALING DRAIN ELBOW.

879473

HANDLE KIT, DOOR, BLACK

HOLES DRILLED ON HANDLE AND DOOR 8-1/8" APART

851217

HANDLE, DOOR, SILVER, GLASS DOORS

HOLES DRILLED ON HANDLE AND DOOR 8-1/8" APART. USED ON GLASS DOORS.

928642

HEATER KIT, CONDENSATE PAN

USED FOR FIELD INSTALL. 927642 HEATED DRAIN PAN SITS INSIDE OF 912540 METAL PAN. (FT #2388)

927642

HEATER, CONDENSATE DRAIN PAN, 115V/160W W/5-15 CORD (FOR
FIELD INSTALL)

USED FOR FIELD INSTALL. SITS IN METAL DRAIN PAN ORDER SEPARTELY

801814

HEATER, CONDENSATE PAN, 115V, ONE-PIECE PAN/HEATER

ONLY USED TO REPLACE AN EXISTING 801814-FI HEATED DRAIN PAN. NEW INSTALLATION IN FIELD VOIDS UL
APPROVAL.

801801

HEATER, DOOR MULLION, 115V

933106

HINGE KIT, DOOR, BOTTOM LEFT OR RIGHT

REPLACES/RETROFITS 870866 PREVIOUSLY USED (FT #2725)

933800

HINGE KIT, DOOR, TOP, LEFT, CARTRIDGE HINGE

USED AFTER 8/12/2009 (PCN #4283)

933799

HINGE KIT, DOOR, TOP, RIGHT, CARTRIDGE HINGE

USED AFTER 8/12/2009 (PCN #4283)

862006

HOLDER, CONDENSATE DRAIN PAN WICKING PAD, CLEAR ALUMINUM

882671

HOSE, EVAPORATOR DRAIN

928718

INSTRUCTION, INSTALLATION T-SE GRILL RETROFIT TO MAGNETIC

820746

INSULATION, DRAIN PAN, EVAPORATOR

831306

KEY, LOCK, DOOR

USED BEFORE 1/6/2009 W/ 831357 LOCK ASSEMBLY

932992

KEY, LOCK, DOOR

USED AFTER 1/5/2009 W/ 831373 LOCK ASSEMBLY

873054

KIT, GASKET BASE, PERIMETER PLASTIC

LOCATED ON CABINET "NOT ON DOOR". SURROUNDS DOOR OPENING. THIS PIECE HOLDS PERIMETER
STAINLESS ( AND PERIMETER HEATER WIRE ON SOME MODELS). 4 PIECE ASSEMBLY.

T-49G 115v w/Suggested spare parts

9/22/11 DS

874707

KIT, GASKET BASE, PERIMETER STAINLESS

LOCATED ON CABINET "NOT ON DOOR". SURROUNDS DOOR OPENING. INSERTS INTO PERIMETER PLASTIC. 4
PIECE ASSEMBLY.

918741

KIT, OVERLOAD/BRACKET, 115V 60 HZ R-134A, 1/3HP, FOR EMBRACO
COMPRESSOR

*USED AFTER 6/5/06 PRODUCTION DATE OR APPROX SERIAL NO. 1-4379187 IN MEX...OR AFTER 6/21/06
PRODUCTION DATE OR APPROX SERIAL NO. 1-4531945 FOR BLDG. 8.

913366

KIT, START COMPONET FOR EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

880982

KNOB, TEMPERATURE CONTROL, DANFOSS

831935

KNOB, TEMPERATURE CONTROL, GE

875548

KNOB, TEMPERATURE CONTROL, RANCO/CUTLER HAMMER

801155

LAMP, 115V/208V, IDL, T-8 24K

USED AFTER 11/28/00 PRODUCTION DATE OR AFTER APPROX. SER. NO. 1-2786221

801101

LAMP, 115V/208V, NON-IDL, T-12

801223

LAMPHOLDER, 115V/208V, NON-IDL

801224

LAMPHOLDER, 115V/208V, NON-IDL

801254

LAMPHOLDER, 115V/208V/220V, DOOR, IDL "BOTTOM"

FOR ALL EXCEPT FROM 12/99 TO 12/8/00 PRODUCTION.

