Trotec TRH 20 E, TRH 22 E Operating Manual

TRH 20 E / TRH 22 E

EN

OPERATING MANUAL

OIL-FILLED RADIATOR

EN This product is only suitable for well

insulated spaces or occasional use.

TRT-BA-TRH20E-TRH22E-TC2017-48-003-EN

Table of contents

Notes regarding the operating manual................................. 2

Safety .....................................................................................2

You can download the current version of the operating manual
and the EU declaration of conformity via the following link:

Information about the device................................................5

Transport and storage...........................................................6

Assembly and installation.....................................................6

Operation ...............................................................................8

Errors and faults....................................................................9

Maintenance ........................................................................10

Technical annex...................................................................10

Disposal ...............................................................................12

Notes regarding the operating manual

Symbols

Warning of electrical voltage

This symbol indicates dangers to the life and health of
persons due to electrical voltage.

Warning of hot surface

This symbol indicates dangers to the life and health of
persons due to hot surface.

Warning

This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.

Caution

This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.

TRH 20 E

https://hub.trotec.com/?id=41295

TRH 22 E

https://hub.trotec.com/?id=41296

Safety

Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!

Warning
Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.

Save all warnings and instructions for future
reference.

This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.

Note

This signal word indicates important information (e.g.
material damage), but does not indicate hazards.

Warning

Children of less than 3years should be kept away
unless continuously supervised.
Children aged from 3years and less than 8years shall

Info

Information marked with this symbol helps you to carry
out your tasks quickly and safely.

Follow the manual

Information marked with this symbol indicates that the
operating manual must be observed.

only switch on/off the appliance provided that it has
been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children aged from 3years and less than 8years shall
not plug in, regulate and clean the appliance or
perform user maintenance.

2 EN

oil-filled radiator TRH 20 E / TRH 22 E

Warning

Do not use the device in small rooms if persons are
present who cannot leave the room independently and
who are not under constant supervision.

• Do not use the device in potentially explosive rooms.

• Do not use the device in aggressive atmosphere.

• Set the device up in an upright and stable position.

• Let the device dry out after a wet clean. Do not operate it
when wet.

• Do not use the device with wet or damp hands.

• Do not expose the device to directly squirting water.

• Never insert any objects or limbs into the device.

• Do not cover or transport the device during operation.

• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.

• Do not sit on the device.

• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.

• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.

• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!

• The electrical connection must correspond to the
specifications in chapter Technical data.

• Insert the mains plug into a properly secured mains
socket.

• Observe the device's power input, cable length and
intended use when selecting extensions to the power
cable. Completely unroll extension cables. Avoid electrical
overload.

• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.

• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.

• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!

• During the installation of the device observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
data chapter.

• Do not use the device in immediate proximity to curtains.

• Make sure that the air inlet and outlet are not obstructed.

• Make sure that the suction side is kept free of dirt and
loose objects.

• Do not place the device on combustible ground.

• Allow the device to cool down before transport and/ or
maintenance work.

• Do not use this device near bathtubs, shower trays,
swimming pools or other water containers. Risk of electric
shock!

• The device must not be positioned directly beneath a wall
socket.

• The device must be set up in a way that the switches and
controllers cannot be touched by a person in a bathtub or
shower.

Intended use

This product is only designed for use inside well insulated
rooms or for occasional use.

The device is only intended to be used as additional heating
device in dry, closed rooms whilst adhering to the technical
data. For intended use it must only be positioned on the ground.

Improper use

• Do not place the device on wet or flooded ground.

• Do not place any objects, e.g. clothing, on the device.

• Do not use this device in the vicinity of fuel, solvents,
varnishes or other easily inflammable vapours or in rooms
where these substances are stored.

• Do not use the device outdoors.

• Do not use the device for heating vehicles.

• The device must not be used near swimming pools.

• Do not use this device in the immediate vicinity of sinks,
bathtubs or other water containers.

Never immerse the device in water.

• Any operation other than as described in this manual is
prohibited. Non-observance renders all claims for liability
and guarantee null and void.

• Please bear in mind that our devices are not designed for
the application in business, craft or industrial enterprises.
We do not accept any liability if the device is used in
business, craft or industrial enterprises as well as for
similar applications.

• Any unauthorised modifications, such as alterations or
structural changes to the device, are forbidden.

EN 3

oil-filled radiator TRH 20 E / TRH 22 E

Personnel qualifications

People who use this device must:

• be aware of the dangers that occur when working with
electric devices in damp areas.

