TROY Group IRD 3005 User Manual

Security Printing Solutions Quick-Start Guide
READ ME FIRST
Product Installation Instructions
Introduction
(For use with TROY MICR / IRD 3005 Security Printing Solutions)
Package Contents
• TROY Security Printing Solutions CD
• TROY Security Printing Solutions Information Sheet
• TROY Software License Agreement
• TROY MICR Document Template
• TROY Security Printing Solutions User’s Guide (provided in PDF format on the CD)
• TROY MICR Basics Handbook (provided in PDF format on the CD)
• TROY Security Printing Solutions Quick-Start Guide (this document)
IMPORTANT
: If you purchased a TROY Font Memory Card Kit, please refer to the TROY Font Card
Installation Guide provided with the TROY product to install the font card into your Hewlett-Packard LaserJet printer before the font card has been installed in your printer, proceed to Step 2 in this document to install the required TROY support files. In addition, a MICR toner cartridge must also be installed in your HP printer to print MICR documents using the TROY Font Card Solution.
proceeding with these setup instructions. After
STEP 1: Unpack / Setup the TROY Security Printing Solutions Printer
1. Follow ONLY the unpacking and setup procedures described in the Hewlett-Packard Getting Started
Guide (supplied in this startup package for TROY Security Printing Solutions printers only), and then proceed to step #2 to install the appropriate PCL 5e printer driver provided on the TROY Security Printing Solutions CD. Do NOT
installation process.
2. Be sure to install the TROY MICR toner cartridge (supplied with TROY Security Printing Solutions
printers only) in the same manner as described for the standard toner cartridge. The TROY MICR toner cartridge must
Document #50-70430-001 Rev. B Page 1 of 11
be installed in your TROY printer or Hewlett-Packard printer to print MICR documents.
use the Hewlett-Packard CD to install the printer software for this
Security Printing Solutions Quick-Start Guide
STEP 2: Install the HP PCL 5e Printer Driver for Microsoft
IMPORTANT: Use only the TROY Security Printing Solutions CD to install the Hewlett-Packard PCL 5e printer
driver designated for your Hewlett-Packard or TROY printer. Some of the steps listed below
IMPORTANT: If connecting a TROY printer to a print server, load and configure the TROY printer driver on the
and/or software screens may differ slightly in appearance depending on your operating system.
print server only. Do not fonts on local workstation(s), and then “Connect” to the TROY printer attached to the print server.
load the printer driver on the local workstation(s). Load only the screen
®
Windows™
1. Close all applications before installing the HP PCL 5e printer driver.
2. Insert the TROY Security Printing Solutions CD into your computer CD drive.
3. Before beginning the installation process, you will need to know the operating system you are using on
your computer. If you already know the operating system you are using, proceed directly to step #4. If you are not sure, right-click on My Computer (located on the Windows desktop), and then click on Properties to view the type of operating system installed on your computer.
4. From the Start menu, click on Settings, and then click on Printers.
5. Double-click on Add Printer, click on Next, choose Local Printer, and then click on Next. If you are
using Windows 2000/XP, skip down to Step 12, and then proceed with Steps 6 through 11.
6. From the Add Printer Wizard window, click on Have Disk.
7. From the Install From Disk window, click on Browse.
8. From the Open window, click on the down-arrow in the Drives box to select the CD-ROM drive on
your computer.
9. Double-click on the appropriate folder for the operating system you are using (e.g., Win98, etc.).
10. Double-click on the appropriate subfolder for the model printer you are using (e.g., 3005). If applicable
for your model of printer, be sure to select either the USB or standard parallel (LPT1) printer. Click on OK to close the Open window, and then click on OK to close the Install From Disk window.
IMPORTANT: All TROY IRD printers must use the 4300 printer driver, regardless of your printer model. After installation of the printer drivers follow the directions for installing the Metrics File ME and Screen Fonts
for WindowsTM 98SE and ME in Step 3, then proceed to Step 4.
for WindowsTM 98SE and
11. Select the appropriate printer driver for your printer model, and then click on Next to continue the driver
installation. You will be given the choice to either replace or keep the existing driver. It is
recommended that you always replace the existing driver. Click on Next to continue. If you are using
Windows 2000/XP, skip down to Step 13.
12. Select the appropriate printer port from the displayed list (usually LPT1), and then click on Next to
continue. If you are using Windows 2000/XP, go back and perform Steps 6 through 11 to complete the
driver installation. Otherwise, for Windows 98SE/ME operating systems, the printer name will be
highlighted.
13. For easy printer identification, it is recommended that you change the highlighted Hewlett-Packard
printer name to the name of the TROY printer you are installing (e.g., TROY MICR 3005 Secure EX
Printer) by typing over the highlighted printer name. If you want to use this printer as your default
printer, be sure to select this printer as the default printer. If you are using Windows 2000/XP, choose
to either share or not share your printer over the network.
14. Click on Yes to print a test page to verify that your printer driver was installed correctly, and then click
on Next to continue.
Document #50-70430-001 Rev. B Page 2 of 11
Security Printing Solutions Quick-Start Guide
15. Click on Finish to complete the installation. The printer driver installation will proceed automatically
and add the printer icon to the printer folder.
STEP 3: Install the TROY
NOTE: The Hewlett-Packard PCL 5e printer driver must be installed on the host computer prior to loading the
TROY support files (refer to STEP 2 on the previous page).
