Page 1
Innovation
7” & 9” DRIVERS
3-WAY DESIGN
9” MODELS ONLY
DIRECTIONAL TWEETER
New Toolless Design
TruGrip technology, a 2-step mechanical
dogear, ensures the tightest grip with zero sag.
TWEETER BRIDGE
HANDLE
1 RING FOR BOTH SIZES
RC-879
PROTECTIVE BACKBOX
40% SMALLER REVEAL
Quick. Easy. Secure.
The fastest way to terminate a speaker.
Connect speaker wire to rough-in ring during
pre-wire, then use the Quick Connect cable to
thether to the speaker’s Quick Connect.
GHOST™ SERIES
In 2007, the Ghost™ Series revolutionized the architectural speaker market with stunning
design aesthetics, and installation characteristics. 13 Years later, TruAudio has done it
again. The new Ghost™ Series has evolved from the ground up; with how it looks, how it
performs, how it functions, and it even has updated, low impact, packaging.
The series has been updated from 6.5” and 8” speakers to 7” and 9” woofers, providing
even warmer tones for your living space. The 9” model now features a 3-way design (a
pivoting tweeter and mid-range, partnered with a fixed woofer). The depth of the reveal
into the living space has been decreased by 40% allowing the speakers to virtually
disappear into the ceiling. TruAudio’s new Ghost™ Series features the revolutionary and
patented TruGrip™ technology, which incorporates a spring-loaded dog ear and
mechanical cinching closure, significantly reducing time spent on trims-outs. TruAudio’s
QuickConnect™ adapters were also incorporated, shaving even more time off of
trim-outs, if QuickConnect™ pre-construction brackets were used in the rough-in stage.
Finally, all new Ghost™ speakers now include a vented protective backbox to protect the
critical components on the back of the speaker and a tweeter bridge that doubles as a
built-in handle.
www.TruAudio.com 888.858.1555 198 North Old Highway 91 Hurricane, UT 84737
Page 2
G91 G92 G71 G72 GD71 GD72
Innovation
Speaker Type
Woofer:
Midrange:
Tweeter:
Power:
Impedance:
Frequency Response:
Sensitivity:
Grill Type:
Speaker Wire Connector:
Finish Dimensions:
Cutout Dimensions:
Rough-in Ring:
Speaker Type
Woofer:
Tweeter:
Power:
Impedance:
Frequency Response:
Sensitivity:
Grill Type:
Speaker Wire Connector:
Finish Dimensions:
Cutout Dimensions:
Rough-in Ring:
G91
In-ceiling, 3 way
9” carbon fiber
3“ carbon fiber
1” titanium, swivel
25-175W
8Ω
32-20kHz
91dB
Microperf, frameless
Quick Connect &
Gold binding post
Diameter:10.51”
(267mm)
Depth: 6” (152mm)
9.9” (251mm)
RC-879
G71
In-ceiling, 2 way
7” carbon fiber
1” titanium, swivel
25-150W
8Ω
36-20kHz
90dB
Microperf, frameless
Quick Connect &
Gold binding post
Diameter:10.51”
(267mm)
Depth: 3.9” (100mm)
9.9” (251mm)
RC-879
G92
In-ceiling, 3 way
9” white polypropylene
3“ white polypropylene
1” silk dome, swivel
25-150W
8Ω
34-20kHz
90dB
Microperf, frameless
Quick Connect &
Gold binding post
Diameter:10.51”
(267mm)
Depth: 6” (152mm)
9.9” (251mm)
RC-879
G72
In-ceiling, 2 way
7” white polypropylene
1” silk dome, swivel
25-125W
8Ω
38-20kHz
88dB
Microperf, frameless
Quick Connect &
Gold binding post
Diameter:10.51”
(267mm)
Depth: 3.9” (100mm)
9.9” (251mm)
RC-879
GD71
In-ceiling, stereo
7” carbon fiber
N/A
1” titanium, swivel
25-150W
8Ω
36-20kHz
90dB
Microperf, frameless
Quick Connect &
Gold binding post
Diameter:10.51”
(267mm)
Depth: 3.9” (100mm)
9.9” (251mm)
RC-879
GD72
In-ceiling, stereo
7” white polypropylene
1” silk dome, swivel
25-125W
8Ω
38-20kHz
88dB
Microperf, frameless
Quick Connect &
Gold binding post
Diameter:10.51”
(267mm)
Depth: 3.9” (100mm)
9.9” (251mm)
RC-879
www.TruAudio.com 888.858.1555 198 North Old Highway 91 Hurricane, UT 84737