• have read and understood the operating manual, especially
the Safety chapter.

Maintenance tasks which require the housing to be opened
must only be carried out by specialist electrical companies or by
Trotec.

Warning

In order to avoid overheating and fire hazards, the
heater must not be covered.

Behaviour in the event of an emergency

1. Switch off the device.

2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.

3. Do not reconnect a defective device to the mains.

Symbols on the device

Symbols Meaning

This symbol located on the device indicates that it
is prohibited to place objects (such as towels,
clothes etc.) above or directly in front of the
device.
In order to avoid overheating and fire hazards, the
heater must not be covered.

Residual risks

Warning of electrical voltage

Work on the electrical components must only be
carried out by an authorised specialist company!

Warning of electrical voltage

Before any work on the device, remove the mains plug
from the mains socket!
Hold onto the mains plug while pulling the power cable
out of the mains socket.

Warning of hot surface

Some parts of this product can become very hot and
cause burns. Particular attention has to be given where
children and vulnerable people are present!

Overheating protection

The device is provided with a safety thermostat which is
activated by overheating of the device (when exceeding the
operating temperature).

Investigate the cause of overheating.

If the safety thermostat does not switch in the event of
overheating, the overheating protection will be tripped. In that
case the device switches off completely. If so, please contact
the customer service to have the overheating protection
replaced.

Tilt protection

The device comes equipped with a tilt protection. The tilt
protection is a safety device intended to minimize the risk of fire
in case the device is tipped over inadvertently. The device will
be switched off when knocked over (or if its upright position is
changed in any other manner).

The tilt protection switches the device off when it is inclined by
a few degrees out of its vertical position. The device can again
be used as usual only a few seconds after placing it back in
vertical position and on solid ground.

Warning

Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!

Warning

The device is not a toy and does not belong in the
hands of children.

Warning

Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.

Warning

Improper installation entails a risk of fire.
Do not place the device on combustible ground.
Do not place the device on high-pile carpets.

4 EN

oil-filled radiator TRH 20 E / TRH 22 E

Information about the device

2

1

3

4

7

4

1

2

5

3

6

Device description

The oil-filled radiators TRH 20 E / TRH 22 E serve to generate
warm air in interior spaces.

The device comes with 3heating levels of up to 2,000W and an
infinitely variable thermostat.

The heat electrically generated by the heating elements within
the device is absorbed by the heating medium oil. The heating
medium oil offers the advantages of quick heat-up and long­term heat storage capacity. On these grounds the heating
medium oil can guarantee a continuous heat emission. The
radiator's 9ribs increase the heat radiating surface and so
enhance its effectiveness.

The device is further equipped with an overheating protection
and a tilt protection.

The device TRH 22 E is further provided with a turbo function.
Accordingly a turbo blower with additional PTC heating element
ensures the quick and effective initial room heating.

Device depiction

TRH 20 E

TRH 22 E

No. Designation

1 Transport handle

2 Control panel

3 Cable winder with plug holder

4 Foot with castors

5 Air inlet (blower)

6 Air outlet (blower)

7 Flip switch (blower)

EN 5

oil-filled radiator TRH 20 E / TRH 22 E

Transport and storage

Note

If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.

Transport

To make the device easier to transport, it is fitted with wheels.

Before transporting the device, observe the following:

• Switch the device off.

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

• Do not use the power cable to drag the device.

• Allow the device to cool down sufficiently.

Storage

Before storing the device, proceed as follows:

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

• Allow the device to cool down sufficiently.

When the device is not being used, observe the following
storage conditions:

• dry and protected from frost and heat

• in an upright position where it is protected from dust and
direct sunlight

• with a cover to protect it from invasive dust, if necessary

• Place no further devices or objects on top of the device to
prevent it from being damaged.

Assembly

Mounting the castors

Make sure to mount the castors before you set the device up.

1. Place the device upside down on a scratch-proof, even
surface and in a stable position.

2. Screw respectively two of each of the castors and cap nuts
to one of the mounting plates.

3. Detach the wing nuts from the U‑bolts.

Assembly and installation

Scope of delivery

• 1x Oil-filled radiator

• 2x Mounting plate for castors

• 4x Castor

• 4x Cap nut

• 4 x Wing nut

• 2x U-bolt

• 1x Manual

Unpacking the device

1. Open the cardboard box and take the device out.

2. Completely remove the packaging.

3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.

6 EN

oil-filled radiator TRH 20 E / TRH 22 E

4. Position the respective U‑bolt between either the first or

A

B

C

C

D

the last two ribs at the device bottom.