Support Files for Microsoft® Windows
™
The TROY metrics file contains the required escape sequences that are used to “call” the T ROY security and/or barcode fonts installed in the TROY Security Printing Solution (via the TROY Memory Card). When properly installed, the TROY metrics file will be associated with the PCL 5e printer driver used by your TROY printer to enable printing of the actual fonts installed in the printer. By associating the metrics file with the printer driver, the TROY TrueType screen fonts will be automatically replaced with the actual TROY fonts at print time. If the TROY metrics file is not properly installed, then the TROY TrueType screen fonts will print instead of the actual TROY installed printer fonts.
Install the TROY Metrics File for Windows™ 98SE and ME Operating Systems
1. Close all applications before installing the TROY Font support files.
2. Insert the TROY Security Printing Solutions CD into your computer CD-ROM drive.
3. From the Microsoft Windows Start menu, click on Settings, and then click on Printers.
4. Right-click on your TROY Security Printing Solution icon, and then click on Properties from the pull-
down menu. If multiple printers are installed, make sure the correct printer icon is selected that
corresponds to your TROY Security Printing Solutions printer.
5. Click on the Configure tab located at the top of the Properties window.
6. Within the Other Options category, click on the More button. Some printer driver versions may not
display the Other Options category. If this is the case, simply skip to the next step.
7. Within the Fonts category, place a check mark in the Font Cards checkbox, and then click on the
Configure button (with some printer driver software versions, the Configure button may already be
“clicked”). A new window will open labeled Configure Font Cards.
8. Click on the Add button to open the Add Font Card window.
9. Click on the Browse button to open a Windows Explorer-style window. Click on the down-arrow in the
Drives box to select the CD-ROM drive on your computer. Double-click on the Support Files folder
from the list of folders, double-click on the HPD Files folder, and then double-click on the Domestic
folder. For international products, double-click on the International folder.
10. Click on the file (located in the left-hand window) named TroySEC.hpd or TroySECINTL.hpd (for
International customers), and then click on Open or OK (the displayed window may vary depending on
the operating system being used). With some printer drivers, the Add Font Card window will appear.
If this window appears, click on OK to close the window.
11. Within the Configure Font Cards window, verify the installation by clicking on the Font Card Name:
TROY Security Font Collection
or TROY International Security Font Collection listed under Installed
Font Cards. Within the Fonts list, the TROY E-13B (enabled) along with other TROY fonts will be
displayed.
12. Repeat Steps 9 through 11 to install the barcode fonts. Double-click on the Support Files folder, the
HPD Files folder, and the Barcode folder, and then select the TroyBAR.hpd file. Verify the installation
by clicking on the Font Card Name: TROY Barcode Font Collection
listed under Installed Font Cards.
Within the Fonts list, the TROY barcode fonts will be displayed.
Document #50-70430-001 Rev. B Page 3 of 11
Security Printing Solutions Quick-Start Guide
13. Close all remaining open windows. Please refer to the TROY Security Printing Solutions User’s Guide,
Section 7 – Using TROY Fonts before using the installed fonts.
Install the TROY Screen Fonts for Windows™ 98SE and ME Operating Systems
In addition to the TROY printer fonts that are permanently programmed into your TROY Security Printing Solution, the TROY screen fonts have been developed for display use only as a visual reference and for making positional adjustments to the MICR line. The TROY screen fonts display differently than the actual printer fonts to prevent unauthorized printing using the MICR screen fonts on other Windows-installed printers.
If the E-13B MICR screen font is used for printing, the inversely printed (white characters on black background) MICR screen font will not be readable by the bank reader/sorter machines. The uniquely displayed screen fonts ensure that the MICR font printed on your MICR documents is generated from a TROY Security Printing Solution and not fonts are provided on the TROY Security Printing Solutions CD supplied with your TROY Security Printing Solution.
1. Close all applications before installing the TROY support files.
2. Insert the TROY Security Printing Solutions CD into your computer CD-ROM drive.
3. From the Start menu, click on Settings, and then click on Control Panel.
from the Windows TrueType™ screen font. The TROY screen
4. Double-click on the Fonts folder icon.
5. Click on File, and then click on Install New Font… A new window labeled Add Fonts will open and
then a Windows Explorer-style window will open.
6. Click on the down-arrow in the Drives box to select the CD-ROM drive on your computer. Double-
click on the Support Files folder from the list of folders, double-click on the HPD Files folder, and then
double-click on the Domestic folder. For international products, double-click on the International
folder.
7. A list of TROY fonts will be listed within the List of Fonts section. Click on Select All to highlight all
available fonts, and then click on OK. A processing window may appear while the installation process
proceeds. Individual fonts may be selected if all the fonts are not needed.
8. Repeat Steps 5 through 7 to install the barcode screen fonts. Double-click on the Support Files folder,
double-click on the HPD Files folder, and then double-click on the Barcode folder. Within the List of
Fonts section, click on Select All to highlight all available barcode fonts, and then click on OK. A
processing window may appear while the installation process proceeds.
9. Close all remaining open windows. The TROY screen fonts are now installed.
NOTE: For International customers, the International numeric fonts are not resident on the TROY
Memory Card. These fonts are located on the TROY Security Printing Solutions CD in the “\Support Files\HPD Files\International\Fonts” folder and can be added to the TROY Memory Card using the TROY Printer Utility – Download Soft Fonts Option. These fonts are designed as non-scalable bitmapped fonts.
Document #50-70430-001 Rev. B Page 4 of 11
