Page 1
Innovation
OL-70V-6
Commercial Outdoor Speakers
OL-70V-6
TruAudio’s Commercial Surface-Mount Outdoor Speaker is equipped with 70v and 100v tap settings
to easily create a distributed audio system throughout a commercial space. A high-excursion 6.5”
polypropylene woofer provides low bass extension, and the 1” soft dome tweeter provides accurate
clarity over a wide area.
The IP66 rating provides environmental endurance and protection from outdoor elements.
Featuring a weatherproof, extreme temperature resistant cabinet and corrosion-proof aluminum
grill, making it a perfect fit for any outdoor application.
Low-profile mounting bracket allows for vertical or horizontal 120 degree range of motion.
Available in either black or white finishes.
www.TruAudio.com 888.858.1555 198 North Old Highway 91 Hurricane, UT 84737
Page 2
Innovation
OL-70V-6
Commercial Outdoor Speakers
Speaker Type:
Woofer:
Tweeter:
Power:
Impedance:
70v Taps:
100v Taps:
Freq Response:
Sensitivity:
Grill Type:
Colors Available:
Mounting:
Cabinet Size:
Family:
OL-70v-6WT/BK
Outdoor, 2 way 70v
6.5” polypropylene
1” silk
30 watts
70v/100v
2W - 15W selectable
4W - 30W selectable
55 - 20k Hz
86 dB
Aluminum mesh
Black, white
U bracket
11.9" (303mm) H,
8.5”(215mm) W,
7.5"(191mm) D
(+/-3 dB)
Vertical or Horizontal
Mounting Options
www.TruAudio.com 888.858.1555 198 North Old Highway 91 Hurricane, UT 84737