7. Turn the device over and set it down on the castors. If
necessary, use a spirit level to check the correct
positioning. Adjust the screw connection if required.

Start-up

Info

Odours might arise upon initial start-up or after a
longer period of non-use.

When positioning the device, observe the minimum distance
from walls or other objects as described in the Technical data
chapter.

5. Attach the mounting plates with the castors to the U‑bolts.
In doing so, observe the position of the cut-outs at one
side of the mounting plates. They should be directed
towards the device front (control panel).

6. Bolt the mounting plates, wing nuts and U‑bolts together.
Ensure the tight fit of the mounting plates. They should
rest evenly on the ribs to ensure the upright position of the
device.

• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.

• The device may only be operated when fully assembled
and set up in a vertical position on a stable surface.
Operation on instable ground is prohibited.

• Set the device up in an upright and stable position.

• Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.

• Make sure that extension cables are completely unrolled.

• Make sure that no curtains or other objects interfere with
the air flow.

• Do not position the device directly below a wall socket.

• Make sure that the device cannot come into contact with
moisture or water.

EN 7

oil-filled radiator TRH 20 E / TRH 22 E

Connecting the power cable

8

9

10

10

8

9

• Insert the mains plug into a properly secured mains
socket.

• Make sure that the power cable is guided along the back
of the device. Never guide the power cable along the front
of the device!

Operation

• Avoid open doors and windows.

Operating elements TRH 20 E

Operating elements TRH 22 E

No. Designation

8 Rotary switch room thermostat

9 Rotary switch for heating level selection

level1: 800 W
level2: 1,200 W
level3: 2,000 W

10 Operating control lamp

Switching the device on

Once you have completely installed the device as described in
the Start-up chapter, you can switch it on.

Info

The device will not be switched on until the room
temperature falls below the temperature set at the
room thermostat.

Setting the heating level

1. Set the rotary switch for heating level selection(9) to the
desired heating level.

Setting the room thermostat

1. Select the desired temperature via the stepless rotary
switch(8) of the room thermostat.

ð When the room thermostat is switched on the operating

control lamp(10) will be illuminated.

ð After approx. 10min the device will have reached the

set heat output.

To find the ideal thermostat setting, please proceed as follows:

• Set the thermostat control to maximum.

• As soon as the desired temperature has been reached,
slowly turn the thermostat control back until the operating
control lamp(10) goes out.

• The device now automatically maintains the desired
temperature level.

The room thermostat controls the room temperature
automatically:

• Upon reaching the set value in heating level2 and 3 the
device reduces its heating performance to 800W (level1).

• When falling below the set value, the heating will
automatically switch back over to 1,200W (level2)
or2,000W (level3).

When the device is set to heating level1, the room temperature
will not be controlled automatically.

Frost monitor function:

1. Set the heating level to level1.

2. Turn the rotary switch for the room thermostat(8) to a
position just above -. In this position, the room thermostat
switches on the heating automatically if the room
temperature drops below the frost protection temperature.

8 EN

oil-filled radiator TRH 20 E / TRH 22 E

Switching on the turbo blower (TRH22E only)

1. Set the flip switch for the blower(7) to I.

ð The lamp at the flip switch will be illuminated.
ð The blower will start to run when the device produces

heat.

ð The blower will turn off when the room thermostat

switches off the heating.

Shutdown

Warning of electrical voltage

Do not touch the mains plug with wet or damp hands.

• Set both rotary switches(8, 9) to position 0 or -.

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

• Allow the device to cool down completely.

• Clean the device according to the Maintenance chapter.

• Store the device according to the Storage chapter.

Errors and faults

Warning of electrical voltage

Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.

The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.

The device makes noises after switch-on:

• The heating medium oil expands due to heating. This is
what causes the noise. It is a perfectly normal process. No
measures are required.

The device does not start:

• Check the power connection.

• Check the power cable and mains plug for damages.

• Check the on-site fusing.

• Check the room temperature. The room thermostat may
have switched off, because the desired room temperature
has been reached.

• Check whether the device is standing upright and on level
ground. The tilt protection may have been tripped owing to
the fact that the device was knocked over. Always put up
the device in an upright position on a suitable, sufficiently
dimensioned surface.

• The room thermostat might be defective. Have a defective
room thermostat replaced by a specialist electrical
company.

• Check whether the overheating protection has tripped, see
chapter Safety.

• Wait for 10minutes before restarting the device. If the
device is not starting, have the electrics checked by a
specialist company or by Trotec.