842111

LAMPHOLDER, 115V/208V/220V/CE, IDL DOOR

115V/208V/220V USED FROM 12/99 - 12/8/01 PRODUCTION.
220V CE STILL USED
FOR BOTTOM OR TOP OF DOOR.

801253

LAMPSHIELD END CAP, T12 LAMP, NON-IDL

810873

LAMPSHIELD, DOOR, 115V/208V/220V & CE, IDL

801206

LAMPSHIELD, T12 LAMP, NON-IDL

872001

LEG KIT, 6" , SET/4, FRAME STYLE

OPTIONAL ANY SERIAL NUMBER

880348

LEG KIT, 6" SET/4, 1/2" DIA. STEM, SEISMIC

OPTION

872025

LEG KIT, 6", SET/4, 1/2" DIA. STEM

USED AFTER SER. NO. 1-793556 EXCEPT FOR (1-1005583 - 1-1088848)

871016

LIGHT ASSEMBLY, 115V/208V, INTERIOR, NON-IDL

871047

LIGHT ASSEMBLY, 115V/208V/220V, LEFT HINGED, IDL DOOR, BLACK

871035

LIGHT ASSEMBLY, 115V/208V/220V, RIGHT HINGED, IDL DOOR, BLACK

920406

LIGHT ASSEMBLY, 115V/208V/220V, RIGHT HINGED, IDL DOOR, SILVER

910802

LINE SET, ACCUMULATOR/CAPILLARY TUBE/SUCTION LINE, R-134A
EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

831373

LOCK, DOOR, GLASS (ONE PER DOOR)

STARTED USING ON 1/6/2009. REPLACES/RETROFITS PREVIOUS (872837) LOCK ASSEMBLY. (PCN #4115)

926534

MAGNETIC CATCH, GRILL

800439

MOTOR, CONDENSER FAN, 115V 60HZ, FOR EMBRACO
COMPRESSOR

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

922036

MOTOR, EVAPORATOR FAN

USED AFTER 3/19/08 PRODUCTION DATE. REPLACES THE 800437 PREVIOUSLY USED. PCN #3968

800437

MOTOR, EVAPORATOR FAN, 115V FOR EMBRACO SYSTEM

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

872926

MULLION ASSEMBLY, VERTICAL, NON-IDL

820344

NAMEPLATE, TRUE

811502

NOZZLE, EVAPORATOR DRAIN, PLASTIC, WHITE (45 DEGREE ELBOW)

830931

NUT, SHELF STANDARD

801229

OUTLET/RECEPTACLE, COMPRESSOR POWER CORD,
115V/208V/220V NON CE

947399

OVERLOAD, 115V 60 HZ R-134A 1/2 HP

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

T-49G 115v w/Suggested spare parts

9/22/11 DS

842474

OVERLOAD, 115V 60 HZ R-134A, 1/3HP, FOR EMBRACO
COMPRESSOR

*USED AFTER 6/5/06 PRODUCTION DATE OR APPROX SERIAL NO. 1-4379187 IN MEX...OR AFTER 6/21/06
PRODUCTION DATE OR APPROX SERIAL NO. 1-4531945 FOR BLDG. 8.

831920

PAD, WICKING

REQUIRES 5 TOTAL PADS

874655

PAD, WICKING (SET OF 5)

891858

PAN, DRAIN, CONDENSATE, BOTTOM, METAL, OPTION

912540

PAN, DRAIN, CONDENSATE, BOTTOM, METAL, WITH HOLE OPTION

USE WITH ONE PIECE-DRAIN PAN HEATER

810231

PAN, DRAIN, CONDENSATE, BOTTOM, PLASTIC

871202

PAN, DRAIN, EVAPORATOR

832103

PIN, STOP, DOOR HINGE

USED BEFORE 7/29/09 (PCN #4283) W/ TORSION SPRING

935910

PROBE, THERMOMETER

USED W/ 800400 THERMOMETER

874525

PULLOUT ASSEMBLY, COMPRESSOR

115V REPLACE WITH 953081 PULLOUT. 208V/220 THIS PART IS STILL USED.

