IDE 20 D / IDE 30 D / IDE 50 D / IDE60D/
IDE 100 D
EN
OPERATING MANUAL
OIL HEATER
TRT-BA-IDE20D-30D-50D-60D-100D-TC-001-EN
Table of contents
Notes regarding the operating manual................................. 1
Safety .....................................................................................2
Information about the device................................................4
Transport and storage...........................................................6
Wear ear protection
Information marked with this symbol indicates that you
should wear hearing protection.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
Assembly and installation.....................................................6
Operation ...............................................................................8
Errors and faults....................................................................9
Maintenance ........................................................................10
Technical annex...................................................................11
Disposal ...............................................................................12
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of flammable substances
This symbol indicates dangers to the life and health of
persons due to flammable substances.
IDE 20 D
https://hub.trotec.com/?id=41240
IDE 30 D
https://hub.trotec.com/?id=41241
IDE 50 D
https://hub.trotec.com/?id=41242
Warning of hot surface
This symbol indicates dangers to the life and health of
persons due to hot surface.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Notice
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
IDE 60 D
https://hub.trotec.com/?id=41243
IDE 100 D
https://hub.trotec.com/?id=41239
1 EN
Operating manual – oil heater IDE 20 D / IDE 30 D / IDE 50 D / IDE60D/ IDE 100 D
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
Warning
Children of less than 3years should be kept away
unless continuously supervised.
Children aged from 3years and less than 8years shall
only switch on/off the appliance provided that it has
been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children aged from 3years and less than 8years shall
not plug in, regulate and clean the appliance or
perform user maintenance.
Warning
Do not use the device in small rooms if persons are
present who cannot leave the room independently and
who are not under constant supervision.
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Set the device up in an upright and stable position.
• Let the device dry out after a wet clean. Do not operate it
when wet.
• Do not use the device with wet or damp hands.
• Do not expose the device to directly squirting water.
• Never insert any objects or limbs into the device.
• Do not cover or transport the device during operation.
• Do not sit on the device.
• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The electrical connection must correspond to the
specifications in chapter Technical data.
• Insert the mains plug into a properly secured mains
socket.
• Observe the device's power input, cable length and
intended use when selecting extensions to the power
cable. Completely unroll extension cables. Avoid electrical
overload.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk.
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
data chapter.
• Do not use the device in immediate proximity to curtains.
• Ensure that the air inlet and outlet are not obstructed.
• Ensure that the side of the device where the air inlet is
found is kept free of dirt and loose objects.
• Do not place the device on combustible ground.
• Only transport the device in an upright position.
EN 2
Operating manual – oil heater IDE 20 D / IDE 30 D / IDE 50 D / IDE60D/ IDE 100 D
Intended use
This product is only designed for use inside well insulated
rooms or for occasional use.
The device was developed for the purpose of generating hot air
and may only be used in roofed over outdoor areas or in wellventilated interior spaces whilst adhering to the technical data.
The device is suited for heating large rooms such as tents,
warehouses, workshops, construction sites, greenhouses or
agricultural halls.
It is intended to be used without frequent site changes.
The device may only be used in rooms with sufficient fresh air
supply and exhaust discharge.
The device must only be operated with EL (ultra-light) fuel oil,
kerosene and diesel, however not with petrol, heavy fuel oil etc.
Warning of flammable substances
Handling fuels entails a risk of fire.
Take sufficient precautions when handling fuels such
as fuel oil, kerosene or diesel.
Do not spill any diesel, kerosene or fuel oil! Do not
inhale the vapours nor swallow any fuel! Avoid skin
contact!
Warning of hot surface
Parts of the device, especially at the air outlet, become
very hot during operation. There is a danger of burning
and fire. Do not touch the device during operation!
During operation observe a safety distance of at least 3
m to the device front! Observe the minimum distance
from walls or other objects according to the technical
data!
Improper use
• Do not place any objects, e.g. clothing, on the device.
• Do not use this device in the vicinity of fuel, solvents,
varnishes or other easily inflammable vapours or in rooms
where these substances are stored.
• Do not use the device outdoors.
• Do not use the device out of doors, unless under a roof.
• The device must not be operated in rooms with an
insufficient combustion air supply.
• Any unauthorised modifications, such as alterations or
structural changes to the device, are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers resulting from heat, fire hazard
and insufficient ventilation when working with oil heaters.
• be aware of the dangers that occur when handling fuels
such as EL fuel oil or diesel.
• have read and understood the operating manual, especially
the Safety chapter.
Personal protective equipment
Wear ear protection
Wear appropriate hearing protection when working
with the device.
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning of hot surface
Some parts of this product can become very hot and
cause burns. Particular attention has to be given where
children and vulnerable people are present!
Warning of hot surface
Improper handling entails a risk of burning. Only use
the device as intended!
Warning
Improper handling entails a risk of burning and electric
shock.
Only use the device as intended!
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
Improper installation entails a risk of fire.
Do not place the device on combustible ground.
Do not place the device on high-pile carpets.
Warning
The device must not be covered, there is an imminent
fire hazard!
3 EN
Operating manual – oil heater IDE 20 D / IDE 30 D / IDE 50 D / IDE60D/ IDE 100 D
Behaviour in the event of an emergency
1. In an emergency, disconnect the device from the mains
feed-in: Switch the device off and disconnect it from the
mains.
2. Remove persons from the danger area.
3. Do not reconnect a defective device to the mains.
Overheating protection
The device is provided with a safety thermostat which is
activated by overheating of the device (when exceeding the
operating temperature).
Investigate the cause of overheating.
If the safety thermostat does not switch in the event of
overheating, the overheating protection will be tripped. In that
case the device switches off completely. If so, please contact
the customer service to have the overheating protection
replaced.
Information about the device
Device description
The directly fired oil heater IDE 100 D serves the purpose of
heating the room air so as to quickly heat large rooms. The oil
heater runs on EL fuel oil, kerosene or diesel, it must not be
used with petrol, heavy fuel oil etc.
It is an oil heater with direct combustion to be installed in roofed
outdoor areas or in rooms with a sufficient fresh air supply.
Functional principle
The device generates warmth by conveying the sucked-in, cold
air past a combustion chamber. Inside the combustion chamber
the fuel is burned. The sucked-in air is heated and fed back to
the environment via the air outlet.
A part of the sucked-in air is compressed and conducted to the
injection. The fuel is fed from the tank to the injection by the
negative pressure thus created. An ignition contact at the
injection ignites the fuel, which is then burned in a continuous
flame.
EN 4
Operating manual – oil heater IDE 20 D / IDE 30 D / IDE 50 D / IDE60D/ IDE 100 D
Loading...
