Trotec TFV10S, TFV30S, TFV10, TFV30 Operating Manual

TFV 10 S / TFV 30 S

EN

OPERATING MANUAL

TURBO FAN

TRT-BA-TFV10S-TFV30S-TC-004-EN

Table of contents

Notes regarding the operating manual................................. 1

Safety .....................................................................................1

You can download the current version of the operating manual
and the EU declaration of conformity via the following link:

Information about the device................................................3

Transport and storage...........................................................4

Assembly and installation.....................................................5

Operation ...............................................................................6

Available accessories............................................................7

Errors and faults....................................................................7

Maintenance ..........................................................................7

Technical annex.....................................................................8

Disposal .................................................................................8

Notes regarding the operating manual

Symbols

Warning of electrical voltage

This symbol indicates dangers to the life and health of
persons due to electrical voltage.

Warning

This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.

Caution

This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.

Notice

This signal word indicates important information (e.g.
material damage), but does not indicate hazards.

Info

Information marked with this symbol helps you to carry
out your tasks quickly and safely.

Follow the manual

Information marked with this symbol indicates that the
operating manual must be observed.

Wear ear protection

Information marked with this symbol indicates that you
should wear hearing protection.

TFV 10 S

https://hub.trotec.com/?id=41187

TFV 30 S

https://hub.trotec.com/?id=41188

Safety

Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!

Warning
Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.

Save all warnings and instructions for future
reference.

This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.

• Do not use the device in potentially explosive rooms.

• Do not use the device in aggressive atmosphere.

• Set the device up in an upright and stable position.

• Let the device dry out after a wet clean. Do not operate it
when wet.

• Do not use the device with wet or damp hands.

• Do not expose the device to directly squirting water.

• Never insert any objects or limbs into the device.

• Do not cover or transport the device during operation.

• Do not sit on the device.

1 EN

Operating manual – turbo fan TFV 10 S / TFV 30 S

• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.

• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.

• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!

• The electrical connection must correspond to the
specifications in chapter Technical data.

• Insert the mains plug into a properly secured mains
socket.

• Observe the technical data when selecting extensions to
the power cable. Completely unroll the extension cable.
Avoid electrical overload.

• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.

• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.

• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the supply cord is damaged, it must be replaced by the
manufacturer, his service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk.

• Observe the storage and operating conditions as given in
the Technical data chapter.

• Ensure that the air inlet and outlet are not obstructed.

• Make sure that there are no loose items located in the
immediate surroundings of air inlet and air outlet.

Intended use

The device TFV 10 S / TFV 30 S may be used for generating a
broad near-ground air current with a high air circulation for the
accelerated drying of flooring or to assist in drying walls and
floors after water damage or else for construction drying. All
other applications are considered improper use.

Improper use

The turbo fan is not suited for installation in fluids or on flooded
or boggy grounds. Any unauthorised changes, modifications or
alterations to the device are forbidden.

Personnel qualifications

People who use this device must:

• have read and understood the operating manual, especially
the Safety chapter.

Residual risks

Warning of electrical voltage

Work on the electrical components must only be
carried out by an authorised specialist company!

Warning of electrical voltage

Before any work on the device, remove the mains plug
from the mains socket!
Hold onto the mains plug while pulling the power cable
out of the mains socket.

Warning

Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!

Warning

The device is not a toy and does not belong in the
hands of children.

Warning

Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.

Caution

Risk of injury due to parts being whirled up by the
strong air current.
Before switching the device on, make sure that there
are no loose parts (clothing, hair ...) located near the
air inlet or outlet!

Notice

Do not use abrasive cleaners or solvents to clean the
device.

Behaviour in the event of an emergency

1. In an emergency, disconnect the device from the mains
feed-in: Switch the device off and disconnect it from the
mains.

2. Remove persons from the danger area.

3. Do not reconnect a defective device to the mains.

Personal protective equipment

Wear ear protection

Wear appropriate hearing protection when working
with the device.