871729

RACK, BUN TRAY, FULL DOOR

FOR 18"(46CM) X 26"(66CM) SHEET PANS. COMES WITH 44 PAN SUPPORTS TO HOLD 22 PANS. MAXIMUM
CAPACITY IS 32 PANS. SPACING OF NOTCHES ON VERTICAL SIDES OF RACK ARE 1-1/2" APART.

871728

RACK, BUN TRAY, HALF DOOR

FOR 18" X 26" PAN COMES WITH 22 PAN SUPPORTS TO HOLD 11 PANS. MAXIMUM CAPACITY IS 13 BUN PANS.

871573

RAINSHIELD, FOR ALL DOORS HINGED RIGHT

871557

RAINSHIELD, FOR STANDARD HINGED DOORS 1 LEFT/1 RIGHT

878038

RECEPTACLE, POWER CORD, DOOR, IDL

USED AFTER 12/4/00 PRODUCTION DATE. LOCATED IN BALLAST BOX. CONNECTS SPLIT "Y" DOOR LIGHT POWER
CORD TO BALLAST.

947398

RELAY, 115V 60HZ R-134A

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN
PRODUCTION.

842463

RELAY, 115V 60HZ R-134A 1/2HP, EMBRACO

**NOTE FACTORY DATES: USED AFTER 11/8/05 PRODUCTION OR SERIAL NO. 1-4310405 FOR PACIFIC
PRODUCTION. USED AFTER 11/20/05 PROUDCTION DATE OR SERIAL NO. 1-43101879FOR BOWLING GREEN

800182

RELAY, TEMPERATURE CONTROL

FOR DANFOSS 077B7633 CONTROL

873008

RETAINER KIT, DOOR GASKET, NARROW GASKET

USED BEFORE 3/29/2007 W/ 810803 GASKET.

934074

RETAINER KIT, DOOR GASKET, NWDG

USED AFTER 9/01/2009 (PCN #4106) W/ 810719 GASKET. THIS IS THE BLACK PLASTIC ON THE DOOR THAT HOLDS
THE GASKET IN PLACE. CONSISTS OF 4 PIECES AND WILL RETROFIT OLDER STYLE DOORS IF THE GASKET IS
ALSO REPLACED.

874654

RIVNUT TOOL, CASTOR OR LEG, 1/2" STEM

874642

RIVNUT TOOL, KIT, SHELF STANDARD

874640

RIVNUT TOOL, SHELF STANDARD

830926

RIVNUT, CASTOR OR LEG, 1/2" STEM

830909

RIVNUT, SHELF STANDARD

861087

SCREEN, CONDENSER FAN MOTOR

832108

SHAFT, DOOR HINGE

USED BEFORE 8/13/2009 (PCN #4283) W/ TORSION SPRING DOORS

929905

SHAFT, DOOR HINGE TOP, FOR 928370 CARTRIDGE HINGE

USED AFTER 8/12/2009 (PCN #4283) W/ CARTRIDGE SPRING DOORS

917307

SHELF KIT, CHROME WIRE

871719

SHELF KIT, STAINLESS STEEL

<<POSSIBLE 3-4 WEEK LEAD TIME DUE TO ELECTRO POLISHING>>

875378

SHELF KIT, WHITE WIRE, FOR TRAY CHANNEL

UK DESIGN (GASTRONORM)

871781

SHELF KIT, WHITE WIRE, IDL

871791

SHELF KIT, WHITE WIRE, NON-IDL

861105

SHELF STANDARD, 47 3/8", CABINET SIDE, WHITE

STANDARD PRODUCTION

832195

SHELF STANDARD, 52", CABINET SIDE, STAINLESS STEEL

(OPTION) INCLUDE: 9)830501 MOUNTING SCREWS

879490

SHELF STANDARD, BACK CENTER, SILVER

871807

SHELF STANDARD, BACK CENTER, WHITE

872974

SHELF STANDARD, CABINET SIDE, WHITE, 52", OPTION

871801

SHELF STANDARD, FRONT CENTER, SILVER

T-49G 115v w/Suggested spare parts

9/22/11 DS

871803

SHELF STANDARD, FRONT CENTER, WHITE

801501

SHROUD, CONDENSER COIL

801504

SHROUD, CONDENSER FAN MOTOR & BLADE

GOES OVER TOP CONDENSER SCREEN TO PROTECT HANDS FROM GOING INTO FAN AREA

867770

SLEEVE, TEMPERATURE CONTROL

832320

SLEEVE, THERMOMETER

USED ONLY WITH LED TEMPERATURE DISPLAY. ONLY THE DISPLAY PROBE IS IN BRASS SLEEVE AND WRAPPED
IN CORK TAPE PER PCN 3866

871754

SLIDE, BUN TRAY RACK, STANDARD

STANDARD RAILS THAT COME WITH THE BUN TRAY RACKS.