The device is switched on, but the heating is not operating:

• Check the room temperature. The room thermostat may
have switched off, because the desired room temperature
has been reached.

• Check whether the overheating protection has tripped, see
chapter Safety.

• The heating resistor might have blown. Have a defective
heating resistor replaced by a specialist electrical
company.

• The room thermostat might be defective. Have a defective
room thermostat replaced by a specialist electrical
company.

The blower is not running (TRH 22 E only):

• Check whether the device is switched on.

• Check the power connection.

• Check the power cable and mains plug for damages.

• Check the room temperature. When the room thermostat
switches off, the blower turns off as well.

• The fan motor might be defective. Have a defective fan
motor replaced by a specialist electrical company.

The air current is reduced (TRH 22 E only):

• Check the air inlet and outlet. Make sure that air inlet and
outlet are not obstructed. Remove any dirt. Observe the
minimum distance from walls or other objects according to
the technical data.

Note

Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.

Your device still does not operate correctly after these
checks?

Please contact the customer service. If necessary, bring the
device to an authorized specialist electrical company or to
Trotec for repair.

EN 9

oil-filled radiator TRH 20 E / TRH 22 E

Maintenance

Technical annex

Activities required before starting maintenance

Warning of electrical voltage

Do not touch the mains plug with wet or damp hands.

• Switch the device off.

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

• Allow the device to cool down completely.

Warning of electrical voltage

Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.

Note

The device is filled with the heating medium oil. Tasks
which require the oil tank to be opened must only be
carried out by Trotec. In case of oil leakage please
contact the customer service.

Cleaning the housing

Warning of electrical voltage

Never immerse the device in water!

Clean the housing with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.

Wipe the housing dry after cleaning.

Technical data

Parameter Value

Model TRH 20 E TRH 22 E

Heating capacity

level 1:
level2:
level3:

Mains connection 220 – 240V/

Max. power input 2000 W 2400 W

Nominal current
consumption

Fusing 10 A 16 A

Plug type Schuko plug

Cable length 1.4 m 1.4 m

Dimensions
(depth x width x height)

Minimum distance to walls
and other objects

top (A):

rear (B):

sides (C):

front (D):

Weight 6 kg 9 kg

800 W
1200 W
2000 W

800 W
1200 W
2000 W

220 – 240V/

50Hz

50Hz

8.7 A 10.4 A

Schuko plug

CEE 7/7

120x 390x
500mm

90 cm
90 cm
90 cm
90 cm

CEE 7/7

125x 420x
590mm

90 cm
90 cm
90 cm
90 cm

10 EN

oil-filled radiator TRH 20 E / TRH 22 E

Information requirements for electrical local space heaters

Parameter Value/item

Model

TRH 20 E TRH 22 E

Heat output

Nominal heat output P

nom

Minimum heat output (indicative) P

Maximum continuous heat output P

min

max,c

0.8274 kW 1.0477 kW

0 kW 0 kW

0.8274 kW 1.0477 kW

Auxiliary electricity consumption

At nominal heat output el

At minimum heat output el

In standby mode el

sb

max

min

NA NA

NA NA

NA NA

Type of heat input

Manual heat charge control, with integrated thermostat NA NA

Manual heat charge control with room and/or outdoor temperature

NA NA

feedback

Electronic heat charge control with room and/or outdoor temperature

NA NA

feedback

Fan assisted heat output NA NA

Type of heat output/room temperature control

Single stage heat output, no room temperature control NO NO

Two or more manual stages, no room temperature control NO NO

With mechanic thermostat room temperature control YES YES

With electronic room temperature control NO NO

With electronic room temperature control plus day timer NO NO

With electronic room temperature control plus week timer NO NO

Other control options

Room temperature control, with presence detection NO NO

Room temperature control, with open window detection NO NO

With distance control option NO NO

With adaptive start control NO NO

With working time limitation NO NO

With black bulb sensor NO NO

Contact details TrotecGmbH&Co.KG

Grebbener Straße 7
D-52525 Heinsberg

NA: not applicable

EN 11

oil-filled radiator TRH 20 E / TRH 22 E

Disposal

The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.

The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.

Heating medium oil

The heating medium oil must be drained from the device and
collected.

The heating medium oil is to be disposed of according to the
national regulations.

12 EN

oil-filled radiator TRH 20 E / TRH 22 E

Trotec GmbH & Co. KG

Grebbener Str. 7
D-52525 Heinsberg

[phone]
[phone]

[e-mail]
www.trotec.com