EN 2

Operating manual – turbo fan TFV 10 S / TFV 30 S

Information about the device

TFV 10S

1

2

3

4

4

5

6

Device description

The device TFV 10 S / TFV 30 S was designed for a very high air
flow rate. It may be used for drying carpets, buildings or screed
as well as for the ventilation of poorly accessible intermediate
spaces. Owing to the high air circulation, the device can also be
used to control excessive humidity levels. The fan is also very
effective for the additional air circulation when heating large
buildings, e.g. in the months of winter.

The TFV 30 S is further equipped with a service socket, which
means that you can operate another device via the same
socket. This socket is ready for operation for as long as the TFV

30 S is connected to the mains – it does not need to be

switched on.
Moreover, you can connect an optional three-way hose

distributor to the TFV 30 S in order to direct the air current
towards 3different locations.

The cable of this device can be wound around the cable holder
at the carrying handle.

The device is designed in a way that several devices can be
safely stacked on top of one another for space-saving storage.
Do not exceed the maximum of five stacked devices.

In addition to all conventional ventilation tasks these turbo fans
are also suited particularly well for the quick elimination of
moisture at the underbody after driving on wet roads.

The device can be set up at different angles in order to reach
difficult corners or otherwise inaccessible hollows: 0°, 45°, 90°.

Device depiction

TFV 10 S

No. Designation

1 Transport handle
2 On/off switch
3 Air outlet
4 Air inlet
5 Foot
6 Cable holder

3 EN

Operating manual – turbo fan TFV 10 S / TFV 30 S

TFV 30 S

TFV 30S

POWER

OUTLET

6AMAX.

1

9

3

7

4

4

8

5

6

Transport and storage

Notice

If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.

Transport

Before transporting the device, proceed as follows:

• Switch off the device.

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

• Do not use the power cable to drag the device.

After transporting the device, observe the following:

• Set up the device in an upright position after transport.

Storage

Before storing the device, proceed as follows:

When the device is not being used, observe the following
storage conditions:

• dry and protected from frost and heat

• in an upright position where it is protected from dust and
direct sunlight

• with a cover to protect it from invasive dust if necessary

• stackable: up to 5devices may be stacked on top of one
another (applies to the TFV30S only)

No. Designation

1 Transport handle
3 Air outlet
4 Air inlet
5 Foot
6 Cable holder
7 Rotary switch for fan stages
8 Service power socket
9 Stacking aid

Info

Do not take the devices into operation when stacked.
Stacking rules out an efficient usage of the devices.

EN 4

Operating manual – turbo fan TFV 10 S / TFV 30 S

Assembly and installation

TFV 30S

TFV 30S

TFV 30S

TFV 30S

Scope of delivery

• 1x Device

• 1x Manual

Unpacking the device

1. Open the cardboard box and take the device out.

2. Completely remove the packaging.

3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.

Assembly

Connecting the (optional) three-way hose distributor

The device TFV 30 S can be connected to an optional three-way
hose distributor in order to direct the air current towards max.
3different locations.

Info

Seal off unused connections by means of suitable
sealing caps and possibly with hose clamps to prevent
a decrease in the air flow rate.

1. Slide the three-way hose distributor onto the air outlet so
that it is held securely.

2. Move the attachment hooks around until they are hooked
into the air outlet grille.

3. Check the three-way hose distributor for tight fit.

4. If attached, remove the sealing caps from the three-way
hose distributor.

5. Connect suitable hoses to the three-way hose distributor
and affix them using an appropriate hose clamp.

5 EN

Operating manual – turbo fan TFV 10 S / TFV 30 S

TFV 30S

6. Check the hoses for tight fit.

0°

45°

90°

2

POWER
OUTLET

6AMAX.

8

7

Start-up

Positioning

• Set the device up separately and in a stable position.

• The device can be variably positioned in a way to allow an
air discharge at an angle of 0°, 45° or 90°.

Operation

Operating elements

TFV 10 S

No. Designation

2 On/off switch

TFV 30 S

Connecting the power cable

• Insert the mains plug into a properly secured mains
socket.