875543

SPACER KIT, DOOR HANDLE, SILVER

875587

SPRING, HINGE, DOOR

USED BEFORE 8/13/2009 (PCN #4283) AFTER THIS DATE DOORS ARE FITTED W/ CARTRIDGE SPRINGS

928369

SPRING, HINGE, DOOR, TOP, LEFT HINGE, CARTRIDGE

USED AFTER 8/12/2009 (PCN #4283)

928370

SPRING, HINGE, DOOR, TOP, RIGHT HINGE, CARTRIDGE

USED AFTER 8/12/2009 (PCN #4283)

830170

STAND OFF, SHELF

PCN5328

953050

STRIKER, ROCKER SWITCH KIT

REPLACES 875510 PER PCN 5050 8/1/2011 OR SERIAL NO 1-7198578

953404

SWITCH, LIGHT, TOGGLE STYLE

801924

SWITCH, POWER, 115V

TO SHUT OFF POWER TO SERVICE.

820204

TAPE, LIGHT, FILLER CHANNEL, IDL

SILVER ALUMINUM

925507

THERMOMETER, DIAL, CELCIUS/FAHRENHEIT, ROUND EXTERIOR,
BLACK FACED, STANDARD

REPLACES 831914 PREVIOUSLY USED (PCN #4115)

830426

THERMOMETER, DIAL, CELCIUS/FAHRENHEIT, ROUND INTERIOR
HANGING

OPTION

822205

THERMOMETER, DIGITAL, CELCIUS, LED, 115V ROUND EXTERIOR,

WITH BUILT IN TRANSFORMER

831904

THERMOMETER, DIGITAL, CELSIUS, LED

REQUIRES TRANSFORMER. IN PRODUCTION THIS WAS USED BEFORE 6/25/03. WHEN WE RUN OUT OF THESE
THE 831930-FI CAN BE SENT AS A REPLACEMENT

831908

THERMOMETER, DIGITAL, FAHRENHEIT, EXTERIOR

OPTION

800400

THERMOMETER, DIGITAL, FAHRENHEIT, LED, 115V, ROUND
EXTERIOR

OPTION

800321

THERMOMETER, FAHRENHEIT/CELSIUS, TUBE TYPE

863105

TIMER BOX

832270

TOOL, ADJUSTMENT, DANFOSS TEMPERATURE CONTROL

USED TO CALIBRATED DANFOSS CONTROL

831970

TRANSFORMER, THERMOMETER, 115V

REPLACES 831909 MODEL 015-0054-01

921754

TRIM, IDL GRILL, BLACK

USED AFTER 10/13/08 PRODUCTION DATE . WILL RETROFIT. . BLACK PLASTIC TRIM THAT GOES AROUND THE
CUTOUT IN THE GRILL. THIS WILL HELP PROTECT THE DOOR CORD. PER FT 4101

820799

WICKING KIT, CONDENSATE PAN

OPTION.

879202

WINE RACK KIT, BLACK

MAXIMUM NUMBER OF RACKS PER DOOR IS 8 USING NO SHELF AND FOR SMALL DIAMETER BOTTLES. FOR
LARGER BOTTLES, 5 - 6 RACKS PER DOOR IS SUGGESTED. 10 AVERAGE SIZED BOTTLES FIT PER RACK.

830263

WRENCH, 2-1/2", 4", 5" CASTOR

FOR 8 SIDED NUT ON UNDERSIDE OF HOUSING. CURRENT PRODUCTION.

872904

WRENCH, DOOR HINGE, TORSION SPRING

THIS IS A NO CHARGE ITEM