No. Designation

7 Rotary switch for fan stages
8 Service power socket

Switching the device on

Once you have completely installed the device as described in
the Start-up chapter, you can switch it on.

TFV 10 S

1. Set the on/off switch(2) to I.
ð The device is switched on.

TFV 30 S

1. Set the rotary switch(7) to the desired fan stage.

stage1= LOW
stage2= MEDIUM
stage3= HIGH

ð The device is switched on.

EN 6

Operating manual – turbo fan TFV 10 S / TFV 30 S

Using the service socket (TFV 30 S)

The device TFV 30 S is equipped with a service socket, which
means that you can operate another device via the same
socket. The service socket is ready for operation as soon as the
device is connected to the mains – it does not need to be
switched on.

Shutdown

Warning of electrical voltage

Do not touch the mains plug with wet or damp hands.

• Set the on/off switch(2) to position0 or the rotary
switch(7) to OFF.

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

• Clean the device according to the Maintenance chapter.

• Store the device according to the Storage chapter.

The fan is not running:

• Check whether the device is switched on.

• Check the power connection.

• Check the power cable and mains plug for damages.

• Check the on-site fusing.

Notice

Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.

Your device still does not operate correctly after these
checks?

Please contact the customer service. If necessary, bring the
device to an authorized specialist electrical company or to
Trotec for repair.

Maintenance

Available accessories

TFV 30 S

Accessories Article number

Hose adapter (three-way hose

6.100.005.060
distributor, 3x Ø100mm),
incl. two sealing caps

Air hose Tronect TF-L, Ø100mm,

6.100.001.115
length 6m

Hose clamp 80 – 130mm 6.100.009.079

Errors and faults

The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.

The device does not start:

• Check the power connection.

• Check the power cable and mains plug for damages.

• Check the on-site fusing.

The fan operates only for a brief period, then switches off:

• Check whether the protective grid at the air inlet is
obstructed in some way. If applicable, remove foreign
objects.

• The motor bearing might be damaged. Please contact the
customer service.

Activities required before starting maintenance

Warning of electrical voltage

Do not touch the mains plug with wet or damp hands.

• Switch off the device.

• Hold onto the mains plug while pulling the power cable out
of the mains socket.

Cleaning the housing

Clean the housing with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.

Cleaning the fan and device interior

• Check fan and protective grid for perfect condition before
and after each application.

• Clean the fan after each operation.

• Use compressed air to remove particles, lint, dust and dirt
from motor, fan wheel and protective grid. Do not in any
event use a high-pressure cleaner to clean the fan.

7 EN

Operating manual – turbo fan TFV 10 S / TFV 30 S

Technical annex

Technical data

Disposal

Parameter Value

Model TFV10S

Air flow rate 355m³/h
Mains connection 1/ N/ PE ~230V/ 50Hz/

0.5A
Power input 75 W
Stat. air pressure (freely

max. 90Pa

blowing)
Protection type IP22
Sound level (distance 3m) 61.5 dB(A)
Dimensions (L x W x H) 300x 275x 330(mm)
Weight 4kg

Model TFV30S

Air flow rate

Stage 1
Stage 2
Stage 3

1,350m³/h
1,880m³/h
2,250m³/h

Mains connection 1/ N/ PE ~230V/ 50Hz/

5.2A
Power input max. 1,050 W
Stat. air pressure (freely

max. 525Pa

blowing)
Protection type IP22
Sound level (distance 3m)

Stage 1
Stage 2
Stage 3

73.5 dB(A)

80.8 dB(A)

86.2 dB(A)
Dimensions (L x W x H) 515x 545x 490(mm)
Weight 18.5kg

The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.

The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.

You are responsible for deleting any personal data stored on the
waste equipment to be disposed of.

EN 8

Operating manual – turbo fan TFV 10 S / TFV 30 S

Trotec GmbH & Co. KG

Grebbener Str. 7
D-52525 Heinsberg

[phone]
[phone]

[e-mail]
www.trotec.com
